Introduction The USB-Blaster™download cable interfaces to a standard USB PC port.
This cable drives configuration data from the PC to the device. Because
design changes are downloaded directly to the device, prototyping is
easy and multiple design iterations can be accomplished in quick
succession.
Device Support
The USB-Blaster download cable allows you to program and configure
Altera®devices. Specifically, you can do the following:
■Download configuration data to FPGA devices:
●Stratix®II, Stratix GX, and Stratix family of devices
●Cyclone™II and Cyclone family of devices
●APEX™II and APEX 20K family of devices
●ACEX®1K devices
●Mercury™devices
●FLEX™10K, FLEX 10KE, and FLEX 10KA family of devices
●Excalibur™devices
■Download configuration data to User Flash Memory (UFM) devices:
●MAX®II family of devices
■Download configuration data to EEPROM-based devices:
●MAX 3000 and MAX 7000 family of devices
■Perform in-system programming of advanced configuration devices:
●EPC2, EPC4, EPC8, EPC16, and EPC1441 devices
■Perform in-system programming of serial configuration devices:
●EPCS1, EPCS4, EPCS16, and EPCS64 devices
In addition, the USB-Blaster download cable supports target systems
using 5.0 V TTL, 3.3 V LVTTL/LVCMOS, and single-ended I/O
standards from 1.5 V to 3.3 V.
Power Requirements
The USB-Blaster download cable requires the following power sources:
■5.0 V from the USB cable
■Between 1.5 V and 5.0 V from the target circuit board

1–2 Altera Corporation
USB-Blaster Download Cable User Guide December 2004
Hardware Setup
Software Requirements
The USB-Blaster download cable is available only for Windows 2000 and
Windows XP systems.
Use the Quartus®II software version 4.0 or later to configure your device.
The USB-Blaster download cable also supports the following:
■Quartus II Programmer (for programming and configuration)
■Quartus II SignalTap®II Logic Analyzer (for logic analysis)
■Quartus II Programmer (standalone version)
■Quartus II SignalTap II logic analyzer (standalone version)
Hardware Setup This section describes how to install and set up the USB-Blaster download
cable for device configuration or programming.
1For plug and header dimensions, pin names, and operating
conditions, see Chapter 2, “USB-Blaster Specifications.”
Connect your USB-Blaster download cable to the circuit board as
instructed below.
1. Disconnect the power cable from the circuit board.
2. Connect the USB cable to the USB port on your PC and to the
USB-Blaster port.
3. Connect the USB-Blaster download cable to the 10-pin header on the
device board. Figure 1–1 shows the USB-Blaster download cable
and the circuit board connector.

Altera Corporation 1–3
December 2004 USB-Blaster Download Cable User Guide
Setting Up the USB-Blaster Download Cable
Figure 1–1. The USB-Blaster Download Cable
4. Reconnect the power cable to reapply power to the circuit board.
1The Found New Hardware wizard may open and prompt you
to install a new hardware driver. Close the wizard and install
the hardware driver using the instructions provided in
“Installing the USB-Blaster Driver” below.
Software Setup This section describes the following:
■Installing the USB-Blaster driver
■Setting up the USB-Blaster hardware in the Quartus II software
Installing the USB-Blaster Driver
This section describes how to install the USB-Blaster driver.
Before you begin the installation, verify the USB-Blaster driver is located
in your directory: \<Quartus II system directory>\drivers\usb-blaster
1If the driver is not in your directory, download the USB-Blaster
driver from the Altera web site:
www.altera.com/support/software/drivers
P
I
N
1
T
A
R
G
E
T
B
L
A
S
T
E
R
S
I
D
E
S
I
D
E
10-pin Female Connector
(connects to target printed
circuit board 10-pin male
header)

1–4 Altera Corporation
USB-Blaster Download Cable User Guide December 2004
Software Setup
To install the driver, follow the directions below:
1. For Window 2000, choose Settings > Control Panel (Windows Start
menu).
or
For Windows XP, choose Control Panel (Windows Start menu).
2. Click Switch to Classic View if necessary (Control Panel window).
3. Double-click the Add Hardware icon to start the Add Hardware
wizard and click Next to continue.
4. Select Yes, I have already connected the hardware and click Next.
5. Select Add a new hardware device from the Installed hardware list,
and click Next to continue.
6. Select Install from a list or specified location (Advanced) and click
Next to continue.
1Depending on your system, the wording of this option may
vary slightly.
7. Select Sound, video and game controllers, and click Next to
continue.
8. Select Have Disk and browse to the location of the driver on your
system: \<Quartus II system directory>\drivers\usb-blaster
Click OK.
9. Select Altera USB-Blaster and click Next to continue.
10. Click Next to install the driver.
11. Click Continue Anyway when the Hardware Installation warning
appears.
12. Click Finish in the Completing the Add/Remove Hardware Wizard
window. Reboot your system.

Altera Corporation 1–5
December 2004 USB-Blaster Download Cable User Guide
Setting Up the USB-Blaster Download Cable
Setting Up the USB-Blaster Hardware in the Quartus II Software
Use the following steps to set up the USB-Blaster hardware in the Quartus
II software:
1. Start the Quartus II software.
2. Choose Programmer (Tools menu).
3. Click Hardware Setup. The Hardware Settings tab of the Hardware
Setup dialog box is displayed. USB-Blaster is visible in the
Available hardware items list of the Hardware Setup dialog box, as
shown in Figure 1–2.
Figure 1–2. Hardware Setup Dialog Box
4. Click USB-Blaster to highlight it and then click the Select Hardware
button.
5. Click Close to close the Hardware Setup dialog box.
6. In the Mode list, select the desired mode (Programmer window).
Table 1–1 describes each mode.

1–6 Altera Corporation
USB-Blaster Download Cable User Guide December 2004
Software Setup
1The USB-Blaster supports the Joint Test Action Group (JTAG),
Passive Serial Programming, and Active Serial modes.
fFor details about programming devices and creating secondary
programming files, see the “Programming & Configuration” chapter of
the Introduction to Quartus II Handbook.
For further information, see the Programming module of the Quartus II
online tutorial.
For further information, refer to the following topics in the Quartus II
software Help menu:
■Changing the Hardware Setup
■Programmer Introduction
■Overview: Working with Chain Description Files
■Overview: Converting Programming Files
Table 1–1. Programming Modes
Mode Mode Description
Joint Test Action Group
(JTAG)
Programs or configures all Altera devices
supported by Quartus II software, excluding
FLEX 6000.
In-Socket Programming Not supported by the USB-Blaster.
Passive Serial Programming Configures all Altera devices supported by
Quartus II software excluding MAX 3000 and
MAX 7000 devices.
Active Serial Programming Programs a single EPCS1 or EPCS4 serial
configuration device.

Altera Corporation 2–1
December 2004
Chapter 2. USB-Blaster
Specifications
Overview This chapter provides comprehensive information about the
USB-Blaster™download cable including the following:
■USB-Blaster connections
●Voltage requirements
●Cable-to-board connection
●USB-Blaster plug connection
●Circuit board header connection
■Operating conditions
USB-Blaster
Connections
The USB-Blaster cable has a USB universal plug that connects to the PC
USB port, and a 10-pin female plug that connects to the circuit board.
Data is downloaded from the USB port on the PC through the USB-
Blaster cable to the circuit board via the connections discussed in this
section.
Voltage Requirements
The USB-Blaster VCC(TRGT) pin must be connected to a specific voltage
for the device being programmed. Connect pull-up resistors to the same
power supply as the USB-Blaster VCC(TRGT). See Table 2–1.
Table 2–1. USB-Blaster VCC(TRGT) Pin Voltage Requirements (Part 1 of 2)
Device Family USB-Blaster VCC Voltage Required
MAX II device As specified by VCCIO of Bank 1
MAX 7000S device 5 V
MAX 7000AE and MAX 3000A devices 3.3 V
MAX 7000B device 2.5 V
Stratix II, Stratix GX, and Stratix devices As specified by VCCSEL
Cyclone II, Cyclone, APEX II, APEX 20K, and Mercury devices As specified by VCCIO
FLEX 10K, FLEX 8000, and FLEX 6000 devices 5 V
FLEX 10KE device 2.5 V
FLEX 10KA and FLEX 6000A devices 3.3 V
EPC2 device 5 V or 3.3 V

2–2 Altera Corporation
USB-Blaster Download Cable User Guide December 2004
USB-Blaster Connections
Cable-to-Board Connection
A standard USB cable connects to the USB port on the device. Figure 2–1
shows a block diagram of the USB-Blaster download cable.
Figure 2–1. USB-Blaster Block Diagram
USB-Blaster Plug Connection
The 10-pin female plug connects to a 10-pin male header on the circuit
board containing the target device. Figure 2–2 shows the dimensions of
the female plug.
EPC4, EPC8, and EPC16 devices 3.3 V
EPCS1 and EPCS4 devices 3.3 V
Table 2–1. USB-Blaster VCC(TRGT) Pin Voltage Requirements (Part 2 of 2)
USB Interface
Chip EPM7064AETC44
I/Os
I/Os
V
CC
Pin 1
V
CC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
USBVCC
USB
Receptacle
10-Pin
Female Plug

Altera Corporation 2–3
December 2004 USB-Blaster Download Cable User Guide
USB-Blaster Download Cable User Guide
Figure 2–2. USB-Blaster 10-Pin Female Plug Dimensions
Table 2–2 identifies the 10-pin female plug pin names and the
corresponding programming mode.
0.250 Typ.
0.700 Typ.
0.425 Typ.
0.100 Sq.
10
9
8
7
6
5
4
3
2
1
0.025 Sq.
Dimensions are shown in inches. Spacing between pin centers is 0.1 inches.
Table 2–2. USB-Blaster Female Plug Signal Names & Programming Modes
Pin
AS Mode PS Mode JTAG Mode
Signal Name Description Signal Name Description Signal Name Description
1DCLK Clock signal DCLK Clock signal TCK Clock signal
2GND Signal ground GND Signal ground GND Signal ground
3CONF_DONE Configuration done CONF_DONE Configuration
done
TDO Data from
device
4VCC(TRGT) Target power supply VCC(TRGT) Target power
supply
VCC(TRGT) Target power
supply
5nCONFIG Configuration
control
nCONFIG Configuration
control
TMS JTAG state
machine control
6nCE Cyclone chip enable –No connect –No connect
7DATAOUT Active serial data out nSTATUS Configuration
status
–No connect
8nCS Serial configuration
device chip select
–No connect –No connect
9ASDI Active serial data in DATA0 Data to device TDI Data to device
10 GND Signal ground GND Signal ground GND Signal ground

2–4 Altera Corporation
USB-Blaster Download Cable User Guide December 2004
Operating Conditions
1The circuit board must supply VCC(TRGT) and ground to the
USB-Blaster cable for the I/O drivers.
Circuit Board Header Connection
The circuit board's 10-pin male header, which connects to the USB-Blaster
cable's 10-pin female plug, has two rows of five pins. These pins are
connected to the device’s programming or configuration pins. Figure 2–3
shows the dimensions of a typical 10-pin male header.
Figure 2–3. 10-Pin Male Header Dimensions
Operating
Conditions
Tables 2–3 through 2–5 summarize the maximum ratings, recommended
operating conditions, and DC operating conditions for the USB-Blaster
cable.
0.025 Sq.
0.235
0.100
Side View
0.100
Top View
Dimensions are shown in inches.
Table 2–3. USB-Blaster Cable Absolute Maximum Ratings
Symbol Parameter Conditions Min Max Unit
VCC(TRGT) Target supply voltage With respect to ground –0.3 5.5 V
VCC(USB) USB supply voltage With respect to ground –0.5 6.0 V
IIInput current TDO or dataout –10.0 10.0 mA
IoOutput current TCK, TMS, TDI, nCS, nCE –20.0 20.0 mA

Altera Corporation 2–5
December 2004 USB-Blaster Download Cable User Guide
USB-Blaster Download Cable User Guide
Table 2–4. USB-Blaster Cable Recommended Operating Conditions
Symbol Parameter Conditions Min Max Unit
VCC(TRGT) Target supply voltage, 5.0-V operation 4.75 5.25 V
Target supply voltage, 3.3-V operation 3.0 3.6 V
Target supply voltage, 2.5-V operation 2.375 2.625 V
Target supply voltage, 1.8-V operation 1.71 1.89 V
Target supply voltage, 1.5-V operation 1.43 1.57 V
Table 2–5. USB-Blaster Cable DC Operating Conditions
Symbol Parameter Conditions Min Max Unit
VIH High-level input voltage VCC(TRGT) –0.2 V
VIL Low-level input voltage 0.15 V
VOH 5.0-V high-level output voltage VCC(TRGT) = 4.5 V, IOH =1mA 4.4 V
3.3-V high-level output voltage VCC(TRGT) = 3.0 V, IOH =1mA 2.9 V
2.5-V high-level output voltage VCC(TRGT) = 2.375 V, IOH = 1 mA 2.275 V
1.8-V high-level output voltage VCC(TRGT) = 1.71 V, IOH = 1 mA 1.61 V
1.5-V high-level output voltage VCC(TRGT) = 1.43 V, IOH = 1 mA 1.33 V
VOL 5.0-V low-level output voltage VCC(TRGT) = 5.5 V, IOL = 1 mA 0.125 V
3.3-V low-level output voltage VCC(TRGT) = 3.6 V, IOL = 1 mA 0.125 V
2.5-V low-level output voltage VCC(TRGT) = 2.625 V, IOL = 1 mA 0.125 V
1.8-V low-level output voltage VCC(TRGT) = 1.89 V, IOL = 1 mA 0.125 V
1.5-V low-level output voltage VCC(TRGT) = 1.57 V, IOL = 1 mA 0.125 V
ICC(USB) Operating current (No Load) (Typical ICC(USB) = 80 mA) 150 mA

2–6 Altera Corporation
USB-Blaster Download Cable User Guide December 2004
References
References For more information on configuration and in-system programmability
(ISP), see the following sources:
■AN 39: IEEE 1149.1 (JTAG) Boundary-Scan Testing in Altera Devices
■AN 95: In-System Programmability in MAX Devices
■AN 250: Configuring Cyclone FPGAs
■“Configuring Stratix II Devices” chapter in Volume 2 of the Stratix II
Device Handbook
■“Configuring Stratix and Stratix GX Devices” chapter in the Stratix
Device Handbook
■“Configuring Cyclone II Devices” chapter in the Cyclone II Handbook
■Serial Configuration Devices Data Sheet
■“Programming & Configuration” chapter in the Introduction to
Quartus II manual
■The Programming module of the Quartus II online tutorial
■Refer to the following glossary definitions in the Quartus II Help:
●“USB-Blaster Cable” (general description)
●“Configuration scheme” (general description)
●“Programming files” (general description)
■Refer to the following procedures in the Quartus II Help:
●Programming a Single Device or Multiple Devices in JTAG or
Passive Serial Mode
●Programming a Single Device in Active Serial Programming
Mode
■Refer to the following introduction and overview topics in the
Quartus II Help:
●Programmer Introduction
●Overview: Working with Chain Description Files
●Overview: Converting Programming Files

Altera Corporation 2–7
December 2004 USB-Blaster Download Cable User Guide
USB-Blaster Download Cable User Guide
Revision History The table below shows the revision history of this user guide.
How to Contact
Altera
For the most up-to-date information about Altera products, go to the
Altera world-wide web site at www.altera.com. For technical support on
this product, go to www.altera.com/mysupport. For additional
information about Altera products, consult the sources shown below.
Chapter Date Version Changes Made
2 December 2004 1.2 Update to conditions in table 2-5.
All November 2004 1.1 Re-release.
All July 2004 1.0 Initial release.
Information Type USA & Canada All Other Locations
Technical support www.altera.com/mysupport/ www.altera.com/mysupport/
(800) 800-EPLD (3753)
(7:00 a.m. to 5:00 p.m. Pacific Time)
[phone] (1)
(7:00 a.m. to 5:00 p.m. Pacific Time)
Product literature www.altera.com www.altera.com
Altera literature services [email protected] (1) [email protected] (1)
Non-technical customer
service
[phone]
(7:00 a.m. to 5:00 p.m. Pacific Time)
[phone]
(7:00 a.m. to 5:00 p.m. Pacific Time)
FTP site ftp.altera.com ftp.altera.com
Note to table:
(1) You can also contact your local Altera sales office or sales representative.

2–8 Altera Corporation
USB-Blaster Download Cable User Guide December 2004
How to Contact Altera
