HAMPTON BAY URM062003C-1 User manual

11 FT OFFSET IN BLACK/WHITE WITH KNIFE CUT
Item # 1007 967 995
Model # URM062003C-1
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YO U
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this umbrella. We strive to continually create
Thank you for choosing Hampton Bay!
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

2
Table of Contents
Table of Contents......................................................... 2 Pre-A
9
ssembly ............................................................... 3
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Operation ........................................................................
Care and Cleaning ....................................................... 12
Assembly ........................................................................ 5
Package Contents ................................................................... 4
Safety Information ..................................................... 2
Product Caution ................................................................... 2
Safety Warnings ...................................................................... 2
Warranty ........................................................................ 2
What is Covered ................................................. 2.....................
What is Not Covered ................................................................ 2
Safety Information
CAUTION: Never use the umbrella in high wind conditions.
Damage to the umbrella can occur.
CAUTION:
this product at all times.
Keep all ame and heat sources away from
WARNING: Please keep children out of the assembly area
before assembly.
Warranty
This umbrella was made for the explicit puropse of providing outdoor functions and is not to be used as a toy. This product isintended for normal
outdoor use.However, the manufacturer recommends storing and / or covering this umbrella when any formidable / severe weather is approaching
Do not locate the product near open ame. Do not use as a support. Do not shake, lean, or climb on product. Children under the age of 10, near
the product, should be supervised by a competent adult at all times. This product is not intended for commercial use, and commercial use will
void the warranty.
SAFETY WARNINGS
WARNING: This umbrella unit is heavy, and may require
two adults for safe assembly.
DDEERREEVVOOCCTTOONNSSIITTAAHHWW
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, re, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com.
PRODUCT CAUTION
2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and offer a two year limited warranty for
the fabric.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
Part
Description Quantity
AA M6x10 Bolt
BB
CC
DD
EE
FF
2+1
1+1
4+1
4+1
1
1
M6x20 Bolt
M10x25 Combination Bolt
M10x30 Combination Bolt
Hex Wrench S8
Hex Wrench S5
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware notshown to actual size.NOTE: Hardware notshown to actual size.NOTE: Hardware notshown to actual size.
AA BB
EE
CC DD
FF
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

PACKAGE CONTENTS
Base Tube
Crank
Lower Umbrella Pole
Umbrella Shade
1
1
1
A
B
C
1 D
1
1
E
F
Turn Plate 1
G
Pedal 1
H
Pedal Tube 1
I
Side Base 2
J
Middle Base 2
K
Upper Base Cover 1
L
Lower Base Cover 1
M
Solar Receiver 1
N
Part
Description Quantity
Lower Bracket
Upper Bracket
Pre-Assembly (continued)
4
L
A
B
C
G
H
IJ
K
K
J
D
F
N
M
E

Assembly
5
NOTE: Place the base in the area where the umbrella to be used.
The umbrella will be very heavy after lled with sand and water.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
1
Open the side bases (J) and the middle bases (K) in the counterclockwise direction.
Pour sand and water totally need 264.55 lbs /120 kg into the side bases (J) and the middle bases (K) for proper stability
of the umbrella.
Close the side bases (J) and the middle bases (K) in the clockwise direction.
Pouring Sand and Water into the Bases
OPEN
① ② ③ CLOSE
④
Sand Water
2Pulling out the Lower Umbrella Pole
Pull out the lower umbrella pole (E) from the base tube (C).
E
C

Assembly (continued)
6
3Attaching the Base Tube to the Turn Plate
Attach the pedal tube (I) to the turn plate (G) using M6x10 bolt (AA) and hex wrench S5 (FF).
Attach the upper bracket (B) onto the lower bracket (A).
Attach the turn plate (G) to the brackets (A & B) using M10x30 combination bolts (DD) and hex wrench S8 (EE).
Attach the base tube (C) to the turn plate (G) using M10x25 combination bolts (CC) and hex wrench S8 (EE).
FF
I
G
AA
①
②
C
EE
CC
G
B
A
EE
DD
③
④
⑤
4Attaching the Middle Bases to the Brackets
Attach the middle bases (K) onto the brackets (A & B).
K
K

Assembly (continued)
7HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
5Attaching the Side Bases to the Brackets
Attach the side bases (J) onto the brackets (A & B).
J
J
6Inserting the Lower Base Cover, the Upper Base and The Lower Umberlla Pole
Into The Base Tube,Connecting the Pedal to the Pedal Tube
Insert the lower base cover (M) and the upper base cover (L) into the base tube (C), as shown below.
Insert the lower umbrella pole (E) into the base tube (C).
Connect the pedal (H) to the pedal tube (I) using M6x10 bolt (AA) and hex wrench S5 (FF), as shown below.
②
L
①
⑤
M
E
H
FF
AA
④③

Assembly (continued)
8
7Attaching the Solar Receiver
Attach the solar receiver (N) to the umbrella shade (F) by turning the solar receiver (N) clockwise until fully tightened.
NOTE: Please leave the solar receiver (N) out in a sunny area to
charge before the first time turning on the LED lights.
①
②
F
N
8
Insert the umbrella shade (F) into the base tube (C) using M6x20 bolt (BB) and hex wrench S5 (FF).
Fully tighten all the bolts at this step.
Shake the canopy to separate the umbrella ribs before opening the umbrella.
Inserting the umbrella Shade Into the Base Tube
F
①
BB FF
②
③

1Raising the Umbrella
Operation
9
Loosen the knob on the umbrella shade (F) by turning it in the counterclockwise direction.
Hold the umbrella handle and push the umbrella shade upward to the desired position.
Once the umbrella is at the desired position, fully tighten the knob on the umbrella shade by turning it in the clockwise direction.
2Opening the Umbrella
Attach the crank (D) to the umbrella shade (F).
Slowly turn the crank (D) clockwise to open the umbrella until the umbrella is fully extended.
2
D
①②
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
2
①
1
②

10
Press the ON/OFF switch to turn the LED light on and off.
Operation (continued)
3Turn the LED Light On and Off
4Rotating the Umbrella
Hold the pedal (H) with one foot and rotate the umbrella pole (the umbrella can rotate up to 360 degrees).
ON-OFF
②
360°
①

Loosen the knob on the umbrella shade (F) by turning it in the counterclockwise direction.
Hold the umbrella handle and push the umbrella shade downward.
11
Operation (continued)
5Closing the Umbrella
6Closing the Umbrella
Slowly turn the crank (D) in a counterclockwise to close the umbrella.
2
1
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
2
1

Operation (continued)
12
Tie the umbrella to the umbrella pole with the velcro belt when not in use, as shown below.
7Tying the Umbrella to the Umbrella Pole
Care and Cleaning
For best results, clean the umbrella with damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Sto
Keep the umbrella away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
re the umbrella in a dry, sheltered place when not in use.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
