Amada AMWS02 User manual
Webcam Stand
Instruction Manual V1.0
Model: AMWS02
Thank you for choosing this AMADA product! At AMADA we
strive to provide you with the best quality products and services
in the industry. Should you have any issues, please don't hesitate
Thank you again
for choosing this AMADA product!
Thank you for choosing this AMADA product! At AMADA we
strive to provide you with the best quality products and services
in the industry. Should you have any issues, please don't
Assembly Instruction
Step 1: Put the hollow ring 2set in the swivel head 8.
Step 2: Fix in the card slot 4on the top of the swivel head 8.
Step 3: Knob tightly the hollow ring 2up to the bottom of the card slot 4.
Step 4: Insert clasp 5into the card slot 4 , please try to find the best cut on
both sides if you install it for the first time.
Step 5: Insert the screw thread 3at the top of the card slot 4, and align
the hole.
Step 6: Put the fixation pin 6in the hole and knob to tighen it.
Step 7: Align the iron tube 7with the desk clamp 1and knob to tighten.
Step 8: According to the thickness of your table, turn knob with long screw to
proper position.
Step 5 Step 6
02
Product Features
1. Webcam Stand Length: Gooseneck arm can be extended to the max approx. 27 in.(68cm)
2. The max thickness 2 in.(5cm) of the clamp makes the webcam stand fit for the desk,
table, sideboard, bed.
3. It is only suitable for the webcam with standard 1/4in. screw thread hold. Before you
place your order, please make sure your webcam comes with this standard 1/4in. screw
hole. It is not suitable for the webcam without screw hold.
4. 360° swivel ball head allows your webcam to rotate to get different best angles.
Note: Recommend to mount the jaws flex clamp on a stable and non-moving object
rather than on something that vibrates, or it’s hard to maintain high quality picture
effects. Please do not use the webcam stand for heavy camera and devices.
Specifications:
Product Parts
Model: AMWS02
Color: Black
Main Material: Metal+plastic
Item Weight: Approx. 0.39kg
Item Length: Approx. 27 in.(68cm)
Max load weight: 0.5kg(1.1lb)
1
2
3
4
5
6
7
8
Desk Clamp
Hollow Ring
Screw Thread
Card Slot
Clasp
Fixation Pin
Iron Tube
Swivel Head
01
8
7
6
1
23
4 5
