Akai AK-82LF User manual

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761
82L Upright Freezer
INSTRUCTION MANUAL
MODEL: AK-82LF
E209

2After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Contents
03 General Safety Instructions
06 Getting Started
07 Installation
08 Product Overview
09 Instructions
12 FAQs and Troubleshooting Guide
14 Other Useful Information

3
3
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
General Safety Instructions
Pay particular attention to messages that follow this safety alert symbol
or the words DANGER, WARNING or CAUTION. These words are used
to alert you to a potential hazard that can seriously injure you and others.
The instructions will tell you how to reduce the chance of injury and let
you know what can happen if the instructions are not followed.
Refrigerant matters
WARNING: Do not damage the refrigerant circuit! Never use an appliance with a
damaged refrigerant circuit! If the refrigerant circuit becomes damaged, avoid proximity
to open fires and all types of heat and ignition sources. Thoroughly ventilate the room in
which the appliance is located.
The room for installing the appliance must be at least 1m³ per 8g of refrigerant.
The amount and type of refrigerant in the appliance can be found in the Technical
Specifications on page 18 and on the appliance rating plate.
It is hazardous for anyone other than an authorised service person to service this appliance.
In Queensland, the authorised service person MUST hold a Gas Work Authorisation for hy-
drocarbon refrigerants to carry out servicing or repairs which involve the removal of covers.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this type of
product. The safety precautions enclosed herein reduce the risk of fire, electric shock and
injury when correctly adhered to. Keep the manual in a safe place for future reference,
along with the completed warranty card, purchase receipt and carton. If applicable, pass
these instructions on to the next owner of the appliance.
This symbol alerts you to take care as the appliance contains flammable
materials: isobutane as refrigerant and cyclopentane as insulation
blowing gas. While isobutane (R600a) is a gas with a high level of
environmental compatibility, it is nevertheless flammable. Do not expose
the appliance to high heat, sparks and open flames. During transport
and installation, ensure that none of the components of the refrigerant
circuit become damaged.
Responsible disposal
At the end of its working life, do not throw this appliance out with your household rub-
bish. Electrical and electronic products contain substances that can have a detrimental
effect on the environment and human health if disposed of inappropriately. Observe any
local regulations regarding the disposal of electrical consumer goods and dispose of it
appropriately for recycling and recovery of the refrigerant and blowing agent. Contact
your municipal authorities for advice on recycling facilities in your area.
WARNING! This refrigeration appliance contains flammable refrigerants and insulation
blowing gases, which must be removed before disposal. Contact your municipal
authorities for any codes or regulations concerning the disposal of such materials.
DANGER! Risk of child entrapment: When discarding this or another freezer, make
sure to take off the door and leave the drawers in place so that children cannot easily
climb in and get trapped inside.

4After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
To reduce the risk of fire, electric shock or injury, always follow basic safety precautions
and accident prevention measures when using this appliance, including the following:
Electrical safety
• Voltage: Plug the appliance in a 220-240V, 50Hz, properly earthed power outlet,
which must be in good working order. Make sure your outlet voltage and circuit
frequency correspond to the voltage stated on the appliance rating label.
• Power connection: Do not use an adaptor; do not use an extension cord. Plug the
power plug directly into a power point that cannot easily be turned off accidentally,
and that is easily accessible so you can switch it off when required.
• Power cord: Do not kink or damage the power supply cord. Do not leave it exposed
or dangling. Secure it behind the appliance so no one steps on or places anything
on the power supply cord or against it. A squashed or damaged power plug may
overheat and cause a fire.
• Damaged cord: Do not use a cord that shows cracks or abrasion damage along
its length or at either end. Any damage to the cord may cause a short circuit, fire
and/or electric shock. If the power cord is damaged, it must be replaced by the
manufacturer or its service agent. Contact the after sales support line for advice.
• Disconnection: Never unplug the unit by pulling the cord. Always grip the plug
firmly and pull straight out from the power point.
• Electrical work: If the installation of this appliance requires any electrical work,
make sure it is carried out by a qualified electrician.
General Safety Instructions (Cont.)
Usage conditions and restrictions
• Indoor domestic use only: This appliance is intended for indoor domestic use only.
It is not suitable for industrial or commercial use.
• Intended purpose: Do not use this appliance for anything other than its intended
purpose, and only use it as described in this manual. Do not attempt to alter or
modify this appliance in any way.
• Usage restrictions: This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• Children: Supervise children to ensure they do not play with the appliance. Close
supervision is necessary when any appliance is used by or near children. Never
allow children to operate, play with or crawl inside the appliance.
• WARNING! Do not use any electrical appliances (such as ice cream makers)
inside the food storage compartments of the appliance, unless they are approved
for this purpose by the manufacturer.

5
5
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
General Safety Instructions (Cont.)
Installation
• Heavy: This appliance is heavy, take care when moving it. To avoid back or other injury,
consider a two person lift or mechanical aid when installing it. Failure to do so can result
in back or other injury.
• WARNING: Ventilation: To ensure proper ventilation, keep any ventilation openings,
in the appliance enclosure or in the built-in structure, clear of obstructions. Ensure
adequate air circulation around the appliance to prevent overheating.
• Level: Install the appliance level in order to ensure proper operation.
• Location: Install the appliance in an area that meets the following requirements:
—Ambient temperature: The ambient temperatures must correspond to the climate
class (T) indicated on the rating plate of the appliance: 16°C – 43°C.
—Floor surface: The floor must be sturdy, level and strong enough to support the unit
when it is fully loaded.
—Areas to avoid: Avoid areas where the appliance would be exposed to direct sunlight,
sources of heat (stove, heater, radiator, etc.), extreme cold ambient temperatures or
excessive moisture and high humidity (such as outdoors or exposed to wind, rain
water spray or drips). Installing it in the coolest area of the room will save energy
consumption and running costs.
Cleaning and maintenance
• Disconnect: Unplug the appliance before cleaning or servicing. Failure to do so can
result in electric shock, injury or death. Do not connect or disconnect the plug when
your hands are wet.
• Flames: Do not let open flames or ignition sources enter the appliance.
• Flammable/explosive substances: Never clean this appliance with flammable fluids.
Do not store or use volatile, flammable or explosive substances such as aerosol cans
with a flammable propellants in or close to this or any other appliance. The fumes can
create a fire hazard or explosion.
• Solvents: Do not use solvent based cleaning agents or abrasives on the interior as
these may damage or discolour the surfaces of the appliances.
• WARNING! Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer. Never use a
sharp or metal instrument to remove frost or clean the appliance. Use a plastic scraper,
if necessary.
• Service: Do not attempt to repair, modify or replace any part of the appliance unless
specifically recommended in this manual. Refer all other servicing to a qualified
technician, or contact the after sales support centre for advice.

6After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Getting Started
Unpacking
• Packaging materials: This product has been packaged to protect it against
transportation damage. Remove all packaging materials from around and inside the
appliance and keep the original packaging carton and materials in a safe place. It
will help prevent any damage if the product needs to be transported in the future,
and you can use it to store the appliance when it is not in use. In the event that the
carton is to be disposed of, please recycle all packaging materials where possible.
Plastic wrapping can be a suffocation hazard for babies and young children, so
ensure all packaging materials are out of their reach and disposed of safely.
• Parts: Check to ensure you have all the parts pictured on page 08.
• Damage: When unpacking, check the appliance carefully for damage. If it is
damaged, do not install the appliance. Contact our after sales support centre for
advice on examination or return of the damaged appliance.
• Power cord: Unwind the power cord to its full length and inspect it for damage.
Do not use the appliance if the appliance or its cord have been damaged or are not
working properly. In case of damage, contact our after sales support line for advice
on examination, repair or return of the damaged product.
• Read the manual: Before installing your new freezer, read all safety instructions,
especially the sections on installation and electrical safety on pages 4-5. Then follow
the installation instructions on the next page.
• Clean: Make sure the freezer is disconnected from the power supply before
cleaning the interior surfaces and all internal accessories with lukewarm water, a
soft cloth and a neutral/mild soap/detergent. This will remove any dust from transit
and storage and help remove the typical smell of a brand new product. Then dry
thoroughly. Important: do not use harsh or abrasive detergents or powders as these
will damage the finish.
• Door opening: Your freezer has the capability of the door opening from the right or
left side. If your set-up requires reversal of the door swing, follow the instructions on
pages 16-17.

7
7
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Space requirements
• Door opening: Place the unit so there
is enough space for the door to open
(Fig.1).
• Clearances: Ensure that air can
circulate freely around the back of the
cabinet, which is necessary to cool the
compressor and condenser. Allow at least
12cm clear space at the back and 5cm at
the sides of the unit.
• Overhanging wall units: To ensure
best performance, if the appliance is
positioned below an overhanging wall unit, the minimum distance between the
top of the cabinet and the wall unit must be at least 10cm. Ideally, however, the
appliance should not be positioned below overhanging wall units.
Levelling
The appliance must be installed level in order to work
properly. If the unit is not level, the doors and magnetic
seal alignments will not be covered properly.
• To level the unit, adjust one or both levelling feet at
the base of the cabinet (Fig.2).
Electrical connection
• WARNING! It must be possible to disconnect the
appliance from the mains power supply; the plug
must therefore be easily accessible after installation.
• Before plugging in your new freezer, let it stand
upright for at least 4 hours. This will allow the refrigerant gases to settle into the
compressor and reduce the possibility of a malfunction in the cooling system.
• The appliance must be earthed. The plug of the power supply cord is equipped
with a contact for this purpose. Do not under any circumstances cut or remove the
third (earth) prong from the power cord. If the plug does not fit your outlet, consult a
licensed electrician for advice to have the outlet changed.
• Plug the unit into a dedicated, properly installed and earthed wall outlet. Ensure that
your outlet voltage and circuit frequency correspond to the voltage stated on the
appliance rating label.
• Secure the freezer’s supply cord behind the unit. Do not leave it exposed or
dangling to prevent injury and accidental disconnection from the power supply.
• Adjust the temperature control as described on page 09.
• Whenrststartingup,andafteraperiodoutofuse,allowtheunittocool
down on the MAX setting for at least 2 hours before placing food in the freezer.
Installation
Fig.1
Fig.2

8After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Product Overview
Scope of delivery
A Parts list
1 Upper hinge cover
2 Temperature control
3 Cabinet
4 Freezer drawers (3)
5 Door
6 Door gasket
7 Levelling feet
B Documentation (not shown)
Instruction Manual, Quick Start Guide, Warranty Certificate
2 1
6
7
4
5
3
NOTE: Due to continued product improvement, images and illustrations in this
manual may vary slightly from the product purchased. All images in this manual are for
reference purposes only. Parts are not necessarily pictured to scale.

9
9
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Instructions
Temperature setting
The temperature control is located at the front of the freezer cabinet and is accessible
when you open the door (Fig.3). It has three settings: MIN (the warmest setting),
NORMAL and MAX (the coldest setting). Use a coin or a large flat-bladed screwdriver
to adjust it.
• The first time you turn the unit on, set the
temperature control to the MAX position. Then,
after a minimum of 2 hours, adjust the temperature
control to the setting that suits your needs,
NORMAL should be appropriate for normal use.
• To turn the freezer off, turn the temperature control to MIN, which will stop cooling.
Then unplug the unit from the power supply.
NOTE: The unit may not work at the set temperature on particularly hot days, or if the
door is opened too frequently. Toensureecientoperation,donotopen
the door unnecessarily or for prolonged periods of time.
Fig.3
The freezer compartment
The freezer compartment is suitable for freezing domestic quantities of fresh food
and long-term storage (up to three months) of frozen food. It is designed to operate
in ambient (surrounding air) temperatures between 16°C and 43°C. For convenient
access and organised storage, the freezer compartment is equipped with three
transparent, easy to pull out drawers.
Freezing fresh food
• Only freeze fresh food that has been thoroughly cleaned.
• Do not store food uncovered in the freezer. Always use good quality, freezer-proof
packaging to maintain food quality. Remove air from packages of solid food and
seal bags tightly before freezing.
• Ensure that food placed in the freezer is dated and labelled. This will help you keep
track of storage times.
• Keeping portions small will ensure they are frozen (and subsequently defrosted)
rapidly.
• Make sure that fresh, unfrozen food packages do not touch food that is already
frozen, thus avoiding a temperature rise in the frozen food.
• When freezing food, do not push food together too much, leave some space for air
to circulate around each item. Do not place packages directly against the back wall.
• When adding large amounts of fresh food to the freezer, keep in mind that it will
take approximately 24 hours for fresh food to freeze to solid frozen state. For best
results, do not add other fresh food to the freezer drawer during this time.
• Do not place hot foods or liquids which may evaporate in the freezer compartment.

10 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Storing frozen food
• When buying frozen food, only buy quantities that you can store straight away; use
an insulated container for your shopping and when you get home, place the food in
the freezer immediately.
• When storing pre-packed, commercially frozen food, follow the food manufacturer’s
instructions for storing the food in a home freezer. Do not exceed any storage times
listed on the packaging.
• Once you have opened a packet of frozen food, rewrap it airtight to prevent surface
evaporation which causes drying or freezer burn.
• Do not place carbonated liquids such as bottles of fizzy drink in the freezer as the
container could explode under pressure and damage the freezer.
• Do not refreeze food once it has been defrosted.
• Frozen food which has thawed accidentally should either be used immediately or
thrown away. Alternatively, if the food is uncooked and has not been completely
defrosted, it may be cooked and then refrozen.
• CAUTION! Do not remove items from the freezer if your hands are damp or wet as
this could cause skin abrasions.
Saving energy
• Locate the freezer in the coolest area of the room, away from heat-producing
appliances and out of direct sunlight.
• Let hot foods cool to room temperature before placing them in the freezer.
Overloading the freezer forces the compressor to run longer.
• Be sure to wrap foods properly, and wipe containers dry before placing them in the
freezer. This cuts down on frost build-up inside the unit.
• Do not line the freezer storage drawers with aluminium foil, wax paper or paper
towelling. Liners interfere with cold air circulation, making the freezer less efficient.
• Do not pack food packages close together as this prevents air circulating.
• Organise and label food to reduce door openings and extended searches. Remove
as many items as needed at one time and close the door as soon as possible.
• Do not open the freezer door unnecessarily or for too long, especially during a
power failure.
• Do not run the appliance permanently on the MAX temperature setting. The MAX
setting is recommended on very hot days, or when you have added a large quantity
of fresh food.
Instructions (Cont.)

11
11
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Power failure
• Most power failures are corrected within a few hours and should not affect the
temperature inside your freezer, if you minimise the number of times the door is
opened. However, if the power is going to be off for a longer period of time, you
need to take proper steps to protect your food.
• Do not refreeze frozen food without checking its condition first.
• If in doubt, discard the food. Do not refreeze food that has thawed completely.
Going away?
• Short vacation: Leave the freezer operating during vacations of less than a month.
• Long vacation: If you are not going to use the freezer for longer periods, remove all
food and unplug the power cord. Clean and dry the interior thoroughly. To prevent
odour and mould growth, leave the door open slightly, blocking it open, if necessary.
(Restrict children’s access to the room with the open freezer to avoid creating a
child entrapment risk.)
Moving the freezer
• Remove all food from inside the freezer, securely tape down the drawers and tape
the door shut. Turn the levelling feet up to the base to avoid damage.
• Protect the outside of the unit with a blanket or similar soft material and make sure
the freezer stays secure in the upright position during transportation.
Instructions (Cont.)

12 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
FAQs and Troubleshooting Guide
If you experience a problem with your freezer, check in the following table for solutions
to help you solve the problem. If after these checks you still have a problem with your
freezer, call the after sales support line for advice.
CAUTION: Before troubleshooting, disconnect the power supply. Any troubleshooting
that is not mentioned in this manual may only be carried out by a qualified electrician
or similarly qualified person.
Problem Possible cause and solution
Appliance does
not work.
Check and ensure that the mains plug is securely plugged into the
power point and power to the socket is switched on.
Check the fuse and replace, if it has blown or is defective, or reset
a tripped circuit breaker.
Ensure that there is power at the socket (plug another appliance
into the outlet to check that it is working).
Food freezes
too much.
If the appliance runs at the MAX setting, reset the temperature
control to a warmer setting temporarily.
Food is not
frozen enough.
Reset the temperature to a colder setting.
Make sure the door is only opened for as long as is necessary. Do
not keep it open for an extended period.
If you have added a large quantity of warm food in the appliance
within the last 24 hours, turn the temperature control to a colder
setting temporarily.
Make sure the appliance is not located near a heat source.
Heavy build-up
of frost on the
door seal.
This is a sign that the door seal is not air-tight. Carefully warm
the leaking sections of the door seal with a hair dryer (on a cool
setting). At the same time shape the warmed door seal by hand in
such a way that it sits correctly.
The door will
not open.
If the door has just been opened, leave it for a few minutes to allow
the air pressure to equalise before trying again.
The door will
not close.
Ensure the freezer is properly levelled and the door gasket is clean.
Unusual
noises.
Check and ensure that the appliance is level. If necessary, adjust
the levelling feet.
If the appliance is touching the wall or other objects, move it slightly.
Some sounds are normal during use and no cause for concern.
These include whirring or pulsating noises from the compressor,
faint gurgling or bubbling sounds from the refrigerant circulation and
clicking noises from the temperature control cutting in and out.

13
13
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Problem Solution
The external
freezer
surface is
warm.
The exterior freezer walls can be warmer than room temperature.
This is normal while the compressor works to transfer heat from
inside the freezer cabinet.
The com-
pressor runs
continuously,
or turns on
and off very
frequently.
Select a lower temperature setting.
Check that the door is closed completely and that the door gasket
is clean and seals properly.
Large quantities of food have recently been placed in the cabinet
and/or the door is frequently opened.
Check that ventilation openings are not obstructed.
If the freezer was recently disconnected for some time, it will need
some time before it will have cooled down to the set temperature.
If the room temperature is hotter than usual, the compressor has to
work harder to maintain the correct temperature.
Excessive
frost and ice
has built up.
Ensure the door is not left open.
Check that nothing is preventing the door from closing.
Check that the door gasket is intact and clean.
Ensure the freezer is defrosted periodically.
Vibrations Ensure the floor is even and the freezer is not touching a wall.
FAQs and Troubleshooting Guide (Cont.)

14 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Other Useful Information
Defrosting the freezer
• For efficient operation and minimum energy consumption, defrost the freezer
compartment when the frost on the freezer walls is building up; do not let frost build
up to more than 3–4mm thickness.
• Turn the temperature control to the MIN position, unplug the freezer and remove the
food and storage drawers. (Keep any frozen food temporarily in a fridge or cooler
bag to keep defrosting to a minimum.)
• Keep the door open and place a tray and old towel underneath the appliance to
collect the defrost water.
• After the frost or ice in the freezer has melted, discard the defrost water and clean
and/or dry all interior freezer surfaces thoroughly. (See below for how to clean the
interior surfaces.) Then turn the freezer temperature control to the desired setting to
restart the freezer.
WARNING!
Before defrosting or cleaning the appliance, make sure it is switched off and disconnected
from the power supply. Failure to do so can result in electric shock or injury.
WARNING!
• Never use sharp or metallic tools to scrape off frost from the evaporator as you could
damage it. To scrape ice off surfaces, use a plastic scraper.
• Do not use boiling water to accelerate defrosting because it may damage the
plastic parts.
Cleaning the freezer
For hygienic reasons the appliance interior, including the interior accessories, should
be cleaned regularly. We recommend cleaning the freezer after defrosting it, while all
frozen food and drawers are already removed from the compartment.
• Make sure the freezer is unplugged from the power supply, the temperature control
is set to MIN and all food and storage drawers are removed.
• Wash the inside surfaces and the interior accessories with a damp, warm cloth
moistened in a water and baking soda solution. The solution should be about 2
tablespoons of baking soda to 1 litre of water. Rinse and wipe dry with a soft cloth.
• Clean the outside of the unit with a damp, well wrung out cloth, making sure the
area of the controls remains dry. Keep the door gasket (seal) clean.
• After everything is dry, place appliance back into service.

15
15
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Service and repair
Do not attempt to alter or modify this appliance in any way.
Do not attempt to repair or replace any part of the appliance unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified
technician. Contact our after sales support line for advice.
Spare parts
Our after sales support centre stocks the following spare parts for the 82L Upright
Freezer. To purchase a part email us at [email protected]g
• Door gasket
• Long levelling foot
• Lower drawer
• Middle drawer
• Short levelling foot
• Thermostat
WARNING!
• Never clean the unit with an abrasive, acid, oil or solvent based cleaning agent, or
with abrasive pads or scourers. Never use flammable fluids or sprays for cleaning
as the fumes from these substances can create a fire hazard or explosion.
• Never clean the appliance with a steam cleaner. Moisture could accumulate in
the electrical components, danger of electric shock! Hot vapours can lead to the
damage of plastic parts.
• The appliance must be completely dry before it is placed back into service.
IMPORTANT!
• Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the
juice form orange peel, butyric acid, or cleansers that contain acetic acid. Do not
allow such substances to come into contact with the appliance parts.
Other Useful Information (Cont.)

16 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Reversing the door swing
This freezer can be opened from either side to suit your individual installation require-
ments. If you want to open the door from the other side, follow the instructions below
and on the following pages to reverse the door swing.
Tools required: Phillips head screwdriver, flat-bladed screwdriver, hexagonal spanner
Help required: We recommend you ask another person to help you during assembly.
• WARNING! Ensure the freezer is empty and disconnected from the power supply.
• Keep all parts you remove for re-installation of the door on the other side.
• Tilt the appliance slightly towards the back and prop it up securely on something
solid so that it will not slip during the door reversing process. Do not lay the unit flat
as this may damage the coolant system.
Other Useful Information (Cont.)
1. Remove the top right hinge cover (Fig.4).
2. Undo the screws, then remove the hinge bracket (Fig.5).
Fig.5
Fig.6
Fig.4
Fig.7
3. Remove the top left screw cover (Fig.6).
4. Move the core cover from the left to the right side (Fig.7). Lift the door and place it
on a padded surface to prevent it from scratching.

17
17
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Other Useful Information (Cont.)
6. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it
(Fig.9).
Fig.10 Fig.11 Fig.12
7. Refit the bracket fitting the bottom hinge pin. Replace both adjustable feet
(Fig.10).
8. Reattach the door, making sure it is aligned horizontally and vertically so the
seals are closed on all sides before finally tightening the top hinge (Fig.11). Insert
the hinge bracket and screw it to the top of the unit. Use a spanner to tighten, if
necessary.
9. Reattach the hinge cover and the screw cover (Fig.12).
Fig.8
5. Unscrew the bottom hinge. Then remove the adjustable feet from both sides (Fig.8).
Fig.9

18 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Other Useful Information (Cont.)
Technicalspecications
Rated voltage 220-240V~
Rated frequency 50Hz
Rated current 0.7A
Climate class T
Dimensions (mm) 840 (H) x 500 (W) x 560 (D)
Net weight 27kg
Capacity 82L gross, 73L net
Refrigerant R600a, 42g
Insulation blowing agent Cyclopentane

19
19
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Other Useful Information (Cont.)
Compliance
This appliance has been fully tested and meets all requirements as set out by
standards AS/NZS 60335.1 and AS/NZS 60335.2.24.
The RCM Mark (Regulatory Compliance Mark) indicates that the product
complies with the relevant guidelines of the ACMA as well as corresponding
government requirements for the safety of electrical devices.
E209

20 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Warranty returns
Should you for any reason need to return this product for a warranty claim, make sure
to include all accessories with the product.
Product does not work?
If you encounter problems with this product, or if it fails to perform to your
expectations, make sure to contact our After Sales Support Centre for advice.
For an electronic copy of this manual, please contact our after sales support centre.
Distributed by Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Australia NSW 2086
IM Version No: V1.0 Issue: August 2020
