Aktobis WDH-TG60L User manual
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Drum Blower WDH-TG60L
Dear Customer,
You have chosen a high-quality product. To ensure that you get a lot of enjoyment from
this product, here are a few more tips:
In case of any problems:
We hope that the unit meets your expectations! If, despite the greatest possible care, there
should ever be cause for complaint, please contact us briefly, as we are very concerned
about your satisfaction and would like to clear up any misunderstanding.
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Description:
This drum blower is very robustly manufactured and designed for a long service life. It
produces a very high air flow rate with relatively low power consumption. The entire unit
and the rotor are made of metal. The blower has three speed levels, castors and two
practical handles. Furthermore, the unit is equipped with an overheating protection and
works with a long-lasting high-performance motor.
Important safety instructions:
- This drum blower must not be exposed to direct moisture (rain) !
- Do not operate the unit in environments where there is a risk of coarse dust, dirt or
small objects being sucked in. These could damage the unit or be blown out like
projectiles !
- Never walk with your head/face into the near area of the escaping wind stream, small
particles or objects can be blown out with it, which can lead to injuries !
- Ensure that the blower stands securely and level !
- Never use the blower on moving surfaces, objects or vehicles ! There is a risk that the
unit may tip over !
- Supervise the fan when children are near the unit !
- This appliance is not intended to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and/or knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Never enter or insert objects into the appliance !
- Never try to touch the moving rotor blades !
- Do not place any objects on the fan !
- Do not block the supply and/or exhaust air of the unit and please ensure sufficient
space/clearance around the unit !
- Ensure that there is sufficient air supply to the unit, otherwise it can lead to a reduction
in performance and, in the worst case, to overheating and/or fire !
- Only qualified personnel or electricians are allowed to open the unit !
- Only use the recommended voltage for operating the unit !
- Make sure that the power cable is unfolded (untied) before connecting it to the socket !
- Make sure that the plug is cleanly and properly connected to the socket before using
the appliance !
- Never reach near the plug or socket with wet hands !
- Do not repair defective or damaged cables on the unit yourself, you could get a severe
electric shock !
- Make sure that highly flammable substances (e.g. gases/oils etc.) are never in the
vicinity of the unit !
- If you are not going to use the unit for a long time, switch it off and disconnect the
mains plug !
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Please switch off the unit immediately and disconnect it from the
mains/power supply if anything seems to be wrong !!! In this case, please
contact a specialist and do not attempt to repair the unit yourself !!!
Examples: Fan does not run during operation or fuse has blown.
Instructions for use:
1. Operational environment
- The maximum operating temperature should not exceed +40°C !
- The unit should not be operated at altitudes higher than 1,000 metres above sea level
!
2. Commissioning
2.1. Position the blower so that the air stream flows in the desired direction after switching
on. Please note that the front (exhaust air) of the fan is marked with the trademark.
The on/off switch is located at the rear of the fan.
Adjustment of the air flow:
The fan head can be swivelled from top to bottom and thus the air flow can be tilted in
any desired direction. To change the airflow in a desired lateral direction, it is sufficient
to slightly change or adjust the standing position of the unit.
2.2. Now insert the mains plug properly into the socket.
2.3. The fan is switched on by a rotary switch located on the back of the unit. Point the
rotary switch in the direction of the arrow to the desired operating position.
O = OFF
1= ON in weak fan stage
2= ON in medium fan stage
3= ON in strong fan stage
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
3. Maintenance, Cleaning & Storage
Please always disconnect the mains plug first and allow the fan to run down completely
before carrying out any cleaning activities on your appliance !
3.1. maintenance:
A professional should treat the blower axle with lubricating oil approx. every 1,500
operating hours to ensure optimum operation and a long blower service life.
3.2 Cleaning:
- Use a soft and damp cloth to clean the outside of the unit.
- Only use mild cleaning agents to clean your blower.
- Please make sure that water does not get inside the motor or the electrical control
box at any time !
- Be careful not to accidentally adjust (bend) the angle of the rotor blades when
cleaning the unit.
3.3 Storage:
- We recommend that you cover the unit for storage or, ideally, pack it in its original
box.
- Store the unit in a dry and sufficiently ventilated place/space.
4. Other operating instructions
4.1. Do not disconnect the mains plug by pulling on the power cable !
4.2. Do not use insect spray, oil spray, paint spray, etc. near the blower. This may cause
damage to the unit or even fire !
4.3. Do not place the appliance on sloping or uneven ground !
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Technical data:
Model name: WDH-TG60L
Voltage: 220-240V / 50Hz
Max. Power consumption: 260 W (1.2 A)
Max. Air circulation: 5,900 m3/h
Protection class: IP24 (foreign body protection with Ø > 12.5 mm, as well
as Splash water protection)
Air duct diameter: Approx. 63 cm
Max. Speed: 1,345 rpm.
Max. Noise emission: 70 dB
Dimension (H/W/D): 765 x 765 x 300 mm
Weight: 18.8 kg
A > Total width =765 mm
B > Depth (total) =300 mm
C > Drum width =665 mm
H > Height (total) =765 mm
We reserve the right to make deviations in the technical data!
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Other:
Warranty statement:
Notwithstanding the statutory warranty claims, the manufacturer grants a warranty in
accordance with the laws of your country, but at least 1 year (in Germany 2 years for
private individuals). The warranty begins on the date of sale of the appliance to the end
user.
The guarantee only covers defects that are due to material or manufacturing faults.
Warranty repairs may only be carried out by an authorised customer service. To make a
warranty claim, please enclose the original sales receipt (with date of sale).
Excluded from the guarantee are:
- Normal wear
- Improper applications, such as overloading the appliance or non-approved
accessories.
- Damage due to external influences, use of force or foreign objects
- Damage caused by non-observance of the operating instructions, e.g. connection to
an incorrect mains voltage or non-observance of the assembly instructions.
- Completely or partially dismantled units
Conformity:
The drum blower has been tested and itself and/or parts thereof have been
manufactured under the following
(safety) standards:
Of course with CE (EMC + LVD) conformity.
EMC conformity tested according to: EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
CE (LVD) Conformity tested according to: EN 60335-1:2012+A11:2014+A13:2017
EN 60335-2-80:2003+A1:2004+A2:2009
EN 62233:2008
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Correct disposal of this product:
Within the EU, this symbol indicates that this product should not be
disposed of with household waste. Waste equipment contains valuable
recyclable materials that should be recycled and not harm the environment
or human health through uncontrolled waste disposal. Therefore, please
dispose of old appliances via suitable collection systems or send the
appliance for disposal to the place where you purchased it. They will then
recycle the appliance.
We hope you enjoy using this appliance:
Keep these instructions for use in a safe place !
