aiTerminal AIT005B User manual

Electric Standing Desk
User Manual
Model: AIT005B

TABLE OF CONTENTS
Parts and Hardware List
Parts
01
02
Hardware 02
Step 1 03
Step 2 03
Step 3 04
Step 4 04
Step 5 05
Operation Guide 06

PARTS AND HARDWARE LIST
NO Component Name Qty
Table Top Base
Left Leg
M6*16 Screw
Right Leg
Bracket
Driveshaft
Control Box
Foot Margin
Foot Pad
M8*10 Screw
Key Pad
Wrench
5mm Hex Spanner
1
2
3
4
5
6
7
8
9
A
B
C
D
1
4
2
1
1
1
2
1
8
1
12
1
1
Cable Tie
E5
Gasket 8
F8
AB C D
F
E
1
2
3
4
56
7
8
9
01

PARTS
HARDWARE
5 Control Box x1
2 Foot Pad x4
3 Foot Margin x2
6 Driveshaft x1 7 Bracket x2
8 Right Leg x1
1 Table Top Base x1
M6*16
Screw x 8
M8*10
Screw x 12
Cable Tie x 5
5mm
Hex Spanner x1
Wrench x1
4 Left Leg x1
9 Key Pad x1
02
A
DF
E
B C
Gasket 6 x 8

STEP 1
Put the right leg on the crossbar end using 6 pcs M8*10 screws
and tighten them with 5mm hex spanner .
STEP 2
Loosen right nut of driveshaft and insert the rod to the left leg. Pay
attention to the insert direction and push the driveshaft all the way
in. Then put the left leg on the crossbar end and firmly secure the
leg using 6 pcs of M8*10 screws with 5mm hex spanner .
5mm Hex Spanner
left nut right nut
M8*10screw 6pcs
03
Tool Required：C
Hardware Required：
B Screws
5mm Hex Spanner
M8*10screw 6pcs
Tool Required：C
Hardware Required：
B Screws

STEP 3
STEP 4
Attach foot margins to leg using 8 pcs M6*16 screws and tighten
them. Pay attention to keep the foot margin longer side same dire-
ction as key pad side.
Insert the left nut on the right leg and secure the left and right nut
with wrench.
left nut
right nut
Nut
04
Tool Required：D
Tool Required：C
Hardware Required：
A Screws
5mm Hex Spanner
M6*16 screws 8pcs
Gasket 6 8pcs

STEP 5
Connect the control box to the key pad and the legs.
05

Operation Guide
06
Activating & Troubleshooting
Lock and Unlock
You will need to activate the memory keypad once the desk is fully assembled, Side note :
if the frame doesn’t seem to be working properly, rest assured that most issues can be
fixed using the exact same activation process.
1.If the handset locked, first step is unlock.
2.Begin by pressing and holding the “Up” and “Down” buttons at the same time.
3.Continue to hold as the frame lowers itself all the way down (if extended ), you will hear a
slight beep sound followed by a brief flash on the display.
4.Press the “Up” button once to engage the motors, your desk should be activated and
ready to go.
Press the lock button for 1 second handset locked.
Press the lock button for 3 seconds handset unlock.
To preset a specific height, drive the desk to desired height, press “Up” and 1 buttons at the
same time for about 2 seconds, “P1” should appear on the display,repeat the procedure for
button 2.
Press “1” “2” and “unlock” button together for about 5 seconds, “C-I” should appear on the
display, press the “2” button you should see “I “ displayed, you have programmed the
handset from centimeters to inches.
Press“1” “2” and “unlock” button together for about 5 seconds, “C-I” should appear on the
display, press the “1” button you should see “C ” displayed, you have programmed the
handset from inches back to centimeters.
Memory Function
Programming Alternative Measurements
Revert Back to Centimeters
