XtendLan DVR-x70PJ User manual

1
DVR-x70PJ
2U Series Standalone DVR User’s Manual

2
Table of Contents
1 FEATURES AND SPECIFICATIONS................................................................10
1.1 Overview...............................................................................................................................................10
1.2 Features................................................................................................................................................10
1.3 Specification.........................................................................................................................................11
1.3.1 4 HDDs Series.................................................................................................................................11
1.3.2 8 HDDs (Extra stream CIF/QCIF) Series....................................................................................15
1.3.3 8 HDDs (Extra stream QCIF) Series............................................................................................18
2 OVERVIEW AND CONTROLS .........................................................................22
2.1 Front Panel...........................................................................................................................................22
2.2 Rear Panel............................................................................................................................................24
2.3 Connection Sample.............................................................................................................................24
2.4 Remote Control....................................................................................................................................25
2.5 Mouse Control......................................................................................................................................26
2.6 Virtual Keyboard & Front Panel.........................................................................................................28
2.6.1 Virtual Keyboard..............................................................................................................................28
2.6.2 Front Panel ......................................................................................................................................28
3 INSTALLATION AND CONNECTIONS.............................................................29
3.1 Check Unpacked DVR........................................................................................................................29
3.2 About Front Panel and Real Panel ...................................................................................................29

3
3.3 HDD Installation...................................................................................................................................29
3.3.1 8 HDD series...................................................................................................................................29
3.3.2 4 HDD Series...................................................................................................................................30
3.4 Rack Installation ..................................................................................................................................30
3.5 Connecting Power Supply..................................................................................................................31
3.6 Connecting Video Input and Output Devices ..................................................................................31
3.6.1 Connecting Video Input..................................................................................................................31
3.6.2 Connecting Video Output...............................................................................................................32
3.7 Connecting Audio Input & Output, Bidirectional Audio ..................................................................32
3.7.1 Audio Input.......................................................................................................................................32
3.7.2 Audio Output....................................................................................................................................33
3.8 Alarm Input and Output Connection .................................................................................................34
3.8.1 Alarm Input and Output Details.....................................................................................................34
3.8.2 Alarm Input Port..............................................................................................................................35
3.8.3 Alarm Output Port...........................................................................................................................35
3.9 RS232....................................................................................................................................................36
3.10 RS485....................................................................................................................................................36
3.11 Other Interfaces...................................................................................................................................37
4 OVERVIEW OF NAVIGATION AND CONTROLS ............................................38
4.1 Login, Logout & Main Menu...............................................................................................................38
4.1.1 Login.................................................................................................................................................38
4.1.2 Main Menu.......................................................................................................................................38
4.1.3 Logout...............................................................................................................................................39
4.1.4 Auto Resume after Power Failure................................................................................................39
4.1.5 Replace Button Battery..................................................................................................................39
4.2 Manual Record.....................................................................................................................................40

4
4.2.1 Live Viewing.....................................................................................................................................40
4.2.2 Manual record..................................................................................................................................40
4.3 Search & Playback..............................................................................................................................42
4.3.1 Search Menu...................................................................................................................................42
4.3.2 Basic Operation...............................................................................................................................43
4.3.3 Calendar...........................................................................................................................................44
4.4 Schedule...............................................................................................................................................45
4.4.1 Schedule Menu ....................................................................................................................................45
4.4.2 Snapshot..........................................................................................................................................46
4.4.3 Image FTP.......................................................................................................................................48
4.4.4 Snapshot Disk (For special series only)......................................................................................48
4.5 Detect....................................................................................................................................................49
4.5.1 Go to Detect Menu...............................................................................................................................49
4.5.2 Motion Detect........................................................................................................................................50
4.5.3 Video Loss.............................................................................................................................................52
4.5.4 Camera Masking..................................................................................................................................52
4.6 Alarm Setup and Alarm Activation....................................................................................................53
4.6.1 Go to alarm setup interface...........................................................................................................53
4.6.2 Alarm setup......................................................................................................................................53
4.7 Backup ..................................................................................................................................................55
4.7.1 Detect Device.......................................................................................................................................55
4.7.1 Backup..............................................................................................................................................56
4.8 PTZ Control and Color Setup ............................................................................................................57
4.8.1 Cable Connection ................................................................................................................................57
4.8.2 PTZ Setup.............................................................................................................................................57
4.8.3 3D Intelligent Positioning Key............................................................................................................59
4.9 Preset/ Patrol/Pattern/Scan................................................................................................................59
4.9.1Preset Setup .........................................................................................................................................60
4.9.2 Activate Preset.....................................................................................................................................60
4.9.3 Patrol setup (Tour Setup)...................................................................................................................60
4.9.4 Activate Patrol (tour)...........................................................................................................................61
4.9.5 Pattern Setup.......................................................................................................................................61
4.9.6 Activate Pattern Function...................................................................................................................61
4.9.7 Auto Scan Setup .................................................................................................................................61

5
4.9.8 Activate Auto Scan..............................................................................................................................62
4.10 Flip.........................................................................................................................................................62
5 UNDERSTANDING OF MENU OPERATIONS AND CONTROLS ...................63
5.1 Menu Tree ............................................................................................................................................63
5.2 Main Menu............................................................................................................................................63
5.3 Setting...................................................................................................................................................64
5.3.1 General.............................................................................................................................................64
5.3.2 Encode .............................................................................................................................................65
5.3.3 Schedule..........................................................................................................................................67
5.3.4 RS232...............................................................................................................................................67
5.3.5 Network ............................................................................................................................................68
5.3.6 Alarm.................................................................................................................................................75
5.3.7 Detect ...............................................................................................................................................75
5.3.8 Pan/Tilt/Zoom..................................................................................................................................75
5.3.9 Display..............................................................................................................................................76
5.3.10 Default..........................................................................................................................................78
5.4 Search...................................................................................................................................................78
5.5 Advanced..............................................................................................................................................78
5.5.1 HDD Management..........................................................................................................................79
5.5.2 Abnormity.........................................................................................................................................80
5.5.3 Alarm Output....................................................................................................................................80
5.5.4 Manual Record................................................................................................................................81
5.5.5 Account.............................................................................................................................................81
5.5.6 Auto Maintain...................................................................................................................................82
5.5.7 TV Adjust..........................................................................................................................................82
5.5.8 Video Matrix.....................................................................................................................................83
5.6 Information............................................................................................................................................83
5.6.1 HDD Information.............................................................................................................................83
5.6.2 BPS...................................................................................................................................................84
5.6.3 Log....................................................................................................................................................84
5.6.4 Version .............................................................................................................................................85
5.6.5 Online Users....................................................................................................................................85

6
5.7 Shutdown..............................................................................................................................................86
6 ABOUT AUXILIARY MENU ..............................................................................87
6.1 Go to Pan/Tilt/Zoom Menu.................................................................................................................87
6.1.1 3D Intelligent Positioning Key.......................................................................................................87
6.2 Preset /Patrol / Pattern /Border Function.......................................................................................88
6.2.1 Preset Setup....................................................................................................................................89
6.2.2 Activate Preset................................................................................................................................89
6.2.3 Patrol Setup.....................................................................................................................................89
6.2.4 Activate Patrol.................................................................................................................................89
6.2.5 Pattern Setup...................................................................................................................................89
6.2.6 Activate Pattern Function...............................................................................................................90
6.2.7 Border Setup....................................................................................................................................90
6.2.8 Activate Border Function ...............................................................................................................90
6.2.9 Flip ....................................................................................................................................................90
7 WEB CLIENT OPERATION..............................................................................92
7.1 Network Connection............................................................................................................................92
7.2 Login......................................................................................................................................................92
7.2.1 Real-time Monitor............................................................................................................................94
7.2.2 PTZ ...................................................................................................................................................96
7.2.3 Color .................................................................................................................................................99
7.2.4 Picture Path and Record Path ......................................................................................................99
7.3 Configure ............................................................................................................................................100
7.3.1 System Information.......................................................................................................................100
7.3.2 System Configuration...................................................................................................................102
7.3.3 Advanced.......................................................................................................................................121
7.3.4 Additional Function.......................................................................................................................126
7.4 Search.................................................................................................................................................127
7.5 Alarm ...................................................................................................................................................130

7
7.6 About...................................................................................................................................................131
7.7 Log out ................................................................................................................................................132
7.8 Un-install Web Control......................................................................................................................132
8 PROFESSIONAL SURVEILLANCE SYSTEM ................................................133
9 FAQ.................................................................................................................134
APPENDIX A HDD CAPACITY CALCULATION .................................................139
APPENDIX B COMPATIBLE USB DRIVE LIST ..................................................140
APPENDIX C COMPATIBLE CD/DVD BURNER LIST........................................141
APPENDIX D COMPATIBLE SATA HDD LIST ...................................................142
APPENDIX E COMPATIBLE DISPLAYER LIST .................................................144
APPENDIX F EARTHING....................................................................................145

8
Welcome
Thank you for purchasing our DVR!
This user’s manual is designed to be a reference tool for the installation and operation of your
system.
Here you can find information about this series DVR features and functions, as well as a detailed
menu tree.
Before installation and operation please read the following safeguards and warnings carefully!

9
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
We assume no liability or responsibility for all the fires or electrical shock caused by improper
handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the DVR before completing installation.
Do not place objects on the DVR
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
The DVR should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.

10
1 FEATURES AND SPECIFICATIONS
1.1 Overview
This series product is an excellent digital monitor product designed for security field. It adopts
embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and
G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame
play function is suitable for detail analysis. It has various functions such as record, playback,
monitor at the same time and can guarantee audio video synchronization. This series product
has advanced technology and strong network data transmission function.
This series device adopts embedded design to achieve high security and reliability. It can work in
the local end, and at the same time, when connecting it to the professional surveillance software
(PSS), it can connect to security network to realize strong network and remote monitor function.
This series product can be widely used in various areas such as banking, telecommunication,
electric power, interrogation, transportation, intelligent resident zone, factory, warehouse,
resources, and water conservancy.
1.2 Features
This series product has the following features:
 Real-time monitor
It has analog output port, VGA port and HDMI port. You can use monitor or displayer to realize
surveillance function.
System supports TV/VGA/HDMI output at the same time.
 Storage function
Special data format to guarantee data security and can avoid vicious data modification.
 Compression format
Support multiple-channel audio and video. An independent hardware decodes the audio and
video signal from each channel to maintain video and audio synchronization.
 Backup function
Support backup operation via USB port (such as flash disk, portable HDD, burner) and eSATA
port.
Client-end user can download the file to local HDD to backup via network.
 Record playback function
Support each channel real-time record independently, and at the same time it can support search,
forward play, network monitor, record search, download and etc.
Support various playback modes: slow play, fast play, backward play and frame by frame play.
Support time title overlay so that you can view event accurate occurred time
Support specified zone enlargement.

11
 Network operation
Support network remote real-time monitor, remote record search and remote PTZ control.
 Alarm activation function
Several relay alarm outputs to realize alarm activation and on-site light control.
The alarm input port and output has the protection circuit to guarantee device safety.
 Communication port
RS485 port can realize alarm input and PTZ control.
RS232 port can connect to keyboard to realize central control, and can also connect to PC COM
to upgrade system and realize maintenance, and matrix control.
Standard Ethernet port can realize network access function.
 PTZ control
Support PTZ decoder via RS485.
Support various decode protocols to allow the PTZ to control the speed dome.
 Intelligent operation
Mouse operation function
In the menu, support copy and paste setup function
Slight function differences may be found due to different series.
1.3 Specification
1.3.1 4 HDDs Series
Parameter
4-ch with audio
4-ch without audio
8-ch with audio
8-ch without
audio
16-ch with audio
16-ch without audio
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
Front panel, USB mouse, remote control
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
System
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Video
Compressio
n
H.264
Compression
Standard
Audio
Compressio
n
G.711A
Video Input
4-CH composite video
input: (NTSC/PAL)
BNC (1.0VP- P, 75Ω)
8-CH composite video
input: (NTSC/PAL)
BNC (1.0VP- P, 75Ω)
16-CH composite
video input:
(NTSC/PAL) BNC
(1.0VP- P, 75Ω)

12
Video
Output
1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output.
Support TV/VGA/HDMI video output at the same time.
Video
Standard
PAL (625 line, 50f/s), NTSC (525 line, 60f/s)
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition
1/4 windows(Optional)
1/4/9 windows
1/4/9 /16 windows
Monitor
Touring
Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
PAL/NTSC
Real-time monitor：
D1 704×576/704×480
Playback：
1/16-ch: D1 704×576/704×480 (6f/s, when other channels’ resolution
are all CIF, the first channel and the ninth channel can support 25f/s.) ,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Resolution
(PAL/NTSC
)
Support dual streams: extra stream resolution QCIF 176×144/176×120
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status
and motion detection status are shown on the bottom left of display
screen.
Video monitor
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio Input
4-ch 200-2000mv
10KΩ(BNC)
Please note there is
also a 4-ch series does
not support audio
function.
8-ch 200-2000mv
10KΩ(BNC)
Please note there is
also an 8-ch series
does not support audio
function.
16-ch 200-
2000mv 10KΩ
(BNC) Please
note there is
also a
16-ch series
does not
support audio
function.
Audio
Output
1-ch audio output 200-3000mv 5KΩ(BNC)
Please note there is also a 4/8/16-ch series does not support audio
function.
Audio
Bidirectional
Audio
1-ch audio talk input 200-3000mv 10KΩ（BNC）
1-ch audio talk output 200-3000mv 5K Ω (BNC)
Please note there is also a 4/8/16-ch series does not support audio
function.
Hard Disk
4 built-in SATA port. Support 4 HDDs.

13
Hard disk
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat
Way
When hard disk is full, system can overwrite previous video file.
Record
Search
Various search engines such as time, type and channel.
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback
and reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the
next file in the current channel
Multi-
channel
Playback
There are two playback modes: 4-ch and full-channel. In 4-ch
playback mode, you can select the 1/2/3/4-ch playback according to
your requirement. In full-channel mode, system can playback in full
channels. Please note the 4-ch has no full-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback
Record and
playback
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk, USB
burner and etc.)
Support peripheral eSATA backup device.
Backup
function
Backup
Mode
Support network download and backup
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as external alarm, motion detection and
video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Network
Function
Network
control
Bidirectional audio.
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate external alarm or screen message prompt.
External
Alarm
Support record activation function or activate external alarm or screen
message in specified period.
Motion
Detection and
Alarm
Manual
Alarm
Control
Enable or disable alarm input channel
Support analog alarm signal to specific alarm output channel.

14
Alarm Input
4-ch alarm input（You
can set normal open or
normal close type to
select the alarm type. ）
8-ch alarm input（You
can set normal open or
normal close type to
select the alarm type. ）
16-ch alarm input
（You can set
normal open or
normal close
type to select the
alarm type. ）
Alarm
Output
6-channel relay output, including one controllable DC +12V output port.
Alarm Relay
30VDC 2A，125VAC 1A（activation alarm ）
USB
Interface
2 USB 2.0 ports.
Network
connection
RJ45 10M/100M self-adaptable Ethernet port
RS485
PTZ control port
Support various PTZ control protocols.
Interface
RS232
Ordinary COM (Debug),keyboard connection and transparent serial
port(COM input and output via network )
Hard Disk
Information
Display HDD current status
Data
Stream
Statistics
Data stream statistics for each channel (in wave mode)
Log
statistics
Backup to 1024 log files.
Support various search engines such as time and type.
Version
Display version information: channel amount, alarm input and output
amount, system version and release date.
System
Information
On-line user
Display current on-line user
Multi-lever user management; various management modes
Integrated management for local user, serial port user and network user.
Configurable user power.
User
Manageme
nt
Support user /group and its corresponding rights modification.
No limit to the user or group amount.
Password modification
Administrator can modify other user’s password.
User
Management
Password
Authenticati
on
Account lock strategy
Five times login failure in thirty minutes may result in account lock.
Upgrade
Web browser, client-end and update tool.
Password login protection to guarantee safety
User-friendly interface when login. Provide the following options: Logout
/shutdown/ restart.
Login, Logout and Shutdown
Right authentication when shut down to make sure only those proper
people can turn off DVR
Power
AC90~264V 50+2% Hz （Max 75W）
Power
Consumptio
n
13W (Exclude HDD)
Working
Temperatur
e
0℃－＋55℃
Working
Humidity
10%－90%
Air
Pressure
86kpa－106kpa
Dimension
2U standard industrial case. 440(W) x460 (D) x89mm(H)
General
Parameter
Weight
5.5-6.5KG(Exclude HDD)

15
Installation
Mode Desktop/rack installation
1.3.2 8 HDDs (Extra stream CIF/QCIF) Series
Parameter
4-ch
8-ch
16-ch
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
Front panel, USB mouse, remote control
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
System
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Video
Compressio
n
H.264
Compression
Standard
Audio
Compressio
n
G.711A
Video Input
4-CH composite video
input: (NTSC/PAL)
BNC (1.0VP- P, 75Ω)
8-CH composite video
input: (NTSC/PAL)
BNC (1.0VP- P, 75Ω)
16-CH composite
video input:
(NTSC/PAL) BNC
(1.0VP- P, 75Ω)
Video
Output
1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output.
Support TV/VGA/HDMI video output at the same time.
Video
Standard
PAL (625 line, 50f/s), NTSC (525 line, 60f/s)
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition
1/4 windows(Optional)
1/4/9 windows
1/4/9 /16 windows
Monitor
Touring
Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
PAL/NTSC
Real-time monitor：
D1 704×576/704×480
Playback：
D1 704 × 576/704 × 480
HD1 352x576/352x480
BCIF 720x288/720x240
CIF 352 × 288/ 352 × 240
QCIF 176 × 144/176 × 120
Resolution
(PAL/NTSC
)
Support dual streams.
Extra stream resolution:
CIF 352 × 288/ 352 × 240
QCIF 176×144/176×120
Video monitor
Quality
6-level image quality (Adjustable)

16
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status
and motion detection status are shown on the bottom left of display
screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio Input
4-ch 200-2000mv
10KΩ(BNC)
8-ch 200-2000mv
10KΩ(BNC)
16-ch 200-
2000mv 10KΩ
(BNC)
Audio
Output
1-ch audio output 200-3000mv 5KΩ(BNC)
Audio
Bidirectional
Audio
1-ch audio talk input 200-3000mv 10KΩ（BNC）
1-ch audio talk output 200-3000mv 5K Ω (BNC)
Hard Disk
8 built-in SATA port. Support 8 HDDs.
Hard disk
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat
Way
When hard disk is full, system can overwrite previous video file.
Record
Search
Various search engines such as time, type and channel.
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback
and reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the
next file in the current channel
Multi-
channel
Playback
There are two playback modes: 4-ch and full-channel. In 4-ch
playback mode, you can select the 1/2/3/4-ch playback according to
your requirement. In full-channel mode, system can playback in full
channels. Please note the 4-ch has no full-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback
Record and
playback
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk, USB
burner and etc.)
Support peripheral eSATA backup device.
Backup
function
Backup
Mode
Support network download and backup

17
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as external alarm, motion detection and
video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Network
Function
Network
control
Bidirectional audio.
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate external alarm or screen message prompt.
External
Alarm
Support record activation function or activate external alarm or screen
message in specified period.
Manual
Alarm
Control
Enable or disable alarm input channel
Support analog alarm signal to specific alarm output channel.
Alarm Input
4-ch alarm input（You
can set normal open or
normal close type to
select the alarm type. ）
8-ch alarm input（You
can set normal open or
normal close type to
select the alarm type. ）
16-ch alarm input
（You can set
normal open or
normal close
type to select the
alarm type. ）
Alarm
Output
6-channel relay output, including one controllable DC +12V output port.
Motion
Detection and
Alarm
Alarm Relay
30VDC 2A，125VAC 1A（activation alarm ）
USB
Interface
2 USB 2.0 ports.
Network
connection
RJ45 10M/100M self-adaptable Ethernet port
RS485
PTZ control port
Support various PTZ control protocols.
Interface
RS232
Ordinary COM (Debug),keyboard connection and transparent serial
port(COM input and output via network )
Hard Disk
Information
Display HDD current status
Data
Stream
Statistics
Data stream statistics for each channel (in wave mode)
Log
statistics
Backup to 1024 log files.
Support various search engines such as time and type.
Version
Display version information: channel amount, alarm input and output
amount, system version and release date.
System
Information
On-line user
Display current on-line user
Multi-lever user management; various management modes
Integrated management for local user, serial port user and network user.
Configurable user power.
User
Manageme
nt
Support user /group and its corresponding rights modification.
No limit to the user or group amount.
Password modification
Administrator can modify other user’s password.
User
Management
Password
Authenticati
on
Account lock strategy
Five times login failure in thirty minutes may result in account lock.
Upgrade
Web browser, client-end and update tool.

18
Password login protection to guarantee safety
User-friendly interface when login. Provide the following options: Logout
/shutdown/ restart.
Login, Logout and Shutdown
Right authentication when shut down to make sure only those proper
people can turn off DVR
Power
AC90~264V 50+2% Hz （Max 75W）
Power
Consumptio
n
13W (Exclude HDD)
Working
Temperatur
e
0℃－＋55℃
Working
Humidity
10%－90%
Air
Pressure
86kpa－106kpa
Dimension
2U standard industrial case. 440(W) x460 (D) x89mm(H)
Weight
5.8-6.8KG(Exclude HDD)
General
Parameter
Installation
Mode
Desktop/rack installation
1.3.3 8 HDDs (Extra stream QCIF) Series
Parameter
4-ch
8-ch
16-ch
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
Front panel, USB mouse, remote control
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
System
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Video
Compressio
n
H.264
Compression
Standard
Audio
Compressio
n
G.711A
Video Input
4-CH composite video
input: (NTSC/PAL)
BNC (1.0VP- P, 75Ω)
8-CH composite video
input: (NTSC/PAL)
BNC (1.0VP- P, 75Ω)
16-CH composite
video input:
(NTSC/PAL) BNC
(1.0VP- P, 75Ω)
Video
Output
1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output.
Support TV/VGA/HDMI video output at the same time.
Video monitor
Video
Standard
PAL (625 line, 50f/s), NTSC (525 line, 60f/s)

19
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition
1/4 windows(Optional)
1/4/9 windows
1/4/9 /16 windows
Monitor
Touring
Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
PAL/NTSC
Real-time monitor：
D1 704×576/704×480
Playback：
1/16-ch: D1 704×576/704×480 (6f/s, when other channels’ resolution
are all CIF, the first channel and the ninth channel can support 25f/s.) ,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Resolution
(PAL/NTSC
)
Support dual streams.
Extra stream resolution:
QCIF 176×144/176×120
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status
and motion detection status are shown on the bottom left of display
screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio Input
4-ch 200-2000mv
10KΩ(BNC)
8-ch 200-2000mv
10KΩ(BNC)
16-ch 200-
2000mv 10KΩ
(BNC)
Audio
Output
1-ch audio output 200-3000mv 5KΩ(BNC)
Audio
Bidirectional
Audio
1-ch audio talk input 200-3000mv 10KΩ（BNC）
1-ch audio talk output 200-3000mv 5K Ω (BNC)
Hard Disk
8 built-in SATA port. Support 8 HDDs.
Hard disk
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat
Way
When hard disk is full, system can overwrite previous video file.
Record and
playback
Record
Search
Various search engines such as time, type and channel.

20
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback
and reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the
next file in the current channel
Multi-
channel
Playback
There are two playback modes: 4-ch and full-channel. In 4-ch
playback mode, you can select the 1/2/3/4-ch playback according to
your requirement. In full-channel mode, system can playback in full
channels. Please note the 4-ch has no full-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk, USB
burner and etc.)
Support peripheral eSATA backup device.
Backup
function
Backup
Mode
Support network download and backup
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as external alarm, motion detection and
video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Network
Function
Network
control
Bidirectional audio.
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate external alarm or screen message prompt.
External
Alarm
Support record activation function or activate external alarm or screen
message in specified period.
Manual
Alarm
Control
Enable or disable alarm input channel
Support analog alarm signal to specific alarm output channel.
Alarm Input
4-ch alarm input（You
can set normal open or
normal close type to
select the alarm type. ）
8-ch alarm input（You
can set normal open or
normal close type to
select the alarm type. ）
16-ch alarm input
（You can set
normal open or
normal close
type to select the
alarm type. ）
Alarm
Output
6-channel relay output, including one controllable DC +12V output port.
Motion
Detection and
Alarm
Alarm Relay
30VDC 2A，125VAC 1A（activation alarm ）
USB
Interface
2 USB 2.0 ports.
Network
connection
RJ45 10M/100M self-adaptable Ethernet port
RS485
PTZ control port
Support various PTZ control protocols.
Interface
RS232
Ordinary COM (Debug),keyboard connection and transparent serial
port(COM input and output via network )
