Akko 3061 Series User manual

用户手册
User Manual

292 x 101 x 37mm
Approximately 0.5KG
China
Mechanical Keyboard
PBT Material
Type-C To USB
YES
YES
YES (use Akko Marco V1.0)
3061 Technical Specifications
9
Dimensions
Weight
Country of Origin
Type
Keycap
Interface
Multimedia Keys
N-Key Rollover
Custom Keys

CtrlFn
3061 HotKeys
10
~
F1 - F10
F11
F12
Delete
Fn+
ESC
1 - 0
-
=
Backspace
=
PrtSc
Calculator
Mute
Decrease Volume
Increase Volume
P
C
M
<
>
Fn+ =
↑
←
↓
→
Insert
W
A
S
D
I
Fn+ =
Fn
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12
1 2 3 4 5 6 7 8 9 10 - =
M < >
ESC
Delete
~
W
SA D
Backspace
Insert
I
PrtSc
P
Cal
C
Fn

Fn
～
3061 System Commands
11
Fn Menu
R
Win Win
Win Fn
W
Swap W A S D with ↑↓ ← →.
Fn+W (Long press 3S)
Switch to right Win key to become the Menu key.
Press and hold to switch back.
Fn+Right Win+ R (Long press 3S)
Press to lock the Win key and press again to unlock.
Fn+Left Win/Right Win
Restore to the factory settings.
Left Win+Right Win (Long press 5S)

12
3061S Single-Color Backlight
12
*Backlight function is only available on the backlight version of 3061S.
Fn
～
Fn
\
[ ]
Fn
Dim
Bright
[
]
\
Fn+ = Lighting effects cycles among Steady /
Breathe / One-key light up /
One-key light off Wave / Ripple / Raindrop

Akko Macro V1.0
Macro Setup Instruction 1
13
1. Akko Macro V1.0 is hardware-based and works without software-driven.
2. The following keys cannot be programmed: "Esc", "Fn", "Left Win" and "Right Win".
3. Press and hold Fn + Win for 3 seconds to switch to the Macro mode. When the keyboard is re-connected or the
system is restarted, the Macro mode will be exited. You need to switch to the Macro mode again to use
programmed keys.
4. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the
two keys in the order of A followed by B.
5. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key A and key
B cannot be defined and will follow the system's default trigger time.

Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key
Exit Macro EditorExit Macro Mode
Fn + Custom Key
Record the next Key
Back to Default Mode Fn+Esc
Long Press Fn +Left Win Fn+Esc (End Recording)
Akko Macro V1.0
Macro Setup Instruction 2
(Press Keys to Store)
14
Clear Macro：
If a key has been defined, after entering the Macro editor, you can press “FN + the key” to
clear its definition.
If you want to re-customize that key, press “FN + the key”again to start the new Macro
recording after clearing its old definition.

Akko Macro V1.0
Macro Setup Instruction 3
Step 1: Press Fn + left Win for 3 seconds to enter the Macro mode.
Step 2: Press Fn + ESC to launch Macro editor.
Step 3: Press Fn + A. This means we choose key “A” to record.
Step 4: Press A, K, K, O, G, E, A, R in order as replacement definition of “A”.
Step 5: Press Fn + A again to end the Macro recording of key “A”.
At this point, pressing “A” in notepad will display “AKKOGEAR”.
If you want to create a Macro for key “B”, press Fn + B to start the Macro recording.
Step 6: Press Fn + Esc to exit Macro editor.
Under the Macro mode, you can configure the keys and Macros you set.
Step 7: Press and hold Fn + Left Win for 3 seconds to exit the Macro mode and return to the default key definition.
Macro Recording Example: Define “A” as “AKKOGEAR”
15

1. Akko provides 1-yr warranty for customers in mainland China. For other regions, please contact your seller
(Akko distributor) for specific warranty policy.
2. If the warranty window expires, customers need to pay for repairs. Akko will also provide instructions if users
prefer to repair the keyboard by themselves. However, users shall take full responsibility for any loss happened
during self-repair.
3. Dissembling the keyboard without manufacturer/seller’s instruction will immediately void the warranty.
4. The return and warranty policy may vary in different platforms and are subject to the specific distributor at the
time of purchase.
Precautions Man-made damage is not limited to immersion, falling off, and pulling off the wires with excessive forces, etc.
Akko Warranty and Service Statement
16
