Alligator KC9503/P-4 User manual

KC9503/P-4FM Transmitter
Instruction Manual
FM Transmitter is designed for the iPod/ iPod mini/iPod NANO/ipod photo/ iPodVIDEO. It is the best
partner you should havewhen you are going out by automobile. It could transmit the audio signalto your
FM radio built-inside your car or other radio speakersystem at home. It is user-friendlyand no extra battery
required. Just plugging in your iPod and you could enjoyyour moment of rockeverywhere with radio
speaker system..
Features
1. Digital frequencyselectionallows stable and clear transmission
2. No Batteryoperation,power is supplied bythe iPod
3. LCD displays the frequency
4. Memorize radio channel,keep interfering fromother FM signals
5. Allowto use with the dockor mobile adaptor simultaneously
6. Slimand light as thenano
7. Can memorize up to 10 favorite channels
Operation
1. Turn off the iPod before connecting FM Transmitter
2. Plug the FM Transmitter to the iPod
3. Select the channel
4. Turn on the iPod
5. Press the Up(+) or Down(-) button to select the radio transmit frequency
6. Matching thesamechannel betweenFM Transmitter andtheradio speaker system in the car or at
home
7. The sound will bebroadcasted through your radio speaker systemonce thefrequencyofradio match
your FM Transmitter
8. Using MEM(M) buttonto memorizethedesired radio channel for next time use
9. Turn offthe the iPod beforeunplugthe FM Transmitter
10. Unplug the FM transmitter fromthe iPodwhen it is notin use
11. Ifyou want to recharge theiPod and playing music via FM transmitter at the sametime,please insert
the iPodwith FM transmitter onto the dockor the car adaptor together.
Store and overwrite the channel:
lChoose the desire frequencybypressing UP(+) or Down(-) button
lPress and hold the MEM(M) button until the M”appears and a number flashes belowit
lChoose the desired number ofchannel and press theMEMbutton for confirmation

Specification
1. InputVoltage: DC 3.3V 25mA
2. High-stabilitycrystal oscillator
3. Phase-lockloop control
4. FM Stereo transmission
5. Radio FrequencyRange:88.1MHz-107.9MHz
6. FrequencyResponse: 150Hzto 20KHz
7. Stereo separation:-25dB at 25cm
8. Signal distortion: less than5%
9. StationMemory Preset: 10 Channels
10. Maximumreceivable range: 19.5 feet
Precautions
lAvoid usingthe FMTransmitter with anydevices simultaneously except theiPod,radio speaker system
or the dock,mobile adaptorfor charging the iPod
lStorage temperature should be less then 60 degrees
lPlease unplug FMTransmitter fromiPod , Dockor mobile adaptor ifyou would planto not use it for a
long time
lDo not lay FMT on a surface that is slanted or unstable
NOTE:
Changesor modifications not expresslyapproved bythe partyresponsible for compliance could
void the user’sauthorityto operate the equipment.
This equipment hasbeentested and found to complywith the limitsforaClass Bdigitaldevice,
pursuant to Part 15 of theFCC Rules. Theselimitsare designed to provide reasonable protection
against harmfulinterference in aresidentialinstallation. This equipment generates, uses and can
radiate radio frequencyenergyand, if not installedand used in accordancewith the instructions, may
causeharmfulinterferenceto radio communications. However,there is noguarantee that interference
will not occur in aparticular installation. If this equipment does causeharmful interference to radio or
television reception, which can bedetermined byturning the equipmentoff andon, the user is
encouraged to tryto correct the interference byone or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC ID: S4CKC9503
MADE IN CHINA
This device complies withpart 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device maynot cause
harmful interference, and (2) this device must
accept anyinterference received, including
interference that maycauseundesired
operation.
Date: 22/11/2005
