Aiwa SX-DV1 User manual
SERVICE MANUAL
DATA
DVD/DIGITAL AMP/5.1CH
SPEAKER SYSTEM
HT-DV1
S/M Code No. 09-02A-362-9R3
U (S)
BASIC DVD/CD MECHANISM : KHM-230
REVISION
HT-DV1
DVD PLAYERSYSTEM
XA-DV1
DTS DECODER
XD-DV1
SPEAKER
SX-DV1
This Service Manual is the Revision Publishing and replaces Simple Manual
(S/M Code No. 09 027 362 9T3).
