Sony VPL-VW790ES Service manual

M:\081-PC179\XP\ML\New Folder (3)\5022945221_VPL-
VW790ES_ML\5022945221\5022945221VPLVW790ESSYQ\01GB-VPLVW790ESSYQ\010COV.fm
masterpage:Cover
Video Projector
VPL-VW790ES
5-022-945-22 (1)
© 2020 Sony Corporation
Quick Reference Manual ___ GB
Guide de reference rapide _ FR
Manual de referencia rapida _ ES
Kurzreferenz______________ DE
Guida rapida all'uso _______ IT
_____________ CT
VPL-VW790ES
5-022-945-21(1)
M:\186-PC173\Win XP ML Acr7.0\ML\5022945211_VPL-
VW790ES_ML\5022945211\5022945211VPLVW790ESSYQ\01GB-VPLVW790ESSYQ\030C01.fm
masterpage: Right
VPL-VW790ES
5-022-945-21(1)

About the Quick Reference Manual
GB 2
This Quick Reference Manual explains the installation and basic operations for projecting pictures.
Before operating the unit, please read this manual thoroughly and retain it for future reference.
Refer to “About Indicators” as necessary.
For details on the operations, refer to the Operating Instructions contained in the supplied CD-ROM.
About the Quick Reference Manual
Preparing................................................................ Page 11
Installing the Unit................................................. Page 12
Connecting the Unit............................................ Page 14
Projecting ............................................................... Page 15
Error Handling About Indicators....................................................................... Page 16
Step 1
Step 2
Step 3
Step 4
Using the CD-ROM manual
The manual can be read on a computer with Adobe
Reader installed.
You can download Adobe Reader free from the Adobe
website.
1Open the index.html file in the CD-ROM.
2Select and click on the manual that you want to read.
If you have lost or damaged the CD-ROM, you can purchase a new
one from your Sony dealer or Sony service counter.
Adobe and Adobe Reader are trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
Note

WARNING 3GB
When using the product, do not use it for purposes other
than those described in the instruction manual.
WARNING
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.
WARNING
This apparatus must be earthed.
WARNING
When installing the unit, incorporate a readily accessible
disconnect device in the fixed wiring, or connect the power
plug to an easily accessible socket-outlet near the unit. If a
fault should occur during operation of the unit, operate the
disconnect device to switch the power supply off, or
disconnect the power plug.
CAUTION
About the LAN connector
For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this
port.
CAUTION
- Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
- When you dispose of the battery or the product, you must
obey the law in the corresponding area or country. Do
not dispose of the battery or the product in a fire or a hot
oven, or mechanically crush or cut the battery. It may
explode or cause a fire. Do not subject the battery to
extremely low air pressure that may result in an
explosion or the leakage of flammable liquid or gas.
- Do not place the battery in a high temperature place,
such as under direct sunlight or near fire. It may ignite,
explode, or cause a fire. Do not immerse or wet the
battery in water or seawater. This may cause an electric
shock.
CAUTION
The following size and number of batteries are required for
the remote control.
• Size: AA (R6)
• Number of battery(ies): Two pieces
To avoid risk of explosion, use only the following type of
battery.
• Alkaline or manganese batteries
For the customers in the U.S.A.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital
device pursuant to Subpart B of part 15 of FCC Rules.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
If you have any questions about this product, you may call;
Sony Customer Information Service Center 1-800-222-
7669 or http://www.sony.com/
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
For the customers the U.S.A.
Radiated Exposure Statement:
The product complies with the US portable RF exposure
limit set forth for an uncontrolled environment and is safe
for intended operation as described in this manual. The
further RF exposure reduction can be achieved if the
product can be kept as far as possible from the user body
Supplier’s Declaration of Conformity
Trade Name: SONY
Model: VPL-VW790ES
Responsible party: Sony Electronics Inc.
Address: 16535 Via Esprillo, San Diego, CA
92127 U.S.A.
Telephone Number: 858-942-2230
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
English
GB

WARNING
GB 4
or if the device is set to lower output power if such function
is available.
For the customers the U.S.A. and Canada
Radiated Exposure Statement:
The product complies with the US/Canadian portable RF
exposure limit set forth for an uncontrolled environment
and is safe for intended operation as described in this
manual. The further RF exposure reduction can be
achieved if the product can be kept as far as possible from
the user body or if the device is set to lower output power
if such function is available.
For kundene i Norge
Dette utstyret kan kobles til et IT-strømfordelingssystem.
For the customers in the U.S.A.
CAUTION
Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
This product is classified as a CLASS 3R LASER
PRODUCT.
WARNING
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
CAUTION
Do not look into the lens while in use.
CAUTION
Do not allow children to operate this product without
supervision.
CAUTION
The use of optical instruments with this product will
increase eye hazard.
For the customers in other countries
WARNING: Do not look into the lens while in use.
Caution
Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
Caution
The use of optical instruments with this product will
increase eye hazard.
För kunderna i Sverige
VARNING: Titta aldrig in i projektorns lins medan den
används.
Försiktighet!
Användandet av kontroller eller justeringar eller utförandet
av andra procedurer än de som specificeras häri kan
resultera I exponering av farlig strålning.
Försiktighet!
Användandet av optiska instrument med denna produkt
ökar risk för ögonskada.
Location information of the labels
Light source specifications
3.75 W laser diodes × 24
Wavelength: 450 - 460 nm
IEC 60825-1:2014
CLASS 1 LASER PRODUCT
As with any bright light source, do
not stare into the beam, RG2 IEC
62471-5:2015.
IEC 60825-1:2014
LASERPRODUKT AV KLASS 1
Precis som med alla starka ljuskällor
bör man inte titta direkt i strålen,
RG2 IEC 62471-5:2015.
LABEL (for service personnel)
APERTURE LABEL
CLASS 3R + CLASS 1 LABEL

WARNING 5GB
Beam divergence angle from lens of this unit
Zoom maximum: α= 42.5°
Zoom minimum: α= 21.3°
Do not place any object just in front of the lens that may
block the light during projection. Heat from the light may
damage the object. Use the picture muting function to cut
off the picture.
About 3D Glasses
The 3D Glasses communicate with the projector via
Bluetooth technology to display 3D signals.
(a) frequency band(s) in which the radio equipment
operates:
2.4 - 2.4835 GHz
(b) maximum radio-frequency power transmitted in the
frequency band(s) in which the radio equipment operates:
4.30 dBm (E.I.R.P.)
Laser emission port

WARNING
GB 6
Bulgarian
С настоящото, Sony Corporation декларира, че това оборудване е в съответствие с Директива 2014/53/EU.
Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес:
http://www.compliance.sony.eu/
Croatian
Sony Corporation ovime izjavljuje da je ova oprema u skladu s Direktivom 2014/53/EU. Cjeloviti tekst EU izjave o
sukladnosti dostupan je na sljedećoj internetskoj adresi:
http://www.compliance.sony.eu/
Czech
Sony Corporation tímto prohlašuje, že toto zařízení je v souladu se směrnicí 2014/53/EU. Úplné znění EU
prohlášení o shodě je k dispozici na této internetové adrese:
http://www.compliance.sony.eu/
Danish
Herved erklærer Sony Corporation, at dette udstyr er i overensstemmelse med direktiv 2014/53 / EU. Den fulde ordlyd af
EU-overensstemmelseserklæringen er tilgængelig på følgende internetadresse:
http://www.compliance.sony.eu/
Dutch
Hierbij verklaart Sony Corporation dat deze radioapparatuur conform is met Richtlijn 2014/53/EU. De volledige tekst van de
EU-conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres:
http://www.compliance.sony.eu/
English
Hereby, Sony Corporation declares that this equipment is in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address:
http://www.compliance.sony.eu/
Estonian
Käesolevaga deklareerib Sony Corporation, et käesolev seade vastab direktiivi 2014/53/EL nõuetele. ELi
vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil:
http://www.compliance.sony.eu/
Finnish
Sony Corporation vakuuttaa, että tämä laite on direktiivin 2014/53/EU mukainen. EU-vaatimustenmukaisuusvakuutuksen
täysimittainen teksti on saatavilla seuraavassa internetosoitteessa:
http://www.compliance.sony.eu/
Greek
Hungarian
A Sony Corporation igazolja, hogy ez a készülék megfelel a 2014/53/EU irányelvnek. Az EU-megfelelőségi
nyilatkozat teljes szövege elérhető a következő internetes címen:
http://www.compliance.sony.eu/
Latvian
Lithuanian
Norwegian
Herved erklærer Sony Corporation at utstyrstypen er i samsvar med direktiv 2014/53/EU. EU-erklæring fulltekst finner du på
Internett under:
http://www.compliance.sony.eu/
Polish
Sony Corporation niniejszym oświadcza, że to urządzenie jest zgodne z dyrektywą 2014/53/UE. Pełny tekst
deklaracji zgodności UE jest dostępny pod następującym adresem internetowym:
http://www.compliance.sony.eu/
Portuguese
O(a) abaixo assinado(a) Sony Corporation declara que o presente equipamento está em conformidade com a Diretiva 2014/
53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet:
http://www.compliance.sony.eu/
Romanian
Prin prezenta, Sony Corporation declară că acest echipament este în conformitate cu Directiva 2014/53/UE. Textul
integral al declaraţiei UE de conformitate este disponibil la următoarea adresă internet:
http://www.compliance.sony.eu/
Slovak
Sony Corporation týmto vyhlasuje, že zariadenie je v súlade so smernicou 2014/53/EÚ. Úplné vyhlásenie EÚ o
zhode je k dispozícii na tejto internetovej adrese:
http://www.compliance.sony.eu/
Slovenian
Sony Corporation potrjuje, da je ta oprema skladna z Direktivo 2014/53/EU. Celotno besedilo izjave EU o
skladnosti je na voljo na naslednjem spletnem naslovu:
http://www.compliance.sony.eu/
Swedish
Härmed försäkrar Sony Corporation att denna utrustning överensstämmer med direktiv 2014/53/EU. Den fullständiga texten
till EU-försäkran om överensstämmelse finns på följande webbadress:
http://www.compliance.sony.eu/

WARNING 7GB
Turkish
For the customers in the U.S.A.
SONY LIMITED WARRANTY - Please visit http://
www.sony.com/psa/warranty for important information
and complete terms and conditions of Sony’s limited
warranty applicable to this product.
For the customers in Canada
SONY LIMITED WARRANTY - Please visit http://
www.sonybiz.ca/pro/lang/en/ca/article/resources-
warranty for important information and complete terms
and conditions of Sony’s limited warranty applicable to
this product.
For the customers in Europe
Sony Professional Solutions Europe - Standard
Warranty and Exceptions on Standard Warranty.
Please visit https://pro.sony/en_GB/support-services/
warranty/support-professional-solutions-europe-
standard-product-warranty for important information
and complete terms and conditions.
For the customers in Korea
SONY LIMITED WARRANTY - Please visit http://
bpeng.sony.co.kr/handler/BPAS-Start for important
information and complete terms and conditions of
Sony’s limited warranty applicable to this product.

Precautions
GB 8
Precautions
On safety
• Check that the operating voltage of your unit is identical
with the voltage of your local power supply.
• Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by qualified
personnel before operating it further.
• Unplug the unit from the wall outlet if it is not to be used
for several days.
• To disconnect the cord, pull it out by the plug. Never pull
the cord itself.
• The wall outlet should be near the unit and easily
accessible.
• The unit is not disconnected to the AC power source
(mains) as long as it is connected to the wall outlet, even
if the unit itself has been turned off.
• Do not look into the lens while in use.
• Do not place your hand or objects near the ventilation
holes. The air coming out is hot.
On preventing internal heat build-up
After you turn off the power with the ?/1(On/Standby)
button, do not disconnect the unit from the wall outlet
while the cooling fan is still running.
Caution
This unit is equipped with ventilation holes (intake/
exhaust). Do not block or place anything near these holes,
or internal heat build-up may occur, causing picture
degradation or damage to the unit.
On repacking
Save the original shipping carton and packing material;
they will come in handy if you ever have to ship your unit.
For maximum protection, repack your unit as it was
originally packed at the factory.
On watching 3D video images
Safety precautions
• You should only use the 3D glasses for watching 3D
video images.
• If you observe flickering or flashing, turn off the lighting
in the room.
• Not for use by children without proper adult supervision.
• Be careful not to pinch your fingers in hinges of the 3D
glasses when bending the temple frames.
• Do not drop or modify these 3D glasses.
• If these glasses are broken, keep broken pieces away
from your mouth or eyes.
On inspection of light source related parts
Since the unit uses a laser, when performing maintenance
or inspection of light source related parts, particular
attention and a safe environment are necessary. Be sure to
consult with qualified Sony personnel (charged).
On LCD Projector
The LCD projector is manufactured using high-precision
technology. You may, however, see tiny black points and/
or bright points (red, blue, or green) that continuously
appear on the LCD projector. This is a normal result of the
manufacturing process and does not indicate a
malfunction.
Also, when you use multiple LCD projectors to project
onto a screen, even if they are of the same model, the color
reproduction among projectors may vary, since color
balance may be set differently from one projector to the
next.
On condensation
If the room temperature where the projector is installed
changes rapidly, or if the projector is moved suddenly from
a cold to a warm place, condensation in the projector may
occur. As the condensation may cause malfunction, be
careful in adjusting temperature settings of the air
conditioner. If condensation occurs, leave the projector
turned on for about two hours before use.
Notes on security
• SONY WILL NOT BE LIABLE FOR DAMAGES OF
ANY KIND RESULTING FROM A FAILURE TO
IMPLEMENT PROPER SECURITY MEASURES ON
TRANSMISSION DEVICES, UNAVOIDABLE DATA
LEAKS RESULTING FROM TRANSMISSION
SPECIFICATIONS, OR SECURITY PROBLEMS OF
ANY KIND.
• Depending on the operating environment, unauthorized
third parties on the network may be able to access the
unit. When connecting the unit to the network, be sure to
confirm that the network is protected securely.
• From a safety standpoint, when using the unit connected
with the network, it is strongly recommended to access
the Control window via a Web browser and change the
access limitation settings from the factory preset values
(refer to “Network Features” in the Operating
Instructions).
Changing the password regularly is also recommended.
• Do not browse any other website in the Web browser
while making settings or after making settings. Since the
login status remains in the Web browser, close the Web
browser when you complete the settings to prevent
unauthorized third parties from using the unit or harmful
programs from running.
Do not place this product close to medical
devices
This product (including accessories) has magnet(s) which
may interfere with pacemakers, programmable shunt
valves for hydrocephalus treatment, or other medical
devices. Do not place this product close to persons who use

Notes on Installation and Usage 9GB
such medical devices. Consult your doctor before using
this product if you use any such medical device. Notes on Installation and
Usage
Do not place the unit in the following situations, which
may cause malfunction or damage to the unit.
Near walls
To maintain the performance and reliability of the unit,
leave space between walls and the unit as illustrated.
Note that the wall on the ventilation holes side may
become hot.
Air from air conditioners or the ventilation holes of this
unit or other devices, may cause oscillation on the screen.
Be sure not to install this unit in the area where the air from
air conditioners or the ventilation holes of these devices
reach to the front side of this unit.
Poorly ventilated location
Leave space of more than 30 cm (11 7/8 inches) around the
unit.
Hot and humid
SONY WILL NOT BE LIABLE FOR DAMAGES OF
ANY KIND RESULTING FROM THE USE OF THIS
UNIT FOR PURPOSES OTHER THAN GENERAL
HOME USE, EITHER DURING THE WARRANTY
PERIOD OR AFTER EXPIRATION OF THE
WARRANTY.
Unsuitable installation
5 cm
(2 inches)
5 cm (2 inches)
5 cm
(2 inches)
5 cm
(2 inches)
15 cm (6 inches)
5 cm
(2 inches)

Notes on Installation and Usage
GB 10
Locations subject to direct cool or warm air from
an air-conditioner
Installing the unit in such a location may cause a
malfunction of the unit due to moisture condensation or
rise in temperature.
Near a heat or smoke sensor
Malfunction of the sensor may occur.
Very dusty and extremely smoky locations
Do not do any of the following while using the unit.
Tilting front/rear and left/right
Avoid using the unit tilted at an angle, as shown in the
following illustrations.
Do not install the unit anywhere other than on a level
surface or on the ceiling. Installing the unit in such a
location may result in uneven color uniformity.
If the unit is tilted up or down, the image on the screen may
be trapezoidal. Position the unit so that the lens is parallel
to the screen.
When installing the unit at high altitudes
When using the unit at an altitude of 1,500 m (approx.
4,900 ft) or higher, set “High Altitude Mode” on the Setup
menu to “On”. Failing to set this mode when using the
unit at high altitudes could have adverse effects, such as
reducing the reliability of certain components.
• Never mount the projector on the ceiling or move it by
yourself. Be sure to consult with qualified Sony
personnel (charged).
• When installing the unit on a ceiling, be sure to use a
safety wire, etc., to prevent the unit from falling. Entrust
the installation to an experienced contractor or installer.
For dealers
• When the projector is mounted on the ceiling, a Sony
bracket or recommended equivalent must be used for
installation.
• Be sure to secure the cabinet cover firmly when
installing to the ceiling firmly.
Unsuitable Conditions
15° or more
15° or more 10° or more
Safety precautions for installing the
unit on a ceiling
15° or more 10° or more

Preparing 11GB
Check the carton to make sure it contains the following
items:
• Remote control RM-PJ24 (1)
• Size AA (R6) batteries (2)
• Lens cap (1)
When you purchase the projector, a lens cap is on the
lens. Remove the lens cap before you use the projector.
• AC power cord (1)
• Quick Reference Manual (this manual) (1)
• Operating Instructions (CD-ROM) (1)
Caution about handling the remote control
• Handle the remote control with care. Do not drop or step
on it, or spill liquid of any kind onto it.
• Do not place the remote control in a location near a heat
source, a place subject to direct sunlight, or a damp
room.
Preparing
Step 1
Checking the Supplied Accessories
Inserting the Batteries into the
Remote Control
Push and slide to open.
Insert the batteries Eside first.

Installing the Unit
GB 12
1Position the unit so that the lens is parallel to the
screen.
2After connecting the AC power cord to the unit, plug
the AC power cord into a wall outlet.
After connecting the AC power cord to the unit, the ON/
STANDBY indicator may blink in orange.
You may not be able to control the unit while the indicator is
blinking, but this is not a malfunction. Wait until it stops blinking
and remains lit in red.
3Press the ?/1(On/Standby) button to turn on the unit.
4Project an image on the screen, then adjust the focus,
size, and position.
aAdjust the focus.
Press the LENS ADJUSTMENT (FOCUS) button to
display the Lens Focus adjustment window (test
pattern). Then adjust the focus of the picture by
pressing the M/m/</,button.
bAdjust the picture size.
Press the LENS ADJUSTMENT (ZOOM) button to
display the Lens Zoom adjustment window (test
pattern). Then adjust the size of the picture by
pressing the M/m/</,button.
cAdjust the picture position.
Press the LENS ADJUSTMENT (SHIFT) button to
display the Lens Shift adjustment window (test
pattern). Then adjust to the proper position of the
picture by pressing the M/m/</,button.
To adjust the tilt of the installation surface
If the unit is installed on an uneven surface, use the front
feet (adjustable) to keep the unit level.
• If the unit is tilted up or down, the projected image may be
trapezoidal.
• Be careful not to catch your finger when turning the front feet
(adjustable).
Installing the Unit
Step 2
Note
Rear of the unit
Lights in red.
Front of the unit
Flashes in green
for tens of seconds
and then lights in
green.
Front of the unit
Notes
Front feet (adjustable)
Tur n to
adjust.

Installing the Unit 13GB
Lens adjustment window (test pattern)
1.78:1 (16:9)
2.35:1
1.85:1
1.33:1 (4:3)
The dashed lines show the screen sizes of each
aspect ratio.
For more information, refer to “Connections and Preparations” in
the Operating Instructions contained in the supplied CD-ROM.

Connecting the Unit
GB 14
When making connections, be sure to do the following:
• Turn off all equipment before making any connections.
• Use the proper cables for each connection.
• Insert the cable plugs properly; poor connection at the plugs may cause a malfunction or poor picture quality. When
pulling out a cable, be sure to pull it out from the plug, not the cable itself.
• Refer to the operating instructions of the connected equipment.
Connecting the Unit
When you monitor and control the projector via the network, access the Setup page of the projector (refer to “Using Network Features” in
the Operating Instructions) via a Web browser and enable the desired control protocol.
Step 3
Right side of the unit
Equipment with HDMI
output connectors
to HDMI
output
HDMI cable (not supplied)
Computer
: Video signal flow
AV amplifier Speakers
to HDMI input
Use a Premium High Speed HDMI cable on which the cable type logo is
specified.
For more information, refer to “Connections and Preparations” in
the Operating Instructions contained in the supplied CD-ROM.

Projecting 15GB
1Turn on both the unit and the equipment connected to
the unit.
2Press INPUT to display the input palette on the
screen.
3Select the equipment from which you want to display
images.
Press INPUT repeatedly or press M/m/ (enter) to
select the equipment from which to project.
1Press the ?/1(On/Standby) button.
The message “POWER OFF?” appears.
2Press the ?/1(On/Standby) button again before the
message disappears.
The ON/STANDBY indicator flashes in green and the
fan continues to run to reduce the internal heat.
The fan stops and the ON/STANDBY indicator
changes from flashing green to remaining red.
The power is turned off completely, and you can
disconnect the AC power cord.
Never disconnect the AC power cord while the indicator is flashing.
Tip
You can turn off the unit by holding the ?/1(On/Standby) button for
about 1 second, instead of performing the above steps.
Press one of the CALIBRATED PRESET buttons.
Projecting
Step 4
Projecting the Picture
Turning Off the Power
Note
Selecting the Picture Viewing Mode
Setting items Description
CINEMA FILM 1 Picture quality suited to reproducing the
highly dynamic and clear images typical of
master positive film.
CINEMA FILM 2 Picture quality suited to reproducing the rich
tone and color typical of a movie theater,
based on the “CINEMA FILM 1.”
REF A picture quality setup suitable for when you
want to reproduce faithfully the original
image quality, or for enjoying image quality,
without any adjustment.
TV Picture quality suited for watching TV
programs, sports, concerts, and other video
images.
PHOTO Ideal for projecting still images taken with a
digital camera.
GAME Picture quality suited to gaming, with well-
modulated colors and fast response.
BRT CINE Picture quality suited for watching movies in
a bright environment, such as a living room.
BRT TV Picture quality suited for watching TV
programs, sports, concerts, and other video
images in a bright environment, such as a
living room.
USER Adjusts the picture quality to suit your taste
then saves the setting. The factory default
setting is the same as “REF.”
CALIBRATED PRESET buttons
For more information, refer to “Projecting” in the Operating
Instructions contained in the supplied CD-ROM.

Error Handling
GB 16
The ON/STANDBY or WARNING indicator lights up or flashes if there is any trouble with your projector.
If there is any problem or an error message appears on the screen, refer to “Error Handling” in the Operating Instructions
contained in the supplied CD-ROM.
If the symptom persists even after carrying out the above methods, consult with qualified Sony personnel.
If the indicator starts flashing in a way of other than the above, turn off, and then turn on the power with the ?/1(On/Standby) button on the
remote control or control panel of the unit.
If the symptom is shown again, consult with qualified Sony personnel.
Error Handling
About Indicators
Flashing/Lighting indicators The number of
flashes Cause and Remedy
Three times The unit does not light properly due to an abnormality of the light source and light
source power. Turn off, then turn on the power after a while.
If the symptom persists, consult qualified Sony personnel.
Six times The unit detects a drop impact.
If there is abnormality on the unit, consult with qualified Sony personnel.
If there are no abnormalities on the unit, disconnect the AC power cord and check
that the ON/STANDBY indicator turns off, then connect the AC power cord and
turn the unit on.
Twice The internal temperature is unusually high. Check to ensure that nothing is blocking
the ventilation holes and the unit is not being used at high altitudes.
Three times The fan is broken. Consult with qualified Sony personnel.
Note
ON/STANDBY
indicator WARNING indicator
(Lights in red) (Flashes in red)
(Flashes in red)
Both indicators flash
(Flashes in red)
If there is any problem or an error message appears on the screen,
refer to “Error Handling” in the Operating Instructions contained
in the supplied CD-ROM.

À propos du Guide de référence rapide
FR 2
Ce Guide de référence rapide décrit l’installation et les procédures de base de projection des images.
Avant d’utiliser l’appareil, veuillez lire attentivement ce manuel et le conserver pour future référence.
Reportez-vous à « À propos des indicateurs », le cas échéant.
Pour plus d’informations sur l’utilisation, reportez-vous au Mode d’emploi que vous trouverez sur le CD-ROM fourni.
À propos du Guide de référence rapide
Préparation .............................................................. Page 8
Installation de l’appareile.................................... Page 9
Raccordement de l’appareil.............................. Page 11
Projection ............................................................... Page 12
Gestion des
erreurs À propos des indicateurs ........................................................ Page 13
Etape 1
Etape 2
Etape 3
Etape 4
Utilisation du manuel sur CD-ROM
Vous devez installer Adobe Reader sur votre ordinateur
pour pouvoir lire ce manuel.
Vous pouvez télécharger Adobe Reader gratuitement
depuis le site Web d’Adobe.
1Ouvrez le fichier index.html situé sur le CD-ROM.
2Sélectionnez le manuel que vous souhaitez lire, puis
cliquez sur ce dernier.
Si vous avez perdu ou endommagé le CD-ROM, vous pouvez
acheter un CD-ROM de remplacement auprès de votre représentant
Sony ou du service clientèle Sony.
Adobe et Adobe Reader sont des marques d’Adobe Systems
Incorporated aux États-Unis et/ou dans d’autres pays.
Remarque

AVERTISSEMENT 3FR
N’utilisez pas ce produit à des fins autres que celles
décrites dans le manuel d’instructions.
AVERTISSEMENT
Afin de réduire les risques d’incendie ou
d’électrocution, ne pas exposer cet appareil à la
pluie ou à l’humidité.
Afin d’écarter tout risque d’électrocution, garder
le coffret fermé. Ne confier l’entretien de
l’appareil qu’à un personnel qualifié.
AVERTISSEMENT
Cet appareil doit être relié à la terre.
AVERTISSEMENT
Lors de l’installation de l’appareil, incorporer un dispositif
de coupure dans le câblage fixe ou brancher la fiche
d’alimentation dans une prise murale facilement accessible
proche de l’appareil. En cas de problème lors du
fonctionnement de l’appareil, enclencher le dispositif de
coupure d’alimentation ou débrancher la fiche
d’alimentation.
ATTENTION
À propos du connecteur LAN
Par mesure de sécurité, ne raccordez pas le connecteur
pour le câblage de périphériques pouvant avoir une tension
excessive à ce port.
AVERTISSEMENT
1. Utilisez un cordon d’alimentation (câble secteur à 3
fils)/fiche femelle/fiche mâle avec des contacts de mise
à la terre conformes à la réglementation de sécurité
locale applicable.
2. Utilisez un cordon d’alimentation (câble secteur à 3
fils)/fiche femelle/fiche mâle avec des caractéristiques
nominales (tension, ampérage) appropriées.
Pour toute question sur l’utilisation du cordon
d’alimentation/fiche femelle/fiche mâle ci-dessus,
consultez un technicien du service après-vente qualifié.
ATTENTION
- Il y a danger d’explosion s’il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie
du même type ou d’un type équivalent recommandé par
le constructeur.
- Lors de la mise au rebut de la batterie ou du produit, vous
devez respecter la loi de la région ou du pays concerné.
Ne mettez pas la batterie ou le produit au rebut dans un
feu ou un four chaud, ou n’écrasez pas mécaniquement
la batterie et ne la coupez pas. Elle risque d’exploser ou
de provoquer un incendie. Ne soumettez pas la batterie à
une pression d’air extrêmement basse qui pourrait
entraîner une explosion ou une fuite de liquide ou de gaz
inflammable.
- Ne placez pas la batterie dans un endroit à température
élevée, tel qu’à la lumière directe du soleil ou à
proximité d’un feu. Elle risque de prendre feu,
d’exploser ou de provoquer un incendie. Ne plongez pas
et ne mouillez pas la batterie dans de l’eau douce ou de
l’eau de mer. Cela risque de provoquer une électrocution.
ATTENTION
La taille et le nombre de piles suivants sont requis pour la
télécommande.
• Taille : AA (R6)
• Nombre de pile(s) : deux pièces
Pour éviter tout risque d’explosion, utilisez uniquement le
type de pile suivant.
• Piles alcalines ou au manganèse
Déclaration d’exposition aux radiations:
Le produit est conforme aux limites d’exposition pour les
appareils portables RF pour les Etats-Unis et le Canada
établies pour un environnement non contrôlé. Le produit
est sûr pour un fonctionnement tel que décrit dans ce
manuel. La réduction aux expositions RF peut être
augmentée si l’appareil peut être conservé aussi loin que
possible du corps de l’utilisateur ou que le dispositif est
réglé sur la puissance de sortie la plus faible si une telle
fonction est disponible.
AVERTISSEMENT
Ne regardez pas dans l’objectif pendant son utilisation.
ATTENTION
L’emploi de commandes ou ajustements ou l’exécution de
procédures autres que celles spécifiées ici peut provoquer
une exposition dangereuse au rayonnement.
ATTENTION
L’emploi d’instruments optiques avec ce produit
augmentera les risques pour les yeux.
IEC 60825-1:2014
PRODUIT LASER DE CLASSE 1
Comme pour n’importe quelle source
de lumière vive, ne regardez pas
fixement le faisceau, RG2 IEC
62471-5:2015.
Français
FR

AVERTISSEMENT
FR 4
Informations sur l’emplacement des étiquettes
Spécifications de la source lumineuse
Diodes laser 3,75 W × 24
Longueur d’onde : 450 - 460 nm
Angle de divergence du faisceau par rapport à
l’objectif de cet appareil
Zoom maximum : α= 42,5 °
Zoom minimum : α= 21,3 °
Ne placez pas des objets juste devant l’objectif pour éviter
de bloquer la lumière durant la projection. La chaleur
provenant de la lumière risque de les endommager. Utilisez
la touche de masquage d’image pour couper l’image.
À propos des lunettes 3D
Les lunettes 3D affichent des signaux 3D en communicant
avec le projecteur via la technologie Bluetooth.
(a) bandes de fréquences utilisées par l’équipement
radioélectrique:
2.4 - 2.4835 GHz
(b) puissance de radiofréquence maximale transmise sur les
bandes de fréquences utilisées par l’équipement
radioélectrique:
4.30 dBm (E.I.R.P.)
Le soussigné, Sony Corporation, déclare que cet
équipement est conforme à la Directive 2014/53/UE.
Le texte complet de la déclaration UE de conformité est
disponible à l’adresse internet suivante :
http://www.compliance.sony.eu/
Pour les clients en Europe
Fabricant : Sony Corporation, 1-7-1 Konan Minato-ku
Tokyo, 108-0075 Japon
Pour toute question relative à la conformité des produits
dans l’UE : Sony Belgium, bijkantoor van Sony Europe
B.V., Da Vincilaan 7-D1, 1930 Zaventem, Belgique
ÉTIQUETTE (pour les technicien du service après-vente)
ÉTIQUETTE
D’OUVERTURE
ÉTIQUETTE DE CLASSE 3R + CLASSE 1
Port d’émission laser
Pour les clients au Canada
GARANTIE LIMITÉE DE SONY - Rendez-vous sur
http://www.sonybiz.ca/pro/lang/en/ca/article/resources-
warranty pour obtenir les informations importantes et
l’ensemble des termes et conditions de la garantie
limitée de Sony applicable à ce produit.
