Akyga AK-EC-09 User manual

AK-EC-09 - user manual
/ak-ec-09
www.akyga.com
Short description of the product
The product is compatible with the applicable national and European requirements.
What is in the box?
- Storage Bag
- AK-EC-09 electric car cable
Symbols explanation:
There is a risk of losing health or life (e.g. by electic shock).
There is a particular danger connected with service.
Important tips and information.
Product accordance with the EU directive 2002/96/EC. The symbol of the crossed out basket
placed on the product means that the marked product can not be disposed of with other
household waste. After use, the product must be return to collection point for used electical and
electronic equipment or to the seller. Appropriate segregation of rubbish for subsequent
processing, recovery or descrution contributes to avoiding negative effects on the environment
and health, and also allows the recovery of raw materials from which the product is made.
p. 1
The CE standard description on the product is the manufacturer's declaration that the marked
product meets the requirements of the directive so-called The "New Approach" of the European
Union (EU). For security and certification (CE) reasons, the device can not be rebuild or change
in any way. In the reason of using the cable for other purposes than those described, the product
may be demaged. The incorrect use may also cause hazard such as short-circuits, burns, electric
shocks, etc. Read the users manual carefully and keep it for later use. The product could be share
to third partie only with the user manual included.
The Akyga AK-EC-09 cable is used to charge electric vehicles at charging stations equipped with a
Type 2 socket. The cable is compatible with all models of vehicles powered between 110-250 V / 32 A
and Type 2 plug. The maximum charging power of the vehicle is 7.2 kW.
EV cable
The RoHS mark on the product is the manufacturer's declaration that the marked product meets
the requirements of the EU Restriction of Hazardous Substances (2002/95/EC) directive, which
aims to reduce the amount of hazardous substances penetrating into the environment from
electrical and electronic waste.
Ecological Solutions
GREEN
IP rating
44
IP
Fire Resistance
UL94V-0
Strength
2T
Mechanical
strength
10 000
Security
lock hole

AK-EC-09 - user manual
p. 2
Safety Precautions
The manufacturer of the product is not responsible for damage or insults caused in effect
of disobey the safety instructions and informations contained in these user manual.
źIf it rains during charging - do not let water get into the power socket and car charging port. If the
plugs got wet - disconnect the mains fuse before pulling them out of the sockets.
źIt is forbidden to apply the mechanical load to the product - strong shocks, impacts, dropping or
crushing may cause its damage.
źCable should be disconnected from vehicle’s socket and power source if the product is not in
use for a long time.
źIn case of any doubts regarding operation, safety or connection of the product, please contact
the manufacturer or a qualified specialist for this purpose.
źThe product operation in adverse conditions is not allowed. Adverse conditions are primarily:
exposure to direct sunlight, high or very low ambient temperatures, strong vibrations, high
humidity, surrounds of gases, dusts or flammable and aggressive liquids.
źKeep the product and the packaging out of range of children and animals. The package
includes a foil that child could choke while playing.
źIf the product has been damaged, does not work properly or has been stored for a long period
of time in bad or unfavorable conditions, safe operation of the device is not possible. It is
essential to stop using the product and to protect it against re-use for security purposes.
źIt is forbidden to insert wet plugs into electrical outlet and the vehicle charging port.
źShort-circuiting the current connection is prohibited.
źIt is forbidden to connect the cable to damaged sockets and plugs.
źMake sure that the power cord is not crushed, bent, twisted, rubbed against sharp edges or
mechanically loaded in any other way. Avoid thermal load of the cable - in particular keep away
from heat sources (such as stoves, radiators, fireplaces).
źStore the EV cable freely so that the cord does not break.
źProduct and power cord should not be touched with moist or wet hands under no
circumstances.
źThe product is intended for private use only. Before using the public charging station, read its
regulations.
źMake sure that the cable is compatible with your vehicle model.
źPower cord should be laid in such a way as to eliminate the risk of stumbling or hooking over.
źIt is forbidden to put fingers or objects in the plug.
źIts forbidden to modify the product plugs and cord. In the case of modifications, the product
may be damaged, causing threats to life, health and property.
źTake into account the user’s manuals for other devices conected to the product.
źWhen disconnecting the cable from the power source and from the device, do not pull on the
cord, but only on the part of the plug provided for this purpose.
źAll maintenance, adjustment and repair work on the product may only be carried out by a
qualified person in a specialist facility.
EV cable
The II protection class device. It provides protection against electric shock against direct and
indirect contact, and thanks to the additional isolation it is not necessary to connect the device
case with the protective earth conductor.

AK-EC-09 - user manual
p. 3
Problem
Cause
Solution
The cable does not work
No voltage
źCheck the correct connection of
the cable to the power source
Problem with the plug
źCheck if EV cable is properly
connected to the vehicle and
power source
There is a suspicion of a
product defect
źStop using and contact the
seller
Vehicle does not charge
Vehicle does not prepare
to charging properly
źMake sure that the another
charger is not connected to
car’s second charging port
źRead the vehicle manual
Problem with the plug
źCheck if the plug is connected
correctly
There is a suspicion of a
product defect
źStop using and contact the
seller
Removing the most common problems
EV cable
Cleaning the EV cable
źUse soft and antistatic cloth for cleaning the cable.
źDo not use abrasive or chemical cleaners.
Disconect the EV cable from the electrical socket and connected devices before cleaning.
How to use
2. Check that the product is not damaged.
3. Make sure the product has the right type of plug for your vehicle.
6. Connect the cable to the power source with a Type 2 plug.
4. Check that the vehicle's and power surce’s socket are not damaged.
8. After charging, disconnect the product from the power source and car's charging port by
pressing the button that releases the clip and put the protective cap on.
1. Prepare the vehicle for charging in accordance with the user manual.
5. Pull the protective cap off the plug.
7. Connect the Type 2 plug to the charging port of the vehicle.

AK-EC-09 - user manual
p. 4
EV cable
The Type 2 connector plugs into
the vehicle's charging socket. It
is characterised by seven
protruding sleeves.
Female Type 2 connector
The Type 2 socket plug should
be connected to a power source
with a connector of the same
type. The Type 2 socket outlet
has seven holes.
Male Type 2 connector
Do not disconnect the plug while charging

AK-EC-09 - user manual
p. 5
Technical specfication
Product manufacturer: Ropla Computers sp. z o.o.
ul. Wrocławska 1c
52-200 Suchy Dwór
EV cable
Product code:
Supply voltage:
Maximum amperage:
Maximum power:
Temperature:
Material:
Isolation material:
IP Rating:
Flame resistance:
Cable length:
Power inlet:
Output connector:
MTBF:
Compilance with standards:
REACH compatibility:
EAN code :
AK-EC-09
110 - 250 V, 50/60 Hz
32 A
7.2 kW
-30 - 50 ºC
Thermoplastic
TPE
IP44
UL94V-0
6 m
IEC 62196-2 Type 2
IEC 62196-2 Type 2
10000 times
CE, FCC, RoHS
Yes
5901720136817
