Extremis HOPPER SHADE User manual

PRODUCT
HOPPER SHADE – ASSEMBLY FOR HOPPER – ASSEMBLY TO
HOPPER LEGS – FLOOR FASTENING – CONCRETE BASE –
MAINTENANCE
HOPPER SHADE
© design by dirk wynants
READ INSIDE
ASSEMBLY INSTRUCTIONS,
HOW TO USE, USEFUL TIPS
FOR KEEPING YOUR TOOL FOR
TOGETHERNESS IN SHAPE
LANGUAGES
EN – NL – DE
MORE
WWW.EXTREMIS.COM

LANGUAGES
ENGLISH P. 3
contents p. 3
combined with hopper p. 6
assembly with freestanding bases p. 9
assembly with oor fastening p. 10
assembly to hopper legs p. 12
oor fastening with hopper table p. 13
opening/closing the shade p. 14
disassembly p. 16
maintenance p. 17
NEDERLANDS P. 19
inhoud p. 19
montage met hopper p. 22
montage betonnen sokkel p. 25
montage vrijstaand p. 26
montage aan hopper poten p. 28
grondverankering met hopper tafel p. 29
openen/sluiten p. 30
demonteren p. 32
onderhoud p. 33
DEUTSCH P. 35
inhalt p. 35
montage mit hopper p. 38
freistehende montage p. 41
montage mit bodenverankerung p. 42
montage an hopper-beinen p. 44
bodenverankerung mit hopper p. 45
önen/schließen p. 46
demontage p. 48
pege p. 49
2 contents

6
3
1
9 A B
7
C
2
8
4 5
4 x xing pin 4 x bolt
M6x30
8 x bolt
M8x16
2 x right-hand side base palte 2 x le-hand side base palte 2 x union tube
OPTION 1: COMBINED WITH HOPPER
8 x spring washer 8 x bolt
M8x20
4 x bolt 4 x nut
4 x pole
(2 le-hand side + 2 right-hand side)
1 x fabric roller rube
BASIC COMPONENTS
CONTENTS
english 3

10
12
11
4 x ground anchor
OPTION 3: FLOOR FASTENING
2 x freestanding base 4 x weight
OPTION 2: FREESTANDING BASE
CONTENTS
4 contents

17
21
18 19
20
13
14 15 16
1 x protective cover
PROTECTIVE COVER
12 x socket head bolt
M10x45
12 x spring washer
M10
8 x thick plastic ring 16 x thin plastic ring 4 x stainless steel tube ø14x2x30
2 x le-hand side inner
fastening plate
2 x right-hand side inner
fastening plate
4 x outer fastening plate
OPTION 4: ATTACHED TO HOPPER LEGS
CONTENTS
english 5

+/- 45 min.
15mm
2. Slide the assembled base plates under the table until the union tube touches the table. e distance between the
table leg and the round axle of the base plate should be the same on both sides (approximately 15 mm).
1. Screw the two base plates (1 le (7) + 1 right (6)) to the union tube (8)
using bolts B (at the bottom) and bolts C, in combination with spring
washer (3) (at the side).
no. 4 - 5 hex key
no. 17 spanner
2 people
UTILITIES
COMBINED WITH HOPPER
6 combined with hopper

4. Tilt the poles (1) inwards and slide the fabric roller tubes (2) into the poles. CAUTION: the fabric roller tubes are
heavy. Use a stable ladder or step stool. TIP: in order not to soil the fabric, we recommend that you rst wash your
hands.
3. Insert the poles (1) into the base plates. Caution! e cut-out at the top should be facing inwards and the hook
should be facing outwards. Position the pole (1) in the base plate (6,7) in such a manner that you can put the bolt (4)
through the hole in the base plate and through the hole in the pole. Tighten the nut (5) on the bolt (6) with an open-
end spanner 17.
english 7

4
COMBINED WITH HOPPER
5. Fasten the fabric roller tubes by means of the 8 M8x20 bolts (C), in
combination with feather ring (3).
8 combined with hopper - freestanding base
6. Loosen the 4 fastening screws to put the fabric under tension. Fasten the screw until it almost entirely disappears
in the black plastic element. CAUTION! If you fasten the screw too much, you risk deforming the pole.

+/- 30 min.
X
X
ASSEMBLY WITH FREESTANDING BASES
UTILITIES
no. 17 spanner
2 people
no. 4 - 5 hex key
1. Position the 2 freestanding bases
(10) parallel to each other, at a
distance of x between the inside of
the 2 bases.
In case of HS10 people X = 353 cm
In case of HS8 people X = 293 cm
In case of HS6 people X = 233 cm
2. Put the weights (11) onto the freestanding bases (10) with their cut-outs facing downwards.
3. Insert the poles (1) in the base (10). CAUTION! e cut-out at the top should be facing inwards the hook should be
facing outwards. Position the pole (1) in the base (10) in such a manner that you can put the bolt (4) through the
hole in the base and through the hole in the pole (1). Tighten the nut (5) on the bolt (4) with a wrench 17.
Proceed to STEP 4 of the “combined with hopper” assembly instructions on the previous pages.
english 9

+/- 30 min.
X
X
147,5 cm
147,5 cm
10 assembly with floor fastening
3. Drill holes at the marked spots.
4. Perfectly align the holes in the ground anchor (12)
with the holes in the oor.
5. You can now attach each ground anchor (12) to the
oor by means of bolts (use the xing media most
suited to the type of ground on which you intend to
install the Hopper Shade).
2. Mark the spots to drill the 4 holes for each of the
ground anchors (12).
1. Position the ground anchors (12)
on the oor as shown in the
drawing, at a distance of x.
In case of HS10 people X = 351.5 cm
In case of HS8 people X = 291.5 cm
In case of HS6 people X = 231.5 cm
ASSEMBLY WITH FLOOR FASTENING
UTILITIES
no. 17 spanner
2 people
no. 4 - 5 hex key

6. Insert the poles (1) in the ground anchors (12). Caution! e cut-out at the top should be facing inwards and the
hook should be facing outwards. Position the pole (1) in the ground anchor (12) in such a way that you can put the
bolt (4) through the hole in the ground anchor and through the hole in the pole. Tighten the nut (5) on the bolt (4).
7. Proceed to STEP 4 of the
“combined with hopper”
assembly instructions on the
previous pages.
english 11

+/- 45 min.
2. Fasten the fastening plates (14/15 & 16) to the 4 legs as shown
in the diagram below. Make sure that the plastic rings are
positioned correctly, i.e. the thick rings (17) on the inside
and the thin rings (18) on the outside!! Only use 1 thin ring
per bolt on the aluminium legs. Use two thin rings per bolt
on the iron legs!
12 assembly to hopper legs
1. If necessary, rst drill holes in the 4 Hopper legs as shown in the diagrams
and assembly the Hopper table as explained in the Hopper manual.
ASSEMBLY TO HOPPER LEGS
UTILITIES
no. 17 spanner
2 people
no. 4 - 5 hex key

FLOOR FASTENING WITH HOPPER TABLE
3. Insert the tubes Ø14 x 2 x 30 (19) in the bottom hole of the 4 poles and insert the poles into the fastening plates.
CAUTION! e cut-outs at the top should be facing inwards and the latches at the bottom should be facing outwards.
Position the pole in the fastening plate in such a manner that you can put the M10 x 45 bolt (20) with its spring
washer (21) through the hole in the fastening plate and in the pole. Tighten the bolt using a socket head wrench
size 7.
4. Proceed to STEP 4 of the
“combined with hopper”
assembly instructions on the
previous pages.
4. Fasten the base plate to the oor
using the anchor bolts.
3. Perfectly align the hole in the
base plate with the hole drilled in
the oor.
2. Drill a hole on the spot you
marked. If necessary, use the
plugs.
1. Mark the spot to drill the hole,
through the hole in the base plate.
IF THE SHADE IS COMBINED
WITH THE HOPPER TABLE,
THE WEIGHT OF THE TABLE IS
SUFFICIENT TO KEEP THE SHADE
IN PLACE. WE NEVERTHELESS
RECOMMEND THAT YOU
ANCHOR THE BASE PLATE TO
THE FLOOR, IF POSSIBLE.
english 13

14 opening / closing the hopper shade
For small people the shade can be too heavy to open
single-handedly by means of the leather strap. In this
case, open the shade together with another person as
shown in the drawing.
CAUTION: Don’t try to open the shade by pulling the
side prole at one side and maken sure both sides are
opened. is way you will prevent any possible damage
to the shade.
3. Tilt the latches downwards and open the other side
of the shade.
4. Tilt these latches downwards as well.
1. Tilt the latch upwards. 2. Open one side of the shade by pulling the leather strap.
OPENING THE SHADE

1. Tilt the latches upwards. 2. Close the two sides of the shade using the strap.
CAUTION: When closing the shade, it will suddenly
speed up when it reaches its tipping point. Keep a rm
grip on the leather strap and carefully guide the shade
into its closed position. Some strength is required to
hold the weight.
3. Tilt the latches downwards and put the protective
cover over the shade to prevent it from blowing open.
INSTALLING THE PROTECTIVE COVER
english 15
1. Put the protective cover (13) over the fabric roller
tubes (2) and the upper parts of the poles (1).
2. Close the buckle under the fabric roller tubes fastening
this side of the protective cover.
3. Put the rest of the protective cover (13) over the fabric
roller tubes and close the protective cover by means of
the zip under the fabric roller tubes and the round
tubes so that the straps are also inside the protective
cover.
CLOSING THE SHADE

4
16 hopper shade disassembly - maintenance
CAUTION
Wrong or incautious use can cause serious injury.
Always make sure that no persons or obstacles are
situated close to the poles when opening the shade.
CAUTION
Always make sure that no obstacles are situated
between the shade and the table when closing the
shade.
1. e springs are under tension! Turn the 4 fastening
screws clockwise to lock the fabric. e groove in the
fabric roller tube must be positioned in line with the
fastening screw.
2. In order to disassemble the Hopper Shade follow the
assembly steps in reverse order.
DISASSEMBLING THE WRONG WAY CAN
CAUSE SERIOUS INJURY!
DISASSEMBLY

english 17
MAINTENANCE
SHADE FABRIC
Clean the shade and the protective
cover by rinsing them with soapy
water (hand soap) and by rubbing
carefully using a sponge or so brush.
Prevent the shade fabric from getting
really dirty. Use the protective cover
as much as possible.
Never use a high-pressure cleaner to
clean the shade.
Always brush very soly and be
particularly careful at the seams. If
you brush too hard, the seams might
come apart.
Aer cleaning, always leave the
shade open to allow the fabric to dry
completely.
Do not use detergents. ey aect the
fabric’s protective layer.
In case of tenacious stains we
recommend using “HG sunshade,
canvas and tent restorer”. For more
information on this product, please
visit www.hg.eu. Strictly follow the
instructions on the bottle!
ROESTVAST STAAL
Stainless steel is not seawater
resistant. Especially in aggressive
environments (maritime climate,
chlorine, acid rain, and aggressive
industrial or urban environments)
we recommend that you regularly
clean the stainless steel surfaces.
Special cleaning products for
stainless steel are readily available on
the market.
CAUTION
In case of strong winds or if it is
not being used, close the shade and
tilt the latches downwards. Put the
protective cover over the shade to
prevent it from blowing open or
getting dirty.
Never leave the shade unattended
when opened.
Do not leave the hopper shade closed
if the fabric is not completely dry. Do
not leave it closed for a long period of
time in damp conditions.
If you will not bu using the shade
for quite a while, store it as follows:
completely dry in dry conditions.

18 inhoud
LANGUAGES
ENGLISH P. 3
contents p. 3
combined with hopper p. 6
assembly with freestanding bases p. 9
assembly with oor fastening p. 10
assembly to hopper legs p. 12
oor fastening with hopper table p. 13
opening/closing the shade p. 14
disassembly p. 16
maintenance p. 17
NEDERLANDS P. 19
inhoud p. 19
montage met hopper p. 22
montage betonnen sokkel p. 25
montage vrijstaand p. 26
montage aan hopper poten p. 28
grondverankering met hopper tafel p. 29
openen/sluiten p. 30
demonteren p. 32
onderhoud p. 33
DEUTSCH P. 35
inhalt p. 35
montage mit hopper p. 38
freistehende montage p. 41
montage mit bodenverankerung p. 42
montage an hopper-beinen p. 44
bodenverankerung mit hopper p. 45
önen/schließen p. 46
demontage p. 48
pege p. 49

nederlands 19
INHOUD
4 x zijproel
(2 links + 2 rechts)
1 x doekrol
8 x veerring 8 x bout
M8x20
4 x bout 4 x borgmoer
2 x rechtse onderplaat 2 x linkse onderplaat 2 x verbindingsbuis
4 x vergrendeling 4 x bout
M6x30
8 x bout
M8x16
BASISCOMPONENTEN
OPTIE 1: COMBINATIE MET HOPPER
6
3
1
9 A B
7
C
2
8
4 5

20 inhoud
INHOUD
2 x vrijstaande voet 4 x verzwaringsblok
4 x grondverankering
OPTIE 2: VRIJSTAANDE VOET
OPTIE 3: GRONDVERANKERING
10
12
11
