AIT iTool User manual

1
Operation Manual
iTool
Digital Video Recorder
Zoom: 1.0x Flip: N Integr:Standard 11.9

4
Content
Introduction.......................................... 5
Warning Notices and Precautions ....... 6
Scope of Delivery................................. 8
System Presentation
Overview iTool....................................................... 9
The 24 Watt Metal Halide Light Source................. 11
The Control Panel ................................................ 12
iTool Interfaces..................................................... 14
Preparing the iTool
Connecting to Power Supply................................ 16
Inserting the SD Card........................................... 17
Connecting a Headset ......................................... 17
Connecting an Output Device .............................. 17
Starting Inspection
Switching-on the iTool.......................................... 18
Menu Structure and Operating ............................. 18
Language Selection ............................................. 19
Resetting to Default Settings ................................ 20
Image Control ...................................................... 21
Format SD Card................................................... 22
Setting Time and Date ......................................... 23
Creating and saving Image Captures
Choosing a Standard Setting ............................... 24
Image Capture and Video Recording
in Mode „OFF“ ..................................................... 25
Image Capture and Video Recording
in Mode „ON“ ...................................................... 26
Comparative Measuring with the iTool .................. 28
Playback of saved Images and
Recordings ......................................... 29
Optimising Camera Settings
Camera Setting.................................................... 32
Camera Setting Standard..................................... 33
Camera Setting Short Integration ......................... 34
Camera Setting Long Integration.......................... 35
Camera Setting Manual........................................ 36
Maintenance
Replacement of the Metal Halide Lamp ................ 37
Cleaning the iTool................................................. 38
Spare Parts and Accessories ............................... 39
Service ................................................................ 41
Technical Specifications...................... 42
Declaration of Compliance with CE .... 43

We congratulate you on buying your iTool DVR Video Imaging Hub, in the following just named iTool.
The iTool constitutes the core of the iTool DVR System. It unites Light Source, TFT Display plus Image
Storage and Video Recording Device. The iTool mostly is delivered in conjunction with an iSeries Videoscope
and an iPack, iCase or iCaseplus.
The diversity of inspection objects, materials and lightning conditions often makes it difficult to get
high-quality images. It is easy to adjust the iTool to your application to receive optimal inspection images
even in extreme situations.
Always keep the Operation Manual with the iTool. It contains all information for safe and efficient operation.
However, should you have further questions, feel free to contact our Service Team.
Introduction

Read the Operation Manual carefully before suing the iTool.
The iTool is designed for a diversified field of applications in Industry, Building and Science.
Caution! The iTool has not to be used in specially designated or prohibited areas (e.g. Explosion
Prevention).
Caution! The iTool has to be employed by skilled and qualified personnel appropriate to the application.
Electric Shock! No unauthorised opening of the casing. There is high danger of electric shock due to
Parts being under voltage.
Caution! Never look directly into the light emitting part of the Videoscope or of the Light Source. There
is ultraviolet and infrared as well as highly intense visible light coming from the Light Source. These can
cause injuries of eyes and skin. Always switch off the Light Source or adjust brightness to a minimum
when changing or controlling the objective or the distal end of the Videoscope.
Warning Notices and Precautions

A Videoscope in use with the iTool should not come into contact with a current or voltage source.
Damage to the product or an electric shock for you may result.
Always switch off the iTool before connecting a Videoscope or a Video Camera.
Take care, that there always is enough free space for ventilation behind and in front of the iTool.
The iTool is not watertight. Operate the iTool in dry environment only. The iTool is not water-proof
and must not be immerged into water.
Only use the iTool as intended.
Warning Notices and Precautions

If the iTool is delivered as part of a Videoscope System
following components will be included in the Scope of
Delivery:
– iSeries Videoscope
– iSeries Interchangeable Objective
– iCase or iCaseplus
– Components (see figure on the right)
You will find additional Accessories in this Operation
Manual on Page 39, in our Accessories Catalogue or on
our Homepage under www.itcworld.de.
We are certainly pleased being at your disposal for personal
consulting as well.
Scope of Delivery
BNC/Cinch Adapter
5-pin Cable short AC Adapter
Screwdriver
Cinch Cable Card Reader
Power Supply Cable
SD Card

The iTool DVR Video Imaging Hub is designed for the use with IT Concepts Videoscopes and CCD Cameras.
The 24W Metal Halide Light Source produces extremely bright light and therefore allows illumination of dark
cavities. Videos and images are shown on the TFT Display. Overlay texts can be attached to them. Video recordings
can also be saved with additional audio comments.
System Presentation
TFT-Display
Keypad
SD-Card Slot
Zoom: 1.0x Flip: N Integr:Standard 11.9
Status Indicator Line
24W Metal Halide Light Source
Light Guide Connector
Brightness Control
5-pin Connector for
Videoscope or Camera
Overview iTool

System Presentation
BNC Connector (IN) for
Videoscope or Camera
BNC Connector (OUT) for
Hard Disk, Monitor, etc.
Microphone Connector
12V DC Input
S-Video IN
Headphones Connector
Overview iTool

11
The 24 Watt Metal Halide Light
Source Caution!
Never look directly into the light
emitting part of the
Videoscope or of the Light Source. There is ultra-
violet and infrared as well as highly intensive visible
light coming from the Light Source. These can
cause injuries of eyes and skin.
Use the Aperture to adjust the intensity of the light.
For most applications we recommend to open it
completely.
For cleaning of the distal end or changing the
Objective switch of the Light Source or remove the
Light Guide Cable from it.
The Metal Halide Lamp installed needs 30 seconds
from engaging to generate full and steady luminance.
An untimely (<30sec.) power-down extremely
reduces the durability of the lamp or can even lead
to its destruction.
High Voltage –
Danger to Life!
Always have a lamp installed into the Light Source
(or even let a depleted lamp installed if necessary)
and close the casing before starting the iTool!
System Presentation
Switch ON/OFF
Aperture

System Presentation
The iTool Control Panel
Using the control panel you can navigate through the menu structure, select and confirm functions.

System Presentation
CROSS Select Measuring Function
CALIBRATION Select Calibration Function
DISPLAY Switch on/off the Status Indicator Line
ZOOM/FLIP Set digital Zoom as well as Image Flip (Mirroring) via arrow keys
COLOUR/GAMMA Set the Colour Saturation as well as the Gamma Value via arrow keys
BRIGHTNESS/CONTRAST Setting of brightness as well as contrast via arrow keys
STANDARD INTEGRATION Automatic optimisation of the Camera Settings
SHORT INTEGRATION Optimised Camera Settings for low lighting conditions.
LONG INTEGRATION Optimised Camera Settings for very low lighting conditions.
MANUAL INTEGRATION Individual Camera Settings.
TEXT Open Text Generator: Input via alpha numeric keypad, arrow keys and OK-button.
MENU Open/Close On Screen Menu
MEMORY Open/Quit Memory Mode
RECORD Start/Stop Video Recording
FREEZE Pause Video Recording / freeze image / frame capture
CANCEL Quit Submenu in Memory Mode
OK Confirm choice / frame capture
ARROW KEY Navigate

14
System Presentation
Videoscope
Light Guide Connector
Camera
5pin Cable SD Card
iTool Interfaces

S-Video IN
Headset
Camera
S-Video IN
cable
Camera
Cinch Cable
BNC - Cinch Adapter
Monitor
Cinch Cable
BNC - Cinch Adapter
AC Adapter
Battery Belt
Cigarette Lighter Cable
+ -
iTool Interfaces

Connecting to Power Supply
The 12V DC plug as well as the socket is marked
with a red dot. Connecting the 12V DC plug to the
iTool, assure that both red dots are visibly opposed.
Connect the mains adapter to the standard AC po-
wer supply cable and plug it in a 100/110V or a
220/240V shockproof socket.
As an option the iTool can be energised by the po-
werBelt (Art.Nr.: 900-06000-0030-V) or a Vehicle
Electric System (Car Battery Cable 900-05000-
0004 or Cigarette Lighter Cable 900-00002-0012).
Install eines
iSeries Videoendoscops
Plug the Light Guide Connector
in the Light Source until
engagement.
Connect the iSeries Videoscope
to the 5pin Video Cable
(black to white).
Connect the iTool
to the 5pin Video Cable
(white to black).
Preparing the iTool
blackwhite

17
Inserting a SD Card
Put a formatted SD Card(32 GB max.) into to SD
Card slot. The SD Card included in the scope of de-
livery is already properly formatted.
Connecting a Headset
Establish following connections:
- Microphone Plug (pink) to MIC Socket
- Headphones Plug (green) to SPK Socket.
Connecting Output Devices
Different output devices can be connected to the
Video- OUT socket by using the Cinch Cable and
the Cinch/BNC Adapter included in the scope of
delivery:
Preparing the iTool

Switching-on the iTool
After having prepared the iTool according to this Ope-
ration Manual first switch-on the iTool, then the Light
Source by pressing the power switches.
Flip open the top of the iTool. The boot sequence is
visible on the TFT Display.
Switch off the iTool
(but not the Light
Source) when
connecting a new
device or chan-
ging the device
and switch it on
afterward
Menu Structure and Operation
After having followed the steps before you may start
inspection now.
Using the control panel you can select and control
functions. A detailed description can be found on
pages 12/13.
Starting Inspection

Language selection
In delivery condition either English or your local
language is preset.
For initial operation you should check the manu lan-
guage and set it to your prefered language if neces-
sary. Following languages are available:
– English (Default Setting)
– German
– French
– Spanish
– Italian
To change the language set proceed as follows:
– MENU
– System Setting - OK
– Select „Language“ – the menu is directly
shown in the selected language.
– to quit – press MENU again
Starting Inspection
Status Line : ON
Freeze Frame : OFF
Language : English
Date/Time : Press OK
SD info : Press OK
SD format : Press OK
Fabric Settings : Press OK
Software Status : P010 55
Serial Number : 20110815
Language : English
Image Control
Camera Control
Annotation
Dimension
System Setting
Safety remove SD
System Setting

Resetting to Default Settings
By selecting the menu item Fabric Settings all
manually changed and adjusted parameters can be
put back to factory setting, except for date, time and
text generator.
– MENU
– System Setting - OK
– Fabric Settings - OK
You are in Live-Mode again afterwards.
Starting Inspection
Image Control
Camera Control
Annotation
Dimension
System Setting
Safety remove SD
System Setting
Status Line : ON
Freeze Frame : OFF
Language : English
Date/Time : Press OK
SD info : Press OK
SD format : Press OK
Fabric Settings : Press OK
Software Status : P010 55
Serial Number : 20110815
Fabric Settings : Press OK
Image Control
Camera Control
Annotation
Dimension
System Setting
Safety remove SD
System Setting
Status Line : ON
Freeze Frame : OFF
Language : English
Date/Time : Press OK
SD info : Press OK
SD format : Press OK
Fabric Settings : Press OK
Software Status : P010 55
Serial Number : 20110815
Fabric Settings : Press OK

Image Control
The image parameters (Brightness, Contrast and
Colour as well as Zoom, Flip and Dimming) can be
adjusted under the menu item Image Control. Change
the marked parameter by using the arrow keys.
The settings will effect directly. You get back to
Live-Mode by pressing MENU. You can put the
marked parameter to fabric setting by pressing the
OK-Button.
Caution! The image parameters set are effective to the
image displayed as well as to all images and videos to
be saved. Images and videos will be saved exactly as
they are displayed (except for Dimming TFT Display).
Notice! The above mentioned image settings can also
be adjusted directly via the iTool keypad (except for
Dimming TFT Display).
Starting Inspection
Image Control
Camera Control
Annotation
Dimension
System Setting
Safety remove SD
Image Control
Brightness |||||||||||||||.............. 50%
Contrast |||||||||||||||.............. 50%
Colour |||||||||||||||.............. 50%
Zoom |............................ 1x
Flip Normal
Dimmen |||||||||||||||.............. 50%
Brightness |||||||||||||||.............. 50%

Format SD Card
The SD card included in the scope of delivery of the
iTool is already properly formatted. To format a SD
card proceed as follows:
Press MENU, select the menu item System Setting
and press OK. By using the arrow keys now choose
the menu item SD format and press OK again. Now
a confirmation prompt appears on the display. Select
by using the arrow keys and press OK to confirm.
Starting Inspection
Image Control
Camera Control
Annotation
Dimension
System Setting
Safety remove SD
System Setting
Status Line : ON
Freeze Frame : OFF
SD format : Press OK
Date/Time : Press OK
SD info : Press OK
SD format : Press OK
Fabric Settings : Press OK
Software Status : P010 55
Serial Number : 20110815
SD format : Press OK
Table of contents
