Alfresco ALF-PZA User manual

24
17
22
21
7
16
16
2
1
23
15
14
25
20
18
26
19
28
1113
10
9
8
9
10
5
6
4
12
3
12
27
BILL OF MATERIAL
NO. PART # DESCRIPTION QTY
1 100-2439 ALF-PZA PIZZA STONE BACK BRACKET 1
2 100-2443 ALF-PZA BUFFER PLATE 1
3 100-2456 ALF-PZA LIGHT MOUNTING PLATE 1
4 100-2470 ALF=PZA BURNER BOX HEAT SHIELD 1
5 100-2474 ALF-PZA BASE LEFT SIDE - HEAT SHIELD 1
6 100-2477 ALF-PZA BASE RIGHT SIDE - HEAT SHIELD 1
7 100-2478 ALF-PZA SMOKER BOX 1
8 200-0057 SCREW 1/4-20 X 1/2 - TRUSS HEAD - PHILPS 2
9 200-0087 WASHER - 1/4" SPRING LOCK- REGULAR - SS 5
10 200-0089 BOLT - HEX HEAD 1/4-20 x 1/2" L 5
11 200-0093 WASHER - PUSH LOCK 1/8" ID X 3/8" OD (LOGO) 2
12 200-0111 SCREW 8-18 X ½ - SELF TAP - 410 SS 45
13 290-0031 LOGO - ALFRESCO 1
14 290-0364 ALF-PZA IR BURNER 1
15 290-0365 ALF-PZA CERAMIC WOOD LOG 1
16 290-0366 ALF-PZA BOTTOM PIZZA STONE 2
17 290-0367 ALF-PZA TOP REFRACTIVE STONE 1
18 510-0782 ALF-PZA FRONT PANEL MAIN ASSEMBLY 1
19 510-0784 ALF-PZA GAS MANIFOLD ASSEMBLY 1
20 510-0785 ALF-PZA OPENING ARCH ASSEMBLY 1
21 510-0786 ALF-PZA OVEN LINER 1
22 510-0787 ALZ-PZA TOP SKIN ASSEMBLY 1
23 510-0788 ALF-PZA GAS LOG SUPPORT 1
24 510-0790 ALF-PZA TOP ASSEMBLY 1
25 510-0791 ALF-PZA LEFT DOOR ASSEMBLY 1
26 510-0795 ALF-PZA RIGHT DOOR ASSEMBLY 1
27 510-0806 ALF-PZA BURNER BOX - BOTTOM STRUCTURE 1
28 510-0815 ALF-PZA ELECTRICAL COMPONENTS 1
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
COMMERCE, CA. 90040
DRAWING NO.: PROJECT TITLE:
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
500-0135 MANUAL
SHEET 1 OF 1
ALF-PZA
ALF-PZA MAIN ASSEMBLY
LAST SAVED BY: »» adrian «« Wednesday, July 10, 2013 3:14:17 PM
DRAWN BY: ADRIAN CRISCI
CREATED: 7/10/2013 2:51:04 PM

14
11
11
4
12
12
1
17
8
10
15
13
10
15
13
3
9
7
5
5
6
2
8
16
BILL OF MATERIAL
NO. PART # DESCRIPTION QTY
1 100-0917 ALF-PZA IR BURNER GAS LINE - 3/8" Ø x 8" - RIBBED 1
2 100-0941 ALF-PZA LOG BURNER GAS LINE - 3/8"Ø X 24" - RIBBED 1
3 100-2484 ALF-PZA IR BURNER PILOT LIGHT - 3/16"Ø AL 1
4 100-2486 ALF-PZA LOG BURNER PILOT LINE - 3/16" Ø AL TUBE 1
5 200-0274 ELBOW 90°- CAST IRON - 1/2" FPT x 1/2" MPT 2
6 220-0275 NIPPLE - 1/2" MPT X 3/8" OD FL 1
7 220-0280 REGULATOR GAS - MAXITROL RV48CL440002 1
8 220-0293 ELBOW 3/8-27 UNS x 3/8" COMP 2
9 220-0298 ALF-PZA MANIFOLD 1
10 220-0438 COUPLING ⅜ NPTF x ⅜ COMPRESSION 2
11 220-0440 PILOT ASSEMBLY - 6210-236 2
12 220-0446 THERMOCOUPLE ASSEMBLY - 36" - 6500-011 2
13 290-0030 KNOB BBQ - ALFRESCO "A" LETTER 2
14 290-0363 ALF-PZA BACK LOG BURNER 1
15 290-0368 VALVE ABCE-W-LH - GAS W/PILOT & LOW ADJ. 2
16 SEE NOTE ALF-PZA LOG BURNER ORIFICE 1
17 SEE NOTE ALF-PZA IR-BURNER NOZZLE ORIFICE 1
NOTE : ORIFICE FUEL SUPPLY REQUIREMENT
ITEM NG - PART # LP - PART #
16 220-0414 220-0415
17 220-0436 220-0437
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
COMMERCE, CA. 90040
DRAWING NO.: PROJECT TITLE:
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0784
SHEET 1 OF 1
ALF-PZA
ALF-PZA GAS MANIFOLD ASSEMBLY
LAST SAVED BY: »» adrian «« Tuesday, July 09, 2013 4:31:07 PM
DRAWN BY: ADRIAN CRISCI
CREATED: 4/30/2013 3:07:48 PM

2
1
5
4
3
3
BILL OF MATERIAL
NO. PART # DESCRIPTION
QTY
1 200-0112 SCREW 10-32 x ¼ x ⅛ x ¼- SHOULDER - ⅛ SOCKET - SS
1
2 200-0206 10-32 KEP NUT 18-8 STAINLESS
1
3 200-0341 NUT WING 10-32 - SS.SLDPRT
2
4 510-0792 ALF-PZA LEFT DOOR HINGE SUBASSEMBLY
1
5 510-0793 ALF-PZA LEFT DOOR SUBASSEMBLY
1
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
COMMERCE, CA. 90040
DRAWING NO.: PROJECT TITLE:
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0791 MANUAL
SHEET 1 OF 1
ALF-PZA
ALF-PZA LEFT DOOR ASSEMBLY
LAST SAVED BY: »» adrian «« Wednesday, July 10, 2013 4:01:35 PM
DRAWN BY: ADRIAN CRISCI
CREATED: 7/10/2013 3:26:21 PM

7
1
3
2
6
5
4
4
BILL OF MATERIAL
NO. PART # DESCRIPTION
QTY
1 200-0112 SCREW 10-32 x ¼ x ⅛ x ¼- SHOULDER - ⅛ SOCKET - SS
1
2 200-0206 10-32 KEP NUT 18-8 STAINLESS
1
3 200-0244 WASHER, FLAT 1/4 TYPE B - REGULAR, SS
1
4 200-0341 NUT WING 10-32 - SS.SLDPRT
2
5 510-0794 ALF-PZA RIGHT DOOR - HINGE SUBASSEMBLY
1
6 510-0805 ALF-PZA RIGHT DOOR SUBASSEMBLY
1
7 510-0809 ALF-PZA DOOR LATCH
1
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
COMMERCE, CA. 90040
DRAWING NO.: PROJECT TITLE:
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0795 MANUAL
SHEET 1 OF 1
ALF-PZA
ALF-PZA RIGHT DOOR ASSEMBLY
LAST SAVED BY: »» adrian «« Wednesday, July 10, 2013 4:00:46 PM
DRAWN BY: ADRIAN CRISCI
CREATED: 7/10/2013 3:35:18 PM

10
6
6
6
6
5
1
7
8
94
23
BILL OF MATERIAL
NO. PART # DESCRIPTION QTY
1 100-2476 ALF-PZA ELECTRICAL BOX COVER 1
2 200-0062 10-32 X 3/4 - PAN HEAD - PHILIPS SCREW 2
3 200-0075 WASHER - LOCK # 10 SPRING REGULAR 2
4 200-0111 SCREW 8-18 X ½ - SELF TAP - 410 SS 6
5 200-0267 10-32 X 1/2 - PAN HEAD - PHILIPS SCREW 1
6 290-0362 LEVEL MOUNT ¼-20 x 2¼ 4
7 510-0813 ALF-PZA IGNITER BRACKET ASSEMBLY 1
8 510-0814 ALF-PZA BULLNOSE BRACKET ASSEMBLY 1
9 510-0814 ALF-PZA BULLNOSE BRACKET ASSEMBLY 1
10 510-0816 ALF-PZA BURNER BOX RIVETED PARTS 1
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
COMMERCE, CA. 90040
DRAWING NO.: PROJECT TITLE:
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0806 MANUAL
SHEET 1 OF 1
ALF-PZA
ALF-PZA BURNER BOX - BOTTOM STRUCTURE
LAST SAVED BY: »» adrian «« Wednesday, July 10, 2013 3:56:12 PM
DRAWN BY: ADRIAN CRISCI
CREATED: 7/10/2013 3:52:00 PM

6
11
11
8
8
4
3
35
9
1
1
2
12
2
7
10
REPLACEMENT LAMP
G940120 - G9 BASE
40 W - 120 VAC
PART# 210-0317
NOTE # 1:
PILOT IGNITER ELECTRODE SHOWN FOR ILLUSTRATION ONLY.
COMPONENT PART NUMBER IS SHOWN ON PIPING DIAGRAM.
ASSEMBLY CONSISTS OF PIPING COMPONENTS ,IGNITER AND WIRING.
NOTE # 2:
ELECTRICAL BOX SHOWN FOR ILLUSTRATION ONLY.
ELECTRICAL BOX IS PART OF BURNER BOX ASSEMBLY 510-0806.
REPLACEMENT GLASS COVER
PART#210-0286
BILL OF MATERIAL
NO. PART # DESCRIPTION QTY
1 200-0007 GROMMET 1/4" Ø - SRB RUBBER 2
2 200-0009 HEYCO STRESS RELIEF BUSHING # 1200 SR 6N3-4 2
3 210-0198 SWITCH - WEATHER BOOT & CAP 2
4 210-0465 IGNITER MODULE (4 POINTS) 1
5 210-0470 SWITCH LIGHT- OFF/ ON 1
6 210-0488 LAMP FIXTURE ASSEMBLY - G9/120V/40W 1
7 210-0499 BLACK POWER SUPPLY CORD 125V 15A 14/3 X 8FT LONG 1
8 210-0501 IGNITER GROUNDING CABLE 2
9 210-0538 SWITCH IGNITER - OFF-[ON] MOMENTARY 1
10 210-0539 IGNITION NEUTRAL WIRE FOR ALF-PZA 1
11 SEE NOTE 1 PILOT BODY AND ELECTRODE 6210-236 2
12 SEE NOTE 2 ALF-PZA ELECTRICAL BOX 1
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
COMMERCE, CA. 90040
DRAWING NO.: PROJECT TITLE:
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0815
SHEET 1 OF 1
ALF-PZA
ALF-PZA ELECTRICAL COMPONENTS
LAST SAVED BY: »» adrian «« Tuesday, July 09, 2013 3:41:58 PM
DRAWN BY: ADRIAN CRISCI
CREATED: 7/9/2013 3:09:55 PM
