1
QUADRIFOGLIO
SEATS
FRONT SEATS WITH MANUAL
ADJUSTMENT
1)
1)
"Sparco" Carbonshell Sport seats
(where provided)
Longitudinal adjustment
Lift lever 1 fig. 1 and push the seat
forwards or backwards.
2)
fig. 1
IMPORTANT Carry out the adjustment
while sitting on the seat involved (driver
side or passenger side).
Height adjustment
(electric)
Move button 2 upwards or downwards to
obtain the required height.
Backrest angle adjustment
Pull lever 3 fig. 1 and accompany the
backrest with the movement of your
torso (operate the lever until the desired
position is reached, then release it).
REAR SEATS
3)
The rear seats allow two passengers.
fig. 2
WARNING
1) All adjustments must be made with the car
stationary.
2) After releasing the adjustment lever,
always check that the seat is locked on the
guides by trying to move it back and forth.
If the seat is not locked into place, it may
unexpectedly slide and cause the driver to
lose control of the car.
3) Always make sure that everyone on
board is seated and wearing their seat belts
correctly.
IMPORTANT
1) The fabric upholstery of the seats has
been designed to withstand long-term wear
deriving from normal use of the car.
Some precautions are however required.
Avoid prolonged and/or excessive rubbing
against clothing accessories such as metal
buckles andVelcro strips which, by applying
a high pressure on the fabric in a small area,
could cause it to break, thereby damaging
the upholstery.
This Supplement integrates the Alfa Giulia Owner Handbook to which it is attached and contains information on the Quadrifoglio
version. For anything not included, refer to the Owner Handbook.
604.90.474 Supplemento Alfa 952Q_GB 9ed.indd 1 19/03/18 09:05

2
BONNET
CLOSING
4) 5)
As it is extremely light, to close the
bonnet, lower it to approximately
16 inches (40 centimetres) from the
engine compartment then apply a slight
pressure. Make sure that the bonnet is
completely closed and not only fastened
by the locking device by trying to open it.
If it is not perfectly closed, do not try to
press the bonnet down but open it and
repeat the procedure.
IMPORTANT Always check that the
bonnet is closed correctly to prevent
it from opening while the vehicle is
travelling. Since the bonnet is equipped
with a double locking system, one for each
side, you must check that it is closed on
both its side ends.
ACTIVE AERODYNAMICS
FRONT MOBILE SPOILER
(Alfa Active Aero)
This is an automatic device adjusted
according to speed, which allows higher
reactivity at average speeds and greater
stability at fast speeds by adjusting the
air flow into the lower part of the car.
The system is not active in temperatures
near or below zero, or when the “Alfa
DNA™ Pro” selector is in the "Normal" or
"Advanced Efficiency" positions.
fig. 3
In case of a fault, the generic failure icon
will light up on the instrument panel
display along with a message which
identifies the type of malfunction.
WARNING
4) Perform these operations only when the
car is stationary.
5) For safety reasons, the bonnet must
always be properly closed while the car is
travelling.
Therefore, make sure that the bonnet
is properly closed and that the lock is
engaged. If you discover that the bonnet
is not perfectly closed during travel, stop
immediately and close the bonnet in the
correct manner.
604.90.474 Supplemento Alfa 952Q_GB 9ed.indd 2 19/03/18 09:05

3
QUADRIFOGLIO
CONTROL PANEL AND ON-BOARD INSTRUMENTS
TFT DISPLAY
fig. 4
1. Tachometer – 2. Digital engine oil temperature gauge with overheating warning light – 3. TFTDisplay
4. Digital fuel level gauge (the triangle on the left side of the symbol indicates the side of the car with the fuel filler)
5. Speedometer.
Apart from the instrument panel display size, there may be small differences according to the version or the end market destination
of the car.
604.90.474 Supplemento Alfa 952Q_GB 9ed.indd 3 19/03/18 09:05

4
SBA (Seat Belt Alert) SYSTEM
REAR SEAT BELT ICON BEHAVIOUR
(where provided)
The icons are shown on the display
(fig. 5) after a few seconds have elapsed
since the ignition device is turned to ON
and disappear after approximately 30
seconds.
After a door closes, or following a change
in belt fastening status, the icons are
shown again for approximately 30
seconds before disappearing.
The icons shown on the display indicate:
1. rear left seat belt;
2. rear right seat belt.
fig. 5
Wear the rear seat belts as shown in fig. 6
and fig. 7.
fig. 6
fig. 7
“Alfa DNA™ Pro” SYSTEM
“Alfa DNA™ Pro” SYSTEM
(Car dynamic control system)
Using the selector (on the central
tunnel) fig. 8, this device allows to select
different car response modes according
to driving style and road conditions:
fig. 8
Ud = Dynamic (sports driving mode)
Un = Normal (mode for driving in normal
conditions)
Ua = Advanced Efficiency (ECO driving
mode for maximum fuel savings).
URACE = track race driving mode.
U= changes the suspension
calibration (where provided).
604.90.474 Supplemento Alfa 952Q_GB 9ed.indd 4 19/03/18 09:05

5
QUADRIFOGLIO
Unlike the other ones, the RACE position
is unstable, therefore, by rotating the
selector to RACE, it will return to its initial
position "d".
The RACE symbol lights up in red on the
selector, when the mode is active.
On the instrument panel display, the
different modes are characterised by
different colours:
UNormal - Blue,
UDynamic - Red
URACE - Yellow
UAdvanced Efficiency - Green
“RACE” MODE
Engagement/disengagement
It is activated by rotating the selector to
position "RACE", the displays light up in
yellow.
IMPORTANT this mode should be
activated on race tracks.
To deactivate the RACE mode, take the
selector to position "RACE" again and the
system will be set to "d" mode.
ALFA ACTIVE SUSPENSION
(AAS)
The vehicle's electronic suspensions
management system is the result of a
sophisticated elaboration of the various
board sensors, aimed at optimizing the
vehicle's performance.
The system continuously monitors the
damping of the suspensions through the
actuator installed on each shock absorber.
In this way, the shock absorbers can be
adjusted to the conditions of the road
surface and to the dynamic conditions
of the vehicle, improving its comfort and
road holding.
The driver can choose between two
calibration types even while driving
(in "d" or "RACE" mode only):
a sportier setting or a more comfortable
one.
By pressing the button, the system
prepares to work with a shock absorber
calibration which favours driving comfort.
fig. 9
In the case of a system failure, the
symbol appears on the instrument
panel display together with a dedicated
message.
604.90.474 Supplemento Alfa 952Q_GB 9ed.indd 5 19/03/18 09:05

6
JUMP STARTING
REMOTE BATTERY CONNECTION POLES
To facilitate operation, the remote poles
of the battery for the jump starting can
be found in the engine compartment: the
battery itself is installed in the boot.
The negative terminal (–) fig. 10 is
positioned next to the right bonnet lock.
fig. 10
The positive terminal (+) can be reached
by lifting the protective flap fig. 11
and is shown in fig. 12.
fig. 11
fig. 12
To carry out the operation, you need to
have the correct cables to connect the
auxiliary battery to the remote poles of
the flat battery.
Usually, these cables have terminals at
the ends and are identified by different
sheath colours (red = positive,
black = negative).
604.90.474 Supplemento Alfa 952Q_GB 9ed.indd 6 19/03/18 09:05

7
QUADRIFOGLIO
SCHEDULED SERVICING PROGRAMME (2.9 V6 engine)
The checks listed in the Scheduled Service Plan, after reaching 90,000 mi (150,000 km)/10 years, must be cyclically repeated
starting from the first interval, thus following the same intervals as before.
Thousands of miles 9 18 27 36 45 54 63 72 81 90
Thousands of kilometres 15 30 45 60 75 90 105 120 135 150
Years 1 2 3 45678910
Check battery charge status with the proper instrument ••••••••••
Check tyre condition/wear and adjust pressure, if necessary.
Check quick tyre repair kit recharge conditions/expiry date
(if provided) ••••••••••
Check operation of lighting system (headlights, direction
indicators, hazard warning lights, boot, passenger compartment,
glove compartment, instrument panel warning lights, etc.) ••••••••••
Check and, if necessary, top up fluid levels (1) ••••••••••
Check exhaust emissions/smokiness ••••••••••
Check the supply/engine control and emissions systems
operation using the diagnosis equipment ••••••••••
Visually inspect conditions of: exterior bodywork, underbody
protection, pipes and hoses (exhaust, fuel system, brakes),
rubber elements (gaiters, sleeves, bushes, etc. ) •••••
Check windscreen wiper blade position/wear •••••
(1) Always only use the liquids shown in the handbook for topping up after having checked that the system is not damaged.
604.90.474 Supplemento Alfa 952Q_GB 9ed.indd 7 19/03/18 09:05

8
Thousands of miles 9 18 27 36 45 54 63 72 81 90
Thousands of kilometres 15 30 45 60 75 90 105 120 135 150
Years 1 2 345678910
Check operation of windscreen washer system and
adjust jets if necessary •••••
Check cleanliness of bonnet and luggage compartment locks,
cleanliness and lubrication of linkage •••••
Visually inspect conditions and wear of front disc brake pads
and operation of pad wear indicators ••••••••••
Visually inspect conditions and wear of rear disc brake pads and
operation of pad wear indicators ••••••••••
Visually inspect the condition and tensioning of the accessory
drive belt(s) ••• ••• ••
Change engine oil and replace oil filter ••••••••••
Spark plug replacement ••
Replace accessory drive belt/s (2)
Replace air cleaner cartridge (3) •••••
Change the brake fluid (4)
Replace passenger compartment cleaner (3) o•o•o•o•o•
(2) Areas that are not dusty: advised maximum distance 36,000 mi (60,000km).The belt must be replaced every 4 years, regardless of
distance travelled. Dusty areas and/or heavy conditions (cold climates, urban driving, long periods of idling): the recommended maximum
distance is 18,000 mi (30,000km). The belt must be replaced every 2 years, regardless of distance travelled.
(3) If the car is used in dusty areas, this cleaner must be replaced every 9,000 mi (15,000 km).
(4) The brake fluid replacement has to be done every two years, irrespective of the mileage.
(o) Recommended operations
(•) Mandatory operations
