Bosch AdvancedAquatak 140 User manual

Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-pt.com
F 016 L81 694 (2019.01) O / 44
en Original instructions
ar   
fa   
F 016 L81 694
AdvancedAquatak 140

2 |
English ...................................................Page 3
 ..................................................  12
.................................................. 21
.......................................................... I
F 016 L81 694 | (10.01.2019) Bosch Power Tools

English | 3
English
Safety Notes
Read all safety warnings
and all instructions. Failure
to follow the safety warnings
and instructions may result in electric
shock, fire and/or serious injury.
The warning and information signs
attached to the unit provide import-
ant information for safe operation.
Apart from the information in the
operating instructions comply with
the general safety regulations and
regulations for the prevention of ac-
cidents.
Explanation of symbols
General hazard safety alert.
Never direct the water jet at
people, animals, the machine
or electric components.
Warning: High pressure jets can be
dangerous if subject to misuse.
According to the applicable
regulations, the appliance
must never be used on the
drinking water network without a
system separator. Use a separator
as per IEC61770 Type BA.
Water flowing though a system sep-
arator is considered not drinkable.
≥100 A
The AdvancedAquatak 140
is intended for use only in
premises having a service cur-
rent capacity ≥100A per phase, sup-
plied from a distribution network hav-
ing a nominal voltage of 230V. If in
doubt please contact your Supply Au-
thority.
Safety Notes for pressure washer
Connecting to the mains
uThe voltage of the power source
must correspond with the data on
the type plate of the product.
uWe recommend that this product is
only connected into a socket which
is protected by a circuit-breaker that
would be actuated by a 30mA resid-
ual current.
uThe circuit breaker supplying mains
power to the high-pressure washer
should have no less than a C16 rat-
ing. If in doubt consult a qualified
electrician for further advice. Do not
attempt to modify your electrical
system yourself.
uRemove the plug from socket
whenever the machine is left unat-
tended for any period.
uThe electric supply installation
should comply with IEC60364-1.
uIf the supply cord is damaged, it
must be replaced by the manufac-
turer, its service agent or similarly
qualified persons in order to avoid a
hazard.
Bosch Power Tools F 016 L81 694 | (10.01.2019)

4 | English
uIf the plug is damaged, pay attention
to the following:
uPlugs and sockets situated near the
work site or outdoors should be to
class IP 55 of BS 5490 to provide
adequate protection against ingress
of water, etc. and cable entries re-
quire effective sealing. Rubber
shrouds should be provided over
cable glands. Drip-proof (class IP X2
of BS 5490) plugs and sockets to BS
4343 are suitable for use indoors
where the plug is away from the wa-
ter spray area where the appliance is
in use.
uNever touch the mains plug with wet
hands.
uDo not pull plug while operating the
device.
uDo not run over, crush or pull the
power supply cord or extension
cord, otherwise it may be damaged.
Protect the cable from heat, oil and
sharp edges.
uDo not use the unit, if the power sup-
ply cord or important parts, e.g.
high-pressure hose, power gun or
safety devices are damaged.
uWarning: Inadequate extension
cables can be dangerous.
uIf an extension cord is used, the plug
and socket must be of watertight
construction. The extension cord
must have a cross section in accord-
ance with the operating instructions
and be protected against splashed
water. The connection must not be in
water.
uWhen replacing plugs on the power
supply cable or extension lead the
spray water guard and mechanical
stability must remain intact.
Water connection
uComply with the regulations of your
water supply company.
uAll connecting hoses must have
properly sealed joints.
uMake sure that the supply hose is at
least 12.7mm (1/2") in diameter
and is reinforced.
uThe appliance should never be used
on the drinking water supply without
a back flow valve. Water which has
passed the back flow valve is re-
garded as undrinkable.
uThe high-pressure hose must not be
damaged (danger of bursting). A
damaged high-pressure hose must
be replaced immediately. Only use
hoses and connections recommen-
ded by the manufacturer.
uHigh-pressure hoses, fittings and
couplings are important for the
safety of the appliance. Use only
hoses, fittings and couplings recom-
mended by the manufacturer.
uOnly clean or filtered water should
be used for intake.
Application
uBefore use, check that the machine
and operating equipment are in per-
F 016 L81 694 | (10.01.2019) Bosch Power Tools

English | 5
fect condition and are safe to oper-
ate. Do not use if it is not in perfect
condition.
uDo not direct the jet against yourself
or others in order to clean clothes or
footwear.
uDo not use solvent-containing li-
quids, undiluted acids, acetone or
solvents, including petrol, paint thin-
ners, heating oil. The sprayed va-
pours are highly flammable, explos-
ive and toxic.
uThe appropriate safety regulations
must be observed when using the
unit in dangerous areas (e.g. petrol
stations). It is forbidden to operate
the unit in potentially explosive loca-
tions.
uThe unit must be placed on a solid
base.
uTake care if using the machine in a
confined space ensuring that there is
adequate ventilation. Ensure that all
vehicles are switched off at all times
whilst cleaning.
uOperation of this machine requires
both hands to be used at all times.
Do not operate from a ladder. Take
care when using the machine on bal-
conies or other raised areas ensuring
that you can see any edges at all
times.
uOnly use detergents recommended
by the manufacturer. Comply with
the application, disposal and warn-
ing instructions of the detergent
manufacturers.
uThe use of other cleaning agents or
chemicals may adversely affect the
safety of the machine.
uAll current-conducting components
in the work area must be protected
against splashed water.
uThe gun trigger must not be jammed
in position “ON” during operation.
uDuring use of high pressure clean-
ers, aerosols may be formed. Inhal-
ation of aerosols can be hazardous to
health.
uShielded nozzles can reduce the aer-
osol effect. If necessary wear per-
sonal protective equipment (PPE)
e.g. safety goggles, breathing pro-
tection etc to protect against water,
particles and/or aerosols sprayed
back from parts.
uHigh pressure may cause objects to
rebound. If necessary wear suitable
personnel protective equipment
such as safety goggles.
uVehicle tyres/tyre valves may only be
cleaned from a minimum distance of
30cm in order to avoid damages by
the high-pressure jet. The first indic-
ation of damage is the discolouration
of the tyre. Damaged vehicle tyres/
tyre valves are dangerous to life.
uMaterials containing asbestos and
other materials which contain sub-
stances which are hazardous to your
health must not be sprayed.
uDetergents must not be used undi-
luted. The products are safe to use
as they contain no acids, alkalis or
Bosch Power Tools F 016 L81 694 | (10.01.2019)

6 | English
substances which are detrimental to
the environment. We recommend
that the detergents are kept out of
the reach of children. If detergent
comes into contact with the eyes,
wash immediately with plenty of wa-
ter and if swallowed contact a doctor
immediately.
uNever use the pressure washer
without the filter or with a dirty or
damaged filter. Using the pressure
washer without a filter or with a dirty
or damaged filter may invalidate the
warranty.
uMetal parts may become hot after
prolonged usage. If necessary wear
protective gloves.
uAvoid high pressure washing in bad
weather conditions especially when
there is a risk of lightning.
Operation
uThe operator must use the product in
accordance with the regulations. The
local conditions must be taken into
account. When working, pay atten-
tion to other people, especially to
children.
uThe unit may only be used by author-
ised persons who have received
training or have demonstrated their
ability to operate the unit. The unit
must not be operated by children or
juveniles (danger of accidents due to
incorrect use of the unit).
uNever allow children, persons with
physical, sensory or mental limita-
tions or a lack of experience and/or
knowledge and/or people unfamiliar
with these instructions to use the
product. Local regulations may re-
strict the age of the operator.
uChildren should be supervised to en-
sure that they do not play with the
product.
uThe unit must never be left unsuper-
vised while the unit is switched on.
uThe water jet from the high-pressure
nozzle produces a recoil on the gun.
You should therefore hold the gun
and spray lance firmly with both
hands.
uNever use a roto nozzle or pencil jet
to clean motor vehicles.
Transport
uSwitch off the motor and secure the
unit before transporting.
Maintenance
uSwitch off the unit prior to all clean-
ing and maintenance work and be-
fore replacing components. Pull out
the mains plug if the unit is mains-
operated.
uRepairs may only be carried out by
authorised Bosch Service Centres.
Accessories and spare parts
uAccessories and spare parts which
have been approved by Bosch must
be used. Original accessories and
spare parts guarantee that the ma-
chine can be operated safely and
without any breakdowns.
F 016 L81 694 | (10.01.2019) Bosch Power Tools

English | 7
Symbols
The following symbols are important for reading and under-
standing the original instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the product in a better and safer
manner.
Symbol Meaning
Movement direction
Reaction direction
Weight
On
Symbol Meaning
Off
Lo Low pressure
Hi High pressure
Accessories
Intended Use
The product is intended for cleaning areas and objects out-
side the house, tools, vehicles and boats, if the appropriate
accessories and cleaning agents approved by Bosch are
used.
The intended use is related to operation within 0°C and
40°C ambient temperature.
This product should not be used for professional use.
Technical Data
Pressure washer AdvancedAquatak 140
Article number 3 600 HA7 D00
Rated power kW 2.1
Supply temperature max. °C 40
Supply rate min. l/min 8.0
Allowable pressure MPa 14
Rated pressure MPa 11
Rated Flow l/min 6.8
Maximum inlet pressure MPa 1
Autostop Function ●
Weight according to EPTA‑Procedure 01:2014 kg 18.0
Protection class / I
Serial number See serial number (rating plate) on pressure washer.
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-
specific models.
Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of unfavourable
mains system conditions. Malfunctions are not to be expected for system impedances below 0.323ohm. If in doubt please
contact your Supply Authority.
Noise/Vibration Information
3 600 HA7 D00
Noise emission values determined according to EN60335-2-79.
Typically the A-weighted noise levels of the product are:
– Sound pressure level dB(A) 79
– Sound power level dB(A) 91
– Uncertainty K dB = 3
Wear hearing protection!
Vibration total values ah (triax vector sum) and uncertainty K determined
according to EN60335-2-79
Bosch Power Tools F 016 L81 694 | (10.01.2019)

8 | English
3 600 HA7 D00
– Vibration emission value ahm/s20.5
– Uncertainty K m/s2= 0.5
Mounting and Operation
Action Figure Page
Delivery scope A 30
Adjusting the Handle B 30
Connecting high pressure gun
to lance C 31
Connecting high pressure wa-
ter supply hose/nozzle D 31
Attaching Nozzle
Adjusting water jet
E – F 32 - 33
Connect detergent bottle G 34
Connecting to the water supply H 35
Switching On and Off I 35
Clean the water filter J 36
Clean nozzle K 36
Gun storage L 37
Gun/lance/nozzle stored during
work breaks M 37
Storage M 37
Selecting Accessories N 38
Switching on
For Your Safety
Warning: Switch off, remove plug from
mains before adjusting, cleaning or if cable
is cut, damaged or entangled.
The operating voltage is 230VAC, 50Hz (for non-EU coun-
tries 220V, 240V as applicable). Contact your Bosch Ser-
vice Centre for details. If in doubt contact a qualified electri-
cian or the nearest Bosch Service Centre.
If you want to use an extension cable when operating your
high pressure washer, only the following cable dimensions
should be used:
– 2.5mm2 – max length 25m
Note: If an extension cable is used it must be earthed and
connected through the plug to the earth cable of your supply
network in accordance with prescribed safety regulations.
If in doubt contact a qualified electrician or the nearest
Bosch Service Centre.
WARNING! Inadequate extension cables can
be dangerous. Extension cable, plug and
socket must be of watertight construction
and intended for outdoor use.
The connections (plugs and sockets) should be kept dry and
off the ground.
For increased electrical safety use a Residual Current Device
(RCD) with a tripping current of not more than 30mA. Al-
ways check your RCD every time you use it.
If the supply cord is damaged, it must be replaced by a
Bosch Service Centre.
For products not sold in GB:
Warning: For your safety, it is required that the plug at-
tached to the product is connected with the extension cord.
The coupling of the extension cord must be protected
against splash water, be made of rubber or coated with rub-
ber. The extension cord must be used with a cable strain re-
lief.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
uProducts that are only sold in AUS and NZ: Use a resid-
ual current device (RCD) with a nominal residual current
of 30 mA or less.
Operation
uTo prevent damage to the appliance, do not allow it to
operate dry.
Starting
Attach water supply hose (not supplied) to the mains water
supply and machine.
Connect the product to the mains supply ensuring that the
mains switch is in the off position.
Open water tap.
Press the safety lock (back button on the gun handle) to re-
lease the trigger. Fully press the trigger until there is a con-
stant flow of water to clear the air from the machine and wa-
ter supply hose. Release trigger. Press the safety lock (front
button on the gun handle).
Turn button on main switch. Point the power gun down-
wards. Press the trigger safety lock to release the trigger.
Fully press the trigger.
Autostop Function
The machine is designed to switch off the motor when the
trigger is released on the gun.
F 016 L81 694 | (10.01.2019) Bosch Power Tools

English | 9
Working Advice
General
uNever use a roto nozzle or pencil jet to clean motor
vehicles.
Ensure that the pressure washer is on level ground.
Do not overreach with the high pressure hose or move the
pressure washer by pulling the hose, this could cause the
ma-chine to become unstable and fall over.
Do not kink or drive a motor vehicle over the high pressure
hose. Do not expose the high pressure hose to sharp edges
or corners.
Working advice for cleaning with detergents
uOnly use cleaning agents suitable specifically for high
pressure washers.
We recommend that you use detergent sparingly for the sake
of the environment. Observe the recommended dilution on
the detergent label.
Recommended cleaning method
Step 1: Attach the fan nozzle and remove the heavy dirt.
Step 2: Attach the foam bottle and spray on the detergent
sparingly.
Step 3: Rinse off the loosened dirt and detergent with the
fan nozzle.
Note: When cleaning a vertical surface spray off dirt/deter-
gent from the bottom and work in an upwards direction.
Rinse from the top and work downwards.
Use with alternative water sources
This high-pressure washer will self prime and can draw water
from water tanks and natural water sources. It is IMPORT-
ANT that the water is clean and the BOSCH inlet filter is clear
and fitted to the machine.
Open tanks/containers and natural water
sources
Use the Self Priming accessory kit comprising:
– Inlet strainer with non return valve
– 3m reinforced supply hose
– Universal coupling to the pressure washer
This enables the pressure washer to draw water up to 0.5m
above the water level in the source. This may take up to 15
seconds.
Submerge the 3m hose in water to displace the air. Connect
the 3m supply hose to the pressure washer ensuring that
the inlet strainer remains submerged in the water source.
Run the pressure washer with the lance disconnected until a
steady flow of water appears from the high pressure hose.
Stop if this has not been achieved within 25 seconds and
check all the connections. Switch off and connect the lance
and nozzle to operate.
It is important to ensure that all hose and coupling connec-
tions are of good quality, air tight and that all washers are in
good condition and correctly seated in place. Failure to do
so may affect the self priming performance.
Water Tanks with outlet connections
When connecting the pressure washer to a water tank with a
suitable tap outlet, first connect the supply hose (not
provided) to the tank outlet, open the tap to allow the water
to displace all the air in the hose and then connect to the
pressure washer.
Troubleshooting
Problem Possible Cause Corrective Action
Motor refuses to start Plug not connected Connect plug
Mains socket faulty Use another socket
Fuse faulty / blown Replace fuse
Extension cable damaged Try without extension cable
Motor protector has activated Allow to cool for 15 minutes
Frozen Wait for pump/water supply hose/accessory to
thaw
Motor stops Fuse faulty / blown Replace fuse
Wrong mains voltage Check that mains voltage corresponds to specific-
ations on the model tag
Motor protector has activated Allow to cool for 15 minutes
Fuses blow Fuses incorrectly rated Change to a mains supply higher than the pres-
sure washer amp consumption
Bosch Power Tools F 016 L81 694 | (10.01.2019)

10 | English
Problem Possible Cause Corrective Action
Motor starts but no
pressure Nozzle partly blocked Clean nozzle
Motor “sounds” but
fails to start Insufficient power supply Check that the voltage of the mains power supply line is the same as that on the plate.
Voltage loss due to use of extension cable Check characteristics of extension cable
Appliance not used for a long period of time Contact your Bosch Service Centre
Problems with TSS (Total Stop System) device Contact your Bosch Service Centre
Pressure pulsating Air in the inlet water supply hose/pump Allow pressure washer to run with open spray
handle and nozzle at low pressure until regular
working pressure is obtained
Inadequate water supply Check that the water supply corresponds to spe-
cifications. The minimum specification for the wa-
ter supply hose is 1/2" or 13mm diameter
Water filter blocked Clean water filter
Water supply hoses squeezed Straighten out kinked water supply hoses
High pressure hose too long Remove high pressure extension hose. Retry (ex-
tension hose max. 7m)
Pressure too low, but
steady
Note: Several types of
accessory will normally
deliver a lower pres-
sure
Nozzle worn Change the nozzle
Start/stop valve worn Activate trigger five times in quick succession
Motor starts up but
with restricted or no
working pressure
No water supply Connect water supply
Water filter clogged up Clean the water filter
Nozzle clogged up Clean nozzle
The pressure washer
starts irregularly by it-
self
Pump/ power gun leaky Contact your Bosch Service Centre
Water leaks from ma-
chine Leaking pump A slight water leak is permissible; in case of ex- cessive leak, contact Bosch Service Centre.
Maintenance and Servicing
Maintenance
uStop, remove plug from the power supply and discon-
nect from water supply.
Note: To ensure long and reliable service, carry out the fol-
lowing maintenance regularly.
Regularly check for obvious defects such as loose fixings,
and worn or damaged components.
Check that covers and guards are undamaged and correctly
fitted. Carry out necessary maintenance or repairs before
using.
In order to avoid safety hazards, if the power supply cord
needs to be replaced, this must be done by Bosch or by an
after-sales service centre that is authorised to repair Bosch
power tools.
After use/Storage
Turn the main switch off and operate the trigger to drain the
water from the high pressure hose.
Clean the exterior of the machine thoroughly using a soft
brush or cloth. Do not use water, solvents or polishes. Re-
move all debris, especially from the ventilation slots.
End of season storage: Drain water out of pump running mo-
tor for a few seconds. Pull trigger to release all water.
Do not place other objects on top of the machine.
Store in a frost-free area.
Ensure cables are not trapped when storing. Do not kink high
pressure hose.
After-sales Service and Application Service
www.bosch-do-it.com
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.
Great Britain
F 016 L81 694 | (10.01.2019) Bosch Power Tools

English | 11
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: [phone]
E-Mail: [email protected]
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: [phone]
Fax: [phone]
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch-pt.com.au
www.bosch-pt.co.nz
Republic of South Africa
Customer service
Hotline: [phone]
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Bosch Headquarters
Midrand, Gauteng
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Environmental Protection
Chemicals dangerous to the environment must not be al-
lowed to enter the ground, ground water or ponds, streams,
etc.
For the use of cleaning agents, observe the instructions on
the package and the prescribed concentration exactly.
For the cleaning of motor vehicles the local regulations
should be observed: Do not allow oil sprayed off to enter into
the ground water. Recycle raw materials instead of waste
disposal.
Disposal
The product, accessories and packaging should be sorted
for environmental-friendly recycling.
Do not dispose of products into household
waste!
Only for EU countries:
According to the European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment and its implementation
into national law, products that are no longer usable must be
collected separately and disposed of in an environmentally
friendly manner.
Bosch Power Tools F 016 L81 694 | (10.01.2019)

12 | 



 




























≥100 A










t


t



t






t


t

t



F 016 L81 694 | (10.01.2019) Bosch Power Tools

 | 13


t


t


t





t




t

t








t





t

t

t

t





t






t





t



t



Bosch Power Tools F 016 L81 694 | (10.01.2019)

14 | 
t


t







t





t

t




t






t




t


t


t

t



t








t



t







t


F 016 L81 694 | (10.01.2019) Bosch Power Tools

 | 15
t










t






t



t



t





t





t






t








t

t

t



t



t

t


Bosch Power Tools F 016 L81 694 | (10.01.2019)

16 | 


t



t





























AdvancedAquatak 140

3 600 HA7 D00

2,1

 40

 / 8,0

 14

 11

 / 6,8

 1

●

18,0

/ I

  )   (     

 

3 600 HA7 D00

F 016 L81 694 | (10.01.2019) Bosch Power Tools

 | 17
3 600 HA7 D00


)A(
79

)A(
91


=3



 


/

0,5

/

=0,5




A30

B30

C31


D31


E - F32 - 33


G34

H35

I35

J36

K36

L37


M37

M37

N38







  




























 






t



 





Bosch Power Tools F 016 L81 694 | (10.01.2019)

18 | 










t











t
























  

 






























F 016 L81 694 | (10.01.2019) Bosch Power Tools

 | 19




















































t











  



Bosch Power Tools F 016 L81 694 | (10.01.2019)

20 | 




































F 016 L81 694 | (10.01.2019) Bosch Power Tools
