RC Kill Switch Dear Customer,
thank you for your purchase of electronic switch RC Kill Switch.
It is an electronic switch for starting spark ignition of gasoline engines
and it can be activated by the transmitter (a free channel is
needed) or by the button on the device itself; a high brightness LED
indicator shows the status of the device (ON/OFF).
The RC Kill Switch brings together an electronic switch, a voltage
regulator and a photocoupler that assures the insulation of the
receiver from electronic ignition interferences.
It is ready to use and any setting is required; anyway the user can
activate the fail safe function in case of loss of signal from the
receiver.
It needs a dedicated battery 4,8-9V and the output voltage can be
set by the user from 5 to 7,4V
FIXING:
CONNECTION RC Kill Switch Spark ignition unit:
Drill a rectangular hole of 53x23,5mm for placing the device.
Position and fix it with the 2 self-threading screws supplied.
It is recommended to realize an installation assuring the right
insulation from engine vibrations.
Connect the 2 wires cable with UNI connector (output of the switch)
to the spark ignition unit.
Connect the 2 wires cable with BEC connector (input of the switch)
to the battery you intend to use for supllying the spark ignition unit.
CONNECTION RC Kill Switch-Receiver:
Connect the 3 wires cable to the receiver into the channel you want
to use for controlling the Kill Switch.
The channel should correspond to a 2 position switch of the
transmitter with ATV and D/R set at 100%.
CONNECTIONS
V1.1
The RC Kill Switch is ready to use after you have fixed the device,
carried out the connections as shown into the “Connection”
paragraph and set the right output voltage for your engine unit.
(See the following 2 paragraphs)
When you turn the device on:
- if the FailSafe function is activated the LED emits 3 rapid flashes
- if the FailSafe function is not activated the LED emits 2 series of 3
rapid flashes.
For starting the engine use the switch on the transmitter or press the
button on the device.
The LED on indicates that the switch is closed and that it is supplying
the spark ignition of the engine.
USAGE
PICTURE 1
®
Cod. 90040210
Connect to
receiver
ON/OFF
Button
Blue LED
Connect to
magnetic sensor
Connect to engine
spark plugs
Connect to
Spark ignition
Unit input
External battery input
from 4.8V to 9V
WARNING:
- Do not connect the Kill Switch to the receiver with inverted
polarity: connections with inverted polarity damage the device.
- Do not connect the battery to the Kill Switch with inverted polarity;
inversion of polarity damages the voltage regulator of the switch.
- Do not connect the Kill Switch output to the spark ignition unit with
inverted polarity; inversion of polarity may damage the spark
ignition unit and the voltage regulator of the device.
- Do not cause short circuits at the output of the switch: short circuit
damages the inner voltage regulator.
USAGE MANUAL
Photocoupled electronic switch with
voltage regulator

TRANSMITTER SETTING:
Rest Zone
Switching Zone
CHECK AND CHOICE OF THE FAIL SAFE MODALITY:
BATTERY FOR SUPPLYING THE SPARK IGNITION UNIT:
For using the Kill Switch first of all you have to choose a channel on the receiver controlling it.
Check that the channel correctly respond to the transmitter and that travels (ATV, D/R) are set at maximum values.
We recommend associating the channel to a 2 position return spring switch; if your transmitter doesn't have one, it is possible to use a 2
position switch or a trimmer or a slade.
The (=Kill Switch not activated) corresponds to a signal from receiver with value of ATV minor than -30% (it is recommended
setting the ATV from transmitter at 100%); when starting the Kill Switch, the signal from receiver must correspond to the rest position.
Check that when you operate on the channel, the (from Kill Switch off to Kill Switch on ), corresponds to a signal from
receiver with ATV higher than +30%
(it is recommended setting the ATV from transmitter at 100%).
Whenever you turn the device on, it check that the signal from receiver corresponds to the rest position; if the signal is not correct, the LED
starts flashing slow for indicating an error and the Kill Switch doesn't activate.
If the signal is correct, the LED on the device flashes in order to show the Fail Safe status:
- 1 series of 3 rapid flashes= Fail Safe is activated
- 2 series of 3 rapid flashes= Fail Safe is not activated
The device features a safety system (Fail Safe) that, if activated, in case of a wrong or missing signal from receiver, forces the Kill Switch to
open; so the spark ignition is no more supplied and the engine turns off.
To verify if Fail Safe is activated or not, proceed as follows:
make sure that the receiver is off, connect the Kill Switch to the receiver into the channel chosen for controlling it; after configuring it, turn
the transmitter on and bring the control to the rest zone.
Turn the receiver on and check the number of flashes of the LED:
-1 series of 3 rapid flashes= Fail Safe is activated
-2 series of 3 rapid flashes= Fail Safe is not activated
To change from a modality to the other, proceed as follows:
make sure that the receiver is off and the Kill Switch is connected to it; press and keep pressed the button on the device and
simultaneously turn the receiver on; release the button and turn the receiver off. Turn on again and check if the number of flashes
corresponds to the modality chosen.
To the Kill Switch you can connect any type of battery having voltage between 4,8V and 9V.
Connect the battery to the 2 wires cable with BEC connector (see picture 1).
Ideal battery is a LiPo 7,4V from minimum 1000 mAh to maximum 2500 mAh.
BEFORE USE
1500us
760us 2290us
Maximum limitMinimum limit
2000us
1000us
-30% +30%
-100% +100%
REST ZONE SWITCHING ZONE
RC Kill Switch not activated RC Kill Switch activated
Undefined Zone
ATV > +30%
SIGNAL > 1640us
SWITCHING ZONE
ATV < -30%
SIGNAL< 1390us
REST ZONE

Connect to
receiver
Connect to
Spark ignition
Unit input
External battery input
from 4.8V to 9V
OUTPUT VOLTAGE SETTING
5V 7.4V
5.5V 7.0V
6.2V
OUTPUT VOLTAGE SETTING
Before using the Kill Switch check carefully that output voltage is correctly set compatibly with your spark ignition unit.
This new concept Kill Switch can be used with both spark ignition units supplied at maximum 5V and last generation LiPo compatible ones.
Using a little screw driver, move the rotary potentiometer to the position corresponding to the desired voltage.
Only after this setting is possible to connect the switch output to the spark ignition unit. .
ATTENTION: a wrong setting of the output voltage may damage the spark ignition unit; always check that the set output voltage is less
than or equal to maximum supply voltage indicated into specifications of your spark ignition unit.
USAGE
After carrying out all connections, checking transmitter configuration, chosing Fail Safe modality and setting the output voltage, the
device is ready to use.
Turn the transmitter on and check that the control of the channel managing it is in rest position.
Turn the receiver on and check the right flashes of the LED.
After one of these 2 actions, the LED starts blinking fast and after 2 seconds the Kill Switch activates the output; the LED turns solid blue and
the spark ignition unit is supplied.
After one of these 2 actions, LED starts blinking fast and after 2 seconds the Kill Switch deactivates the output; the LED turn off and the spark
ignition unit stops being supplied.
Turning on and off the spark ignition unit can be managed by transmitter or manually by the button on the device.
For activating the RC Kill Switch you can act in 2 different ways:
- Press the button on the device for at least 2 seconds
- Move the control on your transmitter from the rest position to the commutation position and keep there for at least 2 seconds (if you
are using a two position switch without return spring or a trimmer/slade, bring it back to the rest position).
When the device is activated (spark ignition unit supplied), you can deactivate it acting in the same 2 ways:
- Press the button on the device for at least 2 seconds
- Move the control on your transmitter from the rest position to the commutation position and keep there for at least 2 seconds (if you
are using a two position switch without return spring or a trimmer/slade, bring it back to the rest position).

53mm
23.5mm
Distance between the holes 60mm
FIXING
Connect to external led
ACCESSORIES
+
_
Positive (RED)
Negative (BLACK)
If you have to mount the device inside your model and you are not able to see the LED, you can use this optional accessory in order to bring
the lighting indicator in a visible position.
Item code: 90010705
Operating voltage: from receiver >5.1V to 9V MAX
Current drain from receiver: 2mA
External battery: 4-5cells
Voltage external battery: from 4.8V to 9V MAX
Output voltage: programmable from 5 to 7.4V
Dropout voltage regulator: 200mV@ 3A
Max load: 3A continuous - 6A peak
Working temperature: -10 up to +60 °C
Nixx, 2s Li.Poli, 2s LiFe
Current drain Switch ON: 10mA
Current drain Switch OFF: 50mA every 6 months
Fail Safe setting: Programmable
52x23x20mm
69x25mm external panel
Dimensions:
Weight: 20g including cables
These specifications may be changed without advance notice.
This is not a toy.
Pay close attention to the following points, as the non
observance of them can destroy the product, nullify your
warranty and lead to property damages or personal severe
injuries!
- Never leave the product unattended while it is switched on, in
use or connected with a power supply. If a defect occurs, it
could set fire to the product or to the surroundings.
- Avoid incorrect connections or connections with reversed
polarity.
- All wires and connections have to be well insulated. Short-
circuits might destroy the product.
- Never allow this product or other electronic components to
come into contact with water, oil, fuels or other conductor liquids,
as these could contain minerals, which are harmful for electronic
circuits. If this happens, stop the use of your product immediately
and let it dry carefully.
- Always wire up all the parts of the equipment carefully. If any of
the connections loosens, due to vibrations, you might damage
your device.
- Never cut off or modify the original plugs
- Never change the polarity of the receiver connectors
- Do not open the product and never solder on the PCB
At the end of its life cycle this product is subject to special
waste disposal and it cannot be disposed with urban
waste
SPECIFICATIONS
WASTE DISPOSAL
WARNING
