AITZ ALPHA User manual

Contents
1. Introduction ………………………………………………… 3
2. Cautions before using ………………………………… 4
3. Cautions when using ………………………………… 5
4. Features …………………………………………… 7
5. Components ………………………………………… 8
6. Part names …………………………………………… 9
7. Button, LED indication ………………………………… 10
8. Installation …………………………………………… 11
9. Functions ……………………………………… 13
10. AITZ ALHPA GUI ……………………………………… 16
11. PC viewer …………………………………………… 28
12. Setting ……………………………………………… 37
13. Specifications …………………………………… 39
AITZ ALPHA User Manual 2
14. A/S ………………………………………………… 40

Introduction
•Thank you for purchasing AITZ ALPHA.
•AITZ ALHPA is offered ADAS(Advanced Driver Assist System) which are Lane departure
system(LDWS), Forward Collision Warning System(FCWS) and STOP&GO. Also record the
front/rear image with sound.
•AITZ ALPHA can save the driving/accident image and sounds together, also check the video
image by 3.5 inch full touch screen.
AITZ is a trademark belonging to ATM CO., LTD.
All contents of this manual and publications of the manufacturer are protected by intellectual property rights.
The product and manual can be changed for further improvement without any notice to users.
The image which in this manual should not be different with actual image.
The manufacturer shall not be liable for product failure or damages due to misuse, incorrect installation or
unauthorized alteration.
Please do not operate this device and touch the LCD during the driving for safety.
Please use this product safety after reading this manual carefully.
3
AITZ ALPHA User Manual

Cautions before using
•Warranty and Limited Liability
AITZ ALPHA is a supplementary device for your safe driving. The manufacturer shall not be liable for any loss
or damage caused by product failure, data loss or use of the product.
This product is used to record and save video. Some functions may not be available depending on the driving
or vehicle’s environment. Performance of the device may also vary as the firmware will be updated from to
time for further improvement.
Although this product can save and record video images of the vehicle’s accident, the manufacturer does not
guarantee that all accidents are recorded by the product. Accidents caused by tiny impact can not recorded as
the event video when the motion sensor does not work. .
•Caution in Use of Micro SD card
Micro SD card is consumable, so please check the recording filed regularly. If the microSD card is not working,
change the microSD card.
If there is a important data, please back up to the other storage media.
Check the recording files and format the microSD card regularly.
※ Micro SD is very important for recording, so please keep the caution before using.
※ If the Micro SD has damaged or lost files, manufactures doesn’t have any responsibility.
※ For using safety Micro SD card, please format the microSD card twice a month.
4
AITZ ALPHA User Manual

Cautions when using
•This section is for safety and proper use of the product to prevent safety accidents. The
manufacture shall not be responsible for troubles caused by use of the product in violation of the
instructions.
Warning ) This message shows that will influence high risk for injury or death to user.
When install the power, please use the cables which provided by ATM. If use other cables, manufacture
doesn’t have any response.
If remove the power cable, do not the wet hand. It may cause electric shock.
Do not disassemble, repair or modify the product. It can cause damage and electronic.
Please remove the power from product when not used the car longtime. It cause of fire or car battery
discharge.
Please install the product a windscreen avoid deep tinted windows or metal coating. GPS receiving error will
be happen, and recording resolution will be indistinct.
Do not operating or states during driving. It could be cause of accident. Please use device after safety parking.
5
AITZ ALPHA User Manual

Cautions when using
Caution ) Injury or property damage can be caused for users the this contents are not followed.
To connect the power cable, please insist on getting cabling done by an authorized personnel from master.
Do not impact to the product. The product will be broken.
Please install the product avoid the drivers sight.
Pleas keep the windshield clean. Foreign materials may prevent normal recording of images.
Do not use the sharp things on LCD screen. If use this, LCD screen or touch panel will be damaged.
Avoid the direct sun light when parking. If used for long hours in an air-tight environment inside a car and in
direct sunlight, the product may malfunction.
Reflections of images of Navigation HIPASS may cause poor recording quality.
Do not use sharp devices on the LCD. The touch panel or LCD may be damaged by sharp devices when the
blackbox is set up with them on the LCD.
When the Micro SD Card is full, the oldest file in the card will be overwritten by a new file. Please back up
data periodically to prevent unwanted data loss.
Please watch out for using Micro SD card and removing it. Please remove the power cable before inserting or
removing the Micro SD Card.
6
AITZ ALPHA User Manual

Features
•Front/Rear FHD-HD high resolution video
•Full Touch LCD Screen(3.5”)
•Max 120°wide angle
•Driving recording
•Event recording : Save the event file when external shock occur
•Enforced recording : Record the enforced file by button
•Parking recording : Motion detected sensor working when parking mode
•Parking impact recording : Save the damaged video when parking mode
•Super Cap : Record the normally when shut-down the device
•ADAS : LDWS(Lane departure warning system), Forward Collision Warning System(FCWS),STOP&GO
•Save the speed/location by GPS
•Voice guidance
•Cut-off voltage
•High-quality MIC
•Exclusive PC viewer
7
AITZ ALPHA User Manual

Components
8
Option
Components
GPS module
Quick guide
Micro SD CardRear camera
AITZ ALPHA device
Main power cable TAPE Sheet
Bracket TAPEBracket
AITZ ALPHA User Manual

Part names
①Camera lens
②Touch LCD(3.5”)
③Enforced recording button
④Power button
⑤Volume
⑥Operated LED
⑦Micro SD card Slot
⑧GPS port
⑨Reset button
⑩Rear camera port
⑪I/F port
⑫Power port
⑬Security LED
⑭Bracket
9
AITZ ALPHA User Manual

Button, LED operation
•LED indication
10
Status RED YELLOW BLUE
Power ON OFF OFF
Booting ON ON OFF
Recording start ON ON ON
Pause
(Repeat)
OFF ON ON
OFF OFF OFF
Parking mode
(Repeat)
OFF ON OFF
OFF OFF ON
Motion detection
(Repeat)
ON ON ON
ON OFF OFF
Event recording ON ON OFF
Driving / User
recording ON ON ON
Power off
(Follow the step) OFF OFF OFF
AITZ ALPHA User Manual

Installation
•When install the product, please off the car engine and do on a flat surface.
•Please check it can record the front and rear as video well before exact installation.
•All components required for installation are provided with product. Check the components and
read the instructions before installation.
•The product should be located in such away that the driver’s view is unaffected.
•ADAS functions can set the calibration(ADAS>calibration).
•Please install it without connecting external camera to the main device.
•Check the Micro SD card is correctly inserted.
•Try to conceal cables for tidiness and safety.
•Please keep the clean on windshield.
•Please not that heavy glass tint or thermal wire in the glass may impair the recording quality.
•After install the product, please remove the camera’s protective plastic.
•Please avoid deep tinted glass or metallic coating on windshield when installation. It may cause
of GPS receiving error.
11
AITZ ALPHA User Manual

Installation
1. Clean the spot on the front/rear windows where the product is installed.
Remove the bracket’s protective plastic and affix on the desired point.
If the car’s ceiling is so high, please attach the TAPE SHEET and spare tape on the bracket tape, then affix the
device.
When use the TAPE SHEET, please remove the protective plastic.
2. After affix the product, push the device to the left, the device will detach from bracket.
3. Connect to the cables by Rear camera > I/F > Power steps.
4. When connect to the power cable, booting is start with AITZ logo.
5. When booting is completed, the front video will be displayed with voice guidance “Recording is
start.”.
12
AITZ ALPHA User Manual

Functions
•ADAS (Advanced Driver Assist System)
•LDWS (Lane departure warning system)
Lane Departure Warning System notifies the driver in real time when the vehicle is leaving its lane.
•FCWS (Forward Collision Warning System)
•STOP&GO
•Caution
For the operation of ADAS very well, , please set the horizon and end point of the road on [ADAS] >
[Calibration]
LDWS function is working when GPS receiving well, also working when over the setting speed.
Working speed can set the [ADAS] > [Speed].
ADAS system may be not working on decipher faded, missing, or incorrect lane markings. Markings covered in
snow or old lane markings left visible can hinder the ability of the system.
13
AITZ ALPHA User Manual

Functions
•Calibration setting
[ADAS] > [Calibration]
14
①Set the red line on center point of read using the Volume
button(▲▼) and push the Enforced recording button(●) for
next step.
②Set the red line to the horizon using Volume button and
push the Enforced recording button(●).
③Set the red line on bonnet of car using volume button.
④Set the red line on right line of car using Volume button.
AITZ ALPHA User Manual

AITZ ALPHA GUI
•GUI Main screen
15
Recording mode
Date / Time
Temperature
Input voltage
Rear cam
Front Cam
AITZ ALPHA User Manual
GPS
(This sign can show when GPS in connected.)

AITZ ALPHA GUI
•Menu
16
①Back
②Main screen
③Voice recording
④Play video
⑤Format
⑥ADAS
⑦Recording setting
⑧System setting
AITZ ALPHA User Manual
①
⑧
⑦⑥
⑤
④
③
②

AITZ ALPHA GUI
•Play video
17
AITZ ALPHA User Manual
①Select the recording mode which
user play file.
②Select the video file

AITZ ALPHA GUI
•Format
18
AITZ ALPHA User Manual
①“Yes” – SD Card format start
“No” – Back to the previous screen

AITZ ALPHA GUI
•Micro SD Format
19
AITZ ALPHA User Manual
•Recording setting
①LDWS : ON/OFF
②FCWS: ON/OFF
③STOP&GO: ON/OFF
④ADAS Voice guidance : ON/OFF
⑤Limit speed setting
- 60,80,100 km
⑥ADAS Calibration setting
①Sensitivity
②Voice setting
③Cut-off voltage
④Memory control

AITZ ALPHA GUI
•Sensitivity
20
AITZ ALPHA User Manual
•Voice guidance
①Motion - Low, Middle, High
②Event - Low, Middle, High
③Parking event - Low, Middle, High
①MIC Volume – 1(Low), 2(Middle), 3(High)
②Voice guidance: ON/OFF
③Voice recording : ON/OFF
