AlcoMate AL6000 Lite User manual

The AlcoMate Core (Model AL6000 Lite) analyzes a breath sample to detect alcohol in
the lungs. This reading is then converted to blood alcohol concentration ( AC). The
AlcoMate Core uses an advanced oxide semiconductor sensor to detect alcohol.
AlcoMate
C
ore
USER’S MANUAL
Mouthpiece Slot
(with Mouthpiece
Attached)
Power Button
READY Indicator
WARN Indicator
BATT L W
Indicator
Digital LED Display
3 Digit %BAC Reading

Device Operation
If you are using the Core for the first time, please install two 1.5V AA batteries (included)
and attach a mouthpiece to the unit.
1. Instructions
a) Press and hold the Power Switch to turn the unit on. The cu ulative test count
will be displayed as you hold the Power Switch down. You can use the
cumulative test count to see when you should replace the sensor module (every 200
tests or at least once yearly).
b) Release the Power Switch. There will be a countdown from to as
the unit warms up.
c) Secure your lips around the mouthpiece and blow sharply and steadily into the
unit for about 4 seconds. You will hear two beeps when the device is done taking
the breath sample. You will see the digit moving left to right in the display as
the device analyzes the sample.
d) When analysis is complete, you will see the blood alcohol concentration ( AC)
results displayed.
c) The results will be shown for about 15 seconds. The unit will then shut itself off.
d) If the device cannot take a successful sample, you will see in the display
and the unit will shut itself off.
2. Understanding Your Results (BAC Reading)
Your Reading Your Range Description
0.00% to 0.01% Safe
*
range. Little/no alcohol
intake.
0.02% to 0.04% Moderate
*
range. Increased alcohol
intake.
0.05% and over Warning
*
range. Ability to drive may
be impaired.
*
Drinking alcohol in ANY amount may impair the ability to drive. There is no “safe” level
of alcohol intake before driving. Don’t drink and drive.
Note: The maximum reading the device can show is 0.40%. A true AC of 0.40% or
above may result in the onset of coma or even death by respiratory arrest. A reading
of 0.40% may indicate an acutely dangerous condition, but may also indicate a
sampling error (such as liquid alcohol blown into the device). Please carefully read
the Warnings section of this manual before operating the device.

General Infor ation about DUI/DWI
The legal limit for intoxication (DUI/DWI) is 0.08% AC across most of the USA.
According to the American Medical Association (AMA), a AC of 0.05% is
enough to impair the ability to drive. You should never operate a motor vehicle
when you are impaired by the consumption of alcohol, drugs or lack of proper
rest.
Warnings
a. Wait at least 20 minutes after eating or drinking before testing. Alcohol
remaining in the mouth, or even excess saliva, may interfere with testing.
This includes alcohol-based mouthwash or similar products.
b. Avoid testing in high wind or enclosed spaces. Poor ventilation may also
lengthen the time required for warm up between tests.
c. Do not blow smoke, saliva or other contaminants into the mouthpiece, as the
sensor may become damaged.
d. Do NOT use the AlcoMate Core as a tool to drink and drive.
e. Keep out of extreme temperatures and out of the reach of children.
f. To aintain accuracy, professional recalibration of the AlcoMate Core
ust be perfor ed every 200 tests or at least once yearly (12 onths),
whichever co es first. To recalibrate, you must mail your device to the
address at the end of this manual. Please contact us for details and related
fees.
g. WARNING DISPLAY “Flo”: If you see “Flo” in the display, the breath
sample was not long enough for measurement. Please try again and make
sure the breath is strong and steady during sampling. As soon as you start
blowing into the device, you will hear a long beep indicating how long you
should blow.
h. WARNING DISPLAY “SEn”: If you see “SEn” in the display, there is a
general sensor module error. Please contact us for technical service.
i. WARNING DISPLAY “Bat”: If you see “ at” in the display, the battery power
is low. Please replace the batteries. Make sure to properly align the
batteries by looking at the +/- marks.

Specifications
Method of Measure reath sample to AC
Range 0.00% to 0.40%
Accuracy +/-0.01% up to 0.10% AC
Sensor Oxide semiconductor
Power Two 1.5V AA alkaline batteries (included)
Testing Capacity Approx. 200 with new batteries
DOT Approved YES
Operating Temperature 10 – 40 degrees Celsius
Warm Up Less than 1 minute
Display 3-Digit (0.00)
Size (mm) 125 (height) X 58 (width) X 41 (thickness)
Weight 117 g
Recalibration Recommended every 200 tests or at least once yearly,
whichever comes first
Warranty
The manufacturer warrants the product to be free from defects in workmanship or
material (excluding calibration) under normal use for one (1) year from the date
of purchase. The manufacturer’s obligation under this warranty is limited to
replacing, adjusting or repairing the unit if returned along with proof of purchase.
This warranty is void if the unit has been tampered with or maliciously damaged.
Recalibration is a periodic maintenance procedure required of any and all
breathalyzers in order to maintain accuracy, and as such, is not a warranty
service.
Technical Support
For technical support or questions, please contact us at:
AK Solutions USA, LLC
21 Grand Ave. Suite 102
Palisades Park, NJ 07650
T-F: 800-943-1016 (Monday-Friday 9AM to 6PM EST)
Tel: [phone] (Monday-Friday 9AM to 6PM EST)
Fax: [phone]
Email: [email protected]
Web: http://www.alcomate.net
