Alienware Area-51 m5550 User manual

Alienware Area-51 m5550 Technical Reference
1
Notice
The information in this user’s manual is subject to change without notice.
THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS
CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL
DAMAGES WHICH MAY RESULT FROM THE PERFORMANCE OR USE OF THIS MANUAL.
The information in this user’s manual is protected by copyright laws. No part of
this manual may be photocopied or reproduced in any form without prior written
authorization from the copyright owners.
Copyright January, 2006
All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation. DOS,
Windows 95/98/ME/2000/NT/XP/Vista are trademarks of Microsoft Corporation.
Product names mentioned herein may be trademarks and/or registered trademarks of
their respective owners/companies.
The software described in this manual is delivered under a license agreement. The
software may be used or copied only in accordance with the terms of the agreement.
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
m5550-04-2007-techref.indd 1 4/6/2007 12:29:44 PM

Alienware Area-51 m5550 Technical Reference
2
TABLE OF CONTENTS
PREFACE
Symbols and Conventions
Protecting Your Computer - Avoid Abusive Handling and Adverse
Environments
Chapter Summaries
1. GETTING TO KNOW THE BASICS
Performance Features (10)
System at a Glance (12)
Top View (12)
Front and Rear Views (15)
Side Views (17)
Bottom View (20)
AC Adapter (23)
LED Status Indicators (24)
Keyboard Features (25)
Function (Quick) Keys (25)
Windows Keys (26)
Embedded Numeric Keypad (26)
Touch Pad (27)
Graphics Subsystem (28)
Adjusting the Display Brightness (28)
Extending the Life of the TFT Display Panel (28)
Opening and Closing the Display Panel (28)
Audio Subsystem (29)
Adjusting the Volume in Windows (29)
Voice Recording (29)
Modem and Modem Setting (29)
m5550-04-2007-techref.indd 2 4/6/2007 12:29:44 PM

Alienware Area-51 m5550 Technical Reference
3
2. BIOS SETUP AND SECURITY
Entering the BIOS Setup Screen (33)
Leaving the BIOS Setup Screen (33)
BIOS Action Keys (33)
Modifying the BIOS Settings (34)
Main Setup (34)
Boot Setup (34)
Security Setup (36)
Power Setup (37)
Exit Setup (37)
3. BATTERY POWER & POWER MANAGEMENT
The Battery Pack (39)
Lithium-Ion Battery Technology (39)
Battery Low-Power Warning (39)
Installing and Removing the Battery Pack (41)
Charging the Battery and Charging Time (42)
Checking the Battery Level (42)
Prolonging the Battery’s Life and Usage Cycles (43)
Using Windows Power Options (44)
Windows’ Power Schemes (44)
Suspend Modes (46)
Power Button Action (47)
Low Battery Warning (48)
Power Menu Quick Access (49)
Windows’ Power Plans (50)
Suspend Modes (52)
Power Button Action (53)
Low Battery Warning (54)
Power Menu Quick Access (55)
m5550-04-2007-techref.indd 3 4/6/2007 12:29:44 PM

Alienware Area-51 m5550 Technical Reference
4
4. UPGRADING YOUR COMPUTER
Upgrading the Hard Disk Drive (57)
Upgrading the System Memory (60)
Installing a memory module (DIMM) into the system (61)
Adding a Mini-PCI Type Wireless LAN Card (Optional Device) (63)
Installing a Mini PCI Card to the System (64)
5. TROUBLESHOOTING
First Step (67)
Audio Problems (68)
Hard Disk Problems (69)
Optical Drive Problems (71)
Display Problems (72)
Keyboard and Mouse Problems (73)
CMOS Battery Problems (74)
Memory Problems (74)
Modem Problems (75)
Network Adapter / Ethernet Problems (76)
PC Card / PCMCIA Problems (77)
Performance Problems (78)
Firewire (IEEE1394) and USB2.0 Problems (79)
APPENDIX A Product Specification (80)
APPENDIX B Agency Regulatory Notices (85)
m5550-04-2007-techref.indd 4 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
5
Preface
Using This Manual
This User’s Manual contains general information about the hardware and software
setup, troubleshooting, and technical specifications of the notebook computer.
Symbols and Conventions
The following conventions and symbols are used in this manual:
• When keys are to be pressed at the same time, a plus (+) symbol is used. For
instance, Fn+F7 means holding Fn and F7 keys at the same time.
• When a series of clicking actions is needed in the Windows O/S, [ ] and >
symbols are used. For instance, [Start > Settings > Control Panel >
Display] means clicking the Start icon first, then the Settings, then
the Control Panel, then the Display icon.
• When you need to make a selection with the touch pad (or mouse), you will
be asked to ’select’, ‘click’, ‘double-click’, or ‘right-click’ the item.
Note: Text in this format and symbol indicates specific instructions, commentary,
sidelights, or any additional information or notes that you should be aware of.
Warning: Text in this format and symbol indicates that failure to comply with the given
instructions or information could result in damage to your computer or could cause
bodily harm or loss of life.
m5550-04-2007-techref.indd 5 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
6
Protecting Your Computer - Avoid Abusive Handling and Adverse
Environments
Following the advice below will help ensure that you get the most out of your investment.
Your computer will serve you well if you take good care of it.
• Do not expose the computer to direct sunlight or place it near sources of heat.
• Do not subject it to temperatures below 0oC (32oF) or above 35oC (95oF).
• Do not expose the computer to magnetic fields.
• Do not expose the computer to moisture or rain.
• Do not spill water or liquid on the computer.
• Do not subject the computer to adverse shock and vibration.
• Do not expose the computer to dust and dirt.
• Do not place objects on top of the computer to avoid damaging the computer.
• Do not place the computer on rocky surfaces.
Here are some ways of taking care of your AC adapter.
• Do not connect the adapter to any devices other than your computer.
• Do not let water get into the adapter.
• Do not block the ventilation airway of the adapter.
• Keep the adapter in a cool and ventilated place.
• Do not step on the power cord or place heavy objects on top of it.
• Carefully tuck away the power cord and any cables away from
pedestrian traffic.
• When unplugging the power cord, do not pull on the cord itself. Instead pull
on the plug.
• Keep the adapter away from children.
• The total ampere ratings of the equipment plugged in should not exceed the
ampere rating of the cord if you are using an extension cord.
• The total current rating of all equipment plugged into a single wall outlet
should not exceed the fuse rating.
• Do not connect the other AC adapter to your notebook. This notebook
exclusively uses the AC adapter: Liteon PA-1900-05 (90W), Liteon PA-1900-
06 (90W), Lishin LSE0202D2090 (90W), Lishin LSE0202C2090(90W)
m5550-04-2007-techref.indd 6 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
7
When cleaning the computer, observe these steps:
1. Power off the computer and remove the battery pack.
2. Disconnect the AC adapter.
3. Use a soft cloth dampened with water. Do not use liquid or aerosol cleaners.
Contact your dealer or see your service technician if any of the
following occurs:
• Computer has been dropped or the body has been damaged.
• Liquid has been spilled into the computer.
• The computer does not operate normally.
Cleaning the Ventilation Grills:
It is suggested that you clean the ventilation grills regularly to maintain optimal
thermal regulation of the notebook. To do this, you may use a soft brush or a
vacuum cleaner (with appropriate head adapter) to remove the dust buildup on the
ventilation grills.
m5550-04-2007-techref.indd 7 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
8
Chapter Summaries
The following is a summary of the available chapters and appendices in this manual.
Chapter 1: Getting to Know the Basics
In this chapter, you will learn the basic operations and features of your computer. It
gives you a general understanding of the components of your computer.
Chapter 2: BIOS Setup / Security
In this chapter, you will learn how to change various firmware settings and what the
settings mean. Also, you will learn how to take advantage of the built-in security
feature provided by the BIOS.
Chapter 3: Battery Power & Power Management
In this chapter, you will learn the fundamentals of power management and how to use
them to achieve longer battery life.
Chapter 4: Upgrading Your Computer
In this chapter, you will learn how to upgrade the system memory and the hard disk
drive, and how to install wireless mini PCI card.
Chapter 5: Trouble-Shooting
In this chapter, you will learn how to solve common hardware and software problems.
Appendix A: Product Specification
In this section, you will find a list of the computer’s system specifications.
Appendix B: Agency Regulatory Notices
In this section, you will find the general electro-magnetic and safety regulatory
information.
m5550-04-2007-techref.indd 8 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
9
CHAPTER ONE
GETTING TO KNOW THE BASICS
This chapter introduces the features and components of the computer.
m5550-04-2007-techref.indd 9 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
10
Performance Features
High Performance Processor with Calistoga Chipset
The notebook PC is equipped with a powerful Mobile Intel Core 2 Duo processor.
Together with the latest Calistoga chipset and technologies, the system offers
advanced PC performance.
Advanced Graphic Engine
The PCI-Express high-end graphics engine offers excellent graphics performance
for the most demanding professionals or gamers. The advanced graphics chip also
incorporates a hardware-based motion-compensation engine, which gives you smooth
MPEG video playback. DirectX 9 graphics capability also adds realism to PC games.
LCD Display
The computer is equipped with a non-wide (16:10) 15.4” TFT display panel for the best
cinematic viewing experience.
Serial ATA Hard Disk Drive Support (on certain models)
The serial ATA bus offers higher data throughput than the traditional parallel ATA bus.
This gives you optimal hard drive performance.
ExpressCard Technology
ExpressCard is the next-generation of the PC Card standard. The bus interface is based
on the two standards: PCI Express for high-performance I/O and USB2.0 for a variety
of devices.
Expandability
The system offers an upgradeable hard disk drive and 2 DDR SDRAM sockets for
expansion, allowing the user to easily increase the storage and system capacities as
the need arises.
Built-in Multiple Card Reader
m5550-04-2007-techref.indd 10 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
11
The built-in 4-in-1 card reader lets you access many of the portable media formats (SD
Card, MMC Card, MS Card, and MS Pro Card).
Ethernet Port
The system provides a built-in 10/100/1000Mbps Ethernet network adapter for high
bandwidth network connection.
Firewire (IEEE1394 / 1394a) and USB2.0 Ports
In addition to a full array of built-in I/O ports, the computer offers IEEE1394 for ultra
high-speed connection to high bandwidth digital video devices and USB2.0 ports to
connect to any USB-based peripheral devices.
Wireless LAN
The internal Wireless LAN module allows your notebook to connect wirelessly to other
802.11-enabled systems, devices, or a network.
m5550-04-2007-techref.indd 11 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
12
System At A Glance
Top View
1. LCD Latch
The LCD latches lock / unlock the LCD panel.
2. LCD Display
The panel is where the system content is displayed.
m5550-04-2007-techref.indd 12 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
13
3. Keyboard
The keyboard is used to enter data. It has an embedded numeric keypad and cursor
control keys. (See Keyboard Section for details.)
4. Touch Pad
The touch pad is a built-in pointing device with functions similar to a mouse.
5. Built-in Microphone
The built-in microphone records sound.
6. Touch Pad Disable / Enable Button
The button enables or disables the Touch Pad function.
7. Built-in Stereo Speakers
The built-in speakers output the sound in stereo.
8. LED Status Indicator
The LED Status indicators reveal the status of these functions: Numeric keypad, cap
lock, scroll lock, WLAN module enabling and disabling and also the ODD and HDD
activities. (See the LED Status Indicator Section for details.)
The LED Status indicators also reveal the status of the system power state and battery-
charging state. See the LED Status Indicator Section for details.
9. Power / Suspend Button
The power/suspend button turns the notebook on and off and it also acts as a system
suspend key. Press momentarily to turn on the system. Press and hold for at least 4
seconds to turn off the system. How this key behaves can be defined in the [Start >
Settings > Control Panel > Power Options > Advanced] menu. Press the power / suspend
button again to return from the suspend mode. (See Chapter 3 for more details on the
system suspend function.)
m5550-04-2007-techref.indd 13 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
14
Note: When the system power is initially turned on, the Scroll-lock, Cap-lock, and
Numeric keypad LED indicators will light up momentarily to indicate the start of the
Power-On sequence.
10. Silent Mode Button
Pressing the key enables the system to lower its power usage; therefore the fan speed
is reduced to achieve the lowest operating noise.
You may need to go to BIOS Setup to enable Silent Mode for this button. See Chapter 2
for details.
11. Outlook Express Quick Key
Pressing the button launches Outlook Express in Windows.
12. Internet Explorer Quick Key
Pressing the button launches Internet Explorer in Windows.
13. Windows Media Player Quick Key
Pressing the button launches Media Player in Windows.
m5550-04-2007-techref.indd 14 4/6/2007 12:29:45 PM

Alienware Area-51 m5550 Technical Reference
15
Front and Rear View
Warning: Do not place any heavy objects on the top of the notebook. This may damage
the display
1. Wireless On/Off Switch
Use the switch to disable or enable the Wireless function.
2. Power Jack (DC-in)
The DC-out jack of the AC Adapter connects here and powers the computer.
3. Modem Port
This is where you plug the phone jack (RJ-11) for fax/modem functions.
4. Battery Pack
The battery pack is a built-in power source for the notebook.
m5550-04-2007-techref.indd 15 4/6/2007 12:29:46 PM

Alienware Area-51 m5550 Technical Reference
16
5. Ventilation Grill
The fan grill is where air is exchanged to dissipate the internal heat. Do not block this
airway.
6. Kensington Lock Key Hole
A Kensington-type security lock latches to this keyhole for anti-theft purposes.
m5550-04-2007-techref.indd 16 4/6/2007 12:29:46 PM

Alienware Area-51 m5550 Technical Reference
17
Side Views
Warning: Do not place any heavy objects on the top of your notebook. This may
damage the display
1. Audio Volume Dial
Use the volume dial to control the loudness of the speakers.
2. Stereo Headphone / SPDIF-out Jack
The stereo headphone jack (3.5-mm diameter) is where you connect the headphones
or external speakers. Alternatively, you may connect the SPDIF output to an external
DTS, AC3, or PCM sound processor / decoder in your home stereo system.
3. Microphone Jack
The microphone jack (3.5-mm diameter) is where you connect a microphone.
4. Optical Drive and Disk Eject Button and Manual Eject Key Hole
If your computer comes with the Combo drive, DVD-RW, DVD+RW, or DVD-Dual drive,
you may save data onto a CD-R / CD-RW or DVD-RW disc. Press the eject button to eject
the disk tray. The manual eject keyhole allows you to manually eject a jammed disk.
m5550-04-2007-techref.indd 17 4/6/2007 12:29:46 PM

Alienware Area-51 m5550 Technical Reference
18
5. USB2.0 Port (x2)
The Universal Serial Bus (USB2.0-compliant) port allows you to connect a wide variety
of devices to your computer at a rate of up to 480 Mbps. This port conforms to the
latest USB2.0 plug-and-play standards.
6. DVI-I Port
The DVI-I video output port is for connecting the external LCD monitor or projector.
7. TV (S-Video) Port
The S-Video port permits you to redirect the screen output to a television set or any
analog video playback device. This TV Port is copyright protected; when a DVD movie is
played, the output is scrambled to prevent analog recording.
8. Ethernet / LAN Port
The port connects to a network hub via the RJ-45 cable and also conforms to
10/100/1000Base-TX transmission protocol.
9. 4-in-1 Card Reader
The 4-in-1 Card Reader supports SD Card, MS Card, MMC Card, and MS-Pro Card.
10. Firewire / IEEE1394 / 1394a Port
This is a high-speed serial data port. You may connect any Firewire-ready device to this
port.
11. USB2.0 Port (x1)
The Universal Serial Bus (USB2.0-compliant) port allows you to connect a wide variety
of devices to your computer at a rate of up to 480 Mbps. This port conforms to the
latest USB2.0 plug-and-play standards.
m5550-04-2007-techref.indd 18 4/6/2007 12:29:46 PM

Alienware Area-51 m5550 Technical Reference
19
12. ExpressCard Slot
The slot is where ExpressCard (Type 54) is inserted. ExpressCard Type 54 allows
insertion of 54mm and 34mm cards. ExpressCard integrates both the PCI-Express bus
technology and USB2.0 standards.
m5550-04-2007-techref.indd 19 4/6/2007 12:29:46 PM

Alienware Area-51 m5550 Technical Reference
20
Bottom View
1. Battery Pack and Battery Latch
The battery pack is a built-in power source for the notebook. Slide the battery latch to
release the battery pack.
2. Hard Disk Drive Cover
The system’s hard disk drive is located under the cover. The HDD can be upgraded to a
larger capacity. (See Chapter 4 for instructions on an HDD upgrade.)
m5550-04-2007-techref.indd 20 4/6/2007 12:29:46 PM
