Alcor HDT-4400 User manual

USER MANUAL
set-top-box
HDT 4400

USER MANUAL
1) Read these instrucons.
2) Keep these instrucons.
3) Heed all warnings.
4) Follow all instrucons.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not install near any heat sources such as radiators ,heat registers. stoves, or other apparatus (including
amplifiers) that produce heat.
8) Operate this product only from the type of power source indicated on the label. If you are not sure of the
type of power connected to your home. Consult your local power company, Disconnect the unit from the
mains before any maintenance or installaon procedure.
9) Protect the mains cord from damage and stress.
10)Only use aachments/accessories specified by the manufacturer.
11)Unplug this apparatus during lightning storms or when unused for long periods of time.
12)Refer all servicing to qualified service personnel, Servicing is required when the apparatus has been damaged
in any way, including damage to the mains cord or plug, if the unit has been exposed to liquid or moisture,
has been dropped or is not operang correctly.
13)Do not impede the air flow into the unit by blocking the ventilaon slots.
14)Aenon should be drawn to the environmental aspects of baery disposal.
15)Use the apparatus in moderate climate.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
WARNING: The baeries shall not be exposed to excessive heat such as direct sun light, fire, etc.
HDT- 4400
High Denition Digital Receiver
Important Safety Instructions

Warning:
※The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
※The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain
readily operable.
※The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
This symbol indicates that dangerous voltages constituting a risk of electric
shock are present within this unit.
This symbol indicates that there are important operating and maintenance
instructions in the literature accompanying this unit.
This symbol indicates that this product incorporates double insulation
Between hazardous mains voltage and user accessible parts.
When servicing use only identical replacement parts.
Package Contents
Before installation, please check the contents of the package.
The package should contain the following items:
1. DVB-T2 TV receiver x1pc
2. Remote control x1pc
3. AAA Battery for the remote control x1pair
4. User manual x1pc

Front and rear Panel………………………………………………………………………………………………………….……………………………….1
Remote Control……..…………………………………………………………………………………………….…………………………………………….2
System Connection.....………………………………………………………………………………………………………………….…………………….4
First time Installation……………………………………………………………………..……………………………………………………….………….5
Basic Operation………………………………………………………………………………………………………………………………………….……….5
Program Settings…….………………………………………………………………………………………………………………………………….……….5
Program Edit………………………………………………………………………………………………………………………………………….6
EPG(Electronic Program Guide)……….…………………………………………………………………………………………………….7
Sorting……….………………………………………………………………………………………………………………………………………….8
LCD(Logical Channel Number)……………………………………………………………………………………………………….……….8
Pictures Setting……….…………………………………………………………………………………………………………………………….…………….8
Resolution….…………………………………………………………………………………………………………………….…………………….8
TV format…..………………………………………………………………………………………………………………………….……………….8
Channel search………….………………………………………………………………………………………………………………………….……………..9
Auto search..………………………………………………………………………………………………………………………..…………….9
Manual search……………………………………………………………………………………………………………………………..………….9
Country……..………………………………………………………………………….………………………………………………………………10
Antenna power..……………………………………………………………………………………………………………………………………10
Time setting……………………………………………………………………………………………………………………………………………………….10
Time offset..……………………………………………………………………………….…………………………………………………………10
Country region..………………………………………………………………………………….…………………………………………………10
Time zone..…………………………….……………………………………………………………………………………………………..………10
Option……………………………………………………………………………………………………………………………………………………………..….10
OSD language…..……………………………………………………………………………………………………………………..….…………11
Subtitle language..……………………………………………………………………………….………………………………………..………11
Audio language..………………………………………………………………………………….…………………………………………..……11
System setting………….……………………………………………………………………………………………………………………………………..….11
Set password…...………………………………………………………………………………….……………………………………………..…11
Restore factory default .………………………………………………………………………………………………………………..………12
Information……...………………………………………………………………………………….……………………………………….………12
USB…………………………..……………………………………………………………………………………………………………………………….……….12
Multimedia……...……………………………………………………………………………………………………………….……….…………12
Photo configuration……...…………………………………………………………………………………………………..……….…………13
Movie configuration..………………………………………………………………………….…………………………………………………13
PVR configuration…...………………………………………………………………………….…………………………………………………13
Trouble shooting……..………………………………………………………………………………………………………………………………………….15
Technical specifications……………………………………………………………………………………………………………………………………….16
Notice about recycling.……………………………………………………………………………………………………………………………………….17
Table of Contents

1. POWER BUTTON: Push to turn on/off the main power supply.
2. POWER INDICATOR: When green, unit working; when red, it is in standby.
3. REMOTE CONTROL SENSOR: Used to receive the signal from the remote control.
4. LED DISPLAY SCREEN: Used to display channel number or information
5. USB: For software upgrade and media playback.
6. CHANNEL UP: Used to change channels without using the remote control.
7. CHANNEL DOWN: Used to change channels without using the remote control.
1. RF IN: This socket connects to your external Aerial.
2. LOOP OUT THROUGH: This socket will feed the RF signal to either your TV or another video system.
3. Coaxial: This socket outputs digital audio signal.
4. HDMI: High definition audio and video output used to connect to a HDMI device.
5. TV Scart output
6. AUDIO for sound
7. Bulit-in Power supplier
-1-
1.Front Panel
2.Rear Panel
Front and Rear Panel

-2-
POWER: Switch the receiver in and out of standby mode.
<0>-<9>: Numeric keys
CH-/CH+: Program changing keys.
MENU: Display main menu on TV screen, and press again to disappear menu
OK: To confirm current setting, or display channel list in no-menu mode.
VOL-/VOL+:To increase/decrease volume; Press to move the cursor
EPG: Shows the electronic program guide.
FAV: Displays your favorite channels list; press FAV again to access to the other
favorite lists.
RECALL: Go back to the previous viewed channel.
Red/Green/Yellow/Blue: Use to navigate between pages in teletext mode and
special functions in Menu or EPG
TTX: Switch on teletext, if current channel has this option, and use EXIT key to
quit teletext.
SUB: Display subtitle options(availability depends on the channel)
EXIT: Use this key to quit current menu
INFO: Display information about the current channel.
TV/RADIO: Switch between digital radio and DVB-T modes.
MUTE: To switch on/off volume.
Remote Control

Installing the Batteries
Remove the battery cover from the rear of the Remote control and place 2xAAA size batteries inside the
compartment.
Please make sure the battery polarities match the polarity markings inside the compartment.
Using the Remote Control
To use the remote control, point it towards the front of the digital set top box.
The remote control has a range of up to 7 meters from the set top box at an angle of up to 60 degrees.
The Remote Control will not operate if its path is blocked.
Sunlight or very bright light will decrease the sensitivity of the Remote Control.
-3-

For a basic connection from your set top box to your television set, you can use
VIDEO/AUDIO-R/AUDIO-L connection. For a higher quality connection, use a direct HDMI
connection, as shown below. Connect a audio amplifier use coaxial is a optional.
-4-
System connection

After all connections have been made properly, switch on TV and make sure the unit is connected
to the Main power. Press power button to switch the unit on.
If you are using the unit for the first time or have restored the unit to factory default, the
installation guide menu will appear on your TV screen.
(1) [OSD Language] press RIGHT/LEFT key to select a language.
(2) [Country] press RIGHT/LEFT key to select your country of residence.
(3) [Channel Search] press RIGHT or OK key to begin Automatic channel search.
(4) Once channel tuning is complete, you can start watching TV programs.
Basic Operation
(1) Program Manage Settings
To access the Menu, press the MENU button and select [Program]. Using the RIGHT/LEFT keys
to navigate through the menu,The menu provides options to adjust the Program manage settings.
Select an option and press OK or RIGHT to adjust that setting. Press the EXIT button to exit the
Menu.
-5-
First Time Installation

(a) Program Edit
To edit your program preferences (lock,skip,favourite,move or delete),you will need to enter
the Program Edit Menu.This menu requires a password to access. Enter the default password
“000000”. The master unlock password is “888888”
Set Favourite Channels
You can create a shortlist of favourite programs that you can easily access.
Set Favourite TV or Radio program.
1. Select your desired channel then press the FAVOURITE button.
A heart-shaped symbol will appear and the channel is marked as a favourite.
2. Repeat the previous step to select more Favourite channels.
3. To confirm and exit the Menu,press the EXIT key.
Disable Favourite TV or Radio Channel:
Select the Favorite channel and press Favorite button on the remote control to cancel.
View Favourite Channel
1. While in normal viewing mode,press Favourite button and the Favourite Menu will appear.
2. Press UP/DOWN to browse through your Favourite Channels.
3. Press OK to select your favourite channel.
Delete a TV or Radio Program
1. Select the Program and then press the BLUE button.
A waring message will appear ,Press OK to delete the channel.
2. Repeat the previous step to select more channels to delete.
Skip TV or Radio Channel
1. Select the channel you would like to skip and press the GREEN button.
A skip symbol is displayed. The channel is marked as a skip.
2. Repeat the previous step to skip more channels.
3. To save your settings and exit the menu, press EXIT key.
Disable the Skip Channel function:
Select the Skip channel and press the GREEN button on the remote control to cancel.
-6-
