ALLEN & HEATH XONE:3D User manual

Allen & Heath 2 XONE:3D Service Manual
OUTIN
FX2 SEND
WARNING: FOR CONTINUE D PROTECTION AGAINST RISK OF FIRE
REPLACE FUSE WITH SAME TYPE AND RATING.
UN DES MEMES CARACTERISTIQUES.
ATTENTION: REMPLACER LE FUSIBLE AVEC
DO NOT EXPOSE APPAR ATUS TO RAIN OR MOISTURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
WARNING: THIS APPARATUS MUST BE EARTHED.
CAUTION
100 - 240V~
47-63Hz ~ 30W MAX
MADE IN THE UK BY ALLEN & HEATH LIMITED
FUSE
T500mAL 250V 20mm
MIX OUT
LEFT RIGHT
I
0
ON
OFF
SERIAL No:
AC MAINS IN ~
TO PC
USB
GAME/MIDI
FOOT
SWITCH
FX RETURNS
MIDI
LINE
L RPHONO
L R LINE
L RPHONO
L R LINE
L RPHONO
L R LINE
L RLINE
L R FX2
L RFX1
L R
INPUT 1INPUT 2INPUT 3INPUT 4
CH1
SOUNDCARD OUTPUTS
R
L
FX1 SEND
R
L
MONITOR
R
L
SPDIF
OUT
IN
L
CH2
R
CH3
L
CH4
R
CH5
L
CH6
R
IN OUT
DIGITAL AUDIO
OPTICAL
A
B
MIC
-12 +12 -12 +12 0
LEVEL
10
PHONES
HFLF
ACK SOCKET-
Pt No. AL5323
ACK SOCKET-
Pt No. AL0328
KNOB-Pt No.
A 4346
POT-Pt No.
AI8004
XLR SOCKET-
Pt No. AL2414
SCREW-Pt No.
KNOB-Pt No.
A 4346
POT-Pt No.
AI8003
QUAD RCA SOCET-Pt No. AL497
SCREW-Pt No. AB2771 ACK SOCKET-
Pt No. AL0328
USB SOCKET-
Pt No. AL6096
5 WAY DIN-
Pt No. AL0095
D TYPE CONNECTOR-
Pt No. AL6351
OPTICAL IN SOCKET-
Pt No. AE6096
OPTICAL OUT SOCKET-
Pt No. AE5899
PHONO DUAL
SOCKET-Pt No.
AL0566
RCA DUAL VERTICAL SOCKET-
Pt No.AL3753
SCREW -Pt No.AB2771
XLR MALE SKT-Pt No. AL2411
SCREW-Pt No. AB2810
SWITCH CAP-Pt
No A 2887
FUSE 20mm 500 mA-
Pt No. AL3534
TERMINAL POST-PT No
AL8106
RCA PHONO PLUG SHORTING-
Pt No. AL4396
OPTICAL IN/OUT BLANKING PLUG-
Pt No. AL6531
CONNECTING WIREFORMS USED IN CONSOLE
From to
AL5904- HEADPHONE ASSY MASTER ASSY
AL5904- 7 SEGMENT DISPLAY USB CONTROL ASSY
AL5904- ANALOGUE SLAVE ASSY POWER SUPPLY ASSY
AL5904- OGWHEEL (L) ASSY MIDI SLAVE (L) ASSY
AL5904- OGWHEEL (R) ASSY MIDI SLAVE (R) ASSY
AL4606- CONNECTOR ASSY MASTER ASSY
AL6407- MIDI SLAVE (L) ASSY USB CONTROL ASSY
AL6592- MIDI CONTROL (R) ASSY USB CONTROL ASSY
AL5485- ANALOGUE SLAVE ASSY USB CONTROL
AL6098- GAMEPORT ASSY USB COTROL ASSY
AL3817- LINEAR FADER ASSY`S INPUT ASSY`S
AL3817- X FADER ASSY FILTER ASSY
AH2228 MIDI FADER ASSY`S MIDI SLAVE ASSY`S

Allen & Heath 3 XONE:3D Service Manual
POWER SUPPLY ASSY-
Pt No. 003-233
CONNECTOR ASSY-
Pt No. 003-527
GAMEPORT ASSY-
Pt No. 003-531
USB CONTROL ASSY-
Pt No. 003-528
HEADPHONE SOCKET ASSY-
Pt No. 003-530
INPUT ASSY-
Pt No. 003521
FILTER ASSY–
Pt No. 003-525
MASTER ASSY-
Pt No. 003-522
X FADER ASSY-
Pt No. 003-579
MIDI SLAVE L ASSY-
Pt No. 003-523
MIDI SLAVE R ASSY-
Pt No. 003-546
MIDI FADER ASSY-
Pt No. 003-532
(under midi slave assy)
MIDI FADER ASSY-
Pt No. 003-532
(under midi slave assy)
LINEAR FADER ASSY-
Pt No. 003-526
OGWHEEL ASSY-
Pt No. 003-533
OGWHEEL ASSY-
Pt No. 003-533
7 SEGMENT DISPLAY ASSY-
Pt No. 003-695
ANALOGUE SLAVE ASSY_
Pt No. 003-519
CONTROL INPUT ASSY_
Pt No.. 003-636 CONTROL INPUT ASSY_
Pt No.. 003-636
CONTROL INPUT P ASSY -
Pt No. 003-635
CONTROL INPUT P ASSY -
Pt No. 003-635
