Pratica Rocket Express User manual

Rocket Express
Speed Oven
PERFORMANCE
ŸThe Rocket Express rapid cook oven utilizes a combination of
convection heat, high speed impinged air, bottom infrared,
and precision microwave to reduce cook times by more than
80% with chef-quality results. Rocket Express ovens are
equipped with a removable catalytic converter, which break
down grease-laden vapors allowing for ventless operation.
FEATURES
ŸUp to 80 recipes with 6 steps each
ŸUSB port to upload/download recipes
ŸEasy to clean
ŸAdjustable temperature from 86F (30C) to 530F (276C)
ŸUser Friendly Interface
ŸCool to the touch exterior
ŸCertied ventless with easy removable catalytic converter
ŸVariable-speed impingement airow
ŸIndependently controlled top and bottom heaters
ŸVentless side panels allow for zero side clearance installation
ŸAllows the use of metal pans
ŸConstructed from AISI430 (exterior) and AISI304 (interior)
stainless steel
ŸManual mode for on-the-y cooking
ŸWarranty – 1 year parts and labor
STANDARD ACCESSORIES
ŸAluminum Paddle
ŸBaking Stone
ŸMesh Cooking Basket
ŸUSB Drive
1. Blower Motor
2. Impingement Heater
3. Impinged Air
4. IR heater
5. Catalytic Converter
6. Magnetrons
Project
Item No.
Quantity
Prática Products, Inc - USA
675 Town Square Blvd/Suite 200
Garland TX 75040
Phone: [phone]
[email protected]
Prática Klimaquip Ind. e Com. S.A. - Brazil
Rodovia BR 459, km 101
37.550-000, Pouso Alegre-MG
Phone: [phone]
[e-mail]

GENERAL INSTRUCTIONS
ELECTRICAL SPECIFICATIONS
DIMENSIONS
Voltage
(V) Phases Freq. (Hz) Power (kW) Circuit
(A) Consum. (kWh) Cable Socket
Rocket
Express
32A
(2P+T)
USA/
Canada
230 7.2 32
Single 50 5
Europe
220 6.3 32
Single 60 3x4mm²
4.4
Brazil
220 6.3 32
Single 60 4.4
Latin
America 60Hz
32A
(2P+T)
32A
(2P+T)
3x4mm²
3x4mm²
230 7.2 32
Single 50 5
Latin
America 50Hz
32A
(2P+T)
3x4mm²
Rocket Express
Speed Oven
Product dimencions Packing dimensions
Capacity
Rocket
Express
Chamber
Dimensions
Height Width
5 ¾"
146mm
Depth
14 ¼"
362mm
15 ½"
394mm
Height Width Depth Weight Width Depth Weight
194lbs
88kg 242lb 110kg
31 ¹⁄"
800mm
22"
560mm 33 ⁷⁄"
860mm
Height
Ensure that the electrical characteristics of the building network are in
accordance with the technical specications located on the data badge
located on rear panel of the unit. The outlet should be located no more than
6ft / 1.8m away from the unit.
This unit must be properly grounded to avoid electrical shock. This unit is
equipped with a 3-prong plug. This plug must be connected to a properly
installed and grounded outlet. In the event of an electrical short, properly
grounding the unit reduces the risk of electrical shock by grounding the
electrical current. The building electrical is the customer's responsibility.
PRODUCT DIMENSIONS
INSTALLATION
The oven must be installed on a base or counter that supports the weight
of the unit (approximately 194 lbs. / 88 kg)
For proper ventilation, a minimum space of 3" (76mm) between the rear of
the oven and the wall is required.
Do not block the air inlets and exhaust outlets located on the bottom and
rear of the oven.
It is not recommended for the unit to be positioned near stoves, deep
fryers, hot plates and other equipment that releases fat, fumes and heat.
The oven must be installed at a leveled and ventilated location.
Improper installation may void the equipment warranty.
Wall
Clearance
Back
3"
76mm
Right SideLeft Side
0.74 cu.ft
21L
0"
0mm 0" 0mm
27 ⁄"
(700 mm)
11 ⁄"
(294 mm)
40"
(1015 mm)
1 ⁄"
(40 mm)
3 ⁄"
(80 mm)
30 ⁄"
(766 mm)
21 ⁄"
(544 mm)
21"
(532 mm)
21 ⁄"
(536 mm)
25 ⁄"
(636 mm)
1 ⁄"
(40 mm)
17 ⁄"
(441 mm)
3 ⁄"
(100 mm)
25 ¹⁄"
636mm
21"
532mm 31 ³⁄"
806mm
3"
(76 mm)
Exhaust
Outlets
Power
Cable
6 
(1.8m)
Maximum
Distance
Circuit
Breaker
Air Inlet
208 6.3 30
Single 60 3x10AWG NEMA 6-30
4
240 7.1 30
Single 60 3x10AWG NEMA 6-30
4
