Unlimited Audience
Unlimited Number of Channels
Unlimited Coverage
Maximum Interactivity
Unlimited Entertainment
Unlimited Usage
Alcatel-Lucent
Unlimited Mobile TV Solution
Deliver Complete Mobile TV for Your Market by Partnering with Alcatel-Lucent
2 Alcatel-Lucent Unlimited Mobile TV Solution
Today’s mobile end users want more from their mobile services. They
want advanced services that let them download and play songs and
videos, send text messages, conference with colleagues and friends, and
exchange pictures or videos on whichever device they are using. Now,
mobile end users worldwide are showing a growing interest in mobile
TV. In fact, the European Commission estimates that mobile TV could
be a market of up to €20 billion by 2011, reaching approximately
500 million customers worldwide.
Mobile TV Ready for Prime Time
3Alcatel-Lucent Unlimited Mobile TV Solution
Simplify the Delivery
of Mass Market Mobile TV
The Alcatel-Lucent Unlimited
Mobile TV solution simplifies the
delivery of mass market mobile TV.
It’s a complete, turnkey solution that
allows you to present end-users with
a truly diversified Mobile TV offer
based on a mix of mainstream broad-
cast channels and an unlimited num-
ber of specialty unicast channels.
The mix of broadcast and unicast
services, combined with interactive
capabilities made possible by Alcatel-
Lucent’s content management and
service platform, can improve cus-
tomer retention and drive higher
mobile service revenues. And, the
Alcatel-Lucent Unlimited Mobile
TV solution delivers service to your
whole market because it is designed
to provide exceptional indoor cover-
age and service availability throughout
a whole country or region.
The result is a mass-market mobile
TV option tailored to deliver an
unlimited number of TV channels,
to an unlimited mobile audience
with unlimited coverage.
Leverage the Experience
of a Trusted Partner
With the Alcatel-Lucent Unlimited
Mobile TV solution, you leverage
Alcatel-Lucent’s experience and
expertise delivering mobile video
and TV services around the world.
As your trusted mobile TV partner,
Alcatel-Lucent helps you design,
develop, deploy and operate an
effective mobile TV solution opti-
mized specifically for your environ-
ment. Alcatel-Lucent’s partnership
approach helps you:
Where it is available, mobile TV has
been successfully deployed on existing
cellular infrastructures in point-to
point mode. But this approach is not
designed to deliver the same content
to many users at the same time. It
prevents mass-market deployment
and, due to potential congestion,
does not allow mobile service
providers to deliver the high quality
of experience end users demand.
To go beyond point-to-point offerings
and provide mass access to mainstream
TV channels on mobile, service
providers must deploy dedicated
mobile broadcast networks that are
complementary to existing cellular
networks. But the design of these net-
works may be expensive and risky.
Alcatel-Lucent minimizes the expense
and risk of mobile TV deployment
with a mass market solution that
addresses the expectations of con-
sumers, television broadcasters and
mobile operators.
• Select the technology that fits
you best
• Initiate an efficient mobile
TV business
• Deploy and operate an unlimited
mobile TV service
4 Alcatel-Lucent Unlimited Mobile TV Solution
Alcatel-Lucent has addressed these
and other technology challenges with
the Unlimited Mobile TV solution.
This solution makes optimal use of
existing network investments and
resources and combines them with
the best technical capabilities of
various technologies and spectrum
options to deliver a complete end-
to-end solution designed to be easily
adapted to your needs.
To deploy and integrate a mobile
broadcast overlay with your network
for a truly mass-market mobile TV
offering optimized for your market
you must address many challenges:
• What spectrum is required?
• Which standard is most appropriate?
• How can you achieve your target
coverage?
• Can you reuse your existing assets?
• What is the best way to combine
services?
CHIPSETS
TERMINALS
SPACE SEGMENT
2G/3G
E2E SOLUTION INTEGRATION, BUILD AND OPERATE ENABLING
APPLICATION AND SERVICE O&M
SYSTEM ARCHITECTURE, DESIGN AND OPTIMIZATION
(Incl. Bcast Head-End)
MICROWAVE
BACKHAULING
SERVICE
DELIVERY PLATFORM
AD AND
CONTENT
AGGREGATION
TRANSMITTERS
(Integration in legacy networks)
Select the Technology that Fits You Best
Figure 1. Alcatel-Lucent Unlimited Mobile TV Solution with DVB-H/-SH
Unicast and Broadcast:
Complementary for Unlimited
Mobile TV
Unicast is communication between
a single sender and a single receiver
over a network. An earlier term,
point-to-point communication,
is similar in meaning to unicast.
Typically, current 3G networks are
unicast, which means that there are
as many mobile TV signals as there
are number of viewers simultane-
ously watching a given program.
By contrast, broadcast is commu-
nication from one sender to all
potential receivers in a given
area/region.
5Alcatel-Lucent Unlimited Mobile TV Solution
Depending on your current assets
(network and spectrum) and service
objectives, the Alcatel-Lucent
Unlimited Mobile TV solution offers
different infrastructure options to
deliver mainstream channels:
• High-power mobile broadcast
satellites which provide direct
terminal reception across rural
areas countrywide
• Medium- to high-power trans-
mitters for urban/suburban
outdoor reception
• Low-power transmitters for cellular-
like quality of service in urban
indoor areas
Full flexibility between terrestrial and
satellite backhauling is also provided
to feed these infrastructures with the
channels to be broadcast.
End-user terminals receive broadcast
TV either from terrestrial repeaters
or from the satellite, and unicast TV
from a 3G broadband connection.
To deliver the content, the mobile
TV service delivery platform adapts
and aggregates TV programs and rich
multimedia services into IP service
174MHz
to 230MHz
400MHz
to 800MHz 850MHz
900MHz
1.4GHz 1.8GHz 2.1-2.2 GHz 2.6 GHz 3 GHz
1.9GHz
2004
2007
Higher frequency range
Higher spectrum efficiency (bit/Hz)
Possible satellite / terrestrial combination
Band III UHF 2G 3G SatelliteL-Band
Figure 2. Alcatel-Lucent: Selecting the Standard Adapted to Your Spectrum Options
streams and selects the transmission
format, either broadcast, or unicast
(2G, 3G, etc.), depending on the
targeted audience.
The service delivery platform lets you
provide end-users with interactive and
personalization features such as chat,
voting, and click-to-buy. And it pro-
vides seamless access to related
services, as well as cross-advertising
opportunities on any combined
unicast and broadcast network.
6 Alcatel-Lucent Unlimited Mobile TV Solution
New DVB-SH Specification Enables Delivery of Mobile
Multimedia Services Using Hybrid Satellite/Terrestrial Networks
The new Digital Video Broadcasting-Satellite services to Handhelds
(DVB-SH) specification is an evolution of the Digital Video
Broadcasting-Handheld (DVB-H) standard. It enhances the
range of DVB standards for the delivery of mobile digital television.
The DVB-SH standard enables the delivery of IP-based media content
and data to handheld terminals like mobile phones and PDAs via
satellite. It has been designed for frequencies below 3 GHz. It com-
plements the existing DVB-H physical layer standard and uses the
DVB IP Datacast (IPDC) set of content delivery, electronic service
guide and service purchase and protection standards.
DVB-SH includes features such as turbo coding for forward error
correction and a highly flexible interleaver in an advanced system
designed to cope with a hybrid satellite/terrestrial network topology.
Satellite transmission ensures wide area coverage and the terrestrial
component assures coverage where the satellite signal cannot be
received, as may be the case in urban areas.
Up to 18
TV Channels
(256 kb/s)
Up to 90
TV Channels
(256 kb/s)
Broadcast (DVB-SH)
Mobile Networks
Service Delivery
Platform
Mobile Networks
(2.5G/3G/HSDPA)
Unlimited
Number of
Channels
1
2
3
Alcatel-Lucent Unlimited Mobile
TV Solution is based on DVB-H/SH
standards
The complete Alcatel-Lucent solu-
tion gives you the most flexibility
for a mobile TV service designed
for efficient operation and optimum
coverage. Based on DVB family
mobile TV standards, it offers wide
spectrum availability, from UHF up
to 3GHz. It allows you to choose the
best combination of DVB-H and DVB-
SH technologies for your market. And
it accommodates multiple infrastruc-
ture options, from satellite, to broad-
cast towers and cellular sites.
And as a true pioneer of the DVB-
SH technology, Alcatel-Lucent has
established an ecosystem of industrial
and research partners to optimize the
delivery of Unlimited Mobile TV
based on this new technology.
Figure 3. Alcatel-Lucent Unlimited Mobile TV Solution in DVB-SH
7Alcatel-Lucent Unlimited Mobile TV Solution
Alcatel-Lucent Supports Major Standards – DVB-H and DVB-SH
9600 DTH TRANSMITTER (UHF BAND)
Alcatel-Lucent has developed a digital transmitter for broadcasting DVB-H
television services to mobile users, which can also broadcast DVB-T signals
to fixed users of digital terrestrial television.
Emerging network architectures need low-power transmitters that can provide
radio coverage with the same quality delivered by cellular networks. The Alcatel-
Lucent 9600 DTH meets these requirements. Two versions are available —
the 9600 DTH 50 and the 9600 DTH 100 — which offer 50 Watts or 100 Watts
of output power, respectively.
This transmitter is an ideal solution for implementing DVB-H/T networks
in the UHF band. Unlike standard broadcasting transmitters, its features are
designed to support mobile-cellular network deployment, including a compact
form factor adapted for installation in mobile sites.
9600 DTR DIGITAL TRANSMITTER (S-BAND)
The Alcatel-Lucent 9600 DTR is based on a flexible architecture, which makes
it a true hardware platform covering any potential need up to the upper S-band
(2.7 GHz), using either the DVB-SH waveform or any other standard.
This transmitter has triple carrier capability, as well as auto-adaptive non-linear
pre-correction, an integrated DVB-S/S2 demodulator, Gigabit Ethernet traffic
interfaces, and an internal GPS receiver for single frequency network (SFN)
operation (as in the 9600 DTH).
The high power amplification is band and power specific, due to the broad
range of requirements (470 MHz to 2700 MHz, and from 10 W to 300 W), and
indoor and outdoor configuration options available.
8 Alcatel-Lucent Unlimited Mobile TV Solution
Mobile Interactive TV successes
Alcatel-Lucent media solutions include mobile interactive TV applications,
which allow extensive interactivity and personalization, complementing
traditional live TV with made-for-mobile content, creating the possibility
to provide targeted advertisement supported content to end-users.
Alcatel-Lucent is heavily involved in interactive mobile TV deployments,
with more than 80 mobile operators around the world using its superior end-
to-end video and music solutions to enable their mobile video, music and live
TV services, including Orange World Video portal, Telefónica in Spain and
Mexico, T-Mobile in Germany, the UK and Austria, MTN South Africa,
Optimus and SIC TV in Portugal.
Alcatel-Lucent demonstrated the world’s first unified Mobile TV experience
across 3G and broadcast networks, enabling a compelling Mobile TV end-user
experience combining unicast and broadcast Mobile TV channels connected
to the same service platform on the same handset.
Leveraging Mobile TV, interactivity and personalization, Alcatel-Lucent enables
the generation of new services, additional revenues and new advertising models.
Initiate Your Mobile TV Business
9Alcatel-Lucent Unlimited Mobile TV Solution
Beyond providing the most effec-
tive technology options with the
Unlimited Mobile TV solution,
Alcatel-Lucent can also help you
kick-start your mobile TV business.
As your mobile TV partner, Alcatel-
Lucent works with you to develop
a complete understanding of your
market and your end users’ service
expectations.
For example, the Alcatel-Lucent
Worldwide Lab (www.alcatel-
lucentlab.com) conducts qualitative
research that sheds light on what end
users around the world expect from
new, personalized services. Recent
research conducted by The Lab
revealed the top five issues users have
with current mobile services and the
top five features users appreciate about
current services. With this and other
research, Alcatel-Lucent can provide
insight into what kind of mobile TV
service will work in your market, what
end users in your market will pay for
an enhanced service offer, and how
that offer should be positioned.
Acquire Licenses,
Build a Business Case
Once you know what kind of service
to introduce, we will work with you
to navigate through the various spec-
trum licenses required to operate your
mobile TV service.
We’ll help you build a business case
that ensures you meet all your business
objectives while keeping capital and
operational expenditures in line.
And we’ll also establish and initiate
ad-hoc partnerships and consor-
tiums with independent, technology-
agnostic third parties to make sure you
build your business based on the most
effective technologies for your market.
Mobile TV Memberships
Alcatel-Lucent is member of several
key industry bodies committed to the
success of mobile TV worldwide,
including the bmco forum (Germany),
the Forum de la Télévision Mobile
(France) and the Mobile Digital TV
Alliance (USA). Alcatel-Lucent rep-
resentatives also actively contribute to
the work of the DVB Project and of the
UMTS Forum and GSM Association
joint mobile TV Workgroup, of ETSI
and of OMA (Open Mobile Alliance).
Capitalize on
Our Market Knowledge
Alcatel-Lucent continuously performs
end user focus groups and studies in
order to design services that match
end user demands. This research
clearly indicates that end users are
waiting for, and are ready to pay for
a mobile TV offering that delivers
a large variety of choices, a high
level of personalization, maximum
interactivity, and great quality of
service — everywhere.
10 Alcatel-Lucent Unlimited Mobile TV Solution
Alcatel-Lucent Enables Mobile TV Launches Worldwide
Alcatel-Lucent is a trusted mobile TV solution provider for operators around
the world.
SES AND EUTELSAT, EUROPE
SES Global and Eutelsat Communications have joined forces to establish the
first European satellite infrastructure for broadcasting video, radio and data to
mobile devices and vehicle receivers.
Under the joint venture, SES and Eutelsat have agreed to create a company,
which will operate and commercialize the S-band payload on the W2A satellite.
The S-band space segment represents an investment of approximately €130
million. It will allow the delivery, for the first time, of mobile multimedia broad-
cast services directly to user terminals in France, Germany, Italy, Poland, Spain
or the UK. The satellite is supported by a hybrid infrastructure that combines
satellite and terrestrial networks and delivers universal coverage and indoor
penetration for mobile TV services.
“SFR has always stood at
the forefront of innovation in
order to provide all its clients
with the most attractive mobile
services. This is why we wished
to evaluate the hybrid technol-
ogy proposed by Alcatel-Lucent
based on the new DVB-SH
standard specified by the DVB
Project, in just the same way
as we had tested the DVB-H
standard last year. These
technologies, which are
recommended at national
and European levels, seem to
us interesting to evaluate, con-
sidering the growing success
encountered by mobile TV
among our customers.”
— JEAN-DOMINIQUE PIT,
DIRECTOR STRATEGY AND
INNOVATION AT SFR
