Alton ECOMAX ELG04 User manual

Model:ELG04
INSTRUCTION MANUAL
18V CORDLESS LEAF BLOWER

CONTENTS
PURPOSE
DESCRIPTION OF SYMBOLS
SYMBOLS
ACCESSORY INFORMATION
TECHNICAL DATA
COMPONENTS
OPERATION
CHARGING THE BATTERY
TRANSPORTATON AND STORAGE
IMPORTANT SAFETY INSTRUCTIONS
BATTERY-OPERATED POWER TOOLS
CHILD SAFETY
RECYCLE
TROUBLESHOOTING
WARRANTY
01
01
02
03
03
03
04
07
09
10
11
12
12
13
14

01 02
PURPOSE
The machine is used to propel air out of a tube to move unwanted materials
such as leaves in the yard.
DESCRIPTION OF SYMBOLS
The rating plate on your tool may show symbols. These represent important information about the
product or instructions on its use.
Read and understand all instructions before operating the product, and follow all
warnings and safety instructions.
Precautions that involve your safety.
Always wear eye protection with side shields marked to comply with ANSI Z87.1
when operating this equipment.
Do not expose the product to rain or moist conditions.
Batteries may enter water cycle if disposed improperly, which can be hazardous for
ecosystem. Do not dispose of waste batteries as unsorted municipal waste.
of waste batteries as unsorted municipal waste
Do not burn.
Li-ion battery. This product has been marked with a symbol relating to ‘separate
collection’ for all battery packs and battery pack. It will then be recycled or disman-
tled in order to reduce the impact on the environment. Battery packs can be hazard-
ous for the environment and for human health since they contain hazardous
substances.
Do not expose the product to rain or moist conditions.
Positive terminal.
Negative terminal.
Thrown objects can ricochet and result in personal injury or property damage. Wear
protective clothing and boots.
SYMBOLS
The label on your tool may include the following symbols. The symbols and their definitions are as
follows:
V
A
W
min
/min
HZ
~
Kg
n｡
mm
dB
° C
Li-ion
Wh
Voltage
Ampere( Current)
Watt(Power)
Time
Revolutions per minute
Direct current
Hertz
Alternating current
Kilograms
No load speed
Millimetres
Decibel
Degrees centigrade
Lithium ions
Watt-hours

03 04
ACCESSORY INFORMATION
Battery pack
Charger
Accessories
1pcs 2.0Ah Li-ion battery
1pcs quick charger
Two section duct
We recommend that you purchase your accessories from the same store that sold you the tool.
Refer to the accessory packaging for further details. Store personnel can assist you and offer advice.
TECHNICAL DATA
18V DC
54.7CFM
140MPH(62m/s)
2. 7 lbs
96.6 db(A), KPA=3 db(A)
100dB(A)
Voltage
Air volume
Air speed
Weight (without battery pack)
Measuered sound pressure level
Guaranteed sound power level
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future reference. The term" power tool "in the
warnings refers to your mainsoperated(corded) power tool or battery-operated (cordless) power
tool.
COMPONENTS
1
1
2
2
3
34
4
5
5
Two section tube
Tube release button
Machine bod
Switch button
Battery pack mounting slot
OPERATION
WARNING! Before any replacements, switch the tool off, wait for it to come to a standstill,
and take the battery out of the tool.
WARNING! Make sure the blower tube is in position before operation.
2. INSTALL THE BATTERY PACK
1）. Align the lift ribs on the battery pack with the grooves in the battery compartment.
2）. Push the battery pack into the battery compartment until the battery pack locks into place.
3）. When you hear a click, the battery pack is installed.
1. INSTALL THE BLOWER TUBE
Move the tube until the bayonet of the pipe is completely stuck into the locating pin.

05 06
WARNING! If the battery pack or charger is damaged, replace the battery pack or the
charger.
WARNING! Stop the machine and wait until the motor stops before you install or remove
the battery pack
WARNING! Read and understand the instructions in the battery and charger manual.
3. REMOVE THE BATTERY PACK
1）. Push and hold the battery release button.
2）. Remove the battery pack from the machine.
4. START THE MACHINE
Press the switch to trigger 4.
5. STOP THE MACHINE
Release the trigger(component 4) to stop the machine.
4
4
7. MAINTENANCE
CAUTION! Do not let brake fluids, gasoline, petroleum-based materials touch the plastic
parts. Chemicals can cause damage to the plastic, and make the plastic unserviceable.
CAUTION! Do not use strong solvents or detergents on the plastic housing or compo-
nents.
WARNING! Remove the battery pack from the machine before maintenance.
6. OPERATION TIPS
Release the trigger(component 4) to stop the machine.
Blow around the outer edge of the unwanted materials to prevent the unwanted materials from
scattering. Use rakes and brooms to clear the unwanted material before you blow.
Make the surfaces wet before you clear the unwanted material in dusty conditions.
Look out for children, pets, open windows, and cleaned cars during operation.
Clean the machine.
Discard the unwanted material when you complete work.
CAUTION! The machine must be dry Humidity can cause risks of electrical shocks.
8. CLEAN THE MACHINE
Clear the unwanted material out of the air vent with a vacuum cleaner.
Do not spray the air vent or put the air vent in solvents.
Clean the housing and the plastic components with a moist and soft cloth
9. OVERLOAD PROTECTION
When overloaded, the motor comes to a stop Relieve the load on the machine immediately and
allow cooling for approx 30 seconds.
10. TEMPERATURE DEPENDENT OVERLOAD PROTECTION
When using as intended the power tool cannot be subject to overload. When the load is too high
or the allowable battery temperature of 75° C is exceeded the electronic control switches off the
power tool until the temperature is in the optimum temperature range again.
11. PROTECTION AGAINST DEEP DISCHARGING
The Li-ion battery is protected against deep discharging by the"Discharging Protection System.
When the battery is empty, the machine is switched off by means of a protective circuit: The
inserted tool no longer start.

07 08
CHARGING THE BATTERY
1. REMOVING THE BATTERY
If the Battery does not slide into the charger easily, do not force it. Instead, slide the Battery out of
the charger again, check the top of Battery and the tool battery slot are clean and undamaged and
that the contacts are not bent.
Setting up the battery charger.
1）. If fitted, remove any Battery(B )from the Battery Charger(A).
2）. Insert the Battery Charger mains plug into a suitable mains socket.
WARNING! Remove the battery pack from the machine before maintenance.
WARNING! The charger is designed for indoor use only, and must not be used in damp or
wet conditions.
2. PUT IN THE BATTERY TO CHARGER
Insert
battery
WARNING! Failure to follow the correct procedure when charging batteries will
result in permanent damage.
Note: Normal charging time is approximately 70 minutes for a recently discharged
2.0Ah capacity battery. However, if the Battery has been left in a discharged state for
some time, it may take additional time to charge.
LED indicate
Nummer
1
2
3
Charger status
Charging
Finished charging
Battery failure
LED status
Red light Green light
ON
OFF
OFF
OFF
ON
OFF
Remark battery operating temperature 0±3°C<T<50±3°C
NOTE: ABOUT BATTERY CHARGING:
The battery should be charged at ambient temperatures between 10 and 40° C. (ideally
around 20°C).
After discharging the battery, please wait 10 minutes for the battery to cool down before
charging.
After charging, allow 15 minutes for the battery to cool before use.
Ensure that the charger is disconnected from the mains supply after use, and is stored
correctly.
Do not leave batteries on charge for extended periods and never store batteries on charging.
The Battery Charger monitors battery temperature and voltage while charging. Remove the
battery once charging is complete to maximise charge cycles of the battery and not waste
power.
Batteries can become faulty over time, individual cells in the battery can fail and the battery
could short. The charger will not charge faulty batteries. Use another battery if possible, to
check correct functionality of the charger and purchase a replacement battery if a faulty
battery is indicated.
Do not store lithium-ion battery packs in a discharged state over a long period as this can
damage the lithium-ion cells.
For long-term storage, store batteries in a high charge state disconnected.
The capacity of batteries will reduce over time. After 100 charge cycles, the battery�s opera-
tion time and the maximum torque performance of the driver will slightly reduce. This decline
will continue until the battery has minimal capacity after 250 charge cycles. This is normal and
not a fault with the battery pack.
When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal
to another. Shorting the battery terminals together may cause burns or a fire.
Under abusive conditions liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
If the tool will not be used for long periods of time, charge the battery every 3-6 months.
01）
02）
03）
04）
05）
06）
07）
08）
09）
10）
11）
12）
13）
ADDITIONAL SAFETY NSTRUCTIONS FOR YOUR BATTERY CHARGER
Before charging, read the instructions.
For charging Li-ion battery packs only.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
After charging, disconnect the battery charger from the supply mains. Then remove the
chassis connection and then the battery connection.
Do not charge a leaking battery.
01.
02.
03.
04.
05.

09 10
Do not use chargers for work other than those for which they are designed.
Before charging ensure your charger matches the local AC supply.
The charging device must be protected from moisture.
Do not use the charging device in the open.
Do not short out the contacts of battery or charger.
Respect the polarity"+/-"when charging.
Do not open the unit and keep out of the reach of children.
Do not charge the batteries of other manufactures or ill-suited models.
Ensure that the connection between the battery charger and battery is correctly positioned
and is not obstructed by foreign bodies.
Keep battery chargers slots free of foreign objects and protect against dirt and humidity. Store
in a dry and frost-free place.
When charging batteries, ensure that the battery charger is in a well-ventilated area and away
from inflammable materials. Batteries can get hot during charging. Do not overcharge any
batteries. Ensure that batteries and chargers are not left unsupervised during charging.
Do not recharge non-rechargeable batteries, as they can overheat and break.
Charge only battery pack of the same model provided by ECOMAX and of models
recom-mended by ECOMAX
06.
07.
08.
09.
10.
11.
12.
13.
14.
15.
16.
17.
18.
TRANSPORTATION AND STORAGE
WARNING! Remove the battery pack from the machine before tranportation and storage.
STORE THE MACHINE
Clean the machine before storage.
Make sure that the motor is not hot when you store the machine.
Make sure that the machine does not have loose or damaged parts. If it is necessary, do these
steps.
INSTRUCTIONS
Replace the damaged parts.
Tighten the bolts.
Speak to a person of an approved service center.
Store the machine in a dry area.
Make sure that children cannot come near the machine.
THE RECOMMENDED AMBIENT TEMPERATURE RANGE:
Temperature
-4°F(-20°C) - 158°F(70°C)
-4°F(-20°C) - 104°F(40°C)
39°F(4°C) - 104°F(40°C)
39°F(4°C) - 113°F(45°C)
1 year: 32°F(0°C) - 73°F(23°C)
3 months: 32°F(0°C)113°F(45°C)
1 months: 32°F(0°C)140°F(60°C)
6.8°F(-14°C) - 113°F(45°C)
Item
Blower storage temperature range
Blower operation temperature range
Battery charging temperature range
Charger operation temperature range
Battery storage temperature range
Battery discharging temperature range
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING (THIS POWER TOOL)
WARNING! Read and understand all instructions before using this product. Failure to
follow all instructions listed below may result in electric shock, fire, and/or serious personal
injury. When using an electrical appliance, basic precaution should always be followed,
including the following:
Do not use on wet surfaces.
Do not charge the unit outdoors.
For household use.
Do not allow to be used as a toy. Close attention is necessary when used by or near children.
Use only as described in this manual. Use only manufacturer�s recommended attachments.
If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped
into water, return it to a service center.
Do not handle appliance with wet hands.
Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce air flow.
Keep hair, loose clothing, fingers and all body parts away from openings and moving parts.
Use extra care when cleaning on stairs.
Do not operate power tools in an explosive atmosphere, such as in the presence of flammable
liquids, gases, or dust Power tools create sparks that may ignite the dust or fumes.
Store indoors. Do not expose to rain or water. Avoid direct sunshine.
Never allow children to operate the equipment. Never allow adults to operate the equipment
without proper instruction.
Wear heavy long pants, boots, and gloves. Avoid loose garments or jewellery that could get
caught in moving parts of the machine or its motor.

11 12
Do not force tool. Use the correct tool for your application. The correct tool will do the job better
and safer at the rate for which it is designed.
Keep firm footing and balance. Do not overreach. Overreaching can result in loss of balance.
Do not use e tool if e w ch es not urn it on or off Any tool that cannot be controlled with the switch
is dangerous and must be repaired.
Do not operate this unit when you are tired, ill, or under the influence of alcohol, drugs, or
medication.
Do not operate in poor lighting.
Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where
they may be present.
Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
Do not use without collection bag, gate or tubes in place(if applicable).
Check the work area before each use. Remove all objects such as rocks, broken glass, nails, wire,
or string which can be thrown or become entangled in the machine.
Use only identical manufacturers replacement parts and accessories. Use of any other parts may
create a hazard or cause product damage.
BATTERY-OPERATED POWER TOOLS
Do not use battery-operated appliance in rain.
Turn off all controls before removing the battery.
Recharge only with the charger specified by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when used with another battery pack.
Use only the charger supplied by the manufacturer to recharge.
Use appliances only with specifically designated battery packs. Use of any other battery packs
may create a risk of injury and fire
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
battery pack, picking up or carrying the appliance. Carry the power tool with your finger on the
switch or energize power tool that have the switch on invites accidents.
Disconnect the battery pack from the power tool before making any adjustments, changing
accessories, or storing the power tool. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
When battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys,
nails, screws or other small metal objects that can make a connection from one terminal to anoth-
er. Shorting the battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery: avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
Do not incinerate the appliance even if it is severely damaged. The batteries can explode in a fire.
Do not use a battery pack or appliance that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury.
Do not expose a battery pack or appliance to fire or excessive temperature Exposure to fire or
temperature above 265°F(130°C) may cause an explosion.
Have servicing performed by a qualified repair person using only identical replacement parts. This
will ensure that the safety of the product is maintained
Don�t modify or attempt to repair the appliance or the battery pack(as applicable)except as
indicated in the instructions for use and care.
Follow all charging instructions and do not charge the battery pack or appliance outside of the
temperature range specified in the instructions. Charging improperly or at temperatures outside
of the specified range may damage the battery and increase the risk of fire.
CHILD SAFETY
Tragic accidents can occur if the operator is not aware of the presence of children.
Keep children out of the working area and under the watchful care of a responsible adult.
Do not allow children under the age of 14 to operate this machine. Children who are 14 years of
age and older must read and understand the operating instructions and safety rules in this
manual and must be trained and supervised by a parent.
Stay alert, and turn the machine off if a child or any other person enters the working area.
Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that
may obscure your view of a child who may run into the path of the machine.
RECYCLE
WARNING! Discard all toxic materials in a specified manner to prevent contamination of
the environment. Before discarding, damaged or worn out Li-ion batter contact your local
waste disposal agency, or the local Environmental Protection Agency for information and
specific instructions. Take the batteries to a local recycling an/or disposal center, certified
for lithiumion disposal.
The toxic and corrosive materials below are in the batteries used in this machine: Lithium-lon, a
toxic material.
WARNING! If the battery pack cracks or breaks, with or without leaks, do not recharge it
and do not use. Discard it and replace with a new battery pack. DO NOT TRY TO REPAIR IT!
To prevent injury and risk of fire, explosion, or electric shock,and to avoid damage to the
environment：
Cover the terminals of the battery with heavy-duty adhesive tape.
Separate collection. You must not scar with usual household waste. If it is necessary to
replace the machine, or it is no more use to you, do not discard it with household waste.
Make this machine available for separate collection.
Separate collection of used machine and packaging let you recycle materials and use
them again. Use of the recycled materials helps prevent environmental pollution and
decreases the requirements for raw materials.

13 14
At the end of their useful life discard batteries with a precaution for our environment. The
battery contains materials that is dangerous to you and the environment. You must
remove and discard these materials separately at a equipment that accepts lithium-ion
batteries.
TROUBLESHOOTING
POSSIBLE CAUSE SOLUTIONPROBLEM
The motor does not start
when you pull the trigger.
The machine does not start.
The air does not flow
through the tube when you
start the machine.
The battery pack is not
installed tightly.
The battery pack is out of
power.
The power switch is defective.
The motor is defective.
The PCB board is defective.
The air inlet or tube outlet has
a blockage.
Make sure that you tighlty
install the battery pack in the
machine.
Charge the battery pack.
Replace the defective parts by
an approved service center.
Remove the blockage.
WARRANTY
