Alpine Blackbird PMD-B200P User manual

1
PMD-B200P
Owner’s Manual

2
PRECAUTIONS
 Important Information
This product is intended to safely provide turn
by turn instruction to get you to a desired
destination. Please read the following precautions
to ensure that you use your navigation system
correctly.
This product is not a substitute for your personal
judgment. Any route suggestions made by the
navigation system may never supersede any local
traffic regulations or your personal judgment
and/or knowledge of safe driving practices. Do
not follow route suggestions if the navigation
system instructs you to perform an unsafe or illegal
manoeuvre, places you in an unsafe situation, or
routes you into an area which you consider unsafe.
Glance at the monitor screen only when necessary
and safe to do so. If prolonged viewing of the
screen is necessary, stop the vehicle in a safe and
legal manner and location.
Do not input destinations, change settings, or
access any functions requiring prolonged viewing
of the monitor and/or remote control while you are
driving. Stop the vehicle in safe and legal manner
and location before attempting to access the
system.
Do not use the navigation system to route you to
emergency services. Not all locations of emergency
service providers such as police and fire stations,
hospitals and clinics are contained in the database.
Please use your own judgment and your ability to
ask for directions in these situations.
The map database contained within the media
in which it is stored is the most recent map data
available at the time of production. Because of
changes in streets and neighbourhoods, there may
be situations where the navigation system may not
be able to route you to your desired destination. In
these cases, use your own personal judgment.
The map database is designed to provide you with
route suggestions. It does not take account of the
relative safety of a suggested route, or of factors
which may affect the time required to reach your
destination. The database does not reflect road
closures or construction, road characteristics (i.e.
type of road surface, slope or grade, weight or
height restrictions, etc.), traffic congestion, weather
conditions, or any other factors which may affect
the safety or timing of your driving experience. Use
your personal judgment if the navigation system is
unable to provide you with an alternate route.
There may be situations where the navigation
system may display the vehicle’s location
erroneously. Use your own driving judgment in
this situation, taking into account current driving
conditions. Please be aware that in this situation
the navigation system should correct the vehicle’s
position automatically; however, there may be
times when you may have to correct the position
yourself. If this is the case, stop the vehicle in safe
and legal manner and location before attempting
operation.
Make certain that the volume level of the monitor
is set to a level which still allows you to hear
outside traffic and emergency vehicles. Driving
while unable to hear outside sounds could cause
an accident.
Please make certain that any other person who
intends on using the navigation system reads
these precautions and the following instructions
carefully.
If there is anything in the manual which you do not
understand, or are uncertain about the operation
of the navigation system, please contact an
authorised ALPINE representative before using the
navigation system.
Please Read Carefully Before Using This Product
Correct Disposal of This Product
The product purchased by you is provided in accordance with the European directive 2002/96
EC on WEEE - Waste Electrical and Electronic Equipment. A symbol of the crossed out dustbin has
therefore been printed on the product. This applies to all member states of the EC and indicates
the fact that the product may not to be disposed of in the normal domestic waste. The product
must be disposed of in accordance with the local regulations at separate collection points.
Disposal in the normal domestic waste harms the environment. Please contact the responsible
waste management authorities or your local dealer where you purchased the product for further
information.

3
WARNINGS
Read the manuals for this device and the
system components carefully before using
your navigation system. They contain
instructions on how to use the system in a safe
and effective manner. ALPINE cannot be held
responsible for problems resulting from failure
to observe the instructions in these manuals.
This manual uses various pictorial displays to
show you how to use this product safely and
to alert you to potential dangers resulting
from improper connections and operation. The
meanings of these pictorial displays are shown
below. It is important fully to understand the
meanings of these pictorial displays in order to
use this manual and the system properly.
Warning
DO NOT OPERATE ANY FUNCTION THAT DIVERTS YOUR
ATTENTION FROM SAFELY DRIVING YOUR VEHICLE.
Any function that requires your prolonged attention should only be
performed after coming to a complete stop. Always stop the vehicle
in a safe location before performing these functions. Failure to do
so may result in an accident.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, fire or electric shock.
KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH
OF CHILDREN.
Swallowing them may result in serious injury. If swallowed, consult
a physician immediately.
USE THIS PRODUCT AS SPECIFIED.
Use for other than its designed application may result in fire,
electric shock or other injury.
DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN
INSERTION SLOTS OR GAPS.
Doing so may result in personal injury or damage to the product.
MINIMISE DISPLAY VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT FOLLOW ROUTE SUGGESTIONS IF THE NAVIGATION
SYSTEM INSTRUCTS YOU TO PERFORM AN UNSAFE OR ILLEGAL
MANOEUVRE, OR PLACES YOU IN AN UNSAFE SITUATION OR
AREA.
This product is not a substitute for your personal judgment. Any
route suggestions by this system should never supersede any local
traffic regulations or your personal judgment or knowledge of safe
driving practice.
Caution
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it to your authorised ALPINE dealer or the nearest
ALPINE Service Centre for repair.
Points to Observe for Safe Usage
Meaning of displays
Warning This symbol means important instructions. Failure to heed them
may result in serious injury or death.
Caution This symbol means important instructions. Failure to heed them
may result in injury or material property damage.

4
KEEP FINGERS AWAY WHILE THE MOTORISED FRONT PANEL
OR MOVING MONITOR IS IN MOTION.
Failure to do so may result in per-
sonal injury or damage to the product.
Temperature
Be sure the temperature inside the vehicle is between +45°C
(+113°F) and 0°C (+32°F) before turning your unit on.
Fuse Replacement
When replacing the fuse(s), the replacement must be of the same
amperage as shown on the fuse holder. If the fuse(s) blow(s)
more than once, carefully check all electrical connections for short
circuiting. Also have your vehicle’s voltage regulator checked.
Servicing the Unit
If you have problems, do not attempt to repair the unit yourself.
Return it to your ALPINE dealer or the nearest ALPINE Service
Station for servicing.
Installation Location
Make sure the PMD-B200P will not be exposed to:
• Directsunandheat • Excessivedust
• Highhumidity • Excessivevibrations
Characteristics of LCD Panel
• Afterturningthesystemoff,aslightghostoftheimagewill
remain temporarily. This is an effect peculiar to LCD technology
and is normal.
• Undercoldtemperatureconditions,thescreenmaylosecontrast
temporarily. After a short warmup period, it will return to normal.
• TheLCDpanelismanufacturedusinganextremelyhighprecision
manufacturing technology. Its effective pixel ratio is over 99.99%.
This means that 0.01% of the pixels could be either always ON or
OFF.
Using Headphones
If ACC or the monitor's power source is turned off, a loud noise may
be produced through the headphone jack. Be sure to remove the
headphones from your ears before you turn the monitor off.

5
USER AGREEMENT
In using this Blackbird Portable Navigation System (hereinafter referred to as “System”), which includes ALPINE
Electronics, Inc. (“ALPINE”) Specifications, Space Machine, Inc. (“Space Machine”) Software and NAVTEQ B.V.
(“NAVTEQ”) Database, you are bound by the terms and conditions set forth below. By breaking the seal on
the System and using your copy of the System, you have demonstrated your agreement to the terms and
conditions of this Agreement. You should, therefore, make sure that you read and understand the following
provisions.
The System may not be copied, duplicated or otherwise modified, in whole or in part, without the express
written permission of ALPINE, Space Machine and NAVTEQ.
The System may not be transferred or sublicensed to any third party for profit, rent or loan or licensed for
reuse in any manner.
The System may not be decompiled, reverse engineered or otherwise disassembled, in whole or in part.
The System may not be used in a network or by any other manner of simultaneous use in multiple systems.
The System is intended solely for personal use (or internal use where the end-user is a business) by the
consumer.
The System is not to be used for commercial purposes.
Neither ALPINE, Space Machine nor NAVTEQ guarantees to the customer that the System meet the specific
objectives of the user.
Neither ALPINE, Space Machine nor NAVTEQ shall be responsible for any damage caused by the use of the
System to the actual user and to any third party.
The warranty on the System shall not extend to an exchange or refund due to misspelling, omission of letters,
or any other cosmetic discrepancy in layout found in the System.
The right to use the System shall expire either when the user destroys this software, or when any of the terms
for use is violated and ALPINE, Space Machine and/or NAVTEQ exercise the option to revoke the license to use
this software.
The terms and conditions hereof apply to all subsequent users and owners as well as to the original purchaser.
NAVTEQ END USER LICENSE AGREEMENT
PLEASE READ THIS END USER LICENSE AGREEMENT CAREFULLY BEFORE USING THE NAVTEQ DATABASE
NOTICE TO THE USER
THIS IS A LICENSE AGREEMENT – AND NOT AN AGREEMENT FOR SALE – BETWEEN YOU AND NAVTEQ B.V. FOR
YOUR COPY OF THE NAVTEQ NAVIGABLE MAP DATABASE, INCLUDING ASSOCIATED COMPUTER SOFTWARE,
MEDIA AND EXPLANATORY PRINTED DOCUMENTATION PUBLISHED BY NAVTEQ (JOINTLY “THE DATABASE”). BY
USING THE DATABASE, YOU ACCEPT AND AGREE TO ALL TERMS AND CONDITIONS OF THIS END USER LICENSE
AGREEMENT (“AGREEMENT”). IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN
THE DATABASE, ALONG WITH ALL OTHER ACCOMPANYING ITEMS, TO YOUR SUPPLIER FOR A REFUND.
OWNERSHIP
The Database and the copyrights and intellectual property or neighboring rights therein are owned by
NAVTEQ or its licensors. Ownership of the media on which the Database is contained is retained by NAVTEQ
and/or your supplier until after you have paid in full any amounts due to NAVTEQ and/or your supplier
pursuant to this Agreement or similar agreement(s) under which goods are provided to you.
LICENSE GRANT
NAVTEQ grants you a non-exclusive license to use the Database for your personal use or, if applicable, for use
in your business’ internal operations. This license does not include the right to grant sub-licenses.
LIMITATIONS ON USE
The Database is restricted for use in the specific system for which it was created. Except to the extent explicitly
permitted by mandatory laws (e.g. national laws based on the European Software Directive (91/250) and the
Database Directive (96/9)), you may not extract or reutilise substantial parts of the contents of the Database
nor reproduce, copy, modify, adapt, translate, disassemble, decompile, reverse engineer any portion of the
Database. If you wish to obtain interoperability information as set out in (the national laws based on) the
European Software Directive, you shall grant NAVTEQ reasonable opportunity to provide said information on
reasonable terms, including costs, to be determined by NAVTEQ.

6
TRANSFER OF LICENSE
You may not transfer the Database to third parties, except when installed on the system for which it was
created or when you do not retain any copy of the Database, and provided that the transferee agrees to all
terms and conditions of this Agreement and confirms this in writing to NAVTEQ. Multi-disc sets may only be
transferred or sold as a complete set as provided by NAVTEQ and not as subset thereof.
LIMITED WARRANTY
NAVTEQ warrants that, subject to the warnings set out below, for a period of 12 months after acquisition of
your copy of the Database, it will perform substantially in accordance with NAVTEQ’s Criteria for Accuracy
and Completeness existing on the date you acquired the Database; these criteria are available from NAVTEQ
at your request. If the Database does not perform in accordance with this limited warranty, NAVTEQ will use
reasonable efforts to repair or replace your non-conforming copy of the Database. If these efforts do not lead
to performance of the Database in accordance with the warranties set out herein, you will have the option to
either receive a reasonable refund of the price you paid for the Database or to rescind this Agreement. This
shall be NAVTEQ’s entire liability and your sole remedy against NAVTEQ. Except as expressly provided in this
section, NAVTEQ does not warrant nor make any representations regarding the use of results of the use of
the Database in terms of its correctness, accuracy, reliability, or otherwise. NAVTEQ does not warrant that the
Database is or will be error free. No oral or written information or advice provided by NAVTEQ, your supplier
or any other person shall create a warranty or in any way increase the scope of the limited warranty described
above. The limited warranty set forth in this Agreement does not affect or prejudice any statutory legal rights
that you may have under the legal warranty against hidden defects.
If you did not acquire the Database from NAVTEQ directly, you may have statutory rights against the person
from whom you have acquired the Database in addition to the rights granted by NAVTEQ hereunder
according to the law of your jurisdiction. The above warranty of NAVTEQ shall not affect such statutory rights
and you may assert such rights in addition to the warranty rights granted herein.
LIMITATION OF LIABILITY
The price of the Database does not include any consideration for assumption of risk of consequential, indirect
or unlimited direct damages which may arise in connection with your use of the Database. Accordingly, in
no event shall NAVTEQ be liable for any consequential or indirect damages, including without limitation, loss
of revenue, data, or use, incurred by you or any third party arising out of your use of the Database, whether
in an action in contract or tort or based on a warranty, even if NAVTEQ has been advised of the possibility of
such damages. In any event NAVTEQ’s liability for direct damages is limited to the price of your copy of the
Database.
THE LIMITED WARRANTY AND LIMITATION OF LIABILITY, SET FORTH IN THIS AGREEMENT, DO NOT
AFFECT OR PREJUDICE YOUR STATUTORY RIGHTS WHERE YOU HAVE ACQUIRED THE DATABASE
OTHERWISE THAN IN THE COURSE OF A BUSINESS.
WARNINGS
The Database may contain inaccurate or incomplete information due to the passage of time, changing
circumstances, sources used and the nature of collecting comprehensive geographic data, any of which may
lead to incorrect results. The Database does not include or reflect information on – inter alia – neighborhood
safety; law enforcement; emergency assistance; construction work; road or lane closures; vehicle or speed
restrictions; road slope or grade; bridge height, weight or other limits; road or traffic conditions; special events;
traffic congestion; or travel time.
GOVERNING LAW
This Agreement shall be governed by the laws of the jurisdiction, in which you reside at the date of acquisition
of the Database. Should you at that moment reside outside the European Union or Switzerland, the law of
the jurisdiction within the European Union or Switzerland where you acquired the Database shall apply.
In all other cases, or if the jurisdiction where you acquired the Database cannot be defined, the laws of
the Netherlands shall apply. The courts competent at your place of residence at the time you acquired
the Database shall have jurisdiction over any dispute arising out of, or relating to this Agreement, without
prejudice to NAVTEQ’s right to bring claims at your then current place of residence.

7
TABLE OF CONTENTS
Precautions.....................................2
Warnings.......................................3
User Agreement.................................5
NAVTEQ end user license agreement ...............5
Table of Contents................................7
System Features.................................9
Installation................................... 11
How to Mount Blackbird .................................. 11
How To Remove the Navigation System
from the Cradle................................................11
Additional On-Screen Buttons .......... 12
Docking with IVA-W205R/IVA-W505R
(not included).................................................. 12
Removing Blackbird from IVA-W205R/
IVA-W505R ...................................................... 12
How to Reset Blackbird .................................... 12
Basic Operation ............................... 13
To Power On.....................................................13
To Power Off .................................................... 13
Set a Destination and Go!................................. 13
Map Function ................................. 15
Setting Estimated Time Display ....................... 15
Setting the Map Orientation............................15
Traffic Information (TMC)................................. 15
Repeating the Announcement.........................15
Zoom Out/In Map............................................ 15
GPS Status ...................................................... 15
Battery Status................................................. 15
Setting a Destination Directly
from Map Display............................................. 16
Switching Map Display................. 16
Map Mode ........................... 16
Split Mode....................................................... 16
Arrow Mode..................................................... 16
Destination................................... 17
Setting a Destination by Address..................... 17
Change Country....................... 17
Selecting Letters...................... 17
Confirm Destination Screen.............................. 17
Finding a Destination by City
Name First ........................... 18
Setting a Destination by POI
(Places of Interest)........................................... 19
Finding a Destination by POI Name ...... 19
Setting a Destination from the Address Book.... 19
Finding a Destination by POI Category ... 20
Near Here............................ 20
Near Destination...................... 20
By POI Name ......................... 20
Within a City ......................... 20
Setting a Destination by Previously Entered
Destinations .................................................... 21
Setting a Destination by Postcode.................... 21
Setting a Destination by Intersection ...............22
Finding a Destination by City Name...... 22
Setting a Destination in the City Centre............ 23
Setting a Destination by Coordinates................ 24
Options ...................................... 25
Find Local POI.................................................. 25
How to Find Local POI Directly from the
Map................................. 25
How to Find Local POI from the Destination
Menu................................ 25
Saving a Destination to the Address Book......... 26
Setting Waypoints ........................................... 27
How to Set a Waypoint Directly
from Map ............................ 27
How to Set a Waypoint from
the Destination Menu ................. 27
How to Set a Waypoint from the Address
Book ................................ 27
Home........................................ 28
Set Destination as Home.................................. 28
Finding Alternate Way to Go Home................... 28
One-Touch Go Home......................................... 28
Route........................................ 29
Recalling the Turn List during Guidance............ 29
Finding Alternate Route .................................. 29
Avoid a Street.................................................. 30
Delete Route ................................................... 30
Reroute ........................................................... 30
Phone ....................................... 31
Placing Calls .................................................... 31
Using the 12 key Dial Pad .............. 31
Using your Phonebook................. 31
Using Dialled, Missed or Received Calls
from your call history.................. 31
Receiving Calls................................................. 32
Call Option Menu ............................................. 32
Mute Mic. ............................ 32
Transfer to Phone ..................... 32
End Call.............................. 32
Information .................................. 33
Simulating Navigation..................................... 33
Start Demo .......................... 33
Stop Demo .......................... 33
GPS Status ....................................................... 33
Trip Info........................................................... 34

Traffic Info....................................................... 35
Checking Traffic Condition.............. 35
By Distance/By Name.................. 35
On Route ............................ 35
Getting more Information on a Traffic
Incident ............................. 36
Map................................. 36
Detail ............................... 36
To Improve Traffic Signal Reception, Please
Follow These Instructions .............. 37
Method 1 ............................ 37
Method 2 ............................ 37
System Info ..................................................... 37
Edit ......................................... 38
Editing Home................................................... 38
Editing Address Book ....................................... 38
Deleting Previously Saved Destinations............ 38
Entertainment ................................ 40
Playing Music from Blackbird ........................... 40
M.I.X. ............................... 40
REPEAT .............................. 40
Setup ........................................ 41
Bluetooth Setup .............................................. 41
Bluetooth............................ 41
Add new phone....................... 41
Auto Connect......................... 41
Auto Answer ......................... 42
Phonebook........................... 42
Device Name ......................... 42
Bluetooth Passcode ................... 42
Bluetooth Indicator Light .............. 42
Pairing Your Bluetooth-Enabled Mobile
Phone ............................... 43
Display Setup................................................... 43
Brightness ........................... 43
Map Colour........................... 43
Austria : © Bundesamt für Eich- und Vermessungswesen
France : source: Géoroute® IGN France & BD Carto® IGN France
Germany : Die Grundlagendaten wurden mit Genehmigung der zuständigen
Behörden entnommen
Great Britain : © Based upon Crown Copyright material.
Greece : Copyright Geomatics Ltd.
Italy : La Banca Dati Italiana è stata prodotta usando quale riferimento anche
cartografia numerica ed al tratto prodotta e fornita dalla Regione
Toscana
Norway : Copyright © 2000; Norwegian Mapping Authority
Portugal : Source: IgeoE – Portugal
Spain : Información geográfica propiedad del CNIG
Sweden : Based upon electronic data © National Land Survey Sweden
Switzerland : Topografische Grundlage: © Bundesamt für Landestopographie
8
Map Style............................ 43
POI Icon and Home Icon................ 43
Trail................................. 43
Background .......................... 43
Display Adjustment ................... 43
Guidance Setup ............................................... 44
Voice Prompt ......................... 44
Navi Mix Vol. ......................... 44
Guidance Time........................ 44
Attention Tone ....................... 44
Clock Setup...................................................... 44
Unit Setup ....................................................... 44
System Setup................................................... 44
Transmitter .......................... 44
Frequency ........................... 44
Beep ................................ 44
Reset All Settings ..................... 44
Traffic Info....................................................... 45
Country.............................. 45
Station .............................. 45
Traffic Reroute........................ 45
Icons ................................ 45
Other Useful Features .......................... 46
How to Listen to Guidance and Music from Your
Car Stereo........................................................ 46
Turning on the Transmitter and Playing
Music from Your Radio ................. 46
Turning Off the Transmitter............. 46
How to Update New Software and Map
Database ......................................................... 46
In Case of Difficulty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
In the Box .................................... 48
Accessories ...................................................... 48
Optional Accessories........................................ 48
Specifications................................. 49
Index ........................................ 50

9
SYSTEM FEATURES
Current Vehicle
Position Icon
Mini USB Connector
External GPS
Antenna Connector
Destination
Volume
Control
Map Zoom Out
Music
Main Menu Button
Map Zoom In
Power Button Headphone Jack
Battery Charging Status Indicator
Remote Sensor
and Ambient
Light Sensor
SD/MMC Card Slot
GPS Antenna
Battery Slot
Speaker
This illuminates when the system is being charged or requires charging. The battery will
typically be charged fully in three hours.
GREEN Battery is fully charged. RED Battery needs charging.
AMBER Battery is charging.
Battery Charging Status Indicator
Blackbird Portable Navigation System
Cradle Connector
Center Key (Phone Key)

10
Please register your Blackbird on our web site, www.alpine-europe.com. You can receive
information about a software update, new ALPINE products, etc. from us.
Main Menu
Cradle with Cigarette Lighter Charger
Get back home from
anywhere.

Page 28
Set and save
Destinations.

Page 17
Modify or choose
alternate routes to a
destination.

Page 29
View Navigation
Demonstration and
system information.

Page 33
Access your Bluetooth
paired mobile phone.

Page 31
Customise the
navigation system.

Page 41
Cradle Eject Lockout Screw
External GPS Antenna
Input
(SMA-type connector)
External Microphone
Input
AMPS/NEC
Mounting Holes
(x 4)
Windshield Mount Slot
Amplified External
Speaker
User Registration
Power Cord
RDS Antenna
Edit Home and
Address Book.

Page 38
Play music.

Page 40

11
INSTALLATION
How to Mount Blackbird
2
3
4
21
Incorrect installation may cause the navigation system
to fall out of the cradle while driving. Please make sure
all locks and knobs are turned tight.
Do not install the navigation while driving.
2
1
Find a suitable spot for the navigation system.
Ensure that both the suction cup and windscreen area
are clean and free of dirt and grease before attaching
the cup.
Stick the suction cup mount against the windscreen.
Turn the knob to activate the vacuum to lock the
position.
Turn the knob counter-clockwise to adjust up/down
position. Then turn clockwise to set the position.
Turn the knob clockwise to adjust right/left position.
Then turn counter-clockwise to set the position.
DEVICE SHOULD NOT BE INSTALLED SO THAT IT
OBSTRUCTS THE DRIVER’S VIEW.
Slide the navigation system into the cradle until you
hear a “click” sound.
Plug the cigarette lighter charger into the cigarette
lighter socket.
2
1
3
4
5
WARNING
Press and hold the eject button on the cradle.
Take hold of the navigation system behind the antenna
and remove by sliding up and out of the cradle.
How To Remove the Navigation System from the Cradle
Remove the navigation system when you are away
from the vehicle to prevent theft.
CAUTION
Note: The cradle consists of 2 separate parts that must be
assembled before mounting.
NOTE: Local regulations may prohibit the place-
ment of any object on windows or the dash. Refer to
your authorised ALPINE dealer for other installation
options.

12
How to Reset Blackbird
In the event the system requires a reset, pull over in a safe and legal manner before doing
so. Press the reset button on the bottom for at least 1 second. Then, to restart the system,
press and hold the power button for 2 seconds. The system will re-start.
Docking with IVA-W205R/IVA-W505R (not included)
CLOSE
1
2
Open IVA-W205R/IVA-W505R head unit monitor.
Insert Blackbird into the unit with the screen facing
up and the hard keys on the left.
Press Blackbird firmly into place.
Touch Close to close IVA-W205R/IVA-W505R face.
Select Blackbird as source.
Additional On-Screen Buttons
When Blackbird is docked, two additional on-screen
buttons allow you conveniently to access additional
system features.
Touching this button will give you access to the A/V
Head Unit’s display control.
NOTE: If left idle for more than 5 seconds, the system
will automatically return to the Blackbird navigation
screen.
Touching this button will display Blackbird’s music
screen. Refer to page 40 for more information on the
music functions.
4
3
2
1
5
Removing Blackbird from IVA-W205R/IVA-W505R
CLOSE
1
2
Touch Open on the screen.
Press the eject button.
Remove Blackbird from the head unit.
3
2
1

Press and hold Power
Button for 2 seconds.
Opening screen appears.
Read carefully.
Touch I Agree to display
map.
The last-known current
location is indicated on
the map.
To Power Off
Press and hold Power Button
for 2 seconds.
Power Button
Touch Main Menu .
Select Destination from
Main Menu or press
Destination button.
1
BASIC OPERATION
Set a Destination and Go!To Power On
1
2
3
4
Select desired method.
(In this example, Places is
selected.)
2
Select a search method.
(In this example, By POI
Category is selected.)
3
The following example briefly describes how
to input a destination.
13

Select the place with
correct address.
7
For Map Function, see page 15.
Scroll the list.
Select desired place list.
(In this example, AIRPORTS is
selected.)
4
Map is displayed.
Follow the navigation.
9
Select OK to Proceed to
set the destination.
8
To Find other routes, see page 29.
To Go Home, see page 28.
Select the search method.
(In this example, By POI
Name is selected.)
5
Type name of a place.
If more than one place with
the same name exists, the sort
method screen appears.
6
14

MAP FUNCTION
Click icon to switch between
Estimated Time Remaining and
Estimated Time of Arrival.
Note: The time estimates are based on
the average speed. The estimated time
will vary depending on vehicle speed.
The arrow always points toward the
destination.
Click icon to switch between North
Up, Heading Up and 3D views.
Setting the Map Orientation
Setting Estimated Time Display
Click icon to repeat the guide
announcement.
Click icon to display scroll bar.
Touch  or blue bar to zoom the
map out or in.
The scroll bar disappears automatically
after 4 seconds.
Repeating the Announcement
Zoom Out/In Map
GPS Status
Battery Status
Click icon to view GPS receiving
condition information from satellite.
Shows status of the battery.
(lightning bolt) being charged.
(4 bars) fully charged.
(3 bars) more than 75% charge.
(2 bars) more than 50% charge.
(1 bar) about 25% charge remaining.
Distance to next
manoeuvre
Next Street Name
Next Manoeuvre
Arrow
Map Orientation
Distance to
Destination
Direction to
Destination
Estimated Time
Remaining (ETR) /
Estimated Time of
Arrival (ETA)
GPS Status Bar
Battery Status
Indicator
Current Street
Name
Display Mode
Button
Current
Position /
Voice Prompt
Repeat Button
Map Scale Bar
Main Menu
Button
Traffic Information
Click icon to see detailed traffic
information.
Blue icon: no TMC events on route.
Yellow icon: TMC events on route
without causing delay.
Red icon: TMC events on route
causing delay.
Traffic Information (TMC)
15

Touch anywhere on map screen.
The crosshair cursor appears.
Move the cursor to the new desired loca-
tion.
Note: Use Map Scale Bar to zoom out the map if the
destination is far from the current location.
Touch Select.
Select Set as Destination.
Touch OK to Proceed on the confirmation
screen.
Note: To use other functions on the confirmation screen,
see page 17 for details.
5
4
3
2
1
Setting a Destination Directly from Map Display
To cancel,
touch Previous
Screen icon.
Touch the to switch among Map, Split and Arrow modes.
Switching Map Display
Arrow Mode
Displays three
successive arrow
manoeuvres all
the way to your
destination while
providing turn-
by-turn guidance
prompts.
Map Mode
Shows a full-screen
map of the area while
providing turn-by-turn
guidance prompts.
Split Mode
Displays a large
arrow and larger
next-street-name
font alongside a
map screen while
providing turn-
by-turn guidance
prompts.
16

DESTINATION
Setting a Destination by Address
OK to Proceed
Starts Guidance.
Option
Set as Waypoint

Page 27
Save in Address Book

Page 26
Find Local POI

Page 25
Change Method
Modifies Route by changing route
settings. (Refer to page 29.)
Go to Main Menu.
Destination Address
1
Confirm Destination Screen
Map
Check the destination on
the map. Touch to
go back to the
confirmation screen.
Call
Make a phone call to your destination.
Note: Bluetooth-enabled phone must
be paired before and phone number
must be available (POIs, Address Book).
Change Country
To choose a different country from
the one shown on the screen, touch
Change to switch to a list to select
from.
Selecting Letters
Selected
characters are
displayed here.
Deleting one character
Adding one space character
Switching to number screen
Switching to special character screens
17

Finding a Destination by City Name First
Select Input City Name.
Note: Pressing Recent, you can directly select from a list
showing the cities set as previous destinations (Proceed
with step 4).
Type the first few characters of the city name
and press OK.
If there are unique matches, the system will automatically
display a short list of city names. Select the desired city.
Type the first characters of the street name.
Touch OK.
The list of applicable street names appears. Select the
desired street.
Enter the address number and press OK.
Confirmation screen appears.
See page 17 for details.
6
5
4
3
2
18

The Places of Interest are sorted by POI Name and by POI Category and are listed in order of
distance from your current location.
Finding a Destination by POI Name
Go to Main Menu
Destination
Places
1
Select By POI Name.
Type the desired POI name. Touch OK.
A list of place names appears.
Note: Use the arrows to the right of the list to move the yel-
low highlight. This will show detailed address information and
phone number (if available) for each entry in the POI data-
base.
Select an entry.
For emergency locations such as Police Stations, Hospitals,
etc., please verify availability before proceeding to such
locations.
Confirmation screen appears. Touch OK to
Proceed to set the destination and start
guidance.
3
5
4
2
DESTINATION
Setting a Destination by POI (Places of Interest)
Go to Main Menu
Destination
Address Book
Select the desired destination.
Confirmation screen appears.
Touch OK to Proceed to set the destination and start guidance.
To save an address in the address book, see page 26.
3
2
1
Setting a Destination from the Address Book
19

Select By POI Category.
Select the required Category.
Select Search Method.
4
3
2
Finding a Destination by POI Category
Near Here
By POI Name
Within a City
A list of POI names appears in order of distance
from the current vehicle position.
Select an entry OK to Proceed
6
5
Follow 3 to 5 in “Finding a Destination by POI Name” on Page 19.
5
Type the city name and select a city.
A list of POI names appears in order of the
distance from the selected city.
Select an entry OK to Proceed
7
6
5
Near Destination
A list of POI names appears in order of distance from the destination.
Select an entry OK to Proceed
6
5
20
