Crio Smart
2 Half Door Dual Digital
Refrigerator, 670lt (-2/-2)
ITEM #
MODEL #
NAME #
SIS #
AIA #
Short Form Specification
Item No.
APPROVAL:
LPENINOX
www.alpeninox.it
Crio Smart
2 Half Door Dual Digital Refrigerator, 670lt (-2/-2)
Crio Smart
2 Half Door Dual Digital Refrigerator,
670lt (-2/-2)
727280 (REX72HDR)2-half door dual temperature
refrigerator 670lt, -2+10°C
/ -2+10°C, digital, AISI 304
727422 (REX72HDR60)2-half door, dual temperature
refrigerator 670lt, -2+10°C
/ -2+10°C, digital, AISI 304
Two half door refrigerator with internal and external structure in 304 AISI
stainless steel; external back panel in galvanized steel and botto panel in
anti-corrosive aterial. Digital control with cabinet teperature display
and setting and anual activation of defrost cycle. Fully copliant HACCP
digital controls include visible alars. Optiized back to front forced air
flow provides even teperature distribution and fast cooling in any
conditions. Fitted with 75 -thick cyclopentane insulating foa. On-site
reversible door features lock and door icroswitch to switch off the fan
when the door is opened. Hidden evaporator to guarantee higher storage
capacity and less corrosion probles. Built-in refrigeration unit;
ventilated operation; autoatic defrost and evaporation of defrost water.
Dual operating teperature: -2/+10°C -2/+10°C. For abient
teperatures up to 43 °C. CFC and HCFC free. R134a gas in refrigeration
circuit.
Supplied with n. 3x2/1GN Rilsan coated grids and n. 3 sets of 2 stainless
steel grid runners. Prearranged to fit RS485 port to facilitate connection
to a reote coputer and integrated HACCP systes.
Main Features
•Right hinged two 1/2 doors.
•Digital control with cabinet teperature display and
setting and anual activation of defrost cycle. Fully
copliant HACCP digital controls include visible alars.
•Large storage area suitable to contain 2/1 GN grids or
shelves on anti-tilt runners.
•Optiized back to front forced air flow provide even
teperature distribution and fast cooling in any
conditions.
•Autoatic defrost.
•Internal structure with nuerous charging positions
available to host grids, ensuring higher net capacity and a
greater storage space.
•Dual teperature type: -2 +10 °C/-2 +10 °C.
•Perforance guaranteed at abient teperatures of +43°
C.
•Cabinet fitted with up to 75 thickness of cyclopentane
insulation for best insulating perforance with 100%
environental protection.
•Reovable triple-chaber balloon agnetic gasket to
iprove insulation and reduce energy consuption.
•Autoatic evaporation of the defrosting water by hot gas
on the top for energy saving.
•60 -thick insulation covering the evaporator can be
easily reoved with a single operation.
•Rilsan coated grids for iproved protection.
•Hidden evaporator thus guaranteeing higher storage
capacity and less corrosion probles.
Construction
•Constructed fro the highest quality AISI 304 Stainless
steel.
•Interior base with corners, pressed fro a single sheet.
•Stainless steel runners and supports easily disassebled.
•Anti-corrosion botto avoids any daage that ay be
caused to the cabinet by aggressive detergents eployed
to clean the floors.
•Easy access to the ain coponents for aintenance.
•Lockable door.
•Door switch stops the fan when door is opened to avoid
cold air exiting the cell, thus saving energy.
•CFC and HCFC-free insulation.
•Mounted on adjustable Stainless steel feet, with castors as
an option.
•Refrigerant type: R134a.
•Doors are self-closing and can be fully opened up to 180°.
•The rounded internal corners, the easily reovable
runners and grids allow for ease of cleaning and high
hygiene standards.

Crio Smart
2 Half Door Dual Digital
Refrigerator, 670lt (-2/-2)
Crio Smart
2 Half Door Dual Diital Refrierator, 670lt (-2/-2)
he company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2013.07.08
Included ccessories
•3 of Grey rilsan grid with 2 runners, GN 2/1PNC 881020
Optional ccessories
•2 stainless steel runners for refrigerated
cabinets - (Marine)PNC 880242 ❑
•Set of 8 GN1/1 PVC containers for fish
(only for 727280)PNC 880243 ❑
•Spacer for 670 lt and 1430 lt refrigerated
cabinetsPNC 880248 ❑
•Pedal opening for cabinetsPNC 880324 ❑
•Plastic container with false botto, GN 1/1PNC 880705 ❑
•4 swivelling wheels (2 with brake) for
refrigerators, dia 125 , NOT for glass
door and reote odels
PNC 881002 ❑
•Grey rilsan grid, GN 2/1PNC 881004 ❑
•AISI 304 stainless steel grid, GN 2/1PNC 881016 ❑
•AISI 304 stainless steel grid with 2
runners, GN 2/1PNC 881018 ❑
•Grey rilsan grid with 2 runners, GN 2/1PNC 881020 ❑
•Set of 2 stainless steel runners for
670/1430lt refrigerators and freezersPNC 881021 ❑
•PVC container with lid and 2 runners, GN
2/1PNC 881039 ❑
•Perforated shelf, GN 2/1PNC 881042 ❑
•Rilsan steel wire basket h=150, GN 1/1PNC 881043 ❑
•Grey rilsan basket+2 runners h=150,
GN 2/1PNC 881047 ❑
•Printer for HACCP basic version (for
cabinets and counters with digital control)PNC 881457 ❑

Crio Smart
2 Half Door Dual Digital
Refrigerator, 670lt (-2/-2)
Crio Smart
2 Half Door Dual Diital Refrierator, 670lt (-2/-2)
he company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2013.07.08
Front
Top
ED=Reote electrical
connection
EI=Electrical connection
RI=Refrigerant Inlet
RO=Refrigerant Outlet
Side
Electric
Supply voltage:
72728 (REX72HDR)230 V/1 ph/50 Hz
727422 (REX72HDR6)220 V/1N ph/60 Hz
Connected load:
72728 (REX72HDR)0.284 kW
727422 (REX72HDR6)0.4 kW
Key Information:
Door hinges:2 Right
External dimensions, Height:2050
External dimensions, Width:710
External dimensions, Depth:837
External dimensions, Depth with
Doors Open:1480
Number and type of doors:2x1/2Full
Gross capacity:670 lt
Number and type of grids
(included):3 - GN 2/1
Type of external material:304 AISI
Type of internal material:304 AISI
Internal panels material:304 AISI
Number of positions & pitch:0; 0
Refrigeration Data
Control type:Digital
Refrigerant type:R134a
Second Unit - Refrigerant Type:R134a
Refrigeration power at
evaporation temperature:-10 °C
Operating temperature - First Unit
(min-max): -2°C / 10°C
Operating temperature - Second
Unit (min-max):-2°C / 10°C
Operating mode:Ventilated
