Allied Vision Bonito PRO Series User manual

1
EN QuickStart Guide
DA Hurtig startguide
DE Schnellstartanleitung
ES Guía rápido
FI Pikaopas
FR Guide de démarrage rapide
IT Guida Rapida
NL Snelstartgids
NO Hurtigstartveiledning
SV Snabbstartsguide
ZH 快速入门指南
JA クイックスタートガイド
Bonito PRO
V1.0.1
2019-Sep-12

2
Validity
This quickstart guide is valid for all Bonito PRO models.
Shipping contents
•BonitoPROcamera
• QuickStart Guide download instructions
What else do you need?
English
Document/Information Document
Bonito PRO Technical Manual
Bonito PRO Features Reference
Go to https://www.alliedvision.com, then select
Support > Technical documentation. In the drop-
down menu, choose Bonito PRO Documentation.
Hardware Selection for Bonito
PRO Cameras application note
Go to https://www.alliedvision.com, 
then select Support > Technical papers,
knowledge base. Open the CoaXPress accordion.

3
Recommended frame grabbers
For a complete list of supported frame grabbers, cables, and accessories, see
the Hardware Selection for Bonito PRO Cameras application note.
Contacting Allied Vision
Website
To directly contact Allied Vision with any support inquiry, go to: 
https://www.alliedvision.com, then select About Us > Contact us > Technical
Support & Repair / RMA.
Software Reference
Euresys Coaxlink Quad G3
PCIe 3.0 four-connection CoaXPress frame grabber, four
CoaXPress CXP-6 connections, 2,500 MBps camera
bandwidth, PCIe 3.0 (Gen 3) x 4 bus, 3300 MBps bus
bandwidth, PoCXP, Windows drivers
Active Silicon FireBird Quad
CXP-6
Quad input CoaXPress frame grabber, four CoaXPress
connections each at 6.25 Gbps, Windows support (32-
bit and 64-bit), PoCXP

4
To find an Allied Vision office or distribution partner, go to:
https://www.alliedvision.com, then select About Us > Where we are.
Telephone and email
For camera-related inquiries contact us at [e-mail]
North and South America (toll-free): // +1-877-USA-1394
Europe, Middle East, and Africa: // [phone]
Asia-Pacific: // [phone]
China: // [phone]
Headquarters
Allied Vision Technologies GmbH
Taschenweg 2a
07646 Stadtroda, Germany
CEO/Geschäftsführer: Andreas Gerk, Peter Tix
Registration Office: AG Jena HRB 208962

5
Compliance, safety, and intended use
For customers in Europe
Allied Vision has demonstrated the fulfillment of the requirements
relating to the Bonito PRO camera family.
• Directive 2014/30/EU (Electromagnetic compatibility)
• Directive 2011/65/EU, incl. amendment 2015/863/EU (RoHS)
Directive 2012/19/EU
(Waste Electrical and Electronic Equipment, WEEE)

6
For customers in the USA
Class B digital device
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.

7
For customers in Canada
This apparatus complies with the Class B limits for radio noise emissions set out
in the Radio Interference Regulations.
CAN ICES-3 (B) / NMB-3 (B)
Avoid electromagnetic interferences
For all power and interface connections, use shielded cables only. 
Please use cables recommended by Allied Vision.
Camera applications and intended use
General use
• The user is responsible for operating the camera within the specifications
defined in the technical manual, and within appropriate environmental
We caution the user that changes, or modifications not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.

8
conditions and technical prerequisites, to ensure trouble-free camera
operation.
• The camera is compliant with current data communication standards;
however, those standards do not allow for self-monitoring. Thus, the camera
cannot be used as a standalone device for security-related monitoring
operations.
• The camera is a hardware product. Only when used with appropriate
accompanying software, the camera will produce the desired results. The
realization of intelligent solutions requires additional software that is
suitable to run with the camera.
• The camera is a component, it is neither a finished product, nor is it a ready-
made technical solution.
• The camera-supporting software can be obtained and installed separately
from the camera. Usage of the software is solely the responsibility of the
user.
• The camera must not be opened. For all repair tasks, contact Allied Vision or
one of Allied Vision's authorized representatives.
• Observe the intended use. The camera must only be used for purposes that
are in conformity with the stated intended use.

9
• Additionally, refer to the warranty information on the Allied Vision website.
Use in medical devices
The camera provides basic adequacy to be used in medical devices as well.
However, it is not specially designated for operation in medical devices. When
used as part of a medical device, a review of the specific application is necessary
in cooperation with Allied Vision. Users who integrate the camera into an
application must comply with the rules and regulations concerning medical
devices.
Environmental conditions
The following values present environmental conditions that are safe for all
Bonito PRO cameras.
Condition Value
Operation (housing temperature) -20 °C to +70 °C (without condensation)
Storage (ambient temperature) -20 °C to +70 °C (without condensation)
Relative humidity, non-condensing 20 to 80% non-condensing

10
Overview of installation
Complete the steps listed below to successfully install your Bonito PRO camera.
Step 1: Install and configure the frame grabber.
Step 2: Connect the camera and ensure the camera is powered.
Step 3: Acquire your first image with the frame grabber software.
Installing and configuring the frame grabber
The procedure to obtain first image from your Bonito PRO camera is dependent
on the frame grabber GenICam browser or SDK.
The maximum cable length between the Bonito PRO camera and the host PC is
dependent on the bit rate and the type of coaxial cable used. For more
information refer to your frame grabber documentation.
Install the frame grabber in your host PC and configure the frame grabber
software including drivers, utilities, and libraries. Ensure the system BIOS
version is compatible with the frame grabber. For additional information, see
the technical documentation provided by the frame grabber manufacturer.

11
Connecting and powering the camera
Connect your Bonito PRO camera to your frame grabber via four 75Ωcoaxial
cables.
Bonito PRO cameras support CXP-6 speeds only. As such, all four cables must be
connected to the camera and the frame grabber. If less than four cables are
connected, the camera will not be discovered and you may receive an error in
the GenICam browser.
Power the camera via the Hirose I/O port using a compatible power supply.
Alternatively, you can power the camera via the CoaXPress connectors with a
frame grabber that supports PoCXP. If both power options are connected,
power via the Hirose I/O port will take priority.
Hirose 12-pin connector: colors and pins for power supply
When connecting an open-ended cable to a Hirose 12-pin connector, ensure
that the pins are connected to the correct wire as described in the table below.
Note that for powering up the camera, the power connection is necessary only.

12
The complete pin assignment is explained in the technical manual. Download it
from https://www.alliedvision.com: select Support > Technical
Documentation, from the dropdown menu choose Bonito PRO.
A camera power adapter and an I/O cable with Hirose 12-pin connector for the
Bonito PRO camera family is available from Allied Vision.
Pin Color Signal I/O Level Description
1Blue Camera
GND In 0 VDC Ground for
camera
power supply
2Red Camera
Power In 24 VDC
±2.4 VDC Camera
power supply
2
6
5
4
11
3
10
7
8
91
12

13
Camera back panel and status LEDs (excerpt)
For a detailed description of flash patterns refer to the technical manual.
Download it from https://www.alliedvision.com: select Support 
> Technical Documentation, from the dropdown menu choose Bonito PRO.
LED Status
Solid amber System booting.
Solid green Device or host connected, no
data being transferred.
Fast flash (12.5 Hz) green. Device or host connected,
data being transferred.
Red flashing, possibly
alternating with amber or
green.
Connection or transfer error,
or incompatibility.

14
Grabbing images
Step 1: Start the frame grabber GenICam browser and wait for the camera
to be discovered. When discovered, the Bonito PRO camera will be
listed on the right side of the window under Remote Devices.
Note the Euresys Coaxlink Quad G3 CXP-6 frame grabber GenICam
browser was used to create the below screenshots. These
screenshots are not representative of every frame grabber GenICam
browser.

15
Step 2: Double-click the camera name. A new window opens.
Step 3: In the new window, click the GenApi tab.
Step 4: Configure camera settings as required.

16
Step 5: Click the Start Stream button to start continuous image acquisition,
using default camera settings.
Step 6: Click the Stop Stream button to stop streaming images.
Copyright and trademarks
All text, pictures, and graphics are protected by copyright and other laws
protecting intellectual property. All content is subject to change without notice.
All trademarks, logos, and brands cited in this document are property and/or
copyright material of their respective owners. Use of these trademarks, logos,
and brands does not imply endorsement.
Copyright © 2019 Allied Vision GmbH. All rights reserved.

17

18
Gyldighed
Denne hurtige startguide gælder for alle Bonito PRO modeller.
Indhold
•BonitoPROkamera
• Hurtig startguide download instruktioner
Dansk

19
Hvad har du ellers brug for?
Anbefalede billedfangere
Dokument/information Dokument
Bonito PRO Technical Manual
Bonito PRO Features Reference
Åbn siden https://www.alliedvision.com vælg
derefter Support > Technical documentation.
Vælg Bonito Pro Documentation fra dropdown
menuen.
Hardwarevalg til Bonito Pro
kameraernes applikationsnotat
Åbn siden https://www.alliedvision.com 
vælg derefter Support > Technical papers,
knowledge base. Åbn CoaXPress folde-ud menuen.
Software Reference
Euresys Coaxlink Quad G3
PCIe 3.0 CoaXPress billedfanger med fire forbindelser,
fire CoaXPress CXP-6 forbindelser, 2,500 MBps kamera
båndbredde, PCIe 3.0 (Gen 3) x 4 bus, 3300 MBps bus
båndbredde, PoCXP, Windows drivere
Active Silicon FireBird Quad
CXP-6
Quad indgang CoaXPress billedfanger, fire CoaXPress
forbindelser hver især på 6,25 Gbps, Windows hjælp
(32-bit og 64-bit), PoCXP

20
Se hardwarevalg til Bonito PRO kameraer anvendelsesnotat for at få en
fuldstændig liste over understøttede billedfangere, kabler og tilbehør.
Kontakt Allied Vision
Website
For at få direkte kontakt til Allied Vision hvis du har brug for hjælp, åbn siden: 
https://www.alliedvision.com, vælg derefter About Us > Contact us > Technical
Support & Repair / RMA.
Allied Vision kontor eller forhandlere findes på: 
https://www.alliedvision.com vælg derefter About Us > Where we are.
