ALZA ToumeiV5 User manual
ToumeiV5
User Manual • Uživatelskýmanuál •
Užívateľskýmanuál • Használatiutasítás •
Benutzerhandbuch
2
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
3
Remote Control
Instruction of Buttons
Note: 1. Please keep the remote control aiming at the picture
2. Please take out the battery if the remote control is not used for a long time.
Power Supply
Focusing
Ok
Left
Down
Return
Volume Down
Acoustic Pattern
3D
Mute
Up
Right
Homepage
Menu
Volume Up
4
Remote Control
Operation of External Mouse
The mouse (optional) can control the intelligent projector conveniently.
1. Enter the Menu by left click
2. Return to Homepage by right click
Text Input
You can enter text through the keyboard on screen, which provides the layout similar to
the keyboard of desktop computer. Some applications will automatically open the soft
keyboard, and you can choose to open the soft keyboard manually if you need to use it
in other applications.
5
Select language
6
Wireless screen (Windows)
Windows with screen operation guide
1. Please confirm your windows and projector IP addresses are connected to the
same LAN.
2. Use the following link to download and
installhttp://cdn.sharemax.cn/app/EShareClient-STD.exe
3. Click Esharecent-STD, and the name and IP address of the projection device will
appear. Click “Start Screen Transmission” to begin using the wireless screen.
7
Airplay (iPhone)
iPhone AirPlay mirror operation guide
Supported by the following devices: iPhone 5 and above, iPad 2 and above, iPod Touch
(5th generation and above).
1. Connect your iPhone and projector to the same –Wi-Fi-- network (5G first)
8
2. Click to open the projected Airplay, and then Eshare-**** will be displayed in the
lower left corner.
3. Slide your finger from the bottom of the iPhone screen to the top, bringing up a
new menu, and open the iPhone control centre (Slide from the top down for
iPhone X).
4. Click Airplay Mirroring and the device list will automatically search for the
projected devices, within the same network.
5. From the device list, click the name of the projected device you want to connect
to (Eshare-****) to successfully cast the screen.
9
Use mobile hotspot for AirPlay mirror operation guide
1. For use without having a LAN or Wi-Fi available, first turn on "Settings" --
"Personal Hot spot" -- "Allow others to join" on the iPhone, select and turn on.
2. Click "Settings" of the projector -- turn on "Wi-Fi", search for the hotspot name of
iPhone, and find and connect.
3. Swipe your iPhone from the bottom up and open the iPhone control centre (Slide
from the top down for iPhone X).
4. Click "Airplay Mirroring" and the device list will automatically search for the
internal projection device in the same network.
5. From the device list, click the name of the projected device you want to connect
to (Eshare-****) to successfully cast the screen.
10
iPhone AirPlay reverse
Screen Projection operation Guide
1. Click to open the projected Airplay, then follow the prompts on the page to scan
the QR code of your iPhone, download and install the corresponding Eshare APP.
2. Open the Eshare app on the mobile phone, and the device list will automatically
search for the internal projection device of the same network.
3. Click the projection device (Eshare-****), "one-click screen transmission" and
"Reverse screen transmission" will appear simultaneously.
4. Click “Reverse Screen Transmission”.
11
Synchronous Screen Display through Wireless
Connection (for Android Mobile Phone)
Course of Synchronous Screen Display for Android Mobile Phones with Multi-
screen Interaction
1. The mobile phone and the projector must connect to the same Wi-Fi
2. Click Setting>Screen Projection for Android>Click Scanning, Retention Interface
12
3. Open “More Connections”/”Screen Projection for Mobile Phone” on the mobile
phone (there are varieties of models of Android mobile phones which may have
different names, and the mobile phone to be referred is HUAWEI mobile phone)
4. After the model of a mobile phone searched through the multi-screen interaction
is consistent with the model displayed in the “synchronous screen display of a
mobile phone”, the mobile phone will be connected automatically (the projector
cannot be connected automatically), and then the synchronous screen display
can be achieved after several seconds.
13
Wireless screen
Android with multi-screen interactive models with screen tutorial (Android phone)
Note: It is recommended to use the built-in Android screen and Eshare android screen.
The voice cannot be transmitted (the system audio acquisition permission cannot be
obtained).
Wi-Fi Connection
Connect to Wi-Fi and Set up Hotspot
Select Wi-Fi that you are intended to connect and click “Finnish” after entering the
password (the device will connect automatically to the Wi-Fi network selected in last
time within the available connection range). It can select the wireless hotspot to set up
the sharing hotspot network when connecting to the cable network.
14
Bluetooth Connection
Connect to Bluetooth device (Homepage>Settings>Bluetooth>Open Bluetooth)
15
Online Upgrade
1. Homage>Setting>System Settings>System Upgrade. Wi-Fi must be kept smooth
and the power supply must be kept stable during the upgrade, otherwise the
update will fail or the update system will crash.
2. If there is no reaction by click during the upgrade, please click by switching to the
mouse model of remote control, and then the system will be downloaded and
upgraded automatically, which only takes ten minutes.
3. When an error is displayed by clicking the system upgrade, it proves that the
current version is the latest version and there is no need to upgrade.
16
Resource Manager
All of the files in the Resource Manager.
Picture Settings
1. Brightness Mode: Optional for Standard Mode/Highlight Mode/Power-down
Mode
2. Keystone Correction: Automatic Keystone Correction/manual Keystone
Correction
3. Projection Mode: Direct Orthographic Projection/Direct Rear Projection/Hoisting
Orthographic Projection/Hoisting Rear Projection
17
Picture Settings
Keystone Correction:
1. Manual Setting: adjust the shape of trapezoid according to the offset, or click
Restore Defaults for automatic correction.
2. Correction of Four-angle Trapezoid: adjust the angle of the trapezoid freely from
four directions, and switch to the correction for the next corner by clicking OK,
and adjust the angle through the direction button and restore the settings by
long pressing “Restore Defaults”
18
Wallpaper Settings
Replace Desktop Background
Sound Settings
1. Sound Output: Output of Digital Audio (RAW/PCM/Off)
2. Key Tone: Open/Close
3. Sound Effect: Standard/Music/Movie/Sport/User
4. Starting-up Sound: Open/Close
19
3D Settings
You can watch 3D movies on the projector by using 3D glasses.
When playing the video, it can open the 3D format conversion on the lower right corner
of the video by pressing “3D” button on the remote control.
3D Format Conversion: Video in Side-By-Side Format/Video in Up-Down Format.
Note: 3D cannot be switched in trapezoid correction mode.
20
You can watch 3D movies on the projector by using 3D glasses;
1. When the DLP projection is applied, the 3D effect can be displayed by using DLP-
Link.
2. 3D glasses must be rechargeable.
3. There are film sources in up-down format and film sources in side-by-side format
when playing 3D videos.
4. When playing film sources in side-by-side format, it requires pressing “3D” button
on the remote control to pop up the menu and then select “side-by-side”, and
then wear 3D glasses and turn on the Power Supply of 3D glasses to switch to
side-by-side format until you feel comfortable.
System Settings
1. Starting-up Source: Close/HDMI
2. Device Information: Device Model/System Version/TMUI Version/Storage Space
3. System Upgrade: Online Upgrade/U-disk Upgrade
4. Fan Settings: Automatic/Manual
5. Settings of Factory Reset: Choose Settings of Factory Reset (Choose Carefully)
