ALT M19 User guide

AUTOCLAVE LOGGER THING
Wireless Autoclave Data Recorder
Model: M19 & M22 & M42
User and Setup Manual
Works With

1
Your Autoclave Logger Thing carries a one-year warranty, from
date of purchase, against manufacturers defects. At our discretion
we will either repair or replace your device free of charge for the
period of one year. This warranty does not cover the autoclave or
guarantee sterility of instruments. This warranty does not cover
physical damage to the unit, modification or negligence. Nothing
else is covered either written or implied. aLT, LLC shall not be held
accountable for damages beyond the cost of if the original value of
the unit.
To obtain warranty service please send an email to
[e-mail].
You must obtain an RMA prior to returning anything to aLT, LLC.

2
Table of Contents
Autoclave Logger Thing Overview ....................................................................................................5
Security, Design and Operation .........................................................................................................6
Installation ............................................................................................................................................8
M19....................................................................................................................................................8
M22..................................................................................................................................................10
Setup...................................................................................................................................................12
1. Connecting to your network..................................................................................................13
DHCP Setup .................................................................................................................................14
Static IP Setup..............................................................................................................................15
2. Time Setup ...............................................................................................................................16
3. Drop Box Setup........................................................................................................................ 17
File Storage & Dropbox .....................................................................................................................19
Dropbox ..........................................................................................................................................19

3
SD Card...........................................................................................................................................20
Log Indicators. ...................................................................................................................................21
Battery Replacement........................................................................................................................ 22
Tips and Troubleshooting...................................................................................................................24
FCC Warning......................................................................................................................................25

4
What You Need Before You Start
Tools
oPhilips Screwdriver (#2)
Info
oAutoclave Logger Thing Serial # __________________________________
oWi-Fi Network Name (SSID) __________________________________
oWi-Fi Network Password __________________________________
oDropbox Email __________________________________
oDropbox Password __________________________________
oAutoclave Name (Your Choice) __________________________________

5
Autoclave Logger Thing Overview
Reset Input Connect
SD Slot Card
FIGURE 1

6
Security, Design and Operation
The Autoclave Logger Thing (aLT) is designed to operate on a majority of 802.11 b/g/n
networks using standard protocols. DHCP and Static IP setup is an option.
The aLT has been designed to operate securely. Once setup, all incoming connections are
disabled. Only 2 secure outgoing connections occur over secure HTTPS connection protocols.
For Security the aLT requires a password to connect to it. The password is the device serial
number. The network configuration page is only available upon initial startup or after a hard
reset. This security feature is to prevents unauthorized access to the device and your network.
After the configuration and setup all other incoming data is disabled.
SD Card may be removed when not running a cycle, if the card is removed during a cycle it
will not be properly saved and will corrupt the data for the entire run. Removing the SD card
when logging must be avoided.
The reset button located to the left if the cable connector (figure 1) serves 2 purposes: First, a
quick press displays the IP address of the wireless connection. Second, a hard reset (held for 3
seconds) will erase all configuration data. This should be used only if you are changing

7
networks, the network password has changedor you are changing between DHCP and static
protocols.
The only function of the aLT is to mechanically record the data from the autoclave, save it
and upload it to the cloud. All proper loading, handling, storing and Biological testing should
be performed in accordance with the autoclave manufacturer.
The aLT is equipped with a battery (CR1220) to back up the Real Time Clock in the event of a
power failure. This retains the clack time and date after a power failure. With normal use the
battery should last 5 years or more. It is recommended to replace the battery every 5 years to
ensure stable operation and to prevent leakage due to a severely discharged battery.

8
Figure 2
Installation
M19
1. Unplug autoclave power cord.
2. Remove right side panel.
•Remove 2 top screws.
•Pull panel top out and push down to release.
3. Remove Inspection plate.
4. Insert cable side marked “Autoclave”.
5. Pass cable end over the chamber to the right.
6. Connect cable with the side marked “Autoclave” into the connector marked “Printer”
•The printer connector may vary in location based on the age and version of
mainboard.
NOTE: The printer connector may have a cable plugged it to it.
Remove this cable and discard.
It will not be needed for use with the aLT.
B
A

9
7. Reinstall right side panel.
•Ensuring both tabs are locked into the base (see insert B, Figure 2)
•Install 2 screws in top cover.
8. Reinstall inspection plate with the wire passing through the notch in the front left of the
panel. (see insert A, Figure 2,)
9. Connect cable to the aLT.
10. Place the unit visibly on the top of the autoclave.
Note: Do not place items that may damage it or block the Wi-Fi signal
on the aLT.
Especially hot and/or metallic items such as trays or instruments.
11. Plug-in autoclave power cord.
12. When “Autoclave Logger Thing” appears on the aLT screen you can proceed to Setup.
•If not see troubleshooting section.

10
Figure 3
M22
1. Unplug autoclave power cord.
2. Remove right side panel.
•Remove 2 top screws.
•Remove 1 rear lower screw.
•Pull panel top out and push down to release.
3. Remove cover plate
4. Insert cable with the larger, 8 pin connector through
The square hole under the cover plate.
5. Connect cable to the mainboard “Printer” connector.
6. Reinstall right side panel.
•Ensuring both tabs are locked into the base (see insert B, Figure 2)
•Install 2 screws in top cover.
•Install 1 rear lower screw.
7. (Optional) The cover plate may be modified to allow the cable to pass through and sit
on top of the reinserted plate. (see included Template)
8. (Or) Place the aLT inside the pocket where the printer would normally sit.
Printer Connector
Cover Plate

11
Note: Do not place items that may damage the unit or block the Wi-Fi
signal on top of the aLT
Especially hot and/or metallic items such as trays or instruments
9. Connect cable to aLT.
10. Plug-in autoclave power cord.
11. When “Autoclave Logger Thing” appears on the aLT screen you can proceed to Setup.
•If not see troubleshooting section.

12
Setup
Once installation is complete there are 3 easy steps to setup:
1. Connect to your network.
2. Configure date and time
3. Link your Dropbox account.
Important: for security set up must be completed within 5 minutes of
power up, after which your device will disable all connections. This is
designed as a security measure.
If necessary, unplug the aLT for 5 seconds then reconnect and run
setup again.

13
Note: If you have multiple devices only plug-in 1 un-setup device at a
time, to avoid confusion.
1. Connecting to your network
From any wireless device navigate to network connections.
You will See a new network called “Autoclave Logger Thing”. Connect to this network.
You will be prompted for network password. The password is the aLT serial number on the
bottom of the unit.
Note: All passwords are 8 digits long, letters are always uppercase.
The password will not contain letters “I” or “O”.
It will always be the numbers “1” or ”0”.
It may take a minute to connect. Once it is connected your device will automatically be
redirected to the configuration portal.

14
Depending on your device the configuration portal may be blocked or unable to be opened.
If the portal does not open.
Go to your web browser and in the search bar enter 192.168.4.1.
DHCP Setup
Select which type of network you will be
connecting to.
Configure Wi-Fi is DHCP setup (most common)
Configure Wi-Fi (Static IP) is for Static setup
(see following page)
Selecting Configure Wi-Fi will bring up a list of
available networks.
Click on your network. Enter the Password and Click
Save.

15
Static IP Setup
If you have a static network, it is best to let your IT department
Help walk you through this step as they will have to assign
you an IP on your network.
Static IP setup requires a few more steps.
You will need a few more pieces of information.
These values are just examples.

16
2. Time Setup
Once your device is connected you will be
redirected back to you network page.
Make sure you are connected to the same wireless
network as your aLT.
open your web browser, in the search bar
enter the number that appears on the Autoclave
Logger Thing screen (This is the IP address).
You should now see the screen on the right.
The top button selects the display time in AM/PM or 24 hr. Time.
Adjust the time Zone + or – so that the correct time is displayed
on the aLT Screen.
DST On/Off button allows you wish to activate Daylight
Savings automatically. It is recommended to leave it on “Observed”.
Click Dropbox Setup.

17
3. Drop Box Setup
Click Get Dropbox Code.
You will be redirected to Dropbox.
If you are not logged in, you will be required to login
Once you authorize your aLT to access your Dropbox
you will be given an Authorization Code.
Make sure you copy the entire key then navigate back
To the “Dropbox Setup” and paste it in the top text box.
Next enter the name of your autoclave this is connected to.
The name can be up to 24 characters in length but cannot
include special characters, (#, !, ? @, …) spaces are ok.
Click Submit.
You must see the autoclave name and “Dropbox Successfully Linked!”
in green on the bottom of your screen.

18
This last authentication step is a fairly complex framework. The Authorization Code is only
good for a few minutes and cannot be presented more than once. It the network is slow or
congested it may take a few tries.
If the aLT resets or it has not completed after 1 minute.
Simply click “Get Dropbox Code”. You should already be logged in to Dropbox. Just copy
and paste the code then resubmit.
Once you are connected you should have a new folder in your Dropbox account and a
welcome message will be sent.

19
File Storage & Dropbox
Dropbox
Your files are stored in Dropbox under
the autoclave name that was chosen
during setup.
Each cycle name is the date and time the
file was created.
To keep the files in chronological order
The file name is Year-Month-Day time (24hr)
Dropbox creates the files in the following:
Dropbox \ Apps \ Autoclave Logger Thing \ ”Your Chosen Name”
Do not move or rename anything, with the only exception is the renaming Apps folder.
The file name should be changed to name the “Autoclave Logs” or something that will be
identifiable.
Changing the other names or location will break the link and you will have to hard reset the
device and rerun setup.
