Alerts Alerts 911 User manual

The user’s guide will explain the functionality and how to set-up GPS Watch/Phone. In order to achieve
all the functions of the GPS Watch/Phone, please be sure to subscribe to Alerts 911 full service GPRS
plan.
Content
1. Appearance and Key Descriptions
2. Sim Card Installation
3. Restoration and Charging
4. Turn ON/OFF
5. Password Setting
6. Working Mode
7. Setting the Phone Numbers
8. Dial /Answer Phone Calls
9. GPS Position
10. Audio Remote Monitor
11. Reminder Function
12. Low Battery
13. Appendix
14. Package Content
Alerts 911 GPS Watch/Phone User’s Manual

1. Appearance and Key Button Functions:
Notes：Long press means to press and
hold key button for 3 sec.
2. Sim Card Installation
2.1 Insert SIM Card 2.2 How to insert the Sim Card
Notes: This kids watch/phone support GSM Quad-band Notes：The metal panel of SIM Card must face up when inserting.
Please make sure the phone power is off
when you install or remove the SIM Card.
Number
Name
Description
1
Power Button
long press the button to power on watch
Backspace key
A. Short press to return the interface of standby module
B. Short press to reject a calls
2
Red \ Hang up
Charging indicator\Low battery indicator\ Hang up key
3
Green \ Calling
Signal Indicator\ Call out key
4
Speed dial- 2
A. Speed calling to the second guardian
B. Long press to call SOS number
5
Speed dial- 3
A. Speed calling to the third guardian
B. Long press to open/close voice prompt
6
Speed dial-1
A.Speed calling to the second guardian
B.Long press to open/close Bluetooth
7
Receiver
8
Loud-speaker
Hand free speaker
9
Adjust the time
Pulling Button to adjust time
10
Dialing Keyboard
Long press “1”as “#” ; Long press “0” as “*”
The Cover of SIM
The metal panel of SIM

3. Restoration and Charging
3.1 Restoration
1）Press the reset key when you install or remove the SIM card
2）To reset watch to factory settings press the button listed in figure 3.1
3.2 Charging
1）Built-in lithium polymer batteries, just changing via a USB cable
2）Charge when watch lights up with red lights, Full Charge = Green Lights
4. Turn ON/OFF
4.1 Turn on
1）Please make sure the SIM card has been inserted correctly.
2）Long press the button to power watch on, watch will light up when turned on.
4.2 After the SIM card has been installed correctly, User will hear the voice prompts “entered the standby mode, self-check normal”
4.3 Once the SIM card is installed incorrectly, User will hear the voice prompts “entered the standby mode, please check the SIM card”
4.4 Once you hear the voice prompt like self-check normal, then this watch phone will check the GPS signal automatically.
4.5 This phone only can be shut down by guardian message “OFF#password”
5. Password Setting
5.1 The default password is the last four digits of IMEI code.
5.2The guardian can change password by sending message to the watch as “MM#old password#new password”
5.3 The new password must be 6 numbers
5.4After successfully creating a new password, the watch will return message as “new password successful setting”
USB for charging
and earphones
Long press this
button and
power on

6. Working Mode
6.1 You can set up three work modes as you want
6.1. The number “1” is “parent’s mode” (Notes: kids can answer and make phone call to anyone, incoming call accompanies ring-tones, vibration,
voice prompts and keyboard LED)
6.1. The number “2” is “kid’s mode” (Notes: kids only can receive the call from guardian and call back to guardian, incoming call accompanies with
ring-tones, vibration, voice prompts and keyboard LED)
6.1 The number “3” is “school mode” (Notes: kids only can receive the call from guardian and call back to guardian, incoming call reminder with
only vibration)
6.2 The guardian can change mode by sending messages to the watch as “MS#password#mode number”
6.3After successfully changing to new mode, the watch will return messages as “mode successful setting”
6.4 You can get the GPS tracking and SOS working in all modes
7. Setting the Phone Numbers
7.1 Any phone and any number can send messages to watch as: “HM#password#Guardian1#Guardian2#Guardian3#SOS number”
7.2 There is no special SOS number when you press SOS button. The watch will call guardians one by one.
7.3 Once the guardian members less than four, edit text as “HM#password#Guardian1#Guardian2”
7.4 After success of the set, the phone number will be assigned to the corresponding side button as follow show:
7.5 After successfully setting the guardian numbers, the watch will return messages as “guardian number successful setting”
8. Dial /Answer Phone Calls
8.1 Answer Phone Calls
1）Automatically answers the calls within 10 seconds
2）Kids answer the calls from guardian button 1 to 3, or press
3）Hang up the calls by pressing or press the power button key
8.2 Dial phone calls
1）In the standby mode, short press the button to make calls to guardian, and you will hear voice prompt as “call out”
2）In parent mode, press the keyboard number and make calls to anybody
3）Long press button 2 calls to SOS number
4）When SOS working, the watch phone will call guardian one by one, and send the positional messages to all guardians
Long press for
power on
Short press for
calls to Guardian1
Short press this
button for calls
to Guardian3
Short press this button for
calls to Guardian2;
Long press this button for
calls to SOS number

9. GPS Position
1) The guardian can get the GPS position by send messages to the watch as “DW#password”
2) The watch will return GPS position messages with Google maps link
3) Login on Computer or smart phone to view coordinates of GPSWatch/Phone
10. Audio Remote Monitor
1) Once the guardian sends messages to the watch as “JT#password”the watch will automatically call back
2) Once the guardian sends messages to the watch as “JT#password#assigned phone number,”then the watch makes the calls to the assigned
number
11. Reminder function
11.1. Alarm
1) The guardian can set the alarm by send messages as“DS#password#alarm time1#alarm time2#alarm time3”, If the setting successful the
watch will return messages as “Alarm successful setting”
2) The guardian can set 3 alarm times, and no need to add colons between numbers, for example: 7AM: 30 is 0730
3) Press any key to stop when alarm is ringing
4) The guardian can shut the alarm off by sending message as “DS#password#0”, then the watch will return message as “alarm have been closed”
5) The guardian can open the alarm by sending message as "DS# password #1", Then the watch will return message as "alarm turned on" if not
the watch will return message as "please set alarm time"
12. Low Battery
Red light Green light
1) Low power prompt will automatically trigger when kids watch/phone is low power, the red light will flash
2) When the power lower than 20% the watch will send message to guardian as “Low power please charge”
13. Appendix
Touch this Green key
for answer the calls
Touch this Red
key for hang up
This is keypad
with 0-9

13.1 Trouble shooting
When the watch/phone may not be functioning correctly, please check the clauses listed below to solve any minor issues. If your problem can’t
be solved, Please contact anAlerts 911 associate right away..
FAQ:
Reason:
Resolution:
No service
no service or you havenotopenthisservice
Connect to your SIM card provide
SIM card is dirty for well connection
Clear the SIM card
Can’t make
phone call
SIM card damaged
Contact with your SIM card carrier
SIM card put wrong
Reset SIM card
SIM card dirty
Clear the SIM card
low signal
locate in lowsignal, such as in high building or
underground
Move to outdoor
During the busy talking time low signal
please avoid the busy talking time
Fail to turn on
low power
please charge it
Can’t charge
voltage don’t match with the watch phone
standard
use the voltage as the watch phone required
the charge is not standard
please charge, use the watch phone matching
with
bad connection
check the USB cable
14. Package Content:
1 x GPS Watch/Phone
1 x USB Charging Cable
1 x Power Cable
Notes: USB charging cable: when the watch phone is low power, it can be connected to PC or charger to charge via USB cable.
