Akuvox A05 Series Service manual

Version: 1.0 | Date: Jan.2021
Akuvox A05 Series Access Control TerminalAkuvox A05 Series Access Control Terminal
Administrator Guide_V1.0Administrator Guide_V1.0
Page: 2 of 49

About T his ManualAbout T his Manual
Thank you for choosing Akuvox A05 series access control terminal. This manual is intended for the
administrators who need to properly configure the access control terminal. This manual applies to
105.30.1.17 version, and it provides all the configurations for the functions and features of A05 series
access control terminals. Please visit Akuvox forum or consult technical support for any new
information or the latest firmware.
Introduction of Icons and SymbolsIntroduction of Icons and Symbols
Related DocumentationRelated Documentation
You are advised to refer to the related documents for more technical information via the link below:
https://knowledge.akuvox.com/
1.Product Overview1.Product Overview
Warning:Warning:
Always abide by this information in order to prevent the persons from injury.Always abide by this information in order to prevent the persons from injury.
CautionCaution:
Always abide by this information in order to prevent the damages to the device.Always abide by this information in order to prevent the damages to the device.
Note:Note:
Informative information and advice from the efficient use of the device.Informative information and advice from the efficient use of the device.
Page: 3 of 49

Akuvox A05 series is a Linux-based access control door phone with a display screen. It incorporates
access control and video surveillance. Its finely tuned SmartPlus and AI-based communication
technology allow featured customization to better suit your operation habit. A05 series has multiple
ports, such as RS485 and Wiegand ports, can be used to easily integrate external digital systems,
such as elevator controller and fire alarm detector, helping to create a holistic control of building
entrance and its surroundings and giving you a great sense of security via a variety of access such as
card access, NFC, QR code and newly added door access in an accompaniment with body
temperature measurement. A05 series access control terminal applies to residential buildings, office
buildings, and their complex.
2.Change Log2.Change Log
The change log will be updated here along with the changes in new software version.
3.Model Specification3.Model Specification
Model
&
Feature
A05S
Display 5” IPS
Touch Screen X
Button X
Housing Material Plastic
Relay Out 1
Alarm In 1
RS485 √
PoE √
Resolution 1280x720
Brightness 500cd/m2
RAM 1GB
ROM 8GB
Card Reader 13.56MHz
Page: 4 of 49

Wi-Fi X
Bluetooth Optional
IP Rating IP65
Temperature Detection Optional
Face recognition √
LTE X
USB X
External SD Card X
Wall Mounting √
Flush Mounting X
Desk Mounting X
POE Stand by P
ower 5.5W
POE Full Load C
onsumption 9.8W
Power Adapter S
tandby Power 5.5W
Power Adapter F
ull Load Consu
mption
10W
Color Option Black
4.Introduction to Configuration Menu4.Introduction to Configuration Menu
Page: 5 of 49

StatusStatus: this section gives you basic information such as product information, Network
Information, and account information etc.
NetworkNetwork: this section mainly deals with DHCP&Static IP setting, and device deployment etc.
SurveillanceSurveillance: this section includes audio&video related settings such as Live stream, RTSP,
ONVIF, MJPEG.
Access ControlAccess Control: this section includes input type setting, relay setting, door access control in
terms private PIN code, Facial recognition, RF card, and BLE setting as well, log related
configurations such as door log and temperature log.
SettingSetting: this second deals with time &language setting, security notification settings and door
prompt text setting.
UpgradeUpgrade: this section covers Firmware upgrade, device reset&reboot, configuration file auto-
provisioning, PCAP.
SecuritySecurity: this section is for Password modification, tamper alarm, and web interface automatic
logout.
DeviceDevice: this section concerns LED light setting, ODSP Setting, screen saver setting,
sound&volume setting and third-party integration in terms of integration via Wiegand, RS485.
Tool selectionTool selection
Akuvox has many configuration tools for you to set up devices more conveniently. Here we list some
common tools, please contact your administrator to get the tool if you need them.
1. SDMCSDMC: SDMC is suitable for the management of Akuvox devices large communities, including
access control, resident information, remote device control, etc.
2. Akuvox Upgrade toolAkuvox Upgrade tool: Upgrade Akuvox devices in batch on a LAN (Local Area NetworkLocal Area Network).
3. Akuvox PC ManagerAkuvox PC Manager: Distribute all configuration items in batch on a LAN.
4. IP scannerIP scanner: it is used to search Akuvox device IP addresses on a LAN.
5. FaceProFacePro: Manage face data in batch for the access control terminal on a LAN.
5.Access the Device5.Access the Device
Before configuring Akuvox A05, please make sure the device is installed correctly and connect a
normal network. Using Akuvox IP scanner tool to search the device IP address in the same LAN. Then
use the IP address to login in the web browser by user name and password adminadmin and adminadmin.
Page: 6 of 49

6.Time and Language Setting6.Time and Language Setting
6.1. Language Setting6.1. Language Setting
When you first set up the device, you might need to set the language to your need. You can select the
language display the device web Setting > Time/Lang > LCD LanguageSetting > Time/Lang > LCD Language interface.
6.2. Time Setting6.2. Time Setting
Time setting on the web interface allows you to set up time and date manually while allowing you to
use NTP server address that you obtained to automatically synchronize your time and date. And when
your time zone is selected, the device will automatically notify the NTP server of its time zone so that
the NTP server can synchronize the time zone setting in your device. To configure the configuration
on the device web Setting > Time/Lang > Time Setting > Time/Lang > Time interface
Note:Note:
Google Chrome browser is strongly recommended.
The Initial user's name and password are “adminadmin” and please be case-sensitive to the
user names and passwords entered.
Page: 7 of 49

Parameter Set-up:Parameter Set-up:
Time Zone:Time Zone: select the specific time zone depending on where the device is used and then
press ConfirmConfirm tab for the confirmation. The default time zone is GMT+0.00.
Primary ServerPrimary Server: enter the primary NTP server you obtained in the NT P ServerNT P Server field.
Secondary ServerSecondary Server: enter the secondary NTP server you obtained in the NT P ServerNT P Server field to
be used as a backup.
Update IntervalUpdate Interval: set the automatic time update via NTP server.
6.3.LED Setting6.3.LED Setting
6.3.1. Configure Card Reader LED Setting6.3.1. Configure Card Reader LED Setting
You can enable or disable the LED lighting on the card reader area as needed on the web interface.
Meanwhile, If you do not want to have the LED light on the card reader area to stay on, you can also
set the timing for the exact time span during which the LED light can be disabled in order to reduce the
electrical power consumption. To configure the configuration on web Setting > Time/Lang >Setting > Time/Lang >
Time Time Interface.
Note:Note:
When the check box is unticked, the parameters related to NTP server will become not
editable.
Page: 8 of 49

Parameter Set-up:Parameter Set-up:
EnabledEnabled: Tick the check box if want to enable the card reader LED lighting and vice versa.
Start Time - End Time (H)Start Time - End Time (H): enter the time span for the LED lighting to be valid, e.g., if the
time span is from 18-2218-22 it means LED light will stay on during the time span from 6:00 pm6:00 pm to
10:0010:00 pm in one day (24 hours).
6.3.2. Configure LED White Light Setting6.3.2. Configure LED White Light Setting
LED White light is used to reinforce the lighting for facial recognition as well as for the QR code
access as needed in the dark environment. To configure the configuration on web Device > Light >Device > Light >
White LightWhite Light interface
Parameter Set-up:Parameter Set-up:
ModeMode: select “AutoAuto” or “OFFOFF”. If you select “AutoAuto” then the white light will turn on for 5
minutes for facial recognition and QR code scan. And if you select “OffOff” then the white light
will be turned off.
Max White Light ValueMax White Light Value: set the white light value from 1-51-5, and the default white light value is
“3”. The greater value it is, the brighter the light will be.
6.4. Screen Display configuration6.4. Screen Display configuration
A05 series access control terminals allow you to enjoy a variety of screen displays to enrich your
visual and operational experience through the customized setting to your preference.
6.4.1. Configure Screensaver6.4.1. Configure Screensaver
Note:Note:
IR LED light should be triggered first before the white light can be valid in the facial
recognition, however IR LED light does not need to be triggered for the white light
function in the QR code scan.
Page: 9 of 49

Await screen is mainly a function for the screen protection. You can make the device to go into idle
status for a predefined time span when there is no operation on the device, or no one is detected
approaching.
To configure the configuration on web Device > LCD > Standby Interface Display Device > LCD > Standby Interface Display interface.
Parameter Set-upParameter Set-up
ScreenSaver Mode: ScreenSaver Mode: tick the check box to enable the screen saver function.
Sleep:Sleep: set the screen saver start time range from “55” seconds to “3030” minutes, for example, if
you set it as “15 seconds” then the device will go into screen saver mode in 15 second when
there is no operation on the device or no one is detected approaching
6.5. Upload Screensaver6.5. Upload Screensaver
You can upload screensaver pictures separately or in batch to the device and to the device web
interface for publicity purpose or for a greater visual experience. To configure the configuration on web
Device > LCD > Upload ScreenSaverDevice > LCD > Upload ScreenSaver interface. You can upload a maximum of 5 pictures, and
each picture will be displayed in rotation according to the ID order with specific time duration (TimeTime
IntervalInterval) you set.
Note:Note:
The pictures uploaded should be in JPG formatJPG format with 2M pixel maximum.
Page: 10 of 49

6.6. Configure Access Screen Display Mode6.6. Configure Access Screen Display Mode
You can select two types of access screen display mode on the home screen, namely, Default mode
for facial recognition and QR code. To configure the configuration on web Device > LCD > T hemeDevice > LCD > T heme
interface.
Parameter Set-up:Parameter Set-up:
Mode: Mode: There are two mode DefaultDefault and QR CodeQR Code. If you choose QR code, the main screen
shows “Please scan your QR codePlease scan your QR code” as default to remind you unlock by QR code. If you
choose Default, the main screen shows “ Please look at the screenPlease look at the screen” as default to remind
you unlock by face recognition.
QR Code Recognition Interval (Sec): QR Code Recognition Interval (Sec): this interval is only available when you choose QRQR
CodeCode mode. It is recognition of the interval between two QR codes.
6.7. Volume and Tone Configuration6.7. Volume and Tone Configuration
Volume and tone configuration in A05 access control terminal refers to Tamper alarm volume, Mic
volume and open-door tone configuration. Moreover, you can upload the tone you like to enrich your
personalized user experience.
6.7.1. Volume Configuration6.7.1. Volume Configuration
You can configure the Mic volume according to your need for open-door notification. Moreover, you
can also set up the tamper alarm volume when unwanted removal of the access control terminal
occurs. To configure the configuration on web Device > Voice > Volume ControlDevice > Voice > Volume Control interface.
Parameter Set-up:Parameter Set-up:
Page: 11 of 49

Ring Volume: Ring Volume: set the ring volume from 0-15 according to your need. The default volume is 88.
Tamper Alarm Volume: Tamper Alarm Volume: set the tamper alarm volume from 0-15 according to your need. The
default volume is 88.
6.7.2. Upload Open Door Tone6.7.2. Upload Open Door Tone
You can upload the Open-Door Tone on the device web interface.To configure the configuration on
web DeviceDevice >> Voice > Open Door Tone SettingVoice > Open Door Tone Setting interface.
6.8. Configure Door Access Prompt Text6.8. Configure Door Access Prompt Text
You can enable or disable the door access prompt to be shown on the access control terminal screen
for door open failure and success. To configure the configuration on web Setting > Door > OpenSetting > Door > Open
Door Succeeded Text Prompt Door Succeeded Text Prompt interface.
Parameter Set-up:Parameter Set-up:
Open Door Success: Open Door Success: Tick the check box if you want to see the text prompt after the door
open success and vice versa.
Open Door Failed: Open Door Failed: Tick the check box if you want to see the prompt words after the door
open failure and vice versa.
7.Network Setting7.Network Setting
7.1. Configure Device Network7.1. Configure Device Network
Page: 12 of 49

You can configure the default DHCP mode (Dynamic Host Configuration ProtocolDynamic Host Configuration Protocol) and static IP
connection. Moreover, you can set up IP address, Subnet Mask, Default Gateway, LAN DNS1 & LAN
DNS2. To configure the configuration on web Network > Ethernet > LAN PortNetwork > Ethernet > LAN Port interface.
Parameter Set-up:Parameter Set-up:
DHCPDHCP: select the DHCPDHCP mode by checking off the DHCP box. DHCP mode is the default
network connection. If the DHCP mode is selected, then the access control terminal will be
assigned by the DHCP server with IP address, subnet mask, default gateway, and DNS server
address automatically.
Static IPStatic IP: select the static IP mode by checking off the DHCP check box. When static IP mode
is selected, then the IP address, subnet mask, default gateway, and DNS servers address
must be manually configured according to your actual network environment.
IP AddressIP Address : set up the IP Address if the static IP mode is selected.
Subnet MaskSubnet Mask: set up the subnet mask according to your actual network environment.
Default GatewayDefault Gateway: set up the correct gateway default gateway according to the IP address of
the default gateway.
DNS1/DNS2DNS1/DNS2: set up DNS1/ DNS2 (Domain Name ServeDomain Name Server) according to your actual network
environment. DNS1 is the primary DNS server address while the DNS2 is the secondary
server address, and the access control terminal connects to DNS2 server when the primary
DNS server is unavailable.
7.2. Configure Device Deployment in Network7.2. Configure Device Deployment in Network
Access control terminals should be deployed before they can be properly configured in the network
environment in terms of their location, operation mode, address and extension numbers as opposed to
other devices for the device control and the convenience of the management. To configure the
configuration on web Network > Advanced > Connect SettingNetwork > Advanced > Connect Setting interface.
Page: 13 of 49

Parameter Set-up:Parameter Set-up:
Server Mode: Server Mode: It is automatically set up according to the actual device connection with a
specific server in the network such as SDMCSDMC or Akuvox SmartPlus Akuvox SmartPlus and None. None None. None is the
default factory setting indicating the device is not in any server type, therefore you are allowed
to choose Cloud, SMDC in discovery mode.
Discovery Mode:Discovery Mode: click “EnabledEnabled” to turn on the discovery mode of the device so that it can
be discovered by other devices in the network and click “DisabledDisabled” if you want to conceal the
device so as not to be discovered by other devices.
Device Address: Device Address: specify the device address by entering device location information from the
left to the right: Community, Unit, Stair, Floor, Room Community, Unit, Stair, Floor, Room in sequence.
Device extensionDevice extension: enter the device extension number for the device you installed
Device LocationDevice Location: enter the location in which the device is installed and used.
7.3. Relay Setting7.3. Relay Setting
You can configure the relay switch(es) and DTMF for the door access on the web interface.
7.3.1. Relay switch setting7.3.1. Relay switch setting
To configure the configuration on web Access Control > Relay > RelayAccess Control > Relay > Relay interface.
Page: 14 of 49

Parameter Set-up:Parameter Set-up:
Trigger Delay (Sec): Trigger Delay (Sec): set the relay trigger delay timing (Ranging from 1-10 Sec.) For
example, if you set the delay time as “55” sec. then the relay will not be triggered until 5
seconds after you press “unlockunlock” tab.
Hold Delay (Sec): Hold Delay (Sec): set the relay hold delay timing (Ranging from 1-10 Sec.) For example, if
you set the hold delay time as “55” Sec. then the relay will be delayed for 5 after the door is
unlocked.
Relay Status:Relay Status: relay status is low by default which means normally closed (NC) If the relay
status is high, then it is in Normally Open status (NO).
Relay Name: Relay Name: name the relay switch according to your need. For example, you can name the
relay switch according to where the relay switch is located for the convenience.
7.4. Web Relay Setting7.4. Web Relay Setting
In additional to the relay that is connected to the access control terminal, you can also control the door
access using the network-based web relay on the device and on the device web interface.
7.4.1. Configure Web Relay on the Web Interface7.4.1. Configure Web Relay on the Web Interface
Web relay needs to set up on the web interface where you are required to fill in such information as
relay IP address, password, web relay action etc. Before you can achieve the door access via web
relay. To configure the configuration on web Access Control > Web RelayAccess Control > Web Relay interface.
Note:Note:
Only the external devices connected to the relay switch needs to be powered by power
adapters as relay switch does not supply power.
Page: 15 of 49

Parameter Set-up:Parameter Set-up:
Type: Type: select among three options Disabled,Disabled,WebRelayWebRelay and BothBoth. Select WebRelayWebRelay to
enable the web relay. Select DisableDisable to disable the web relay. Select Both Both to enable both
local relay and web relay.
IP Address: IP Address: enter the web relay IP address provided by the web relay manufacturer.
User NameUser Name: enter the User name provided by the web relay manufacturer.
Password: Password: enter the password provided by the web relay manufacturer. The password is
authenticated via HTTP and you can define the passwords using “http gethttp get” in Action.
Web Relay Action:Web Relay Action: enter the specific web relay action command provided by the web
manufacturer for different actions by the web relay.
http://admin:admin@192.168.1.2/state.xml?relayState=2http://admin:admin@192.168.1.2/state.xml?relayState=2.
After the web relay is set up, you can configure the specific web relay to be triggered based on the
relay location for the door access. To configure the configuration on web Access Control > UserAccess Control > User
interface.
8.Door Access Schedule Management8.Door Access Schedule Management
You are required to configure and make schedule for the user-based door access via RF card, Private
PIN and Facial recognition.
Page: 16 of 49

8.1. Configure Door Access Schedule8.1. Configure Door Access Schedule
You can create door access schedules so that they can be later conveniently applied to the door
access control intended for individual user or a group of users created. Moreover, you can edit your
door access schedule if needed.
8.1.1. Create Door Access Schedule8.1.1. Create Door Access Schedule
You can create the door access schedule on the daily or monthly basis, and you can also create
schedule that allows you to plan for a longer period of time in addition to running the door access
schedule on the daily or monthly basis. To configure the configuration on web Access Control >Access Control >
Schedule SettingSchedule Setting interface.
To create a weekly schedule, select Schedule TypeSchedule Type as WeeklyWeekly.
To create a longer period schedule, select Schedule TypeSchedule Type as NormalNormal.
Page: 17 of 49

8.1.2. Import and Export Door Access Schedule8.1.2. Import and Export Door Access Schedule
In addition to creating door access schedule separately, you can also conveniently import or export the
schedules in order to maximize your door access schedule management efficiency. To configure the
configuration on web Access Control > Schedule Setting> Import/Export Schedule(.xml)Access Control > Schedule Setting> Import/Export Schedule(.xml)
interface.
8.1.3. Edit the Door Access Schedule8.1.3. Edit the Door Access Schedule
If you want to edit or delete your door access schedule you created, you can edit or delete the
configured schedule separately or in batch on the web Access Control > Schedule Setting>Access Control > Schedule Setting>
Schedule Management Schedule Management interface.
9.Door Unlock Configuration9.Door Unlock Configuration
Note:Note:
It only supports .xml format file for importing and exporting the schedule.
Page: 18 of 49

A05 series access control terminal offer you three types of door access via QR code, RF card and
Facial recognition. You can configure them on web interface. Moreover, you can import or exporting
the configured files to maximize your RF card configuration efficiency.
9.1. Configure RF Card for Door Unlock9.1. Configure RF Card for Door Unlock
9.1.1. Configure RF Card on the Web Interface9.1.1. Configure RF Card on the Web Interface
To configure the configuration on web Access Control > UserAccess Control > User interface.
9.1.1.1. Configure RF Card Code Format9.1.1.1. Configure RF Card Code Format
If you want to integrate with the third-party intercom system in terms of RF card door access, you can
change the RF card code format to be identical with that applied in the third-party system. To
configure the configuration on web Access Control > CardSettingAccess Control > CardSetting interface.
Note:Note:
Please refer to PIN code access schedule selection for the RF card user(s)-specific door
access.
Note:Note:
RF card with 13.56 MHz and 125 KHz can be applicable to the access control terminal for
the door access.
Page: 19 of 49

Parameter Set-up:Parameter Set-up:
IC-Card Display ModeIC-Card Display Mode: select the card format for the ID CardID Card for the door access among
five format options: 8H10D; 6H3D5D(W26); 6H8D; 8HN; 8HR. 8H10D; 6H3D5D(W26); 6H8D; 8HN; 8HR. The card code format is
8HN by default in the access control terminal.
9.1.2. Configure Facial Recognition on Web Interface9.1.2. Configure Facial Recognition on Web Interface
To configure the configuration on web Access Control > UserAccess Control > User interface.
Parameter Set-upParameter Set-up:
Status: It will show “Registered”Registered” when the picture uploaded conforms to the format and
standard otherwise it would show “UnregisteredUnregistered” as the default. However, the status will be
changed back to “UnregisteredUnregistered” if the picture uploaded is cleared when you press the ResetReset
tab.
Photo(jpg/png): Photo(jpg/png): select the picture with jpg or png format to be uploaded to the device and
press if you want to clear the picture uploaded.
9.2. Configure Door Access Using Configured Files.9.2. Configure Door Access Using Configured Files.
Note:Note:
Pictures to be uploaded should be in jpg or png format.
Page: 20 of 49
Other manuals for A05 Series
2
Table of contents
Other Akuvox Touch Terminal manuals
Popular Touch Terminal manuals by other brands

Nurit
Nurit 8320 manual

Elo TouchSystems
Elo TouchSystems 15A2 for wireless card Quick installation guide for memory 512mb/1gb ram

Displays2go
Displays2go DT156TLBX user manual

Control Data
Control Data CC535-A Programming manual

Star
Star AsuraCPRNT Configuration manual

Epson
Epson IR-320 Technical reference manual

POSIFLEX
POSIFLEX JIVA HS-3310A user manual

Humanware
Humanware Braille Trail Reader LE user guide

Beckhoff
Beckhoff KL2751 Documentation

Beckhoff
Beckhoff CU8810-0010 Installation and operating instructions

Partner
Partner PT-6910 Series user manual

Adtron
Adtron Total Access 1000 Installation and Maintenance
