Altice UBC1326AA00 User manual

!
UBC1326AA00
DOCSIS 3.1
Wireless eMTA
Quick
Installation
Guide

!
UBC1326AA00
D3.1 Wireless eMTA
Quick Installation Guide
Subscriber
Grounding the Device: Install the cable modem to include
grounding the coaxial cable to the earth as close as practical to
the building entrance per ANSI/NFPA 70 and the National
Electrical Code (NEC, in particular, Section 820.93, Grounding of
the Outer Conductive Shield of a Coaxial Cable). The device is
designed for IT power systems with phase-to-phase voltage at
120V.
This unit requires a 100-240V, 50/60Hz power adapter. The
power adapter must be keyed for proper polarization, and must
be fully inserted to contact the back of the power connector
port to ensure snug connection. Do NOT use any other power
adapter.
Disconnecting the Device: If the cable modem becomes
damaged or encounters some other abnormality, disconnect the
power plug from the AC wall outlet immediately.
Temperature and Altitude: Install the device in a location not to
exceed the maximum temperature of 104°F (40°C). Regular
operating altitude is 2000 m, and maximum operating altitude
is 4500 m.
•SAFETY NOTICES
•PREPARING FOR INSTALLATION
✓Locate the RF (coaxial) cable connector on the wall.
✓Verify the power outlet is working and is wired correctly.
✓Place your cable modem within a proper distance from the
outlet.
To connect a modem and a television to the same wall outlet,
you must use a cable line splitter (not included).
2. Connect an Ethernet cable (supplied) to one of the LAN
(Ethernet) ports on the back panel of the modem and connect
the other end to the Ethernet port of a computer. Use a
Category 5e or Category 6 Ethernet cable with RJ-45
connectors to ensure Gigabit Ethernet speeds (when the
computer supports it).
3. Connect an RJ-11 phone cable (not supplied) to the TEL
(telephone) port on the modem (when provisioned for voice
service as specified by the service provider), and connect the
other end to the phone port of the telephone. If voice service
is not provisioned through the service provider, telephone
service is not available.
4. Connect the power adapter (supplied) to the PWR (power)
port. Connect the other end to a power outlet.
1
UBC1326AA00
Wireless Voice Gateway
RJ-45
Analog Phone
RJ-11
Cable/RF
Device must be installed
vertically using the included leg
stands to obtain optimum
wireless performance.
Connect computers or Ethernet enabled
devices (wireless switch or router). A PC
should be connected for initial device
installation and configuration.
2
1
3
4
1. Connect the included leg stands to the bottom of the device
to enable the modem to be installed vertically. Connect the
coaxial cable (not supplied) to the DS/US (cable) connector
on the rear panel of the modem and connect the other end to
the cable wall outlet. Do not bend or over tighten the cable,
as this may strain the connector and cause damage.
•INSTALLING THE UBC1326AA00

!
•DEVICE WALL MOUNT INSTRUCTIONS
2
Label
Millimeters
(mm)
A
7.2 +/- 0.5
B
2.6 +/- 0.15
C
19.0 +/- 1.2
D
3~4
UBC1326AA00 Quick Installation Guide
5. Separate the wall mounting pieces. Mount the top and
bottom leg stand pieces (Figure 1) onto the UBC1326AA00
as shown in Figure 2.
6. You can now mount the UBC1326AA00 onto the wall using
the screws installed in Step 4.
2. Fit the 2 leg stand pieces
together with the wall mount
template as represented in the
graphic to the right.
3. Place this on the wall and use it
as a template to mark the wall
for the appropriate placement
of the screws.
4. Install the 4 screws on the wall
(158 mm or 6.2 inches apart).
NOTE: The screws should protrude
from the wall so you can fit the
device between the head of the
screws and the wall. If you install
the screws in drywall, use hollow
wall anchors to ensure the unit
does not pull away from the wall
due to prolonged strain from the
cable and power connectors.
You can mount the UBC1326AA00 on a wall by following the
steps below:
1. You will need 4 round or pan head screws with the following
measurements:
Figure 1
Figure 2

•FEDERAL COMMUNICATION COMMISSION
(FCC) INTERFERENCE STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment offand on, the user is encouraged to try
to correct the interference by one of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
3
UBC1326AA00 Quick Installation Guide
5GHz Wireless Statement:
For operation within the 5.15~5.25GHz and 5.47~5.725GHz
frequency ranges, this device is restricted to indoor
environments.
This device meets all the other requirements specified in Part
15E, Section 15.407 of the FCC Rules.
FCC Caution:
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate this equipment.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 30 cm between
the radiator & your body.
This reminder is provided to call the CATV systems installer's
attention to section 820-93 of the National Electric Code, which
provides guidelines for proper grounding and in particular,
specify that the Coaxial cable shield shall be connected to
grounding system of the building, as close to the point of cable
entry as practical.
•NOTE TO CATV INSTALLER
42
