Aiyima DAC-A2 PRO Installation and operation manual

Website:www.aiyima.com Email: [email protected]
Telephone: [phone] VK: https://vk.com/aiyima
Location: 4F, Building 7 Hekan industrial park. Wuhe south road 41. Long-Gang district.
ShenZhen. CHINA. 518000
Shenzhen Yima Technology Co.,Ltd
Headphone DAC Game Decoder
USER MANUALS
Model DAC-A2 PRO:

2
1
Front and Rear Panel Description Operation Steps
Type-C Data Input Operation Instructions
2
1
5
6
7
3
4
3.5 microphone input interface
3.5 headphone output + MIC input interface（Support two in one
earphone with microphone and listening function）
Input Channel indicator light (The light flashes when the volume
is minimum or maximum)
Treble adjustment knob
Bass adjustment knob
Encoder knob (short press: start/switch input channel; rotate left
and right to adjust total volume; long press to shut down)
3.5 AUX output interface
9
8
12
13
14
10
11
Coaxial input
Optical fiber input
USB input interface 1（connected to keyboard, mouse, U disk, etc）
USB input interface 2（connected to keyboard, mouse, U disk, etc）
USB input interface 3（connected to keyboard, mouse, U disk, etc）
Type-C data input interface（Support sound recording and OTG functions）
Type C Power Interface (DC voltage shall not be higher than 5V)
1. Connect the audio device to be used to the audio input port.
2. Connect the rear stage equipment to be used to the 3.5AUX output port.
3. Connect the power supply (DC voltage shall not be higher than 5V).
4. Briefly press the encoder knob to start the machine and adjust it to the appropriate volume,
treble and bass.
5. Connect the type-C data input to the computer or mobile phone.
6. Connect the 3.5 microphone you need to use to the microphone input port and the headphone
to the 3.5 output port.
7. Connect the type-A USB device to usb1, 2 、3.
8. Microphone and listening two in one headphone, connected to the 3.5mm headphone
output + microphone input port.
1. Connect the configured USB cable to the computer (USB supports hot plug).
2. Short press the encoder knob to switch to type-C data input.
3. As shown in the figure, find the icon with horn symbol in the lower right corner of PC
1. Connect this device to the mobile phone using the full function cable of double headed type-c.
2. Supports answering calls, recording, data transmission and OTG functions.
4.Right click popup options，click【Playback device】.
5.Select the USB device recognized by the PC in the pop-up box（USB HIFI AUDIO）.
6.Click to confirm the recognized digital output and set it as the default value.
7.The mouse, keyboard, U disk can be connected to the USB ports 1, 2, 3 of the machine.
Ⅰ：Connect the computer
Ⅱ：Connect Mobile phone

Specification Parameters
FQA
4
3
Warning
Type-C IN
Type-C Operating
System Supported
Type-A USB Version
Frequency Response
Noise
192K/24Bit
Win7/Win8/Win10/
MAC/Linu
3.0
Coaxial / Optical IN 192KHz/24bit
Maximum
Output Level 1.8V
Headphone
Impedance Matching 16-300Ω
Maximum Output
Power of Earphone 150mW
Package Weight 0.58kg
Package Size L195*W160*H70mm
SNR ≥112dB
THD ≤0.005%
20Hz-20KHz（-0.5dB）
Power Supply DC5V
-128dBV
Q: All my wires are connected. Why is there no sound?
A: 1. Check whether the machine is started, whether the indicator light is on, and whether it is
switched to the corresponding input channel.
2. Check whether the rear stage is connected correctly and whether the volume is at the
minimum.
3. If the above is normal, check whether the input playback device is muted, paused, or the
volume is at the minimum.
Q: Why is the sound distorted?
A: The input level may be too large. If the volume of the input device is turned on to the
maximum and the volume of the machine is turned on to the maximum, it is easy to distort.
Just turn down the volume of the sound source input device or machine.
Q: Can I use the 3.5 microphone to connect to the machine to sing?
A: Yes, type-C data input is connected to a computer or mobile phone, and 3.5 microphone
input supports recording and Call function.
Q: When I connect my mobile phone, can I answer the phone directly when there is a call?
A: Yes, the prerequisites must be 3.5mm, 4-segment plug and earphone with microphone.
Q: Why do I connect this device to my mobile phone with a mobile phone charging cable,
but the mobile phone cannot find the device and cannot realize the OTG function?
A: the ordinary mobile phone charging cable only has the normal data transmission and
charging function, and does not have the full function of type-c. if you need to use the
OTG function, please use the full function type-C cable.
Q: When the 3.5 microphone, microphone and listening 2-in-1 headset are plugged in at
the same time,Why does the microphone of the two in one headset have no sound?
A: 3.5 microphone is the first choice (if you need to use a two in one headset, not plug in 3.5
microphone or unplug 3.5 microphone plug).
Q: Why is the 96KHz sampling rate selected for both the speaker and microphone, but the
microphone has no sound?
A: The USB sound card of this device is drive free mode because the bandwidth limitation does
not support bidirectional 96KHz mode. It is recommended to reduce the sampling rate of
the microphone.
1.Please do not open the machine casing. Improper operation may cause electric shock hazard.
2.Please choose the power supply of a regular manufacturer, otherwise there is a risk of d
amaging the machine.
3.Do not use the machine in high temperature or humid environment.
