Instruction Manual
50cm Twin Cavity Freestanding Cooker
CETS501W / CETS501B

2
Contents
1 Safety information
Safety information 3
2 Getting to know your
Freestanding Cooker
Overview 5
Accessories 6
3 Installing your Freestanding
Cooker
Installation requirements 7
Electrical connection 9
4 Using your Freestanding
Cooker
Control panel 10
Oven functions 11
General oven and cooking tips 12
Practical Cooking Advice 13
Using the solid plate zones of your cooker 14
5 Care and Maintenance
Cleaning 15
Replacing oven lamps 16
Technical specification 17
6 Product support
Troubleshooting 20
Help and assistance 21
Your appliance guarantee 22
Declaration of conformance to product 23
standards
Disposal 23

Safety information
Important - Please read these instructions fully before
installing or operating
3
INSTALLATION WARNINGS
IMPORTANT: Prior to installation ensure that the
local supply conditions (electricity, voltage and
frequency) are compatible with the requirements
of your freestanding cooker.
IMPORTANT: Carefully unpack and examine the
appliance for any damage. If you think there is a
defect, do not use the appliance and contact
Product Support on 0330 041 7490. Packaging
materials should be collected together and
disposed of immediately as they may be harmful
to children.
IMPORTANT: Keep the electrical cable (not
supplied) of your freestanding cooker away from
the hot areas of your appliance, do not let the
cable touch the appliance. Keep the cable away
from sharp edges and heated surfaces.
IMPORTANT: Ensure that the electric supply
cable is not trapped or damaged during
installation.
IMPORTANT: In the event that the cable
connecting your freestanding cooker becomes
damaged, it must be replaced by a suitably
qualified person. This cable must not be
replaced by an unauthorised person.
IMPORTANT: Protect your freestanding cooker
against atmospheric effects. Do not expose your
cooker to effects such as sun, rain, snow etc.
IMPORTANT: The materials surrounding the
appliance (cabinets) must be able to withstand a
minimum temperature of 100°C.
IMPORTANT: When using your oven for the first
time your cooker may give off an unusual odour
from the heating elements and insulation
materials. To eliminate this odour, run the oven at
250°C for 40-60 minutes with the oven empty.
WARNING: Before obtaining access to
terminals, all supply circuits must be
disconnected.
DURING USAGE
IMPORTANT: This appliance can be used by children
aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children should not play with the appliance.
Cleaning and user maintenance should not be made
by children without supervision.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
WARNING: NEVER try to extinguish a cooking fire with
water. Instead, switch off the appliance and cover the
flame e.g. with a lid or a fire blanket.
CAUTION: Do not allow children in the kitchen when
cooking or after, as the appliance may still be hot. Many
parts of the cooker will become hot and present a
considerable hazard to children.
CAUTION: When the cooker is hot, never touch the
oven glass by hand or with tools.
CAUTION: Before starting to use your appliance,
ensure curtains, paper or flammable items are kept
away from your appliance. Do not keep flammable
materials inside or around your cooker.
CAUTION: Take care when closing the oven door that
there is nothing obstructing it from closing as this may
break the glass.
IMPORTANT: When using the grill, the oven door must
be kept closed.

Safety information
Important - Please read these instructions fully before
installing or operating
4
IMPORTANT: Make sure the cooker control
knobs are all in the off position when not in
use.
IMPORTANT: If you do not intend to use your
cooker for a long period of time, turn off the
electric supply to the cooker.
GENERAL SAFETY
WARNINGS
IMPORTANT: This appliance has been
designed for non-professional, domestic use
only. Do not use this oven for commercial use
or any other application e.g. room heating.
WARNING: Danger of fire - do not store
flammable items on or near the cooking
surfaces or inside the oven.
IMPORTANT: Do not try to lift or move this
appliance by pulling on the door handle.
WARNING: Ensure that the appliance is
switched off before replacing the lamp to avoid
the possibility of electric shock.
IMPORTANT: Your appliance is produced in
accordance with all applicable local and
international standards and regulations.
IMPORTANT: Maintenance and repair work
must only be performed by authorised service
technicians. Installation and repair work that is
carried out by unauthorised technicians is
dangerous and could invalidate your guarantee.
IMPORTANT: When the door of the oven is open, do
not hang or lean anything on it. You may unbalance
your appliance or damage the door or door hinges.
IMPORTANT: Do not hang towels, dishcloths or
clothes from the cooker or its handles.
CLEANING AND
MAINTENANCE
IMPORTANT: Always turn the appliance off before
operations such as cleaning or maintenance. You can
do this by switching the freestanding cooker off using
the cooker isolation switch.
IMPORTANT: Do not remove the control knobs to
clean the control panel.
WARNING: Do not use harsh abrasive cleaners or
sharp metal scrapers to clean the oven door glass
since they can scratch the surface, which may result
in shattering of the glass.
TO MAINTAIN THE EFFICIENCY AND SAFETY OF
YOUR APPLIANCE, WE RECOMMEND YOU
ALWAYS USE OUR AUTHORISED SERVICE
AGENTS AND ORIGINAL SPARE PARTS.
IF YOU REQUIRE ASSISTANCE WITH THE
OPERATION OF YOUR APPLIANCE, PLEASE
CALL OUR PRODUCT SUPPORT TEAM ON
0330 041 7490.
TROUBLESHOOTING ADVICE CAN BE FOUND ON
PAGE 20. IF YOUR APPLIANCE IS FAULTY AND
NEEDS A REPAIR, PLEASE CALL 0300 024 5648.

Getting to know your Freestanding Cooker
5
Overview
1. Solid plate
2. Thermostat knob
3. Function knob for oven
4. Hob temperature knobs
5. Upper cavity door
6. Upper cavity handle
7. Adjustable feet
8. Grill pan
9. Lamp
10. Wire shelf

Getting to know your Freestanding Cooker
6
Accessories
Tray / Glass tray
Used for pastry (cookie, biscuit etc.), frozen foods.
In tray wire grill
Used with the grill for toasting bread or grilling other foods.
Wire grill
Used for cooking foods that are not suitable in baking trays - ie Pizzas.

Installing your Freestanding Cooker
7
Installation requirements
THIS COOKER MUST BE INSTALLED BY
A QUALIFIED INSTALLER IN
ACCORDANCE WITH LOCAL
REGULATIONS
IMPORTANT: CONTACT AN
AUTHORISED SERVICE AGENT FOR
INSTALLATION OF YOUR FREESTANDING
COOKER!
Positioning
1. Make sure that there are no combustible or
flammable materials, such as curtains, in
the vicinity of the installation.
2. Furniture and cabinets surrounding
the cooker must be of material
resistant to temperatures greater than
100°C.
3. Surrounding furniture, cabinets and
extractor fans should be positioned
in accordance with the diagram
shown in the figure.
4. There must be at least 2cm of free
space between the back wall and the
rear of the appliance to allow for
ventilation and air circulation.
5. If fitted, the extractor fan must be at least
65cm above the hotplates. If no fan is
fitted, the minimum distance between the
hotplates and any cabinet or other structure
must be 75cm.
First Use
IMPORTANT: When using your oven for the
first time your cooker may give off an unusual
odour from the heating elements and insulation
materials. This is normal for new cookers. To
eliminate this odour, run the oven at 250°C for
40-60 mins with the oven empty.
Unpacking
Carefully unpack and examine the appliance
for any damage. If you think there is a
defect, do not use the appliance and contact
Product Support on 0330 041 7490.

Installing your Freestanding Cooker
8
Levelling feet
The height and level of the appliance can be adjusted by rotating the feet located underneath the
appliance at each corner. Rotate the feet to decrease or increase the height.
Safety chain
The appliance must be secured against the possibility of tipping forward by using the supplied
safety chains attached to the rear of your oven.
Fasten the stability hook provided by inserting a wall plug into the kitchen wall and then connect
the safety chain to the hook via the locking mechanism.

9
Installing your Freestanding Cooker
Electrical connection
IMPORTANT: Electrical connections must be carried out by a suitably qualified person and in accordance
with all relevant local building and installation regulations.
Fitting a Power Supply Cable
Connecting appropriate power supply terminal board/connector block:
l Using a screwdriver, prize open tabs of the Terminal board cover.
l Remove the wire clamp screw.
l Fasten the wires beneath the corresponding screw heads.
l Fasten cable clamp and close the cover of the terminal board.
l The ac power supply should be 220-240V, 50/60 Hz. For electric cookers, the minimum 32A fuse, or
at least a 32A distribution circuit breaker.
220-240V~50/60Hz
H05 VV-F 3G 4 mm²
Connecting the supply cable to the mains
Install an approved circuit breaker with a minimum contact opening of 3mm, between the appliance and the
mains fuse box. The circuit breaker should be sized according to the load and should comply with current
regulations (the earth wire should not be interrupted by the circuit breaker).
The supply cable should be positioned so that it does not reach a temperature of more than 50℃with respect
to the room temperature, anywhere along its length. Before switching the fuse ON in the meter-box check:
l Earth continuity - the electrical safety of this appliance can only be guaranteed if the cooker is correctly
installed and earthed, in compliance with regulations on electrical installations.
l That the electrical capacity of the system and sockets will support the maximum power of the appliance, as
indicated on the data plate.
L
N
Liv
e
Neutra
l
Neutr
e
Earth
Terre

Using your Freestanding Cooker
10
Control panel
1 2 3 4 5 6
1. Thermostat
• Sets temperature for the grill.
2. Function
• Sets function & temperature for cooking in main oven.
3. Back Left Hob
• Adjusts temperature of hotplate.
4. Front Left Hob
• Adjusts temperature of hotplate.
5. Front Right Hob
• Adjusts temperature of hotplate.
6. Back Right Hob
• Adjusts temperature of hotplate.

Using your Freestanding Cooker
11
Oven functions
Grill
Top & Bottom Element
Bottom Element
Oven light
Grill - The top central heating elements come on. The extremely high and direct temperature of the
grill makes it possible to brown the surface of meats and roasts while locking the juices in to keep
them tender. The grill is also highly recommended for dishes that require a high temperature on the
surface: beef steaks, veal, rib steak, fillets, hamburgers etc.
Top & Bottom Element - Hot air comes from the upper and lower elements in the oven. This is
called Conventional cooking and is ideal for joints ofmeat.
Bottom Element - Bottom element cooking is used for foods that typically need cooking with heat
from underneath. Cakes and bread are examples of where this function would be useful.
Oven light - The oven light will operate on all oven functions.
Using your appliance for the first time
The first time you use your appliance, we recommend that you set the temperature setting to the
highest mark. Set the function switch control knob to a cooking mode and leave the oven on for about
40-60 minutes with nothing in it and the oven door shut. Then, open the oven door and allow the oven
to cool. Any odour that may be detected during this initial use is due to the evaporation of substances
used to protect the oven during storage.

12
Using your Freestanding Cooker
General oven and cooking tips
General Oven Tips:
The wire shelves should always be pushed firmly to the back of the oven.
Baking trays with food cooking on them should be placed level with the front edge of the oven’s
wire shelves. Other containers should be placed centrally. Keep all trays and containers away from
the back of the oven, as over-browning of the food may occur.
For even browning, the maximum recommended size of a baking tray is 340 mm (13½”) by 340
mm (13½”).
When the oven is on, do not leave the door open for longer than necessary, otherwise the knobs
may get very hot.
l Always leave 1cm gap between dishes on the same shelf. This allows the heat to circulate freely
around them.
l To reduce fat splashing when you add vegetables to hot fat around a roast, dry them thoroughly
or brush lightly with cooking oil.
l Where dishes may boil and spill over during cooking, place them on a baking tray.

13
Using your Freestanding Cooker
Practical Cooking Advice
The oven offers a wide range of alternatives that allow you to cook any type of food in the best possible way.
With time, you will learn how to make the best use of this versatile cooking appliance. The following directions
are only a guideline, which may be varied according to your own personal experience.
Preheating
You should always preheat your oven before placing food in it to cook.
Once the food has been placed in the oven, the most appropriate cooking mode can then be selected.
Using the Grill
Use the grill mode placing the food under the centre of the grill (situated on the 3rd or 4th rack from
the bottom) due to the central part of the top heating element being active.
Please use the grill pan set provided ensuring that there are no unwanted spillages formed inside your oven.
When using this mode, we recommend that you set the thermostat to the highest setting. However, this does
not mean that you cannot use lower temperatures, by simply by adjusting the thermostat knob to the desired
temperature.
When using this mode, we advise you to set the thermostat to 200℃, as it is the most efficient way to
use the grill.
Baking Cakes
When baking cakes, always place them in a preheated oven. Make sure you wait until the oven has been
preheated thoroughly. To prevent cakes from dropping or sinking, do not open the oven door during baking.
If the cake or pastry is too dry
Increase the temperature by 10℃and reduce the cooking time.
If the cake or pastry dropped
Use less liquid or lower the temperature by 10℃.
If the cake or pastry is too dark on top
Place it on a lower rack, lower the temperature, and increase the cooking time.
If the cake or pastry is cooked well on the inside but sticky on the outside
Use less liquid, lower the temperature, and increase the cooking time.
If the cake or pastry sticks to the pan
Grease the pan well and sprinkle it with a dusting of flour or use greaseproof paper.
Use a lower temperature setting. It is not necessary to remove the food from all the racks at the same time.
Cooking Fish and Meat
When cooking white meat, fowl and fish, use temperature settings from 180℃to 200℃.
For red meat that should be well done on the outside while tender and juicy in the inside, it is a good idea to start
with a high temperature setting (200℃-220℃) for a short time, then turn the oven down afterwards.
In general, the larger the roast, the lower the temperature setting. Place the meat on the centre of the grid and place
the dripping pan beneath it to catch the fat.
Make sure that the grid is inserted so that it is in the centre of the oven. If you would like to increase the amount
of heat from below, use the low rack heights. For savoury roasts (especially duck and wild game), dress the
meat with lard or bacon on the top.

14
2
2
Using your Freestanding Cooker
Using the hotplates of your cooker
l Do not use pots and pans which are unsteady, as these could become un-sturdy.
l Do not use mats, heat diffusers or wok stands. These will cause a temperature build-up which can
damage the hob.
l Do not let cooking pots overspill; this could leave a mark and residue on the hob.
Choosing Cooking Pots
Look at this diagram below which shows you which pans to use on the hotplates and which pans should
not be used.
l Always use pots and pans with flat bottoms. Uneven or thin bottoms will waste energy and cook slowly.
l Always use pots and pans which are slightly larger than the hotplate. Small pans waste energy.
l Always put dry pots and pans on the hotplates.
Solid Hotplates
l The strong solid-cast hotplates give wide contact for cooking.
l The hotplates are sealed all around which means that spilt liquids cannot get under the hotplates.
Before first use
l The top surface of the hotplates are sealed with a heat
resistant coating. Before using for the first time, the hotplates
should be heated for a short period without a pan to harden the
protective coating. 1
1
l Turn the heat setting to high for approx. 3 minutes to fully harden
the coating. When the hotplates have cooled, apply a thin coating
of cooking oil to the hotplate to seal and protect the surface.

15
Care and maintenance
Cleaning
WARNING! Isolate the power supply to the appliance and make sure that the cooker is cool.
Before cleaning your cooker or performing maintenance, make sure that the cooking mode selection knob
and the cooking temperature selection knob is set to ‘OFF’. To extend the life of your cooker, it must be
cleaned frequently. The inside of the cooker should preferably be cleaned immediately after use, when it is
still warm (but not hot), with warm water and soap. The soap should be rinsed away and the interior dried
thoroughly. Avoid using abrasive detergents, scourers, acidic cleaners such as lime scale remover, etc, as
these could damage the enamel, and can result in the development of rust and corrosion. If stains are
particularly tough to remove, use cleaners specifically recommended to clean cookers and follow the
instructions provided with the cleaner.
Never use a steam cleaner for cleaning inside the cooker.
Do not clean using caustic creams, abrasive cleaning powders, thick wire wool or hard tools. Enamelled parts of
the cooker can be damaged if excess cleaning liquids are not immediately removed.
After cleaning the interior parts of the cooker with a soapy cloth, rinse it and then dry thoroughly with a soft
cloth.
Clean the glass surfaces with special glass cleaning agents.
Never use flammable agents like acid, thinner or petrol when cleaning your appliance.
Do not clean your cooker with a steam cleaner.
Do not wash any part of your cooker in a dishwasher.
Enamelled Parts:
In order to keep enamelled parts as new, it is necessary to clean them frequently with mild warm soapy water
and then dry with a cloth. Do not wash them while hot and never use abrasive powders or abrasive cleaning
materials. Do not leave anything spilled onto enamelled parts for long periods of time.
Stainless Steel:
Stainless steel parts must be cleaned frequently with mildly warm soapy water and a soft sponge and then
dried with a soft cloth. Do not use abrasive powders or abrasive cleaning materials. Do not leave anything
spilled onto stainless steel parts for long periods of time.

16
Care and maintenance
Replacing the oven lamps
l Disconnect the oven from the power supply at the fuse-box by means of the switch used to connect the
appliance to the electrical mains or unplug the appliance.
l Remove the glass cover of the lamp-holder by rotating anti-clockwise.
l Remove the lamp and replace with a lamp resistant to high
temperatures (300℃) with the following characteristics:
Voltage: 220-240V
Wattage: 25W
Type: G9
l Replace the glass cover. Reconnect the appliance to the mains power supply.
Cleaning the oven door / How to remove the oven doors
For a more thorough clean, you can remove and disassemble the oven door. Proceed as
follows using the oven door removal and assemble procedure:
- Open the door to the full extent (fig.1).
- Open lever A completely on the left and right hinges (fig.2).
- Hold the door as shown in (fig.3).
- Gently close the door (fig.3) until the left and right hinge levers (A) are hooked to part B of the door (fig.4).
- Withdraw the hinge hooks from their location following arrow C (fig.4).
- Rest the door on a soft surface.
- To replace the door, repeat the above steps in reverse.
Fig.1
Fig.2
Fig.3
Fig.4

17
Care and maintenance
Technical specification
Model
CETS501W / CETS501B
Voltage and frequency
220-240V AC/50Hz
Top oven power
1400W
Bottom oven power
1815W
Top oven usable capacity
23L
Oven usable capacity
48L
Power consumption for big hot plate
1500W (x2)
Power consumption for small hot plate
1000W (x2)
Total hot plate power consumption
5000W
Total power
8215W
We apologise for any inconvenience caused by minor inconsistencies within these instructions that may occur due to
product improvements and development. All images and drawings are for illustration purposes only.

18
PRODUCT FICHE
Comply with Energy Label Directive Eu 2010/30/EU - Regulation No 65/2014 of ovens according to
EN 60350-1 or EN 15181
Comply with EU directive 2009/125/EC- regulation No 66/2014 according to EN 60350-1or EN 15181
Brand
ALTIMO
Model
CETS501W / CETS501B
Type of oven
Free Standing
X
Built-in
Mass of the appliance(M)(Net weight)kg
44,2
kg
Number of cavities
2
Heat source per cavity
Electrical
X
Gas
Mix
Volume per cavity
48
Energy consumption (electricity) required toheat a
standardised load inacavityofanelectric heated ovenduringa
cycleinconventional mode per cavity (electric finalenergy)
EC
electric
cavity
0.71
kWh/cycle
Energy consumption required to heat a standardised load in a
cavity ofanelectric heated oven duringa cycle infan-forced
mode per cavity (electric final energy)
EC
electric
cavity
kWh/cycle
Energy consumption required to heat a standardised load in a
gas!fired cavity of an oven during a cycle in conventional mode
per cavity (gas final energy)
EC gas
cavity
MJ/cycle
kWh/cycle (')
Energy consumption required toheat a standardised load in a
gas!fired cavity of an oven during a cycle in fan-forced mode
per cavity (gas final energy)
EC gas
cavity
MJ/cycle
kWh/cycle (')
Energy Efficiency Index per cavity
EEIcavity
94,7
Energy Efficiency Class
A
(1) 1 kWh/cycle= 3,6 MJ/cycle.

19
PRODUCT FICHE
Information for domestic electric hobs
ComplywithEUdirective 2009/125/EC -Regulation No66/2014accordingtoEN60350-2
Brand
ALTIMO
Model
CETS501W / CETS501B
Type of hob
Electrical
X
Gas
Mix
Number of cooking zone and or area
4
Heating Technology
Radiant Cooking zone
Induction Cooking zone
Solid Plates Cooking zone
X
For circular cooking zones or area: diameter of
useful surface area per electric heated cooking
zone, rounded to the nearest 5 mm(0/cm)
Front Left Zone
14,5
Rear left zone
18
Front right zone
18
Rear right zone
14,5
Front centre zone
Rear centre zone
Fornon-circular cooking zones orareas:length
and widthofuseful surface area per electric
heated cookingzone or area, rounded tothe
nearest 5mm (LxW) cm
Front left zone
Rear left zone
Front right zone
Rear right zone
Front centre zone
Rear centre zone
Energy consumption perelectric cooking zone or
area calculated per kgEC electric cooking Wh/kg
Front left zone
193
Rear left zone
193
Front right zone
193
Rear right zone
193
Front centre zone
Rear centre zone
Energy consumption for the hob calculated per kg EC electric hob (Wh/kg)
193

Product support
20
Troubleshooting
If you have a problem with your appliance, check the troubleshooting table below to try and rectify your problem
before calling your product support service centre.
Problem
Causes
What to do
Oven or grill not working
Power not turned on
Switch on electricity
Household fuse blown
Check fuses
Controls incorrectly set
Reset controls
Circuit breaker tripped
Check circuit breaker
Oven light not working
Power not turned on
Switch on electricity
Household fuse blown
Check fuses
Circuit breaker tripped
Check circuit breaker
Lamp blown or loose in socket
Replace or tighten globe
Oven not hot enough
Heat escaping through incorrectly sealed
door
Check shelves or dishes are not preventing door
closing properly. Check that door is fitted properly
after door removal for cleaning
Door seal is worn or has moved
Replace seal or refit it
Unit smoking when first
used
Protective oils being removed
This is normal
Odour on first use of
oven
This is normal. Allow 2-4 hours for odour to
dissipate (open all windows)
Oven shelf tight
Oven shelf not inserted correctly, may be
upside down or back to front
Remove shelf and insert as per diagram
Note: Do not attempt to repair this cooker yourself. Please call our Repairs Team on 0300 024 5648.
