Technical Manual
GPS Grandmaster Clock
Platform Hardware Version: A
Platform Software Version: 05
Publication Reference: RT434-TM-EN-2

GPS Grandmaster Clock
2
RT434-TM-EN-2
Contents
TECHNICAL MANUAL 1
PREFACE 6
ACRONYMS AND ABBREVIATIONS 7
1. DESCRIPTION 10
1.1 INTRODUCTION 10
1.2 FOREWORD 11
1.3 KEY FEATURES 11
1.4 AVAILABLE MODELS 12
1.4.1 NETWORK PORTS 13
1.4.2 POWER SUPPLY 14
1.5 FRONT AND REAR VIEWS 14
1.6 TECHNICAL SPECIFICATIONS 16
1.6.1 POWER SUPPLY 16
1.6.2 GPS ANTENA INPUT 16
1.6.3 INTERNAL OSCILLATOR 17
1.6.4 TTL LEVEL ELECTRICAL OUTPUTS (IRIG-B004/PPX/DCF77) 17
1.6.5 OPEN COLLECTOR ELECTRICAL OUTPUTS 17
1.6.6 OPTICAL OUTPUTS 18
1.6.7 AMPLITUDE MODULATED OUTPUTS 18
1.6.8 SERIAL PORT (RS232, RS422/485) 19
1.6.9 DRY-CONTACT RELAY (LOCKED) 19
1.6.10 EVENT INPUT 20
1.6.11 PRECISION TIME PROTOCOL PTP (IEEE 1588) 20
1.6.12 ETHERNET PORTS 21
1.6.13 ENVIRONMENT 21
1.6.14 DIMENSIONS, WEIGHT 21
2. INSTALLATION 23
2.1 UNPACKING 23
2.2 EXTERNAL INDICATIONS 23
2.3 ENVIRONMENT 24

RT434
RT434-TM-EN-2
3
2.4 MOUNTING 24
2.5 CONNECTORS 24
2.6 POWER SUPPLY 25
2.6.1 AC POWER CONNECTION 26
2.6.2 DC POWER CONNECTION 27
2.7 POWERING UP 27
2.8 GPS ANTENNA TERMINAL 28
2.9 TTL ELECTRICAL OUTPUTS 30
2.10 OPEN-COLLECTOR ELECTRICAL OUTPUTS 31
2.11 OPTICAL OUTPUTS 32
2.12 AMPLITUDE MODULATED OUTPUTS 33
2.13 SERIAL PORT (RS232, RS422/485) 33
2.14 DRY-CONTACT RALAY (LOCKED) 35
2.15 EVENT INPUT 35
2.16 TYPE TESTS 36
3. COMMUNICATION 41
3.1 COMMUNICATIOM 41
3.2 FACTORY DEFAULT SETTINGS 42
3.3 NETWORK PORT AND COMMUNICATION PROTOCOLS 43
3.4 DIRECT COMMUNICATION 44
3.5 COMMUNICATION VIA ETHERNET NETWORK 45
3.6 EQUIPMENT ACCESS 46
4. CONFIGURATION 47
4.1 WEB INTERFACE 47
4.2 NETWORK PARAMETERS 48
4.2.1 ETHERNET 1/2/3/4 48
4.2.2 DEFAULT GATEWAY 49
4.2.3 DNS SERVER 49
4.2.4 SENDING CONFIGURATION 49
4.2.5 CONFIGURATION SUMMARY 50
4.3 TIME FEATURES 51
4.3.1 TIME SETTINGS 52
4.3.2 SENDING CONFIGURATION 52

GPS Grandmaster Clock
4
RT434-TM-EN-2
4.3.3 CONFIGURATION SUMMARY 53
4.4 SYNCHRONISM OUTPUTS 53
4.4.1 OUTPUTS 54
4.4.2 SERIAL DATAGRAM 55
4.4.3 CUSTOMIZABLE DATAGRAMS 56
4.4.4SENDING CONFIGURATION 57
4.4.5 CONFIGURATION SUMMARY 58
4.5 PTP CONFIGURATION 60
4.5.1 PROFILE 60
4.5.2 DOMAIN NUMBER 61
4.5.3 NETWORK PROTOCOL 61
4.5.4 OPERATION MODE 61
4.5.5 DELAY MECHANISM 62
4.5.6 MASTER AND SLAVE CLOCKS 62
4.5.7 PTP MESSAGES 62
4.5.8 SENDING CONFIGURATION 63
4.5.9 CONFIGURATION SUMMARY 64
4.6 CONFIGURATIONS CONTROL 65
4.6.1 CONFIGURATION MENAGEMENT 65
4.6.2 PASSWORD CONFIGURATION 66
5. OPERATION 67
5.1 LOCAL ACCESS (IHM) 67
5.1.1 STATE INDICATORS 67
5.1.2 DISPLAY MONITORING 67
5.2 REMOTE ACCESS (INTERFACE WEB) 68
5.2.1 MONITORING EQUIPAMENT STATUS 69
5.2.2 GENERAL INFORMATION 70
5.2.3 EVENTS INNPUT 71
6. MAINTENANCE 73
6.1 SYNCHRONISM FAILURE ( LOCKED SIGNALING) 73
6.1.1 LOCKED INDICATOR (IHM) 73
6.1.2 REMOTE MONITORING ( WEB INTERFACE) 73
6.1.3 DRY-CONTACT RELAY (LOCKED) 74

RT434
RT434-TM-EN-2
5
6.1.4 SINAL IRIG-B 74
6.1.5 PTP PROTOCOL 74
6.1.6 NTP PROTOCOL 74
6.1.7 SNTP PROTOCOL 74
6.2 BATTERY REPLACEMENT 75
6.3 FIRMWARE UPDATE 75
6.4 EQUIPMENT KEY CHANGE 77
6.5 CLEANING INSTRUCTIONS 78
6.6 RETURNING THE EQUIPMENT 78
APPENDIX A -CORTEC 79
APPENDIX B -IRIG-B STANDARD SUMMARY 81
APPENDIX C - PTP STANDARD CONCEPTS (IEEE1588) 87
APPENDIX D –SERIAL DATAGRAMS 94
APPENDIX E - GPS ANTENNA DELAY COMPENSATION 98
APPENDIX F –APPLICATION EXAMPLES 101

GPS Grandmaster Clock
6
RT434-TM-EN-2
PREFACE
© 2014 Alstom. All rights reserved.
Products developed by Alstom are continuously improved. The information this document contains reflects this
improvement, and for this Alstom it is subject to change without notice. Please make sure that this is latest version of
this document before proceeding. All specifications are subject to changes without prior notice.
Certification to the the ISO 9001:2008 quality standard is an example of this commitment.
We encourage and appreciate any feedback and will use it to improve our products and
services.

RT434
RT434-TM-EN-2
7
ACRONYMS AND ABBREVIATIONS
AC - Alternating Current;
ACEB NEMEA - Acronyms and Abbreviations;
ASCII - American Standard Code for Information Interchange;
BMC - Best Master Clock;
BNC - Bayonet Neil Concelman connector;
Bps –Bytes per second;
bps - Bits per second;
CAT5 - Network Cable;
CF - Federal Constitution;
PLC –Programmable Logic Controller;
CMOS - Complementary Metal-Oxide-Semiconductor;
CR2032 - Lithium battery model;
DB9 - Conector do tipo D-subminiature;
DC - Direct Current;
DCF77 - Time synchronism protocol Deutschland LORAN-C (Long Range Navigation - C) Frankfurt 77 (77,5 kHz);
DNS - Domain Name System;
DTE - Data Terminal Equipment;
E2E - End-to-end;
ETH - Abbreviation of the term Ethernet;
FW - Abbreviation of the term Firmware;
GND -Abbreviation of the term Ground;

GPS Grandmaster Clock
8
RT434-TM-EN-2
GPS - Global Positioning System;
GPZDA - Serial Datagram format;
HTTP - Hypertext Transfer Protocol;
HTTPS - Hypertext Transfer Protocol Secure;
IEC - International Electrotechnical Commission;
IED - Intelligent Electronic Devices;
IEEE - Institute of Electric and Electronic Engineers;
IHM - Human-Machine Interface;
IP - Internet Protocol;
IP40 - Degree of protection 40;
IRIG-B - Time synchronism protocol Inter Range Instrumentation Group (Rate Designation B);
LCD - Liquid Crystal Display;
MAC - Media Access Control;
NTP - Network Time Protocol;
OUT - Abbreviation of the term Output;
P2P - Peer-to-peer;
PLC- Programmable Logic Controller;
PPM - Pulse per minute;
PPS - Pulso por Segundo;
PPX - Pulso por X s;
PTP - Precision Time Protocol;
RFC - Data formatting specification RFC 1951, DEFLATE; RJ45 - Conector para rede Ethernet com 8 condutores;
RS232/485 - Serial port levels;

RT434
RT434-TM-EN-2
9
RT - Temporal Recorder (Alstom's Temporal Synchronization Equipment);
RX - Receiving data;
SNMP - Simple Network Management Protocol;
SNTP - Simple Network Time Protocol;
ST - Bayonet-lock connector;
TCP - Transmission Control Protocol;
TMARK - Daily pulses with programmable time;
TTL - Transitor-to-Transitor logic;
TX - Data transmission;
UDP - User Datagram Protocol;
UTC - Universal Time Coordinate.

GPS Grandmaster Clock
10
RT434-TM-EN-2
1. DESCRIPTION
1.1 Introduction
RT434 - GPS Grandmaster Clock is a clock referenced to GPS satellites, whose main application is to be a source
of temporal synchronization signals in different formats and protocols to synchronize internal clocks of equipment
and systems based on digital processing.
It has high accuracy (100 ns) and signal stability, even in situations where there is loss of GPS satellites. Provides
temporal synchronization for applications as synchrophasor measurement, traveling wave fault location, and other
applications.
The timing information presented on the front display of the RT434 can be referenced local or UTC time and can
be modified by the DST rules defined by the user.
It supports the following protocols sync time:
PTP (Precision Time Protocol) according to IEEE1588 standard, eliminating delay from message processing
which pass in other devices in the network;
NTP/SNTP;
IRIG-B004 (Demodulated);
IRIG-B124 (Modulated);
DCF77;
Serial Datagrams through the RS232 and RS422/485 serial ports.
This User Manual is structured as follows:
Chapter 01 presents the description of the RT434, its applications, technical characteristics and presentation of the
manual.
Chapter 02 shows how the RT434 should be installed considering the power, cable connection, sync outputs, etc.
Chapter 03 shows the communication mechanisms to access monitoring and configuration interfaces of the RT434.
Chapter 04 describes how the RT434 should be configured according to the options parameter of timing sources
and network parameters.

RT434
RT434-TM-EN-2
11
Chapter 05 shows how to operate the RT434, describing the local interface access and status indicators for
operation and remote monitoring.
Chapter 06 describes concepts and procedures to maintain the RT434.
Appendix A presents the format of the signals that compose the standard IRIG-B timing.
Appendix B presents the concepts of standard PTP synchronization (IEEE1588).
Appendix C presents the format of the synchronization signals based on Serial datagrams.
Appendix D presents the considerations used by RT434 to compensate delays inserted by the cable length of the
GPS antenna.
Appendix E gives some architectures implementing the RT434 as a source of timing for different electronic devices.
1.2 Foreword
This technical manual provides a functional and technical description of Alstom Grid's RT434, as well as a
comprehensive set of instructions for using the device. We have attempted to make this manual as accurate,
comprehensive and user-friendly as possible. However we cannot guarantee that it is free from errors. Nor can we
state that it cannot be improved. We would therefore be very pleased to hear from you if you discover any errors, or
have any suggestions for improvement. All feedback should be sent to our contact centre via the following URL:
http://www.alstom.com/grid/contactcentre/
1.3 Key Features
100 ns accuracy;
Temporal synchronization reference through GPS antenna and PTP server input;
PTP temporal synchronization protocol according to IEEE1588-2008 standard;
PTP profile option, according to IEEE C37.238 standard;
High accuracy internal oscillator system;
Time signals in IRIG-B004, IRIG-B124, or DCF77 format;

GPS Grandmaster Clock
12
RT434-TM-EN-2
Pulses: 100 pulses-per-second, 1 pulse-per-second, 1 pulse-per-minute;
Freely configurable low frequency pulse generator from 1 pulse-every-60-seconds to 1 pulse-every-24-
hours;
Pulse on-time with daily repetition;
User-configurable rules for daylight-saving-time and configurable time zone;
Delay compensation for GPS antenna cables;
NTP/SNTP server using Ethernet port;
Status monitoring using SNMP;
Configurable over Ethernet using Web Interface;
RS232 and RS422/485 serial ports with frequency variable pulse and datagram subject to user definitions;
4 independent Ethernet network outputs 10/100Base-T for configuration and access to the equipment;
2 electrical outputs with screw connectors (one of them is insulated) with an individual supply capacity up to
150 mA, TTL level, normal or reversed polarity, and singly programmable output signal;
2 electrical outputs with BNC connectors (one of them is insulated) with an individual supply capacity up to
150 mA, TTL level, normal or reversed polarity, and singly programmable output signal;
2 open collector outputs for voltages up to 400 V, normal or reversed polarity, and singly programmable
output signal;
1 output in modulation amplitude for IRIG-B124 signal;
2 optical outputs with ST connector and multimode fiber;
1 event input with screw connector CMOS/Level TTL;
Synchronization fault contactor Relay (LOCKED);
Front indicators for monitoring synchronization from GPS antenna and equipment status;
19’’ Panel Installation;
AC or DC power sources with two sources for equipment redundancy external power possibility;
1.4 Available Models
RT434 is available in different versions, according to the features used in the two Ethernet network interfaces and
the level of the power supplies.

RT434
RT434-TM-EN-2
13
For information about the different models, go to the order code on datasheet of the equipment.
1.4.1 Network Ports
Each network interface can have the configuration shown in the table below:
TABLE 1.1: Possible configuration of Ethernet ports according to the enabled and blocked features.
ETHERNET PORT 1
ETHERNET PORT 2
ETHERNET PORT 3
ETHERNET PORT 4
ONLY MC1
ONLY MC1
ONLY MC1
ONLY MC1
MC1 + IEEE 1588 PTP +
NTP/SNTP
MC1 + IEEE 1588 PTP +
NTP/SNTP
MC1 + IEEE 1588 PTP +
NTP/SNTP
MC1 + IEEE 1588 PTP +
NTP/SNTP
MC1 + NTP/SNTP
MC1 + NTP/SNTP
MC1 + NTP/SNTP
MC1 + NTP/SNTP
1Ethernet interface for monitoring and configuration.
The equipment comes from manufacturer with a key that enables the features requested by the client. To check the
enabled features, access chapter 5. For instructions about key changes to enable new features, access charpter 6.

GPS Grandmaster Clock
14
RT434-TM-EN-2
1.4.2 Power Supply
It is also possible to obtain equipment with one or two power supply sources option, the second used for
redundancy. Each power supply source can have the configuration shown in the table below:
TABLE 1.2: Possible configuration of the power supply source.
POWER SUPPLY 1
POWER SUPPLY 2
Not applicable
Without
110-240 V a.c.
110-240 V a.c.
1.5 Front and Rear Views
The front panel of RT434 comprises a LCD display, two indicators and buttons to navigate through the screen.The
figure 1, shows the front view of the equipment.
Figure 1: Front view of the RT434
It has an LCD display (16 columns) for time monitoring and network setup. The display's first screen shows temporal
reference information: day of the week, day, month, year, day of the year, hours, minutes, seconds, time zone and
the number of monitored satellites.
By navigating through the display using the buttons (arrows pointing right and left), it is possible to check the
configuration of the equipment's two Ethernet network. IP addresses, network mask, gateway, broadcast and DNS
server are shown for each network.

RT434
RT434-TM-EN-2
15
The LOCKED indicator on, indicates that the equipment is synchronized with time reference from at least 4 GPS
satellites.
The Alarm indicator on, indicates that the equipment is not operating and it is necessary the operator's attention.
Figure 2, shows the equipment's rear panel components.
Figure 2 : Rear view of the RT434
The rear panel of the RT434 comprises two feeding inputs, AC or DC; two BNC connector electrical outputs for
synchronization, one of them insulated; two TTL level screw connector electrical outputs for synchronization, one of
them insulated; two open collector outputs; LOCKED contactor relay and one CMOS/TTL level input; one amplitude-
modulated output for IRIG-B124 signal; two optical outputs; RS232 and RS422/485 serial ports; Ethernet network
communication ports and GPS antenna input.
For information on installing the equipment, access chapter 2.

GPS Grandmaster Clock
16
RT434-TM-EN-2
1.6 Technical Specifications
1.6.1 Power Supply
TABLE 1.3: Power supply specifications.
Operating voltage range
80-275 V d.c., 88-264 V a.c.
Frequency
50/60 Hz ± 3Hz
Power input
15W
1.6.2 GPS Antena Input
TABLE 1.4: GPS Antenna input specifications for temporal synchronizationl.
Signal
GPS L1 (1575.42 MHz), C/A code
Sensibilivity
152 dBm (After acquisition)
Sensibilivity
142 dBm (During acquisition)
Number of channels
12
Antenna type
Active
Antenna’s supply
3,3 V, max 100 mA
Impedance antenna
50 Ω
Cable
25m (Standard)
50m, 75m e 100m (optionals)
Connctor
BNC (female)

RT434
RT434-TM-EN-2
17
1.6.3 Internal Oscillator
TABLE 1.5: Internal oscillator specifications.
Drift (without external reference)
< 0.1 ppm ( )
1.6.4 TTL Level Electrical Outputs (IRIG-B004/PPx/DCF77)
TABLE 1.6:Electrical outputs specifications
Connectors (4)
4 screw ( two outputs)
2 BNC
High Level 1
>4,8 Vd.c.
Low Level 2
<0,2 Vd.c.
Impedance
>10 Ω
Current
150 mA
1Level above which the equipment recognizes the activated output;
2Level below which the equipment recognizes the disabled output.
Two electrical outputs are insulated, one with screw connector and the other with BNC connector.
1.6.5 Open Collector Electrical Outputs
TABLE 1.7: Open callector outputs epecifications.
Maximum collector emetter voltage
400 V
Maximum current
300 mA

GPS Grandmaster Clock
18
RT434-TM-EN-2
1.6.6 Optical Outputs
TABLE 1.8:Optical outputs specifications.
Connector
ST
Weve-length
820 nm
Fiber Type
Multimodo 50 / 125 µm, 100 / 140 µm ou 200 µm
HCS
Emission power
- 17.8 dBm (50 / 125 µm)
- 14.0 dBm (62.5 / 125 µm)
- 8.5 dBm (100 / 140 µm
- 5.7 dBm (200 µm HCS)
Length of optical fiber cables should not exceed 2 Km
1.6.7 Amplitude Modulated Outputs
TABLE 1.9: Amplitude modulated outputs specifications.
Signal
IRIG-B124
Connector
BNC (female)
Empty Amplitude
4 Vpp
50 ΩAmplitude
3 Vpp
Relative level High/Low
3.3
Carrier Frequency
1 kHz
Outputs Impedance
15 Ω
Maximum Current
80 mA
It is recommended that the length of cables not to exceed 100m.

RT434
RT434-TM-EN-2
19
1.6.8 Serial Port (RS232, RS422/485)
TABLE 1.10: RS232 or RS422/485 serial port specifications.
Signal Level
RS232 ou RS422/485
Bitrate
1200, 2400, 4800, 9600, 19200 ou 38400
bps
Databits
7 ou 8
Stopbits
1 ou 2
Parity
none, even or odd
Connector
DB9 (male), standard DTE
1.6.9 Dry-contact Relay (LOCKED)
TABLE 1.11: LOCKED dry-cantact Relay specifications.
Switching Capacity
300 mA @250 V d.c.
1000 mA @ 125 V d.c.
Contact
Normally Closed

GPS Grandmaster Clock
20
RT434-TM-EN-2
1.6.10 Event Input
TABLE 1.12: Event Input specification.
Signals
PPS, PPM or other variable frequency signals
Voltage Level
TTL
1.6.11 Precision Time Protocol PTP (IEEE 1588)
TABLE 1.13: PTP time synchhronization protocol specifications.
Protocols
UDP/IPv4 (Leyer 3) (Multicast/Unicast)
IEEE 802.3 (Leyer 2) (Multicast)
Delay Compensation
End-to-End (Multicast/Unicast)
Peer-to-Peer (Multicast)
Profiles
Standard, Power System
