Alfalaval SolidC Series User manual

Instruction Manual
IM70821-GB1 2003-06
SolidC Pump

2

Alfa Laval
Company Name
Bjarne Søndergaard
Declaration of Conformity
The designating company
Designation
is in conformity with the following directives with amendments:
- Low Voltage Directive 73/23/EEC
- EMCDirective89/336/EEC
- MachineryDirective89/392/EEC
hereby declare that
Denomination Type Year
Address
Phone No.
Name
Title
Company Signature
Vice President, R & D
Alfa Laval
Albuen 31, DK-6000 Kolding, Denmark
[phone]
Centrifugal Pump SolidC
3

4

The information contained herein is correct at the time of issue but may be subject to change without prior notice.
5
1. Safety .................................................................................................... 6
1.1 Important Information ....................................................................... 6
1.2 Warning Signs .................................................................................. 6
1.3 Safety Precautions ........................................................................... 7
2. Installation ............................................................................................ 8
2.1 Unpacking/Delivery.......................................................................... 8
2.2 Installation ........................................................................................ 9
2.3 Pre-use Check............................................................................... 10
3. Operation............................................................................................. 11
3.1 Operation/Control .......................................................................... 11
3.2 Fault Finding .................................................................................. 12
3.3 Recommended Cleaning ............................................................... 13
4. Maintenance ....................................................................................... 14
4.1 General Maintenance ..................................................................... 14
4.2 Dismantling of Pump/Shaft Seals ................................................... 16
4.3 Assembly of Pump/Single Shaft Seal ............................................. 18
4.4 Assembly of Pump/Flushed Shaft Seal .......................................... 20
4.5 Adjustment of Shaft ........................................................................ 22
5. Technical data ..................................................................................... 23
5.1 Technical Data................................................................................ 23
6. Parts List and Service Kits ............................................................... 25
6.1 Drawing.......................................................................................... 25
6.2 SolidC-1 Pump .............................................................................. 26
6.3 SolidC-2 Pump .............................................................................. 28
6.4 SolidC-3 Pump .............................................................................. 30
6.5 SolidC-4 Pump .............................................................................. 32

6
Unsafe practices and other important information are emphasized in this manual.
Warnings are emphasized by means of special signs.
Always read the manual before using the pump!
WARNING!
Indicates that special procedures must be followed to avoid severe personal injury.
CAUTION!
Indicates that special procedures must be followed to avoid damage to the pump.
NOTE!
Indicates important information to simplify or clarify practices.
General warning.
Dangerous electrical voltage.
Caustic agents.
1. Safety1.1 Important Information
1.2 Warning Signs

7
Installation:
Always read the technical data thoroughly. (See chapter 5).
Always use a lifting crane when handling the pump.
Never start in the wrong direction of rotation with liquid in the pump.
Always have the pump electrically connected by authorized personnel. (See the motor instruc-
tions).
Operation:
Always read the technical data thoroughly. (See chapter 5).
Never touch the pump or the pipelines when pumping hot liquids or when sterilizing.
Never run the pump with both the suction side and the pressure side blocked.
AlwaysAlways
AlwaysAlways
Always handle lye and acid with great care.
Maintenance:
Always read the technical data thoroughly. (See chapter 5).
-Never service the pump when it is hot.
-Never service the pump with pump and pipelines under pressure.
Motors with grease nipples:
Remember lubrication according to information plate/label on the motor.
Always disconnect the power supply when servicing the pump.
All warnings in the manual are summarized on this page.
Pay special attention to the instructions below so that severe personal injury and/or damage to the pump are avoided.
1.3 Safety Precautions1. Safety

8
The instruction manual is part of the delivery. Study the instructions carefully.
The standard delivery does not include the test certificate. This can be supplied on request.
The large pump sizes are very heavy.
Alfa Laval therefore recommends the use of a lifting crane when handling the pump.
2.1 Unpacking/Delivery 2. Installation
Step 3
Inspect the pump for visible transport damages.
Step 1
Always use a lifting crane when handling the pump (see
technicaldata).
CAUTION!
Alfa Laval cannot be held responsible for incorrect unpacking.
Step 2
Remove possible packing materials from the inlet and the
outlet, and remove the plastic film wrapped around the pump.
Avoid damaging the inlet and the outlet.
Avoiddamaging the connections for flushingliquid,if supplied.
Step 4
Always remove the shroud, if fitted, before lifting the pump.
Check the delivery for:
1. Complete pump.
2. Delivery note.
3. Motor instructions.
4. Test certificate, IF ORDERED!I
NOTE!
US pumps have no shroud
NOTE!
US pumps have no shroud

9
Study the instructions carefully and pay special attention to the warnings! Always check the pump before operation.
- See pre-use check in section 2.3
The large pump sizes are very heavy.
Alfa Laval therefore recommends the use of a lifting crane when handling the pump.
2.2 Installation2. Installation
Step 1
AlwaysAlways
AlwaysAlways
Always read the technical data thoroughly (see chapter 5).
AlwaysAlways
AlwaysAlways
Always use a lifting crane when handling the pump (see technical data).
AlwaysAlways
AlwaysAlways
Always have the pump electrically connected by authorized personnel (see the motor instructions).
CAUTION!
Alfa Laval cannot be held responsible for incorrect installation.
Step 2
Ensure that there is sufficient clearance around the pump
(min. 0.5 m) (1.64 ft) .
Step 3
Check that the flow direction is correct.
Step 4
1. Ensure that the pipelines are routed correctly.
2. Ensure that the connections are tight.
Outlet
Inlet
Correct!
Remember
Seal rings!
Few bends
Correct!
Step 5
Avoid stressing the pump.
Pay special attention to:
- Vibrations
- Thermal expansion of the tubes
- Excessive welding
- Overloading
NOTE!
US pumps have no shroud
Avoid
bending
pipelines

10
Step 1
Never start in the wrong direction of rotation with liquid in
the pump.
1. Start and stop the motor momentarily.
2. Ensure that the direction of rotation of the motor fan is
clockwise as viewed from the rear end of the motor.
2. Installation
Study the instructions carefully and pay special attention to the warnings!
Solid C is with impeller screw as standard.
Check the direction of rotation of the impeller before operation.
- See the indication label on the pump.
2.3 Pre-use Check
See indication label!
Correct
Rear view of
motor

11
3. Operation 3.1 Operation/Control
Burning
danger!
Study the instructions carefully and pay special attention to the warnings!
The pump is fitted with a warning label indicating correct throttling.
Step 1
Always read the technical data thoroughly (see chapter 5).
CAUTION!
Alfa Laval cannot be held responsible for incorrect operation/control.
Step 2
Never touch the pump or the pipelines when pumping hot liquids
or when sterilizing.
Step 3
Never run the pump with both the suction side and the pressure
side blocked.
Step 4
CAUTION!
- The shaft seal must not run dry.
-Never throttle the inlet side.
Explosion danger!
See the warning label!
Correct!
Do not run dry!
Wrong
Step 5
Flushed shaft seal:
1. Connect the inlet of the flushing liquid correctly.
2. Regulate the water supply correctly.
Step 6
Control:
Reduce the capacity and the power consumption by means of:
- Throttling the pressure side of the pump.
- Reducing the impeller diameter.
- Reducing the speed of the motor.
R1/8"(BSP)
Tmax = 100oC
(212°F)
Correct!
Inlet
Free outlet
Pmax = 1 bar (water)
(14.5 psi)
Throttling!

12
3. Operation3.2 Fault Finding
Pay attention to possible faults.
Study the instructions carefully.
NOTE!
Study the maintenance instructions carefully before replacing worn parts. - See section 4.1
Problem
Overloaded motor
Cavitation:
- Damage
- Pressure reduction (sometimes to
zero)
- Increasing of the noise level
Leaking shaft seal
Leaking seals
Cause/result
- Pumping of viscous liquids
- Pumping of liquids with high
density
- Low outlet pressure (counter pres-
sure)
- Lamination of precipitates from the
liquid
- Low inlet pressure
- High liquid temperature
- Dry run (See operation/control)
- Incorrect rubber grade
- Abrasive particles in the liquid
Incorrect rubber grade
Remedy
- Larger motor or smaller impeller
- Higher counter pressure (throttling)
- Frequent cleaning
- Increase the inlet pressure
- Reduce the liquid temperature
- Reduce the pressure drop before the
pump
- Reduce speed
Replace:
All wearing parts (See general
maintenance)
If necessary:
- Change rubber grade
- Select stationary and rotating seal ring
in Silicon Carbide/Silicon Carbide
Change rubber grade

13
1 kg (2.2 lb) + 100 l (26.4 gal) = Cleaning agent.
NaOH water
2.2 l (0.6 gal) + 100 l (26.4 gal) = Cleaning agent.
33%NaOH water
0.7 l (0.2 gal) + 100 l (26.4 gal) = Cleaning agent.
53% HNO3water
The pump is designed for cleaning in place (CIP). CIP = Cleaning In Place.
Study the instructions carefully and pay special attention to the warnings!
NaOH = Caustic Soda.
HNO3= Nitric acid.
3.3 Recommended Cleaning3. Operation
Step 1
AlwaysAlways
AlwaysAlways
Always handle lye and acid with great care.
AlwaysAlways
AlwaysAlways
Always use AlwaysAlways
AlwaysAlways
Always use
rubber gloves! protective goggles!
Caustic danger!
Step 2
NeverNever
NeverNever
Never touch the pump or the pipelines when sterilizing.
Water Cleaning agent
Always rinse!
Burning
danger!
Step 3
Examples of cleaning agents:
Use clean water, free from chlorides.
1. 1% by weight NaOH at 70oC
(158°F) .
2. 0.5% by weight HNO3at 70oC
(158°F) .
1. Avoid excessive concentration of the
cleaning agent
⇒Dose gradually!
2. Adjust the cleaning flow to the process
Sterilization of milk/viscous liquids
⇒Increase the cleaning flow!
Step 4
AlwaysAlways
AlwaysAlways
Always rinse well with clean water after the cleaning.
NOTE!
The cleaning agents must be stored/disposed of in accord-
ance with current rules/directives.

14
4. Maintenance
Maintain the pump carefully. Study the instructions carefully and pay special attention to the warnings!
Always keep spare shaft seals and rubber seals in stock.
See separate motor instructions.
4.1 General Maintenance
Step 1
Always read the technical data thoroughly (see chapter 5).
Always disconnect the power supply when servicing the pump.
NOTE!
All scrap must be stored/disposed of in accordance with current rules/directives.
Step 2
Never service the pump when it is hot.
Step 3
Never service the pump with pump and pipelines under pres-
sure.
CAUTION!
Fit the electrical connections correctly if they have been re-
moved from the motor during service (see pre-use check).
Pay special attention to warnings!
Burning danger!
Step 4
Recommended spare parts:
Service kits (see chapter 6).
Order Service Kits from Service kits list (see chapter 6).
Ordering spare parts
Contact the Sales Department.
Atmospherie
pressure
required!

15
4. Maintenance
Maintain the pump carefully. Study the instructions carefully.
Always keep spare shaft seals and rubber seals in stock.
See separate motor instructions.
Check the pump for smooth operation after service.
4.1 General Maintenance
Preventive maintenance
Maintenance after leakage
(leakage normally starts
slowly)
Planned maintenance
Lubrication
Shaft seal
Replace after 12 months:
(one-shift) Complete shaft seal
Replace at the end of the
day:
Complete shaft seal
- Regular inspection for lea-
kage and smooth operation
- Keep a record of the pump
- Use the statistics for plan-
ning of inspections
Replace after leakage:
Complete shaft seal
Before fitting
Lubricate the O-rings with sili-
cone grease or silicone oil
Rubber seals
Replace when replacing the
shaft seal
Replace when replacing the
shaft seal
Replace when replacing the
shaft seal
Before fitting
Silicone grease or silicone oil
Motor bearings
Yearly inspection is recom-
mended
- Replace complete bearing
if worn
- Ensure that the bearing is
axially locked (See motor in-
structions)
The bearings are permantly
lubricated
Pre-use check
CAUTION!
Fit the electrical connections correctly if they have been removed from the motor during service.
(See pre-use check).
Pay special attention to warnings!
1. Start and stop the motor momentarily.
2. Ensure that the pump operates smoothly.

16
Step 5
1. Pull off the O-ring (26) from back plate (25).
2. Unscrew nuts (20) and remove washers (21) and the back plate.
Step 6
1. Remove the stationary seal ring (11).
2. Remove the O-ring (12) from stationary seal ring (11).
4. Maintenance
Study the instructions carefully. The items refer to the parts list and service kits section.
Handle scrap correctly.
: Relates to the shaft seal.
4.2 Dismantling of Pump/Shaft Seals
Step 1
1. Remove screws, spring washers, clamps (55)
and pump casing (29).



Step 4
1. Remove impeller screw (36).
2. Remove impeller (37). If necessary, loosen the impeller by
tapping gently on the impeller vanes.
The shaft can be fixed with a screwdriver in the compression
ring
3. Remove the O-ring (38) from the impeller.
Step 2
Flushed shaft seal:
Unscrew tubes (42) using a spanner.
Step 3
Remove safety guards (22). This is easily done by Lifting out
the safety guards, for exampel with a screwdriver.
Use the tool supplied
Left hand thread

17
4. Maintenance 4.2 Dismantling of Pump/Shaft Seals
Study the instructions carefully. The items refer to the parts list and service kits section.
Handle scrap correctly.
: Relates to the shaft seal.









Step 7
Flushed shaft seal:
1. Remove screws (41) and seal housing (40).
2. Pull out lip seal (43) from the seal housing.
Step 8
1. Remove the complete shaft seal from stub shaft (7).
2. Remove spring (13) and rotating seal ring (14) from the drive
ring (10).
Alternative dismantling of single shaft seal - Front loading
1. Complete steps 1 through 4.
2. Remove stationary seal ring.
3. Remove o-ring (12) from stationary seal ring (11).
4. Remove complete shaft seal from stub shaft.
5. Remove spring (13) and rotating seal ring (14) from the drive
ring (10).
Use the tool supplied
Left hand thread

18
Step 6
Lubricate O-ring (26) and slide it onto back plate (25).
Step 5
1. Clean the sealing surfaces with contact cleaner before fitting
back plate (25).
2. Carefully guide the back plate onto adaptor (16).
3. Fit washers (21) and nuts (22).



4. Maintenance
Study the instructions carefully. The items refer to the parts list and service kits section.
Handle scrap correctly.
: Relates to the shaft seal.
4.3 Assembly of Pump/Single Shaft Seal



Step 1
1. Remove spring (13).
2. Lubricate O-ring (15) and fit it in rotating seal ring (14)
NOTE!
Make sure that O-ring (15) has max. clearance from the sealing
surface.
Step 2
1. Refit spring (13) on rotating seal ring (14).
2. Fit the spring and the rotating seal ring on drive ring (10).
CAUTION!
Ensure that the driver on the drive ring enters the notch in the
rotating seal ring.
Step 3
Fit the complete shaft seal on stub shaft (7).
NOTE!
Make sure that connex pin on the stub shaft enters the notch in
drive ring (10).









Step 4
1. Fit O-ring (12) on stationary seal ring (11) and lubricate.
2. Screw the stationary seal ring into back plate (25).
CAUTION!
Only tighten by hand to avoid deforming the stationary seal
ring.
Use the tool suppliedUse the tool supplied
Use the tool suppliedUse the tool supplied
Use the tool supplied
Left hand threadLeft hand thread
Left hand threadLeft hand thread
Left hand thread

19
4. Maintenance
Study the instructions carefully.
The items refer to the parts list and service kits section.
Handle scrap correctly.
: Relates to the shaft seal.
4.3 Assembly of Pump/Single Shaft Seal
Step 8
Fit safety guards (22).
Step 7
1. Lubricate O-ring (38) and fit it in impeller (37).
2. Lubricate impeller hub with silicone grease or oil.
3. Screw the impeller onto stub shaft (7).
4. Fit impeller screw (39) and tighten.
Step 9
1. Fit pump casing (29), clamps, spring washers
and tighten screws (55).
Alternative assembly of single shaft - front loading
1. Fit rotating seal ring (14) and spring (13) on drive ring (10).
2. Fit complete shaft seal on stub shaft.
3. Fit O-ring (12) onto stationary seal ring (11).
4. Fit stationary seal ring.
5. Complete steps 4 through 1.
CAUTION!
Ensure that the driver on the drive ring enters the notch in the rotating
seal ring.
Use the tool suppliedUse the tool supplied
Use the tool suppliedUse the tool supplied
Use the tool supplied
Left hand threadLeft hand thread
Left hand threadLeft hand thread
Left hand thread

20
4. Maintenance



Use ø63 mm tube!
Step 2
Flushed shaft seal:
1. Fit lip seal (43) in seal housing (40).
2. Lubricate O-ring (44) and slide onto the seal housing (40).
3. Fit the seal housing on back plate (25) and tighten screws (41).
Step 5
Fit complete shaft seal on stub shaft (7) so that connex pin on the
stub shaft enters the notch in drive ring (10).
Step 4
1. Lubricate O-ring (45) and fit it in drive ring (10).
2. Fit spring (13) and rotating seal ring (14) on the drive ring.
CAUTION!
Make sure that the driver on the drive ring enters the notch in the
rotating seal ring.
Step 6
1. Carefully guide back plate (25) onto adaptor (16).
2. Fit washers (21) and tighten nuts (20).
Note: Make sure that holes in the seal housing are in a vertical
position
4.4 Assembly of Pump/Flushed Shaft Seal
Study the instructions carefully.
The items refer to the parts list and service kits section.
Lubricate the rubber seals before fitting them.
 : Relates to the shaft seal.



Step 1
1. Fit O-ring (12) on stationary seal ring (11) and lubricate.
2. Screw the stationary seal ring into back plate (25).
CAUTION!
Only tighten by hand to avoid deforming the stationary seal
ring.
Use the tool supplied
Left hand thread



Step 3
1. Remove spring (13).
2. Lubricate O-ring (15) and fit it in rotating seal ring (14)
NOTE!
Make sure that O-ring (15) has max. clearance from the sealing
surface.
