K7I741CX
SiS® 741CX & SiS®964 Chipset
Supports Socket 462
AMD®GeodeTM NX Processor
USER Manual
Dimensions (Mini-ATX form-factor):
z170 mm x 170 mm (W x L)
Operating System:
zWindows®XP/2000

Attention- Im
p
ortant Information
Follow the procedures below…
Troubleshooting Tips
Refer to other sections in this manual…
Things You Should Know
0The images and pictures in this manual are for reference only and may vary from the
product you received depending on specific hardware models, third party components
and software versions.
0This mainboard contains very delicate IC chips. Always use a grounded wrist strap
when working with the system.
0Do not touch any IC chip, lead, connector or other components.
0Always unplug the AC power when you install or remove any device on the mainboard
or when confuguring pins and switches.
Packing List
K7I741CX mainboard
HDD Cable
I/O Bracket
SATA Cable (Optional)
USB Cable (Optional)
K7I741CX Mainboard User Manual CD
K7I741CX Setup Driver CD
K7I741CX Mainboard Quick Installation Guide
Symbols
The following list explains the convention for symbols that will be used throughout this
manual:

Contents
CHAPTER 1. GETTING STARTED ............................................................1
INTRODUCTION ................................................................................................1
SPECIFICATION ................................................................................................2
CONFIGURATION..............................................................................................5
Layout of K7I741CX .........................................................................5
HARDWARE INSTALLATION .............................................................................6
CPU Processor Installation ................................................................6
Memory Installation: DIMM .............................................................7
Back Panel Configuration..................................................................9
Connectors .......................................................................................10
Headers & Jumpers..........................................................................12
Audio Configuration ........................................................................14
Slots..................................................................................................14
Power Supply Attachments ..............................................................15
CHAPTER 2. BIOS SETUP..........................................................................16
INTRODUCTION ..............................................................................................16
MAIN MENU ..................................................................................................17
CHAPTER 3: SOFTWARE SETUP............................................................19
SOFTWARE LIST.............................................................................................19
SOFTWARE INSTALLATION.............................................................................19
CHAPTER 4: TROUBLESHOOTING .......................................................22

K7I741CX Mainboard
1
Chapter 1. Getting Started
Introduction
Congratulations on the choosing the K7I741CX Mainboard. It is based on the SiS®741CX
Northbridge chipset and the SiS®964 Southbridge chipset with possessing integrated graphics feature.
The mainboard supports the AMD GeodeTM NX Processor with FSB (Front Side Bus) frequencies up
to 266 MHz.
The K7I741CX provides one DIMM (Dual In-Line Memory Modules) socket. The socket allows you
to install 184-pin, non-ECC & unbuffered DDR 333 (PC2700)/ DDR 200 (PC2100) SDRAM which
supports a total memory capacity of 1 GB.
The mainboard provides one IDE connector for two hard drives supporting Ultra ATA 133/ 100/ 66
IDE devices. In addition, the onboard comes with one PCI slot for use with a graphics card or
expansion cards which the PCI interface compatible.
Moreover, the K7I741CX provides one VGA connector (equal to D-Sub connector), one Printer port,
and one serial port for use. Several headers are also available on the mainboard for two USB 2.0/1.1
headers for front panel, one IrDA header and one COM header that can be connected additionally
with cables on the back panel of your case.
The onboard AC’ 97 Audio CODEC (ALC203) supports high quality performance 2-channel audio
play. Furthermore, there are maximal six USB2.0/ 1.1 ports which can be set up on this mainboard.
The K7I741CX also comes with an onboard 10/100 Mbps Ethernet LAN chip (RTL8201CL). There
is a LAN port on the back panel of your case that you can directly plug into an internet cable.
In addition, the mainboard comes with two SATA connectors (Optional) which the interface can
provide the transmit rate up to 1.5 Gbps.
All the information (including hardware installation and software installation) in this manual are for
reference only. The contents in this manual may be updated without notice. The company will not
assume any responsibility for any errors or mistakes within.

K7I741CX Mainboard
2
Specification
CPU:
zSupports Socket 462 (Socket A)
zSupports AMD®GeodeTM NX processors
zSupports FSB (Front Side Bus) Frequencies up to 266 MHz
Chipset:
zNorthbridge Chipset – SiS®764 CX
zSouthbridge Chipset – SiS®964
zI/O Controller – Winbond®W83627HG-AW
zAC’ 97 Aduio Codec – Realtek®ALC203
zLAN PHY – Realtek® RTL8201CL LAN PHY
Memory:
zOne DIMM socket
zSupports a total memory capacity of 1 GB
zSupports to use the 184-pin, unbuffered & non-ECC DDR333 (PC2700)/ DDR266
(PC2100) SDRAM
AC’97 Sound CODEC Onboard:
zHigh performance CODEC with high S/N ratio (>100 db)
zCompliant with AC’ 97 2.3 specification
zSupport 2-channel playback capability
zSupport 3D stereo enhancement
Slots:
zOne 32-bit slot for PCI interface for expansion cards
zSupports one-way bandwidth up to 133 MB/s per channel
Onboard IDE Connector:
zOne IDE connector that supports up to two IDE devices
zSupports Ultra ATA 133/ 100/ 66/ 33
zSupports high capacity hard disk drives

K7I741CX Mainboard
3
Serial ATA Connector (Optional):
zTwo SATA connectors that support up to two SATA hard disk drives
zSupports SATA 1.0 specification which provides 1.5 Gb/s transmit rate
zSupports RAID 0/ 1 mode
I/O facility Connectors:
zOne multi-mode Parallel Port is capable of supporting the following specifications:
1. Standard & Bi-direction Parallel Port
2. Enhanced Parallel Port (EPP)
3. Extended Capabilities Port (ECP)
zSupport one serial port and one VGA port
zSupports one PS/2 mouse port and one PS/2 keyboard port
zSupports one IrDA header, two USB headers, and one COM header compatible with
external devices connected
Universal Serial Bus:
zTwo onboard USB 2.0/ 1.1 ports
zTwo front USB 2.0/ 1.1 headers come with this mainboard supporting four additional
USB 2.0/ 1.1 ports to be set
zSupports a maximum of six USB 2.0/ 1.1 ports for compliant devices
Onboard LAN Chip:
zSupports 10/100 Mbps Ethernet LAN
zSupports Auto-negotiation (NWAY) function of full/half duplex operation for both 10
Mbps and 100 Mbps
BIOS:
zPhoenix-Award™ BIOS
zSupports APM 1.2
zSupports ACPI 2.0 power management
Green Function:
zSupports Phoenix-Award™ BIOS power management function
zSupports system-wake-from-power-saving-mode by keyboard or mouse touching

K7I741CX Mainboard
4
Shadow RAM:
zIntegrated memory controller provides shadow RAM functionality and supports ROM
BIOS
Flash Memory:
zSupports flash memory functionality
zSupports ESCD functionality
Hardware Monitor Function:
zMonitors CPU/ Chassis Fan Speed
zMonitors CPU and system temperatures
zMonitors system voltages
Watch Dog Timer:
zThis function is used for detecting the system hangs during the POST stage due to
conflicts resulting from changing the system BIOS settings. Once the problem is detected,
the system will reset the configurations and reboot the system within five seconds.

K7I741CX Mainboard
5
Configuration
Layout of K7I741CX

K7I741CX Mainboard
6
Hardware Installation
This section will assist you in quickly installing your system hardware. Wear a wrist ground strap
before handling components. Electrostatic discharge may damage your system components.
CPU Processor Installation
This mainboard supports AMD®GeodeTM NX processors using a Socket A (Socket 462 Pin package).
Before building your system, we suggest you visit the AMD website and review the processor
installation procedures. http://www.amd.com
CPU Socket A Configuration Steps:
1. Locate the CPU socket on your mainboard and nudge the lever away from the socket. Then lift
the lever to a 90-degree angle.
2. On the socket, locate the corner that has the pin-1 receptor. This corner will have a cut-corner
on the rectangular shaped pattern of pin holes on the socket.
Match the corner on the CPU with the pin-1 receptor on the socket and lower the CPU onto the
socket. The bottom of the CPU should be flush with the face of the socket.
3. Lower the lever until it snaps back into position. This will lock down the CPU.
4. Smear thermal grease on top of the CPU. Lower the CPU fan onto the CPU and use the clasps
on the fan to attach it to the socket. Finally, extend the power cable from the fan and insert it
onto the CPUFAN adapter.
Pin-1
Receptor Gold Triangle

K7I741CX Mainboard
7
FAN Headers: CPUFAN
There is one fan header available for cooling fans. The cooling fan plays an important role in
maintaining ambient temperatures in your system. The CPUFAN header is attached with a CPU
cooling fan.
Pin Assignment
1 Ground
2 Power (+12V)
1
CPUFAN
3 FAN RPM rate sense
Memory Installation: DIMM
The K7I741CX provides one DIMM socket. The socket allows you to install 184-pin, non-ECC &
unbuffered DDR 333 (PC2700)/ DDR 266 (PC2100) SDRAM that supports it to install a total
memory capacity of 1 GB.
Attention
DO NOT touch the CPU pins in case they are damaged. Also, make sure that
you have completed all installation steps before powered on the system.
Finally, double-check that the cooling fan is properly installed and the CPU
fan power cord is securely attached, in case your CPU and other sensitive
components are damaged because of high temperature
s
.
Attention
You can avoid damaging your CPU due to high temperatures with proper
cooling equipment. It is recommended that attach a cooling fan on top of
your CPU. Use the CPUFAN header to attach the fan cord.
On most fan power cord, the black wire of the fan cable is the “ground” and
should be attached to pin-1 of the heade
r
.

K7I741CX Mainboard
8
Memory Installation Steps:
1. Pull the white plastic tabs at both ends of the socket away.
2. Align a memory on the socket such that the notch on the memory matches the break on the socket.
3. Lower the memory vertically into the socket and press firmly by using both thumbs until the
memory snaps into place.
* The pictures shown above are for reference only. The actual
installation may vary depending on models.

K7I741CX Mainboard
9
Back Panel Configuration
PS/2 Mouse & PS/2 Keyboard Connectors: KB/MS
This mainboard provides a standard PS/2 mouse port and a PS/2 keyboard port. The pin assignments
are described below.
Serial and Parallel Interface Ports
The mainboard provides one serial port and one parallel port on the back panel.
The Serial Interface: COM2
This mainboard provides a serial port COM on your back
panel, and is used to connect mice, modem and other
peripheral devices. Through this port, you can also transfer
data from your computer hard disk drive to other computers.
Parallel Interface Port: PRT
The parallel port on your mainboard is a standard 25-pin one,
and is used to connect a parallel printer.
Pin Assignment Pin Assignment
1 Data 4 +5 V (fused)
2 N/A 5 Clock
3 Ground 6 N/A
PS/2 Mouse
PS/2 Ke
y
board

K7I741CX Mainboard
10
D-Sub Connector: VGA
Your VGA monitor can attach directly to this VGA connector.
USB & LAN Ports: USB/LAN
There are two USB 2.0/ 1.1 ports on the back panel. These USB ports are used to attach with USB
devices, such as keyboard, mice and other USB supported devices. There is also a 10/100 Mbps
Ethernet LAN port available for you to attach an Internet cable.
Audio Ports: Sound
This mainboard provides three audio ports, the Mic-in, Line-in
and Line-out. These are the standard audio ports that provide
basic audio function.
Line-In (Blue)
This port is for audio input and connects to external audio devices
such as CD player, tape player, etc.
Line-Out (Green)
This port is an output audio port used for connecting to speakers
or a headset.
Mic-In (Pink)
This port is for connecting to a microphone.
Connectors
Hard Disk Drive Connectors: IDE
The mainboard provides one IDE connector that supports Ultra ATA 133/ 100/ 66/ 33 IDE devices.
You can attach a maximum of two IDE devices, such as hard disk drive (HDD), CD-ROM,
DVD-ROM, etc. using IDE ribbon cables.
Pin Assignment Pin Assignment
1 TXC 4 RX+
2 TX+ 5 RX-
3 TX- 6 RXC
Pin Assignment Pin Assignment
1/5 +5 V (fused) 3/7 USBP0+/P1+
2/6 USBP0-/P1- 4/8 Ground

K7I741CX Mainboard
11
Primary IDE Connector
In general, two IDE devices can be attached onto one IDE connector. If you attach two HDD, you
must configure one drive as the master and the other one as the slave.
SATA Connectors: SATA1/SATA2 (Optional)
The two SATA connectors support 1.5 Gbps transmission speeds and RAID 0/1 mode. One SATA
connector only can attach one SATA HDD of each time using SATA cables.
Front Panel Headers: SW/LED, SPEAK
SW/LED/ SPEAK
Pin Assignment Function Pin Assignment Function
1 PWRLED (+) 2 HDLED (+)
3 Key 4 HDLED (-)
Hard Drive LED
(HDLED)
5 PWRLED (-)
Power LED
(PWLED)
6 PWRBTN (+)
7 SPK_OUT 8 PWON (-)
Power-on Switch
(PWR)
9 N/A 10 RESET_SW (-)
11 N/A 12 RESET_SW (+)
Reset Switch
(RST)
13 +5V
SPEAKER
(SPEAK)
14 N/A
Pin Assignment Pin Assignment
1 Ground 2 TX+
3 TX- 4 Ground
5 RX- 6 RX+
SATA1/2
7 Ground

K7I741CX Mainboard
12
Power LED Connector (PWLED)
The mainboard provides a 3-pin power LED header. If there is a 3-pin power LED cord on your case
front panel, you can attach it to this 3-pin header on the SW/LED header. Then the power LED will
illuminate while the system is powered on.
Hard Drive LED Connector (HDLED)
If your case front panel has a hard drive LED cable, attach it to this header. The LED will flicker
when there is hard disk drive activity.
Power-on Switch (PWR)
This header can be attached to a power switch cable on your case front panel. You can turn your
system on or off by pressing the button attached to this power switch cable.
Reset Switch (RST)
This header can be attached to a momentary SPST switch (reset button) cable on your case front
panel. The switch is normally left open. When the switch closed, it will cause the mainboard to reset
and run the POST (Power-On Self Test).
SPEAKER (SPEAK)
A speaker cable on your case front panel can be attached to this header. When you reboot the
computer, this speaker will issue a short audible (beep). If there are problems during the Power On
Self-Test, the system will issue an irregular pattern of audible beeps through this speaker.
Headers & Jumpers
Front USB Headers: USB1/USB2
This mainboard provides two onboard USB 2.0/1.1 ports (back panel) that attach to USB devices.
There are two additional USB headers that can be connected by a cable to four more USB ports on
the front panel of your case giving you a possible six USB 2.0/1.1 ports.
Pin Assignment Pin Assignment
1 +5V 2 +5V
3 USB- 4 USB-
5 USB+ 6 USB+
7 Ground 8 Ground
USB1/2
9 N/A 10 N/A
Serial Interface Header: COM
This mainboard provides a COM header for you connecting an additional serial connector on the
back panel of your case. Attach the cable of serial connector (Optional) onto this header, and then
you can use the serial connector connecting with a mic, modem or other peripheral device.

K7I741CX Mainboard
13
Pin Assignment Pin Assignment
1 RIN1 2 RIN3
3 DOUT2 4 DOUT3
5 Ground 6 RIN2
7 DOUT1 8 RIN4
COM
9 -XRI1 10 N/A
IrDA Header: IrDA
The infrared sensing device attached to this header can support to provide wireless infrared. You can
transfer data connectionless to or from the portable device (i.e., laptop, PDA, etc.) which with this
header attached.
Clear CMOS Jumper: Clear CMOS
The “Clear CMOS” function is used when you are unable boot your system and need to reset the
BIOS settings (CMOS settings) back to the manufacturer’s original settings. This is also a way to
reset the system password if you have forgotten it.
Clear CMOS Assignment
Pin 1-2 Close Clear CMOS Data
Pin 2-3 Close Normal (Default)
Note: Close stands for putting a jumper cap onto two header pins.
1. Turn off your system and disconnect the AC power cable.
2. Set Clear CMOS header to OFF (1-2 Closed).
3. Wait several seconds.
4. Set Clear CMOS header to ON (2-3 closed).
5. Connect the AC power cable and turn on your system.
6. Reset your new password.
Pin Assignment Pin Assignment
1 +5V 2 N/A
3 IR_RX 4 Ground
5 IR_TX
The following steps explain how to reset your CMOS
configurations when you forgot a system password.

K7I741CX Mainboard
14
Audio Configuration
CD-ROM Audio-In Connector: CD-IN (Optional)
The CD-IN connector is used to attach an audio cable to audio devices such as CD-ROMs,
DVD-ROMs etc.
Pin Assignment
1 Left channel input
2 Ground
3 Ground
1
CD-IN
4 Right channel input
Slots
PCI Interface Slots: PCI
PCI stands for Peripheral Component Interconnect and is a bus standard for installing expansion
cards such as network card, SCSI card, etc. to these PCI slots.

K7I741CX Mainboard
15
Power Supply Attachments
ATX Power Connector: ATX_PWR
This mainboard provides one 20-pin ATX power connector. You must make it be attached before the
system is powered on. The power connector support several power management functions such as the
instant power-on function. The connector pins are described below.
Pin Assignment Pin Assignment
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PWR_ON-
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PWR_GD 18 -5V
9 +5V standby voltage 19 +5V
ATX_PWR 10 +12V 20 +5V
Attention
In general, power cords are designed and should be attached with a specific
direction. The black wire of the power cord is Ground and should be
attached onto the header location of Ground.

K7I741CX Mainboard
16
Chapter 2. BIOS Setup
Introduction
This section describes PHOENIX-AWARD™ BIOS Setup program which resides in the BIOS
firmware. The Setup program allows users to modify the basic system configuration. The
configuration information is then saved to CMOS RAM where the data is sustained by battery after
power-down.
The BIOS provides critical low-level support for standard devices such as disk drives, serial ports
and parallel ports. As well, the BIOS control the first stage of the boot process, loading and executing
the operating system.
The PHOENIX-AWARDTM BIOS installed in your computer system’s ROM is a custom version of
an industry standard BIOS. This means that it supports the BIOS of Intel®based processors.
This version of the PHOENIX-AWARDTM BIOS includes additional features such as virus and
password protection as well as special configurations for fine-tuning the system chipset. The defaults
for the BIOS values contained in this document may vary slightly with the version installed in your
system.
Key Function
In general, you can use the arrow keys to highlight options, press <Enter> to select, use the <PgUp>
and <PgDn> keys to change entries, press <F1> for help and press <Esc> to quit. The following table
provides more detail about how to navigate within the BIOS Setup program.
Keystroke Function
Up arrow Move to previous option
Down arrow Move to next option
Left arrow Move to the option on the left (menu bar)
Right arrow Move to the option on the right (menu bar)
Esc Main Menu: Quit without saving changes
Submenus: Exit Current page to the next higher level menu
Move Enter Move to the option you desire
PgUp/ PgDn key Increase/ Decrease the numeric value or enter changes
+/ - Key Increase/ Decrease the numeric value or enter changes
Esc key Main Menu – Quit and do not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu – Exit
Current page and return to Main Menu
F1 key General help on Setup navigation keys
F5 key Load previous values from CMOS
F6 key Load the optimizd defaults from BIOS default table
F7 key Load the standard defaults from BIOS default table
F10 key Save all the CMOS changes and exit
