Akyga AK-PS-04 User manual

Emer
Model: AK-PS-04
600W Portable Power Station
gency Power Source
User Manual

Thank you for purchasing this 600W portable power station.
This portable power station has a powerful battery capacity of 560Wh,
supporting AC wall outlets, solar panels and vehicle charging ways, and is
designed to keep your electronic devices powered while on the go.
It comes with AC outlets, 12V DC output ports, 12V car port, Type-C port and
fast charging USB ports 3.0 for your convenience. Perfectly for outdoor travel,
it is compatible with most electronic devices such as drones, laptops, lights,
smart phones, tablets and cameras.
You can charge your electrical or digital devices with this unit in case of a
power failure or when you are out or on a road trip.
It also works as an emergency power kit. Especially, it’s suitable for locations
that are prone to severe weather patterns and natural disaster related power
failures including typhoons, floods, hurricanes, earthquakes, forest fires,
snowstorms and low-temperature disaster-prone areas.
The power station is also suitable for camping and works well in keeping
outdoor electrical appliances charged for uses such as night time power
supply,medical power supply and general household electricity storage.
Before using our power station, please read the following instructions carefully:
1. This power station has a built in lithium battery which is highly sensitive to
high temperature - Keep it away from heat sources like direct fire or any heat
sources.
2. Keep away from moisture or water.
3. Do not disassemble microwave, puncture, incinerate or insert foreign objects
into the power station.
4. Do not crush, bend, shred, drop or place heavy objects on top of the device.
5. Do not use the product if damaged or punctured.
6. Always be prepared - Charge the unit every three months also if it is not used.
1 * AC Power Adapter
1 * AC Power Cord
1 * DC Cable
1 * User manual
Warm Tips:
Preface
Package Contents

Battery Capacity
AC Input Charging
Car Input Charging
Solar Input Charging
USB-C Charging
Output Ports
LED Lights
Safety Protections
Operation Temperature
Battery Charge Cycles
Pass-Through Charging
Weight
0~40℃(32~104℉)
1000times DOD≥80% + capacity
Support
5 kg
2W MAX,3 Levels(L/M/H adjustable) with SOS function
Short-Circuit
Over-Current
Over-Voltage
Low-Voltage
Over-Load
Over-Temperature
2* AC Output: 230V, 50Hz, 600W, Peak 1200W
*Note: when the battery capacity ≤10%, AC max output
power is 150W(to protection of battery cycle life)
USB Output 1: DC 5V3A or DC9V2A or DC12V1.5A
USB Output 2: DC 5V3A or DC9V2A or DC12V1.5A
USB Type-C : DC 5V5A or DC9V5A or DC12V5A or
DC15V5A or DC20V5A(PD100W)
DC Output 1: DC13.8V, 3A
DC Output 2: DC13.8V, 3A
DC Output 3: DC13.8V, 10A Max Output Regulated
Lithium-ion 461Wh(20.8Ah/22.2V)
External 120W adapter
DC12V~24V/120W MAX
DC12V~24V/120W MAX
PD 100W MAX
Technical Specification

1.
2.
3.
4.
Press the power button or any other port button to turn on the unit. When
not using certain ports, it is best to turn them off to conserve power.
Read the LCD screen to know which port is turned on.
Plug in your gear.
Your unit supports full pass-through charging so you can charge your
power station and run your gear at the same time.
Using Your 600W Power Station
Product Diagram
DC Input
12-24V
DC button
AC output
600W Max
DC output
12V/3A*2
LCD display
LED Button
Car lighter
DC12V/10A
USB button
AC button
Type-C PD 100W*1
&USB QC3.0*2
Handle
LEDDISP button
FAN

LCD Display
1. Remaining usage time is dependent on output wattage and what
item(s) are being charged.
2. Remaining wattage and time will priority to display output power
and usage time while charging and discharging simultaneously.
Remaining Battery
Percentage
Cooling Fans
Output Power
Input Power
USB Output Indicator
Type-C Output
Indicator
DC Output Indicator
Temperature warning
Remaining Usage Time or
Remaining Charging Time(Minute)
Remaining Usage Time or
Remaining Charging Time(Hour)
Please Note
1 2
4
3
6
8
10
5
7
9
11
AC Output Indicator
OUTPUT Watts
INPUT
Watts
OUTPUT
INPUT
Watts
1 4 5 7 9
682 3
10
11

To avoid forgetting to turn off the output during use, which leads to
unused battery consumption, this product will turn to Auto-Sleep mode
when no device is connected or the connected device is less than or
equal to a certain value, the unit will automatically shut down after
1 hour.
Refer to the table below for more details:
*Press any of the port buttons to restart the power station.
*The unit will entering to Auto-Sleep mode by detected no output after 1hour,
user can switching the time with the following setting. Set up time to 1 hour or
12 hours by long pressing “USB”button for 3 seconds, Please check the time on
the LCD screen within 3 seconds after hear the buzzer sounds which shows the
set standby time.
The Auto-Sleep time is 1Hour: If there is no power output
within 1 hour, the automatic sleep mode is activated, and the power station
will be automatically turned off.
The Auto-Sleep time is 12Hours: If there is no power output within 12 hour,
the automatic sleep mode is activated, and the power station will be
automatically turned off.
Output
AC Output
USB Output
Car Output
≤2W
≤2W
≤2W
The device will automatically
shut down after 1 hour
The device will automatically
shut down after 1 hour
The device will automatically
shut down after 1 hour
Output Power Defaults
Auto-Sleep Mode:

Ways to Recharge
1.AC Wall Charging
2.AC Wall Charging + USB-C(PD100W) Charging
1.Only support the original charger to recharge the power station,
DO NOT USE generic chargers, they could overheat or start to burn.
2. The surface of AC adapter heats up when charging.
During hot summer seasons the temperature of AC adapter surface will
reach up to 80°C. Therefore the AC adapter working temperature range is
strictly comply with safety certification. Please do not cover the surface while
charging.
*USB-C(PD100W) charging Instructions:
1).Please turn on ”USB”Button to when using USB-C charging.
2).When unit in deep discharge 0%,you need to charging power station by
AC adapter to activate power station firstly and insert USB-C charger to start
charging.
3).USB-C charger(PD charger)need to buy it separately,do not included in this
package.
5-6 Hours
fully charged
2.5-3.5 Hours fully charged
NOTE:
AC Adapter
AC Adapter

3.DC Vehicle Charging
4.Solar Panel Charging
We recommend a 100W-120W solar panel with the voltage of DC 13V-24V.
Never use higher than DC 24V to recharge this power station.
12V Car Charging
6-7 Hours
fully charged
24V Car Charging
5-6 Hours
fully charged
5-6 hours
fully charged (in full sun)
1*120W Solar Panel
1. Do not charge from car charger and solar panel at the same time,
otherwise it will damage the car fuse.
2. Please don't put the power station in direct sunlight while charging in
the high temperature environment.
Safety Precautions When Charging

Emergency:
Used as an emergency power supply, the unit is especially suitable for
locations that are prone to severe weather patterns and natural disaster
related power failures including typhoons, floods, hurricanes, earthquakes,
forest fires, snowstorms and low-temperature disaster prone areas.
Outdoor Activities:
Road trips, camping, outdoor celebrations, fishing, climbing, outdoor
photography enthusiasts, RC helicopter drone charging, farming and bird
watching.
Home Backup:
Home and office electrical device charging, energy-saving lamps, television,
mini refrigerators, Christmas decoration lights, printers, laptops, fans and
smart mobile phones.
Usage
NOTES:
1.Run time=461Wh*90%(conversion rate)/Your device's power(Watts).
2.Support all electronic devices less than 600 Watts.
3.It is recommended to use a DC port instead of an AC outlet to power your CPAP machine.
4.*The usage time for refrigeration machines with compressors mainly depends on temperature
setting and start frequency of compressors,it’s usually lasting longer time than certain reference
time.
5.The above charging times are calculated as a reference guide only. The actual usage time will
depend on the power of the connected devices.
iPhone
90+ Times
20W Lamp
25 Hrs
DRONE
16+ Recharge
Laptop 13”
12 Hrs
50W Fan
10 Hrs
*Mini Cooler
24 Hrs
CPAP
11.5 Hrs
32” LCD TV
6.5 Hrs
Usage time of devices

1. How do I know whether my appliance can work well with the power station?
Please check the rated label of your device first. If the device's operating
power is within 600W, you can use the device normally.
2. How long can it run my device?
Running time = 461Wh battery capacity*90% conversion rate / Device Rated
Power Eg. If your run a 50W cooling fan, the running time
will be: 461Wh × 90% /50W ≈ 8,3hrs
Please Note:
1) The formula is NOT suitable for inductive loads with compressors, like
refrigerator, air conditioner, etc.
2) The above data is for reference ONLY.
3. Why is there any sound during use or charging?
This product with intelligent temperature control system, built-in fans help our
product to get better cooling and securing usage, slight noise is normal during
using or charging.
4. Can i charge the power station while a device is plugged in?
Yes, this unit support Pass-Through Charging, you can simultaneously
charge other devices while recharging the power station.
5. How to keep this product when it is not used for a long time?
If the battery is to be unused for a long time (more than 3 months),
please recharge it every 3 months to keep the battery power above
50% if you don't use it (it's recommended to check and charge every
3 months). Store it in a dry and cool place with temperature range between
-20° and 60° Celsius, and humidity 20%~85%RH. Avoid contact with corrosive
substances fire and heat sources.
6. Can it be used to jump start a car?
No, it cannot be used to jump start a vehicle.
FAQS and Solutions

7. Why does the power station has the Auto-Sleep mode?
To avoid forgetting to turn off the output during use, which leads to unused
battery consumption, this product will turn to Auto-Sleep mode when
no device is connected or the connected device is less than or equal to a
certain value, the unit will automatically shut off after 1 hours.
9. Are the batteries used replaceable or upgradeable?
NO.Batteries are built in.NOTE-Opening of the unit will void your warranty.
10. Are the built-in batteries replacement or upgradeable?
No. If the battery pack is faulty or even dead, please contact our Customer
Service.
8. Is the power station waterproof?
No, please do NOT store it in a humid environment for a long time.
Please store it in a dry and cool place.
Unit can not charging from
AC wall outlets AC charging fault
1.Please ensure to use
original AC adapter.
2.Please check if the AC
wall plug is correct
connection.
If not solved,Please
contact our after-sales
service.
1.Please ensure solar charging connection
is correct under user manual.
2.Please ensure connected solar panel
specification is meet specified standard.
3.Please ensure solar panel charging
under sunlight environment.
4.If not solved,Please contact our
after-sales service.
Resolve the problem by pulling out
plug or remove electrical devices,
the product can recover itself
after re-start.
If not solved,Please contact our
after-sales service.
DC solar charging fault
Unit can not charging from
solar panel
LCD Screen icon flash
"AC"
"DC"
"USB
Over-current protection
Short circuit protection
Over-voltage protection
Low-voltage protection
Over-Load protection
High-temperature warning Power station can recover itself
after battery cooled.
High-temperature icon
continuous appears
Failure Description Types Solutions
Common Trouble Shooting

Warranty & Customer Service Support
Thanks for purchasing our 600W portable emergency power station.If you have any questions
about it, please feel free to contact us.Your valuable opinions and suggestions are highly
appreciated.Welcome to leave your real and objective reviews to help other buyers for reference.
The AK-PS-01 is covered a warranty of 24 months from the date of its original purchasing.
a) Do not overcharge the internal battery. See instruction manual.
b) Do not smoke, strike a match or cause a spark in the vicinity of the
POWERSTATION.
c) Only charge the internal battery in a well ventilated area.
d) Risk of Electric Shock. Connect only to properly grounded outlets.
e) Risk of Injury to Persons. Do not use this product if the power co
battery cables are damaged in any way.
f) Keep away from moisture or water. Do not use outdoors on rainy days.
CAUTION
