ALLPOWER APW5118 User manual

Pressure Washer
Important Safety Instructions
WARNING – When using this product basic precautions should always be followed,
including the following:
1. Read all the instructions before using the product.
2. To reduce the risk of injury, close supervision is necessary when a product is
used near children.
3. Know how to stop the product and bleed pressures quickly. Be thoroughly
familiar with the controls.
4. Stay alert – watch what you are doing.
5. Do not operate the product when fatigued or under the influence of alcohol or
drugs.
6. Keep operating area clear of all persons
7. Do not overreach or stand on unstable support. Keep good footing and balance
at all times.
8. Follow the maintenance instructions specified in the manual.
“WARNING – Risk of Injection or Injury– Do Not Direct Discharge Stream At
Persons.”
1. “WARNING: If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.”
2. “In the event of pilot outage, wait at least five minutes to clear out any gas before
relighting.”
3. “Use only your hand to push in or turn the gas control knob. Never use a tool. If
the knob will not push in or turn by hand, don’t try to repair it; call a qualified service
technician.”
1

Table of Contents
Topic Page
Safety Guidelines-Definitions 3
General Precautions
4
Assembly/Start-up
7
Maintenance 11
Trouble Shooting 14
Warranty 16
2
Pressure Washer
Parts List 18

3
Owner’s Manual
Safety Symbols
The following symbols are used throughout this manual. Follow listed instructions to
ensure your safety.
Warning! Read And Understand All Safety Precautions In
This Manual Before Operating. Failure To Comply With
Instructions In This Manual Could Result In Personal
Injury, Property Damage, And / Or Voiding Of Your
Warranty. All Power America Will Not Be Liable For Any
Damage Because Of Failure To Follow These Instruc-
tions.
DANGER
Indicates an imminently hazardous situation
which, if not avoided will result in serious
injury or even death.
WARNING
Indicates an imminently hazardous situation
which, if not avoided will result in serious
injury or even death.
CAUTION
Indicates a potentially hazardous situation
exists, which if not avoided, may result in
minor or moderate injury or product damage.
NOTE
Indicates operation or maintenance information helpful to improve performance
or operation.

4
Owner’s Manual
Pressure Washer
The following safety precautions apply whenever using, storing, or servicing your
pressure washer to reduce the possibility of personal injury.
Overlooking or ignoring these precautions can lead to personal injury or product
damage.
• Read this manual carefully. Know your equipment. Consider applications, potential
hazards and limitations for your unit.
• This equipment is designed for specific applications. Do not modify or use for any
application other than which it is designed for.
• Store the pressure washer in a well ventilated area with the fuel tank empty. Fuel
should not be stored near the pressure washer.
• Never operate pressure washer under these conditions:
a. A noticeable change in engine speed.
b. A noticeable loss of pressure.
c. Engine misfires.
d. Smoke or flames are present.
e. Enclosed area.
f. Excessive vibration.
g. Rain or bad weather.
• Water spray must never be directed towards people, pets, electric wiring, or directly
towards the pressure washer.
• Do not allow the hose to come in contact with the hot muffler
• Equipment must be placed on a firm supporting surface.
• Remove the spark plug or cable from the spark plug to prevent accidental starting
when not in use, or prior to detaching the high pressure hose.

5
Owner’s Manual
General Precautions (cont’d)
• Keep the pressure washer clean and free of oil, mud and other foreign matter.
• Do not wear loose clothing, jewelry, or anything that may be caught in the engine.
• Never direct spray at people or animals.
• Never allow children to operate pressure washer at any time.
• Use both hands to control the wand.
• Do not touch the nozzle or water spray while operating.
• Wear safety goggles while operating.
• Only approved hoses and nozzles should be used.
• Do not kink the high pressure hose.
• All hose connections must be properly sealed.
• In extremely cold conditions, prior to starting be sure ice has not formed in any part of
the pressure washer.
• Use only recommended chemicals.
• Outdoor use only.
• Place pressure washer away from cleaning site during operation.
• To prevent accidental discharge, the spray gun should be secured by locking the
trigger when not in use.
• Do not run the pressure washer more than 5 minutes without depressing the trigger
or damage to the pump may occur.
• Check the pressure washers periodically for damage, leaks or signs of deterioration.
All defects should be corrected before operating the pressure washer.

6
Owner’s Manual
General Precautions (cont’d)
• Do not touch hot muffler.
• Service, operate and refuel under the following conditions:
a. Good ventilation
b. Refuel the pressure washer in a well lit area.
c. Avoid fuel spills and never refuel while the pressure washer is running.
d. Avoid any ignition source when refueling.
e. Use lead free fuel with a minimum of 85 octane.
• Do not smoke near pressure washer.
• Do not operate under 40º fahrenheit.
Safety Features
THERMAL RELIEF VALVE
A thermal relief valve is provided to protect the pump from overheating if the spray gun is
closed for an extended amount of time or the nozzle becomes plugged. However, it is
intended to be used as a backup system and every effort should be made to not permit the
pump to heat up.
We recommend to turn the pressure washer OFF if it will not be used for more than 5
minutes. This saves wear on the unit, reduces fuel consumption and extends the life
of the pump by avoiding overheating.
SAFETY LOCK LATCH
To prevent accidental discharge of high pressure water, the safety latch on the trigger
should be engaged whenever the pressure washer is not in use.
LOW-OIL SHUTDOWN
Some engines are equiped with low-oil shutdown systems. If the engine oil level becomes
lower than required, the pressure washer wil automatically shut off. Refer to the engine
manual for this feature. This protects your pressure washer engine from operating without
proper lubrication.
If the pressure washer engine shuts off and the oil level is according to specification,
check to see if the pressure washer is sitting on an angle that forces the oil to shift.
Place on even surface to correct this. If the engine fails to start, there may not be enough
oil to deactivate the low oil level switch.
Pump will overheat and may be damaged,
or cause damage if allowed to circulate
more than 5 minutes

7
Owner’s Manual
Before Operation
NOTE: The engine and pump on your pressure washer will often have improved
performance after a break-in period of several hours.
PRE-START PREPERATION
Before starting the pressure washer, check for loose or missing parts and for any
damage which may have occured during shipping.
Assembly & Start-Up
HOSE & GUN ASSEMBLY
NOTE: Align threaded connections carefully to prevent damaging threads during
assembly. Tighten connections securely to prevent leaks during operation.
Attach the hose to the inlet on the trigger.
LUBRICATION
Do not attemp to start the pressure washer engine without filling the engine crank case
with the proper amount of oil. Your pressure washer has been shipped without oil in the
crankcase. Operating the pressure washer without oil will ruin the engine. Use oil that is
recommended (10W-30). DO NOT OVERFILL!
FUEL
Fill the tank with unleaded gasoline. Regular gasoline may be used provided a high
octane rating is obtained (at least 85 octane).
Hose
Gasoline is highly flammable and explosive
and you can be burned or seriously injured
when refueling if not carefull.
Gun Wand

8
Owner’s Manual
Operating Connections
HIGH PRESSURE HOSE
• Attach the high pressure hose to the pressure washer by pulling back on the collar of
the quick-connect coupling on the hose and pushing it over the coupling half on the
pressure washer outlet.
NOTE: Do not use pressure hose from another manufacturer.
WATER CONNECTION
Before connecting the garden hose to your pressure washer, run water through the
garden hose (not supplied) to flush out any foreign matter.
• Attach garden hose quick-connect to the garden hose (see below).
• Then attach that to the quick-connect inlet on the pressure washer pump. Make sure
it locks into place by pulling back on the garden hose quick-connect collar and
inserting it into the quick-connect inlet.
NOTE: The water supply must supply a minimum of 4 gpm at 20 PSI, or the pump
can be damaged.
PRESSURE WASHER PUMP Detergent Connection

9
Owner’s Manual
Operating Instructions
Start-up Procedure
1. Make sure water supply is connected and turned on.
2. Release gun safety if locked.
3. To allow air to escape from the hose, squeeze trigger on the gun until there is a
steady flow of water coming out from the nozzle.
Starting Engine
1. Check oil and gas.
2. Connect hose and turn on water.
3. Squeeze trigger.
4. Make sure the engine switch is on the ON position (illustration 1).
5. Set the fuel valve to open (illustration 2).
6. Set choke to CLOSE position (illustration 3) & set throttle to slow (illustration 4).
7. When starting engine, pull cord slowly until resistence is felt, then pull rapidly.
8. If engines starts and fails to continue running or if increase resistance is felt during
starting pull attemps repeat step 3 - 7.
4) Throttle Control
1) ON/OFF Switch 2) Fuel Valve
3) Choke

10
Owner’s Manual
This pressure washer is intended for use only with liquid car wash detergents,
developed specifically for pressure washers and with mild soaps. Only use chemicals
compatible with the aluminum and brass parts. Powdered soaps may clog the injection
system. Always use chemicals according to the manufacturers directions. We assume
no responsiblity for any damages caused by chemicals injected through this pressure
washer.
1. Attach injection tube assembly to the detergent connection on the pump. Assembly
instruction(BELOW).
2. Pour the two kinds of detergents into the detergent bottles. It is recommend to have
one detergent bottle filled with allpurpose detergent, and the other filled with a more
specific cleaning detergent.
3. The indicator on the detergent dial shows the amount and the consumption of
detergent Fig A.
4. Remove the high pressure nozzle from the wand and install the black injection nozzle.
The solution will automatically mix with the water and discharge through the nozzle.
NOTE: For certain models, if the engine throttle is not in the fast position, the injection
of the solution may be decreased or stopped.
CLEANING TECHNIQUES
When cleaning with the pressure washer, many cleaning tasks can be solved with water
alone, but for most tasks, it is advantageous to use a detergent. A detergeng ensures a
quick soaking of the dirt allowing the high pressure water to penetrate and remove the
dirt more effectively.
APPLICATION OF SOAP OR DEGREASER
1. Apply the solution to the dry work surface. On a vertical surface, apply horizontally
from side to side starting from bottom to avoid streaking.
NOTE: Wetting the surface first is not recommended, it dilutes the detergent and
reduces its cleaning effects. Please disconnect the Detergent Hose from the Pump
when do not use the detergent, and let the pressure washer run until you no longer
notice detergent coming out of the wand.This will prevent detergent from gumming up
the wand and reducing pressure for next use.
CAUTION
Detergent
Connection
Detergent
Hose
From out of
Detergent Bottle
Fig A

11
Owner’s Manual
Operation
Avoid working on hot surfaces or in direct sunlight to minimize the chances of the
chemical damaging painted surfaces. Damage may occur to painted surfaces if the
chemical is allowed to dry on the surface. Hold the nozzle far enough away from surface
to prevent damage to the surface.
2. Allow chemical to remain on the surface for a short time before rinsing.
3. Rinse with clean water under high pressure. On a vertical surface, first rinse from
the bottom up, then rinse from top down. Hold nozzle 6 to 8 inches from the work surface
at a 45° angle using the flat spray as a peeling tool rather than a scrub brush.
APPLICATION OF WAX
1. Immediately after cleaning, apply wax. Place injection tube in container of wax.
2. Apply the wax sparingly in an even layer. Apply to wet surfaces from bottom up for even
distribution and to avoid streaking.
3. Remove the suction tube from the wax bottle rinse off the surplus wax.
NOTE: If surplus wax is not removed, a hazy finish may result.
4. Wipe dry to reduce water spotting.
END OF OPERATION
When you have completed use of chemical injection system, remove tube from container.
Continue to run in low pressure position and inject clean water through the tube and
injection system by placing end of tube in a container of clean water. Continue to run
until it is thoroughly cleaned.
Maintenance
CONNECTIONS
Connection on pressure washer hoses, gun and spray wand should be cleaned
regularly and lubricated with the manufacturers recommended grease to prevent leakage
and damage to the O-ring.
NOZZLE
Clogging of the nozzle causes the pump pressure to be too high, cleaning is immediately
required.
A nozzle cleaner must only be used when the spray
wand is disconnected from the gun or personal injury
may occur.
1. Seperate the wand from the gun.

12
Owner’s Manual
CAUTION
Maintenance
2. Clear the nozzle with a small rigid piece of wire such as a paper clip.
3. Flush the nozzle backwards with water.
4. Reconnect the wand to the gun.
Restart the pressure washer and depress the trigger on the spray gun. If the nozzle is still
plugged or partially plugged, repeat above instructions 1-4.
If the previous procedure does not clear the nozzle, replace with a new nozzle.
ENGINE MAINTENANCE
During the winter months, rare atmospheric conditions may develope which will cause
an icing condition in the carburetor. If this develops, the engine may run rough, lose
power and may stall. This temporary condition can be overcome by deflecting some of the
hot air from the engine over the carburetor area.
Storage
PUMP STORAGE
If you must store your pressure washer in a location where the temperature is below 32° F,
you can minimize the chance of damage to your machine by utilizing the following
procedure:
1. Shut off water supply and relieve pressure to the spray gun by depressing the trigger.
Disconnect the garden hose from the pressure washer, but leave the high pressure hose
connected.
2. Tip the unit on its side with the inlet connection pointing up.
3. Insert a small funnel (to prevent spilling) into the inlet and pour in approximately 1/4 cup
of antifreeze.
4. Disconnect spark plug wire.
5. Without connecting garden hose pull the recoil several times to criculate the antifreeze
in the pump system.
6. Disconnect spark plug wire.
Prior to starting, thaw out any possible ice from the pressure washer hoses, spray gun
and wand.

13
Owner’s Manual
Maintenance
Another method of reducing risks of freeze damage is to drain your pressure washer as
follows:
1. Stop the pressure washer and detach supply hose and high pressure hose. Squeeze
the trigger of the discharge gun to drain all water from the wand and hose.
2. Restart the pressure washer and let it run briefly about 5 seconds) until water no
longer discharges from the high pressure outlet.
Engine Storage
When the pressure washer is not being used or is being stored for more than a month
follow these instructions:
1. Replenish engine oil to upper level.
2. Drain gasoline from fuel tank, fuel line, fuel valve and carburetor.
3. Pour about one teaspoon of engine oil through the sparkplug hole, pull the recoil
starter slowly until you feel increase pressure which indicates the piston is on its
compression stroke and leave it in the position. This closes both the intake and exhaust
valves to prevent the inside of the cylinder from rusting.
4. Cover the pressure washer and store in a clean, dry place that is well ventilated
away from open flame or sparks.
NOTE: The use of a fuel additive, such as STA-BIL, or an equivalent, will minimize
the formulation of fuel gum deposits during storage.
Technical Specification
Maximum Inlet Pressure Up To 90 PSI
Maximum Pressure 3200 PSI
Rated Flow 2.6 GPM
Engine Model JF210
Displacement 208 cc
RPM 3600 RPM
Fuel Tank 0.95 gallon
Temperature OF Pumped Fluids Up To 80
Inlet Ports (2) 1/2 inch BSP
Discharge Ports (2) 1/2 inch BSP
Weight 81.6 lbs.
Engine Oil 10W-30
Fuel Unleaded Gas

14
Owner’s Manual
Trouble Shooting
• Engine wil not start or stops while operating.
Low-oil shutdown: Fill engine with oil
Engine switch not in “ON” position: Turn switch “ON”S
Pressure built up in hose: Squeeze trigger while starting
• Engine is overloaded
Nozzle partially blocked Clean Nozzle
Excessive pressure Shorten the spring coil on the reflux valve
• Pressure increases when gun is locked
Bypass valve blocking Clean the bypass valve
• Engine is running but pump won’t build maximum pressure or has irregular pressure
Faucet closed Open faucet
Unit has been stored in freezing temp. Thaw out unit completely
Inadequate water supply Provide a minimum of 4 GPM at 20 PSI
Water inlet screen clogged Clean screen
Kink in garden hose Straighten garden hose
Wand nozzle worn or damaged Replace nozzle
Air in pump Run with gun open & wand removed
until steady stream of water is released
Adjustable pressure knob not set Set to maximum position
to maximum position
Suction or discharge valves clogged Clean the suction or discharge valves
or worn out
Bypass valve not operating effectively Clean the bypass valve
• No intake of chemicals
Injection tube not securely inserted Push firmly into injector
into unit
Tube cracked or split Replace tube
Wrong nozzle Switch to low pressure nozzle
Injector turned off Turn collar counter
• Trigger will not move
Gun safety lock engaged Release safety lock

15
Owner’s Manual
Trouble Shooting
• Water in crankcase
High humidity Change oil more frequently
Worn seals Change the oil seals
• Noisy operation
Worn bearings Change the bearings
Air mixed with water Check inlet lines for restrictions
and / or proper sizing
• Rough / pulsating, operating with pressure drop
Inlet restriction Check system for stoppages, air leaks,
correctly sized inlet plumbing to pump
Unloader Check unloader for proper operation
Air mix in water Check inlet lines for restrictions and or
proper sizing
• High crankcase temperatures
Wrong grade of oil Use recommended oil
Improper amount of
oil in crankcase Adjust oil to proper amount

16
Owner’s Manual
Limited Warranty
All-Power America warrants to the original purchaser who uses the product in a
consumer application (personal, residential or household usage) that all products
covered under this warranty are free from defects in material and workmanship for one
year from the date of purchase. All products covered by this limited warranty which are
used in commercial applications (i.e. income producing) are warranted to be free of
defects in material and workmanship for 90 days from the date of original purchase.
Products covered under this warranty include air compressors, air tools, service parts,
pressure washers and generators.
All-Power America will repair or replace, at All-Power America’s sole option, products
or components which have failed within the warranty period. Service will be scheduled
according to the normal work flow and business hours at the service center location,
and the availability of replacement parts. All decisions of All-Power America with regard
to this limited warranty shall be final.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
RESPONSIBILITY OF ORIGINAL PURCHASER (initial User):
To process a warranty claim on this product, DO NOT return item to the retailer. The
product must be evaluated by an Authorized Warranty Service Center. For the location
of the nearest Authorized Warranty Service Center contact the retailer or place of
purchase.
Retain original cash register sales receipt as proof of purchase for
warranty to work.
Use reasonable care in the operation and maintenance of the product as described in
the Owner’s Manual(s).
Deliver or ship the product to the Authorized Warranty Service Center. Freight costs, if
any must be paid by the purchaser.
If the purchaser does not receive satisfactory results form the Authorized Warranty
Service Center, the purchaser should contact All-Power America.

17
Owner’s Manual
Limited Warranty (cont’d)
THIS WARRANTY DOES NOT COVER:
• Merchandise sold as reconditioned, used as rental equipment, or floor or display
models.
• Merchandise that has become damaged or inoperative because of ordinary wear,
misuse, cold, heat, rain, excessive humidity, freeze damage, use of improper chemicals,
negligence, accident, failure to operate the product in accordance with the instructions
provided in the Owner’s Manual(s) supplied with the product, improper maintenance,
the use of accessories or attachments not recommended by All-Power America, or
unauthorized repair or alterations.
• Repair and transportation costs of merchandise determine not to be defective.
• Costs associated with assembly, required oil, adjustments or other installation and
start-up costs.
• Expendable parts or accessories supplied with the product which are expected to
become inoperative or unusable after a reasonable period of use.
• Merchandise sold by All-Power America which has been manufactured by and
identified as the product of another company, such as gasoline engines. The product
manufacturer’s warranty, if any, will apply.
• ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL LOSS, DAMAGE, OR
EXPENSE THAT MAY RESULT FROM ANY DEFECTS, FAILURE OR
MALFUNCTION OF THE PRODUCT IS NOT COVERED BY THIS WARRANTY.
Some states do not allow the exclusion, so it may not apply to you.
• IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR FROM
THE DATE OF ORIGINAL PURCHASE. Some states do not allow limitations on how
long an implied warranty lasts, so the above limitations may not apply to you.
Distributed by:
ALL-POWER AMERICA
www.allpoweramerica.com

18
Owner’s Manual
PARTS and PARTS LIST

19
Owner’s Manual
.YTQNOITPIRCSED.oNstraPAPA.ON
1 APW5118-YG-01 Detergent bottle switch 1
2 APW5118-YG-02 Spring Lock 5
3 APW5118-YG-03 Detergent bottle cap 2
4 APW5118-YG-04 Detergent bottle gasket 2
5 APW5118-YG-05 Upper frame Assy. 1
6 APW5118-YG-06 Crosshead bolt M5*45 2
7 APW5118-YG-07 Gasket φ513
8 APW5118-YG-08 Hose hook 1
9 APW5118-YG-09 High pressure hose 1
10 APW5118-YG-10 Detergent bottle 2
11 APW5118-YG-11 Crosshead bolt M5*12 2
12 APW5118-YG-12 Injection hose 3
13 APW5118-YG-13 inner hexagonal bolt M8*25 4
14 APW5118-YG-14 Spring gasket φ84
15 APW5118-YG-15 Gasket φ814
16 APW5118-YG-16 pump 1
17 APW5118-YG-17 Drain hose 1
18 APW5118-YG-18 Thermal relief cap 1
19 APW5118-YG-19 Crosshead bolt M5*40 6
20 APW5118-YG-20 Locknut M5 9
21 APW5118-YG-21 Nether frame Assy. 1
22 APW5118-YG-22 Crosshead bolt M6*45 4
23 APW5118-YG-23 10" wheel 2
24 APW5118-YG-24 Locknut M8 6
25 APW5118-YG-25 Rubber foot 2
26 APW5118-YG-26 Inner hexagonal bolt M8*50 2
27 APW5118-YG-27 Inner hexagonal bolt M8*40 4
28 APW5118-YG-28 Gasket φ65
29 APW5118-YG-29 Locknut M6 5
30 APW5118-YG-30 Axle buckle 2
31 APW5118-YG-31 Spring wire 2
32 APW5118-YG-32 Wheel shaft 2
33 APW5118-YG-33 Gasket φ16 2
34 APW5118-YG-34 Circlip 2
35 APW5118-YG-35 Gun tip holder 1
36 APW5118-YG-36 Engine foot 1
37 APW5118-YG-37 Engine 1
38 APW5118-YG-38 Gun holder 1
39 APW5118-YG-39 Crosshead bolt M5*55 1
40 APW5118-YG-40 High pressure gun 1
41 APW5118-YG-41 Nozzle 5
42 APW5118-YG-42 Nozzle gromet 5
43 APW5118-YG-43 Detergent bottle wsitch nut 1
