Alpine PLD120 User manual

PLD120
Illumination Light
Limited Warranty Information
Thank you for choosing an Alpine product! We aim to please with our wide range of products
including Fountains, Birdbaths, Statuary, Pond Supplies & More. All of our products are constructed
from the highest quality materials. In the event that we have not achieved our usual standard of
excellence, we will repair or replace, at our discretion within the warranty period. A valid proof of
purchase with the purchase date clearly indicated must be provided. Photos of defective
merchandise will also be required to help distinguish the actual cause of the defect. Please read
below for a detailed description of warranty coverage.
Water Damage
Alpine products are not manufactured to withstand extreme temperatures. Improper
storage that allows water to freeze within a product may cause damage, is considered
negligence and will not be covered under this warranty. The use of “hard water” and/or
caustic cleaners can affect the painted or other finishes. Failure to keep the unit clean and
use of such additives/cleaners will also void the warranty. Please note: for fountains, it is
normal for some splashing to occur and protecting the immediate surfaces is not the
responsibility of Alpine Corporation
Procedure/Service
Should a warranty/claim be needed, you should contact the retailer from whom you
purchased the product. If that not an option, you can contact Alpine Corporation at
www.alpine4u.com. When contacting Alpine Corporation, you must be prepared to
show proof of purchase, provide photographs and any other information needed to
validate your claim. This may be necessary to distinguish between a partial or complete
replacement of a defective product. The warranty does not cover any items with multiple
parts; the warranty will ONLY cover the individual component of the unit/item that may be
defective. Replacement parts can be made available to a consumer through the original
selling party, or an approved parts retailer. If this is not an option, contact our customer
service department.
Not Covered Under Warranty
The limited warranty will NOT cover cases of damages due to
1. Damages caused in Transit
2. Inadequate care and/or neglect
3. Environmental and/or natural elements
4. Immersion in water, unless specified
5. Improper Installation/Storage and/or Maintenance
This warranty is void if the product has been damaged by accident, misuse, negligence, improper
installation and/or modifications have occurred. This includes any and/or all defects arising out of
freezing water damage, hard water damage, failure to keep the unit clean and free of harmful
additives such as bleach, chlorine, etc…. which affects the paint and/or parts. This warranty also
does not cover any additional charges or installation, removal, disposal and/or shipping costs or
consequential damage associated with any warranty claim

20-Watt Low Voltage Illumination Lights can be used indoor or outdoor, out
of water or in water. Must be used with a transformer at all times, an Alpine
transformer is recommended to use with this light.
Must be operated with a transformer (not included):
Before Reading instructions below, this light MUST BE used with a transformer.
Suggested use with an Alpine multi-light transformer. Please use a transformer with
the correct wattage and never exceed the maximum wattage indicated on the
transformer.
Operating Instructions:
Before plugging in the unit, be sure the input voltage indicated on your transformer is
the same as your local power supply. If not, please do not operate the light until you
obtain the appropriate transformer from your local dealer.
To reduce the risk of electrical shock, inspect all cords for damage before installation.
Plug the connector of the Illumination Light into the socket on the transformer and
screw the coupling until tight.
Plug the transformer into the nearest outlet. Your Illumination light should light up.
Changing the Bulb or Colored Lenses to your Illumination Light:
To replace the 20 watt halogen bulb, first make sure to unplug the transformer and
remove it from the water (if submerged)
After allowing a sufficient amount of time for the light to cool, let it dry and remove the
lens retainer from the Illumination light by pushing on it and turning counter-clockwise
quickly.
Remove the lens carefully and make sure the “O” ring stays in place and is not lost
during this process
Gently pull out the socket and remove the bulb and replace with the new 20 watt bulb
by aligning the pins of the bulb into the socket. Gently push the new bulb down, DO
NOT force it. Turn 20 watt bulb around if it does not fit easily.
Re-Install the lens and lens retainer ensuring the “O” ring remains in the correct
position in the groove of the Illumination Light
To maintain a water tight seal, make sure the lens is flush with the front lip of the
rubber seal.
To change your Illumination color lens, remove the lens and replace it with a colored
lens of your choice.
Make sure the lens is on the rubber seal then take the cover and place it correctly onto
the slots of the Illumination Light, turning tightly clockwise.
Make sure the cover is tightly locked
Troubleshooting your Illumination Light:
If light fails to illuminate, please check the following:
Check that the light set is getting power by testing another applicant in the
power outlet that the lights use
Check to ensure that your light bulb has not burned out from usage
If water gets into any of your Illumination lights, lift it out of the water, remove
the lens and empty the water until dry
Caution & Warning:
Always handle the light from the base. The light housing can and will become
HOT!
Operating the lights with missing or damaged covers can result in risk of fire or
electrical shock
Use ONLY recommended 20 watt halogen bulbs
Do not exceed the voltage & wattage indicated on the transformer
Keep away from flammable and/or children
This light assembly has not been tested or deigned for use in swimming pools
and hot tubs
