Allegro Classics FLEX UMBRELLA Assembly instructions

FLEX UMBRELLA
INSTRUCTIONS FOR ASSEMBLY AND
RECOMMENDATIONS FOR USE
READ THIS HANDBOOK IMMEDIATELY
These instructions have to be handed over to the end-user of the product who has to read and keep them.
These instructions are provided for an easy set-up of your FLEX and for your safety. It is essential that the given
instructions are followed carefully.
Failure to do so may resultininjury topeople or damage to materials. If in doubt always contact a technical expert.
∆This symbol indicates very important information. Strictly follow instructions accompanied by this symbol. This
does not mean that the other information contained in this handbook is not important.
Keep this handbook for future reference.
IMPORTANT SAFETY INSTRUCTIONS
∆APPLIES TO ALL IN THIS SECTION
1. TRUCTION
Please read and follow all the instruction. Only one manual is supplied for all the possible combinations of the
FLEX.
Damage or injuries may result if the FLEX is not assembled and used as described in the
instruction.
For safe use it is essential that anyone using the FLEX read all the instruction in advance.
Only persons familiar with the safety aspects of the FLEX should operate the
FLEX.
2. CAUTIONS
The FLEX principally isa protection from the sun, not a protection against inclement weather. It
must be closed in presence of strong winds or thunderstorms, as well as heavy rain or snow
(danger of water pooling on the cover).
Always close the FLEX when not in use, and consider using the optional storage cover
when leaving it unattended for longer periods.
Each freestanding base must be weighed down with a minimum weight of
550 lbs using concrete pavers 24"x24"
6 pavers should be used per base, or a minimum of 4 pavers PLUS heavy planters
filled with sand or gravel. 24"concrete pavers are available at most building supply stores and landscape centers.

ASSEMBLY INSTRUCTIONS
COMPONENTS (pict. 1, 2A, 2B, 2C, 3):
(Fig. 1) Cover contained in one carton composed of the following parts: sliding canopy A, Roll fabric panels, 2 long crossbars C,
2 short crossbars D, castings Rand R' with a handwheel S, an Allen key W, screws to secure fabric panels.
(Fig. 2A): Cantilever pole F, cantilever pole G,
(Fig. 2B) Pair of upright poles E, screws e’’ and an Allen key e’’’ fixed on the poles.
(Fig. 2C) Opening rod I
(Fig. 3)2 bases contained in two cartons composed of the following parts: base Lfor floor slabs 24"x24" and 2 stabilizers M
and a hardware bag H, unless the unit was ordered with Ground Insert Bases or Deckmount Plates
BASES AND POLES ASSEMBLY (pict. 4, 4A, 5, 5A)
1. Take out the content of the bag of hardware (H).
2. (Fig.4) fix the stabilizers Mand the upright pole (E) to the base (L).
Important: the screws (h) must be inserted with their head facing down.
The drain hole on the bottom of the poles E should face back towards the base slabs.
∆CAUTION: tighten the bolts well.
3. (Fig. 5) SODFH the bases (L) at the correct distance IRU the FDQRS\VL]H DVSHUGLVWDQFHWDEOHRQSDJH
7he GLVWDQFHVLQGLFDWHGDUHIURPFHQWHUWRFHQWHU
∆CAUTION: make sure that the bases are perfectly aligned, horizontal and on the same level on the ground.
For installation of Deck Mount Plates and Ground Insert Bases take note of the orientation and spacing
indicated on the drawings on page 7.
4. (Fig.4A) Place 4pavers 24"x24" in each base as shown in the picture.
5. (Fig.5A) Join upright poles E with the cantilever poles F e G. To join upright and cantilever poles unscrew the screws e” on
both sides of the upright poles E, insert the cantilever poles and fix the screws e” with an Allen key e’’’.
6. Put additional weight on each base until the minimum weight of 550 lbs is reached. As an example, 2 more pavers,
or concrete flower pots of adequate size, filled with sand or gravel, may be used.
INSERTING THE CROSSBARS INTO THE SLIDING CANOPY (Pict.6, 7, 8, 9, 9A, )
1. (Fig. 6) Unscrew 4 screws Q and join 2 crossbars C with 2 crossbars D and screw the 4 screws Q.
2. (Fig. 7) Align the sliders P and P’ as shown in the picture.
ATTENTION Align the crossbars C+D with the screws Qfacing upwards.
3. (Fig. 8) Insert the crossbars into the sliders P e P’
4 (Fig.9) Join the casting R to the crossbars C+D and fix the screws Ywith the Allen key W. Remove the hand wheel S,
the washer s’ from the casting R but don’t remove the spring r.
5 (Fig. 9A) Join the casting R’ to the crossbars C+D making sure that 2 ends of the belt are not tangled or twisted and fix
the screws Y with the Allen key W. Remove the hand wheel S, the washer s’ from the casting R’ but don’t remove the
spring r.
6 After FRPSOHWLQJ the above VWHSV you can mount the sliding canopy on the poles, for details please see the next section
MOUNTING THE SLIDING CANOPY ON THE POLES (Fig.9-10-10A-11-12-12A-12B)
∆CAUTION: To avoid damage the operation has to be done simultaneously by two persons with 2 step ladders.
Important: Before attaching the sliding canopy to the poles, decide on which side you would like to operate the crank.
1. (Fig. 10) Raise the sliding canopy. Make sure that on the castings R-R’ the spring r is installed according to the Fig.
10A.
2. (Fig. 10A) Join 2 castings R eR’ to the poles and screw on the hand wheel S putting the washer s’ between Sand the
castings on the poles.
3. (Fig.9) Push 2sliders P' against the casting R. Fix 2 sliders P’ so that the stem of 2 hand wheels J is inserted into the holes
of the crossbars C+D.
4. (Fig.12- Fig.12A – 12B) unscrew the handwheel r’’ from the casting R. Pull the belt support V and insert it in the casting R
and lock it replacing the handwheel r’’. Important: make sure that the belt is not tangled or twisted
5. (Fig.11) The Flexy is now ready to be used.

USE OF THE FLEXY (Fig.13, 14, 14A)
1. (Fig.13) To operate the Flexy insert the Opening rod Iin the opening mechanism XX, keeping the rod perpendicular to the top.
2. To tilt the canopy follow these steps:
(Fig.14A - 14) Loosen the hand wheel S on both sides. The teeth of the casting must be fully separated to allow free
movement of the top.. Re-tighten both handwheels S, making sure that the the teeth of both castings are fully engaged.
APPLICATION OF THE OPTIONAL PROTECTIVE COVER
1. Close the sliding canopy Acompletely.
2. Put on the protective coverand fasten it with the snap buttons, ties and velcros.
∆CAUTION: always close the TENDASOL FLEXY in presence of strong winds or
thunder storms, as well as heavy rain (danger of waterpockets on the cover), or whenever it is not under supervision.
APPLICATION OF OPTIONAL VALANCES
In the application of valances it is recommended to apply the lateral valances first
1. To apply lateral valances, slide into the empty groove of the outermost ribs.
2. Fix each end of the welt with a screw same as the main panels.
3. The frontal valances are fixed to the individual ribs by snap buttons fastened to the rib ends.
REMOVAL AND RE-INSTALLATION OF CANOPY PANELS (Page 14)
1. Remove screws from both sides of the ribs.
Push the end of the panel outward removing it completely from the ribs.
2. To re-install the panel insert the weltsinto the grooves of the ribs. Take the panel with both hands and slide
it in all the way.
3. Insert the screws and fasten the welt on each end as shown on page 14.
MAINTENANCE AND CARE
CLEANING CANOPY PANELS
The panels can be cleaned by hand with a smooth cloth, lukewarm water (about 30°C ≈85°F) and a common detergent for delicate
fabrics. After extensive rinsing the material has to be dried. To extend the life span of the fabric, it is advisable not to perform
this operation in the bright sun.
For washing in industrial washing machines, take the panels off the structure to have them washed with a mild detergent, delicate
program, extensive rinsing and water temperature not exceeding 40°C (≈110°F). Have them air dried (do not tumble dry!) and
do not iron.
To maintain or restore waterproofing on your panels please use 303 FabricGuard after cleaning, available at
http://www.303products.com/303r-fabric-guard-16oz.html
STORING THE FLEXY AT THE END OF THE SEASON
To extend the life span of the product, it is advisable to disassemble and store the awning away in a dry place at the end of the
season. Before storing your FLEXY away, clean the structure with a damp cloth and dry it. For the cleaning of the
cover see the preceeding paragraph.
∆CAUTION: Check the integrity of all components. Should any part be damaged contact the dealer where it was
purchased and order the required spare parts.
Touch up any possibly chipped paint. Lightly lubricate all moving parts with silicon spray.
Important: to avoid damage caused by mold or oxidation never put your TENDASOL FLEXY away when it is wet or damp.

R
R'
S
B
C
C
D
Fig. 1
A
D
e'''
e''
e''
e''
e''
S
W
Fig. 2A Fig. 2B Fig. 2C
Fig. 3
G
F
I
L
L
M
MMM
E
E
HH

Fig. 4A
L
L
N
N
e''
e''
e'''
Z
Fig. 4
M
M
h
L
E
E
G / F
Fig. 5
Fig. 5A
Tab. 1

Q
C
C
D
D
Fig. 6
Q
Q
Q
Q
Q
Q
Q
Q
Fig.7
SR
P'
J
J
R'
A
P
C + D
C + D
C + D
C + D
S
R
Y
Y
J
J
Fig. 8
P'
P

Fig. Fig. A
S
s'
rR
W
W
Y
Y
J
J
P'
P'
C + D
C + D
C + D
R'
S
s'
r
WY
W
Y
S
s'
Ss'
r
r
R'
R
G
F
E
E
Fig. 10

Fig. 10A
r
s'
S
R /R'
Fig. 11

Fig. 12
Fig. 12A
r''
R
R
v

r''
R
xx
I
Fig. 12B
Fig. 13

Fig. 14Fig. 14
Fig. 14A
S

Flex Panel Fastening Instructions
In order to make the Flexy Panels easier to install, with a cleaner look, we have updated
the process to fasten the panels into the track.
Slide the panel into the tracks on the
bottom of the support arms, making sure
the white welt strip is facing up to the top
of the awning, which is the rounded side of
the support arm
Position the panel so the finished edge of
the fabric is flush with the end of the
support arm, and grab one of the included
fastening screws
Start the screw so it will pinch the welt
cord in the track, making sure you do not
push back the panel in the process. Note
that the screw needs to start in the small
gap between the welt and the aluminum
groove
Turn in the screw carefully – it will grab
both the welt and the aluminum and lock
the panel firmly in position
The finished look from top. Note the screw
head is cleanly flush with the end of the
support arm. Repeat process on the
opposite end. You will need to stretch the
panel slightly to be flush on that side as
well, giving the panel a smooth, wrinkle
free appearance

IMPORTANT MAINTENANCE ADVISORY
The crank-and-belt mechanism on our Flex is designed to provide smooth,
effortless opening and closing of our sunshade for man ears.
If ou experience higher than usual resistance operating the crank, or can hear
squeaks or squeals, please stop operation and refer to the advisor below.
• NEVER force the crank handle to move the canop . This ma cause the pulle to
skip cogs on the belt and thus damage it, or it ma break the belt altogether.
• The onl reason wh the canop might be harder to operate is increased friction.
This friction is caused b accumulation of dust, grit, particles deposited b insects
or birds, and general airborne pollution. Depending entirel on the specific location
of our installation, this might happen more or less frequentl .
• Just as the fabric panels should be cleaned frequentl , the cross bars and roller
carriers must be cleaned if operating smoothness noticeabl degrades.
In fact, cleaning of the top of the panels and of the mechanical parts can be
accomplished in the same procedure.
• Please follow these eas steps below:
• Gentl crank the canop open all the wa . Do not force it – free an stuck or frozen carriers b
hand onl .
Open the tilt knob on each end, making sure the locking teeth are full separated.
Slowl rotate the canop upside down, so the crossbar and runners are facing the floor. (Please
do this with 2 people and when there is NO wind)
Lock the canop b closing the tilt knobs. Make sure the teeth are properl interlocked.
You can now use a garden hose and a soft bristle brush, or an irrigated automotive brush, to
thoroughl rinse and clean all components. A mild soap ma be used in assisting removal of more
stubborn residue.
After a final rinse let all components dr out thoroughl , then spra all moving parts, as well as
the aluminum crossbars, with a high-grade, non-stick lubricant such as SailKote Marine Dr
Lubricant, available at marine stores or Jigaloo, available at Home Depot.
Use of oil-based lubricants is NOT recommended, as the tend to actuall accelerate the
accumulation of dust, and the ma also stain the fabric.
Return the canop the the regular position, lock it, and enjo the continued, smooth operation
of our Flex .
