1.The appliance, complete with unattached items
and accessories, may be delivered in one or
more packages. Check to ensure that the
following items have been received as standard
with each unit.
500-S: 2 - SIDE RAC S, 3 - WIRE SHELVES, 4 - CASTERS
750-S: 2 - SIDE RAC S, 3 - WIRE SHELVES, 4 - CASTERS
1000-S: 2 - SIDE RAC S, 4 - CASTERS
1200-S: 4 SETS PAN SLIDES, 4 - CASTERS
2. This appliance is designed for the purpose of
maintaining hot food at a temperature for safe
consumption. The unit must be installed on a
level surface in a location that will permit the
equipment to function for its intended purpose
and allow adequate access for proper cleaning
and maintenance.
3. The appliance must not be installed in any area
where it will be affected by steam, grease,
dripping water, high temperatures, or any other
severely adverse conditions.
4. Level the appliance from side-to-side and front-
to-back using a spirit level.
5. In order to maintain standards established by the
National Sanitation Foundation, all equipment
must be equipped with casters or 6" (152mm)
legs to provide minimum unobstructed space
beneath the unit; or secured flush at the bottom
and the entire base sealed with NSF approved
sealant. Warranty will become null and void if
these directions are not followed.
#823 • IN STALLATION/ OPERATION/ SERVICE MANUAL • 3.
SITE INSTALLATION
INSTALLATION
C L E A R A N C E R E Q U I R E M E N T S
3-inches (76mm) at the back,
2-inches (51mm) at the top,
1-inch (25mm) at both sides
TO PREVENT PERSONAL INJURY,
USE CAUTION WHEN MOVING OR
LEVELING THIS APPLIANCE.
WEIGHT (EST.)
1000-S/STD 1000-S/HD
ET 138 lb (63 kg) 150 lb (68 kg)
SHIP 163 lb (74 kg) 180 lb (82 kg)
CARTO DI ME SIO S:45" X27" X35" EST.
(H x W x D) (1143mm x 686mm x 889mm)
WEIGHT (EST.)
1200-S/STD 1200-S/HD
ET 165 lb (75 kg) 180 lb (82 kg)
SHIP 163 lb (74 kg) 180 lb (82 kg)
CARTO DI ME SIO S:48" X33" X36" EST.
(H x W x D) (1219mm x 838mm x 914mm)
W E I G H T
750-S/STD 750-S/HD
ET 152 lb (69 kg) 162 lb (73 kg)
SH IP 193 lb (88 kg) 203 lb (92 kg)
CARTO DI ME SIO S:40" X28" X34 EST.
(H x W x D) (1015mm x 686mm x 889mm)
W E I G H T EST.
500-S/STD 500-S/HD
ET 94 lb (43 kg) 104 lb (47 kg)
SHIP 120 lb (54 kg) 130 lb (59 kg)
CARTO DI ME SIO S:40" X20" X30" EST.
(H x W x D) (1015mm x 508mm x 762mm)
