Alba CBB191CD User manual

CD boombox
With radio
Instruction manual
CBB191CD

Page 1
Table of contents
Accessories included............................3
Overview of controls.............................3
Getting started ............................... 3
Battery installation..............................3
Battery installation (cont) .......................4
Mains operation.................................4
Power modes ...................................4
Volume control ..................................4
CD operation ................................. 4
Load a CD ....................................... 4
Playing a CD.....................................4
Skip & search tracks ............................4
Repeat & Random playback.....................5
Programmed playback ..........................5
Radio operation .............................. 5
Aux audio input............................... 5
UK Mains plug information.................... 6
Disc handling information .................... 6
Technical specifications ...................... 6
Care & maintenance .......................... 6
Disposal information ......................... 7
Product Code
CBB191CD

Page 2
Safety information
Important – Please read these instructions fully before using
CAUTION:TO REDUCETHE RISK OF ELECTRIC SHOCK,DO NOT REMOVE ANY COVER.NO USER-SERVICEABLE
PARTS INSIDE,REFER ANY SERVICINGTO QUALIFIED SERVICE PERSONNEL.
• Please take the time to follow the instructions in this
owner’s guide carefully. It will help you set up and operate
your system properly and enjoy all of its advanced
features.
• Please save this owner’s guide for future reference.
• The product label is located on the back of the product.
• Heed all warnings - on the product and in the owner’s
guide.
• Do not use this apparatus near water or moisture.
• Do not use this product near a bathtub,washbowl,
kitchen sink,and laundry tub, in a wet basement, near a
swimming pool, or anywhere else that water or moisture
is present.
• Only use attachments/accessories specified by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time - to prevent damage to
this product.
• Refer all servicing to qualified service personnel
• Servicing is required when the apparatus has been
damaged in any way:such as liquid has been spilled or
objects have fallen into the apparatus;the apparatus
has been exposed to rain or moisture,does not operate
normally, or has been dropped -
• Do not attempt to service this product yourself.
• Opening or removing covers may expose you to
dangerous voltages or other hazards.
• To prevent risk of fire or electric shock,avoid overloading
wall outlets,extension cords,or integral convenience
receptacles.
• Use suitable power sources - Plug the product into a
suitable power source,as described in the operating
instructions or as marked on the product.
• The mains plug is used as the disconnect device,the
disconnect device shall remain readily accessible.
• The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,such as
vases,shall be placed on the apparatus.
• Where the MAINS plug or an appliance coupler is used as
the disconnect device,the disconnect device shall remain
readily operable.
• Batteries shall not be exposed to excessive heat such as
sunshine,fire or the like.
This symbol means that this unit is double
insulated.An earth connection is not required.
CAUTION :CLASS 1 LASER PRODUCT
This product utilizes a Class 1 laser.This laser DVD Player is
equipped with safety switches to avoid exposure when the
door is open and the safety interlocks are defeated.Invisible
laser radiation is present when the Player’s lid is open and
the system’s interlock has failed or been defeated.It is very
important that you avoid direct exposure to the laser beam
at all times.Please do not attempt to defeat or bypass the
safety switches.
LASER SAFETY
This unit employs a laser, only qualified service personnel
should attempt repair.
• Any electrical work that is required to install this
appliance MUSTbe carried out by a qualified electrician.
• Before making any electrical connections,ensure the
following:
• Do not bend,stretch or pull the supply cable in order to
avoid electric shock.
• The supply voltage should be the same as that indicated
in the technical specifications and the appliance rating
plate.
• When installed,the power socket must be within easy
reach.
• If the socket outlets in your home are not suitable for
the plug supplied with this unit check with a qualified
electrician for replacement.
• The use of multiple connectors or extension cables are
not recommended.
• The appliance must be connected to a 100-240 volt
50/60Hz AC supply by means of a three pin socket.
• The main plug is used as the disconnect device,the
disconnect device shall remain readily operable.
• In order to disconnect the apparatus from the mains
completely, switch off the outlet and remove the mains
plug completely.
This product complies with European low voltage
(2006/95/EC) and electromagnetic compatibility
(2004/108/EC) directives.
CAUTION
RISK OF ELECTRIC SHOCK!
DO NOT OPEN!

Page 3
Getting started
Battery installation
1: Remove the battery compartment cover carefully.
2: Install 6x ‘C’ size batteries (UM-2 or equivalent)
while observing the correct polarities.
NOTE:There is an engraved diagram showing
battery installation directions inside the battery
compartment.
3: Replace the battery compartment cover.
Functions & controls
Please familiarize yourself with the parts and accessories listed below
Accessories included
• 1 x CBB191CD • 1 x Mains cable • 1 x Instruction manual
Overview of controls
1: TELESCOPIC antenna
2: VOLUME control
3: SPEAKERS
4: LED DISPLAY
5: SKIP button
6: REPEAT button
7: PREVIOUS button
8: POWER LED indicator
9: PROGRAM LED indicator
10: PROGRAM button
11: PLAY/PAUSE/ECO PWR button
12: STOP button
13: CD compartment lid
14:TUNING DIAL control
15: RADIO BAND FM/MW switch
16: MAINS INPUT socket
17: AUX LINE INPUT socket
18: FUNCTION switch
2
15
6
7
8
5
11
10
9
12
3
13
14
17
18
3
4
1
16
2
15
6
7
8
5
11
10
9
12
3
13
14
17
18
3
4
1
16

Page 4
Battery installation (cont)
NOTE:The mains cable must be detached
from the AC mains socket of the player for the
batteries to power the unit.
Leaking batteries may damage the battery
cabinet and the player as a whole,so they should
be removed from the cabinet when becoming flat
or when the player is not to be used with batteries
for some time.
Mains operation
This unit is supplied with a DC mains cable.
1: To connect the power insert the mains cable figure
eight plug into the rear of the unit (16).
2: Insert the UK plug into a household power socket and
switch the power ON.
Power modes
Follow the below steps to power the unit off or enter
standby mode.
1: To power the unit OFF, slide the FUNCTION switch
(18) to the OFF position.
2: To enter STANDBY mode (power saving) press and
hold the PLAY/PAUSE/ECO PWR button (11) for 5
seconds.
3: To wake the unit from STANDBY mode press the
PLAY/PAUSE/ECO PWR button (11) once.
AUTO STANDBY Due to new ECO regulation
requirements this product incorporates a power
saving feature.
When in CD mode or AUX mode,once audio
playback has ceased and the unit has stood idle
for approximately 20 minutes it will switch into a
‘power-down’ power saving mode.
THIS IS NOTA FAULT.
To wake the unit up, press the PLAY/PAUSE/ECO
PWR button (11).
Volume control
1: To increase the volume level rotate the VOLUME
control (2) clockwise.
2: To decrease the volume level rotate the VOLUME
control (2) Anti-clockwise.
CD operation
Load a CD
1: Open the CD door by lifting the raised part of the lid
(front above the display) upwards.
2: Load a CD onto the disc tray with the label facing
upwards you.
3: Close the CD door.
Playing a CD
1: Wake the unit from STANDBY mode if required.
2: Slide the FUNCTION switch (18) to the CD position.
3: Follow the steps above to load a disc (if not loaded).
4: The player begins to read the disc immediately.
5: When the disc is successfully read the total number
of tracks found on the disc will be displayed.
6: Press the PLAY/PAUSE button (11) once to begin
playback.Press again to PAUSE the music playback,
a dot flashes on the display to indicate the player is in
Pause mode.Pressing the PLAY/PAUSE button (11)
resumes playback.
7: Press the STOP button (12) to cease music playback.
the display shows the total number of tracks again.
Skip & search tracks
1: Press the SKIP button (5) once during playback
to skip to the next track.To skip to a specific track
ahead,press this button several times until you reach
the track number required.
2: Press the PREVIOUS button (7) once during
playback to return to the beginning of the current
track.Press the PREVIOUS button (7) twice
repeatedly to skip to the previous track.To skip back
to a specific track,press this button several times.
3: Hold the SKIP button (5) during playback to fast
forward the current track.
4: Hold the PREVIOUS button (7) during playback to
fast rewind the current track.
Installation

Page 5
Repeat & Random playback
Should you wish to play an entire disc in a random
order or simply repeat a single track or entire disc,
follow the below steps.
1: During playback of a CD,press the REPEAT button (6).
After one press you will see a dot on the right of the
display flash,to indicate the current track will repeat.
2: Press the REPEAT button (6) again and the dot on the
right of the display will stop flashing.This indicates
the entire disc will repeat.
3: Press the REPEAT button (6) once more,you will see
the dot disappear from the display to indicate no
REPEAT function is active.
Programmed playback
To program an alternative playback order of tracks
follow the below steps.
1: Make sure the unit is not playing a disc.
2: Press the PROGRAM button (10) once.The program
sequence “01” appears on the LED display & the
PROGRAM LED indicator (9) flashes.
3: Select the first track to be programmed using either
SKIP button (5) or PREVIOUS button (7).
4: Press the PROGRAM button (10) again to store and
advance to the next programmed track.
The program sequence indication changes to“02”
momentarily waiting for your next input.
5: Repeat the steps above to program more tracks.
A maximum of 20 tracks can be programmed.
6: Press the PLAY/PAUSE button (11) to begin the
programmed playback in the preferred order.
7: You can press the STOP button (12) to terminate
programmed playback.
Radio operation
1: Wake the unit from STANDBY mode if required.
2: Slide the FUNCTION switch (18) to the RADIO/LINE
IN position.
3: Extend the antenna fully, and angle for best reception
(you may need to adjust once tuned to a station).
4: Set the RADIO BAND switch (15) to either FM or MW.
5: Tune to the required station using the TUNING DIAL
(14).
NOTE:When receiving an FM broadcast, fully
extend the telescopic antenna and angle it for the
best reception.
Radio operation (cont)
5: Adjust the volume to a comfortable listening level
using the volume control (2).
Aux audio input
Connect an external audio source like an MP3 player
using a 3.5mm audio cable (not supplied).
1: Connect one end of the cable to the MP3 players
headphone output and the other end to the AUX LINE
INPUT socket (17) on the rear of the unit.
MW
2: Wake the unit from STANDBY mode if required.
3: Set the FUNCTION switch (18) to the RADIO/LINE IN
position.
NOTE:When a 3.5mm audio cable is connected
to the LINE-IN socket, radio output will be muted
until the cable is removed.
4: Press PLAY on the external audio source EG:-MP3
player.
NOTE:the volume output is effected by the
volume level on the source EG: MP3 player so
make sure that is set to about 70-80% ( not too
loud to avoid distortion ).
5: Adjust the VOLUME control on the unit to the required
listening level.
User instructions

Page 6
User instructions
UK Mains plug information
For your convenience a mains plug with a fuse (3
Amp) has been fitted to this appliance. For your safety
please observe the following information.
• The unit is designed to operate on AC mains supply 230
volts, 50 Hz.
• The wires in the mains lead are coloured in accordance
with the following code:
BLUE - NEUTRAL
BROWN - LIVE
Under no circumstances should the Neutral or Live
wires be connected to the ‘E’ (Earth) terminal.
Disc handling information
• Do not touch the playback side of the disc.
• Do not attach paper or tape to disc.
• Fingerprints and dust on the disc cause picture and
sound deterioration. Wipe the disc from the centre
outwards with a soft cloth. Always keep the disc clean.
• If you cannot wipe off the dust with a soft cloth,wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
• Do not use any type of solvent such as thinner,
benzene,commercially available cleaners or antistatic
spray for vinyl. It may damage the disc.
• Do not store discs in a place subject to direct sunlight
or near heat source.
• Do not store discs in a place subject to moisture and
dust such as a bathroom or near a humidifier.
• Store discs vertically in a case,stacking or placing
object on discs outside or their case may cause
warping.
Technical specifications
Supply Voltage, Mains: .............230-240V~50Hz
Max. Power Consumption:..................... 12W
Speaker Power:............................. 2 x 1W
FM:...................................88-108 MHz
MW: ................................ 540-1600 KHz
Net Weight:................................. 1.28kg
Care & maintenance
After using your radio
• Set to Standby.
• Switch the unit off at the mains and unplug it if you are
leaving it unattended for a long period (holidays etc).
• Avoid leaving batteries fitted if you leave the radio
unattended for long periods.They may leak and
damage the radio.
Care and cleaning
• All care and cleaning operations should be carried out
with the unit unplugged from the mains power.
• Occasionally wipe the cabinet with a lint free duster.
Never clean the unit with liquids or solvents.

Page 7
User instructions
Troubleshooting
In the unlikely event of difficulties with your appliance please follow the trouble shooting guide below.
If the problem persists,contact the retailer if the machine is still under guarantee.
Problem Reason(s) Solution(s)
No Power Power cable not connected to wall
socket
Power socket is not switched on
Make sure the plug is connected
Switch the power on
No Sound CD/AUX/RADIO
No Sound from AUX input
Volume is too low
AUX source volume is too low
Increase the volume
Increase the output volume of the AUX
source.
Sound is distorted
Sound is distorted from AUX
input
Volume is too high
AUX source volume is too high
Reduce the volume
Reduce the output volume of the AUX
source.
Unable to Play No disc in the tray
Disc not loaded properly
Disc is dirty
Insert a compatible disc
Check the disc loaded
Clean the disc
Static Sound Poor reception Re-locate the antenna (FM) or relocate
the unit (MW)
Unit switches off after 20
minutes of inactivity
Auto standby mode in operation This unit is designed to enter STANDBY
mode automatically after 20 MINUTES
of inactivity. Press the STANDBY button
to wake the unit.
Disposal information
WEEE marking“Information for the consumer”
Disposal of your old product Your product is
designed and manufactured with high quality
materials and components,which can be
recycled and reused.When this crossed out wheeled bin
symbol is attached to a product it means the product is
covered by the European Directive 2002/96/EC. Please
make yourself aware of the local collection system for
electrical and electronic products.Please act according
to your local rules and do not dispose of your old
products with your normal household waste.The correct
disposal of your old product will help prevent potential
negative consequences for the environment and human
health.

Page 8
Guarantee
PRODUCT GUARANTEE
This productis guaranteed against manufacturing defects for a period of
Year
This product is guaranteed for twelve months from the date of original purchase.
Any defect that arises due tofaulty materials or workmanship will either be replaced,
refunded or repaired free of charge where possible during this period by the dealer from
whom you purchased the unit.
The guarantee is subjectto the following provisions:
The guarantee does not cover accidental damage, misuse, cabinet parts,knobs or
consumable items.
The productmust be correctly installed and operated in accordance with the instructions
contained in this manual.
It must be used solely for domestic purpose.
The guarantee will be rendered invalided if the product is re-sold or has been damaged by
inexpert repair.
Specifications are subject tochange without notice.
The manufacturer disclaims any liability for the incidental or consequential damages.
The guarantee is in addition to, and does not diminish your statutory or legal rights.
Guarantor: Argos Limited
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
