Amana ACSS920402BN User manual

® Copyright 2014 Goodman Company, L.P.
RT6612029
August2014
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does
not assume any responsibility for property damage or personal injury due to improper service
procedures performed by an unqualified person.
*MSS92,*CSS92
34.5" SINGLE STAGE
MULTI-SPEED GAS FURNACE
UP TO 92%AFUE
•RefertoServiceManualRS6612012for installation, operation, and troubleshooting information.
•Allsafetyinformation must be followed asprovidedin the Service Manual.
•RefertotheappropriatePartsCatalogforpart number information.
•Models listed on page 3.
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUALAL
ALAL
AL
is a registered trademark of Maytag Corporation or its related companies
and is used under license to Goodman Company, L.P., Houston, TX, USA. All rights reserved.

PRODUCT IDENTIFICATION
2
The model and manufacturing number are used for positive identification of component parts used in manufacturing.
Pleaseusethesenumbers when requesting service orpartsinformation.
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed ONLY by indi-
viduals meeting the requirements of an "entry level tech-
nician",ataminimum, asspecified bythe Air-Conditioning,
Heating, and Refrigeration Institute (AHRI). Attempting to
install or repair this unit without such background may
result in product damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING WARNING
WARNING
* M S S 92 060 3 B N A A
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Brand Minor Revision
A- Amana® Brand G- Goodman® Brand A - Initial Release
B - 1st Revision
Configuration
M - Upflow/Horizontal Major Revision
C - Downflow/Horizontal A - Initial Release
K - Dedicated Upflow B - 1st Revision
D - Dedicated Downflow
Nox
Airflow N - Natural Gas
C - Variable Speed/ComfortNet X - Low Nox
E - High Efficiency
S - Single Speed Cabinet Width
A - 14"
Gas Valve Stages B - 17.5"
M - Modulating C - 21"
V - 2 Stage D - 24.5"
H - Convertible 2 Stage
S - Single Stage Max i mum CFM
3 - 1200 CFM
AFUE 4 - 1600 CFM
92 - 92% AFUE 5 - 2000 CFM
MBTU/h
040 - 40,000
060 - 60,000
080 - 80,000
100 - 100,000
120 - 120,000

3
PRODUCT IDENTIFICATION
Themodeland manufacturing number are used forpositiveidentificationofcomponentpartsusedin manufacturing. Please
usethesenumberswhenrequesting service or parts information.
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING
ACSS920402BN** GCSS920402BN**
ACSS920603BN** GCSS920603BN**
ACSS920804CN** GCSS920804CN**
ACSS921005CN** GCSS921005CN**
AMSS920402BN** GMSS920402BN**
AMSS920603BN** GMSS920603BN**
AMSS920803BN** GMSS920803BN**
AMSS920804CN** GMSS920804CN**
AMSS920805CN** GMSS920805CN**
AMSS921004CN** GMSS921004CN**
AMSS921005CN** GMSS921005CN**
AMSS921205DN** GMSS921205DN**
DANGER
0140M00020-D
CARBON MONOXIDE POISONING HAZARD
Special warning for installation of furnaces or air handling units in enclosed area such as garages, utility rooms or parking areas. Carbon monoxide producing
devices (such as automobile, space heater, gas water heater, etc.) Should not be operated in enclosed areas such as unventilated garages or utility rooms because
of the danger of carbon monoxide (CO) poisoning resulting from the exhaust emissions. If a furnace or air handler is installed in an enclosed area and a carbon
monoxide producing device is operated therein, there must be adequate direct outside ventilation. Carbon monoxide emissions can be (re)circulated throughout
the structure if the furnace or air handler is operating in any mode. CO can cause serious illness including permanent brain damage or death.
Avertissement special au sujet de l'installation d'appareils de chauffage ou de traitement d'air dans des endroits clos, tets les garages, les locaux d'entretien et les
RISQUE D'EMPOISONNEMENTAU MONOXYDE DE CARBONE
stationnements. Evitez de mettre en marche les appareils produisant du monoxyde de carbone (tels que les automobile, les appareils de chauffage autonome,etc.)
dans des endroits non ventilés tels que les d'empoisonnement au monoxyde de carbone. Si vous devez faire fonctionner ces appareils dans un endroit clos,
assures-vous qu'il y ait une ventilation directe provenant de l'exterie . Les émissions de monoxyde de carbone peuvent etre recircules dans les endroits clos,
si l'appareil de chauffage ou de traitement d'air sont en marche. Le monoxyde de carbone peut causer des maladies graves telles que des dommages permanents
au cerveau et meme la mort.
Advertencia especial para la instalación de calentadoresó maneja oras de aire en áreas cerradas como estacionamientos ó cuartos de servicio. Los equipos ó
RIESGO DE INTOXICACIÓN POR MONÓXIDO DE CARBONO
aparatos que producen monóxido de carbono (tal como automóvil, calentador de gas, calentador de agua por medio de gas, etc) no deben ser operados en
áreas cerradas debido al riesgo de envenenamiento por monóxido de carbono (CO) que resulta de las emisiones de gases de combustión. Si el equipo ó
aparato se opera en dichas áreas, debe existir una adecuada ventilac ón directa al exterior. Las emisiones de monóxido de carbono pueden circular a través
del aparato cuando se opera en cualquier modo. Elmonóxido de carbono puede causar enfermedades severas como daño cerebral permanente ó muerte.
‘
DANGER
PELIGRO

PRODUCT DIMENSIONS
4
*MSS92
C =If placed on combustible floor, the floor MUST be wood ONLY.
Horizonta l 6" 0" 3" C 0" 6"
Position Sides Rear Front Bottom Flue Top
Upfl ow 0" 0" 3" C 0" 1"
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIAL
5
9¼
19 ⅝
34 ½
¾
19½
⅞
¾
DIMB
DISCHARGE
23
2⅜
1⅞
2½
2
6½
C
5
9¼
19 ⅝
23
24 ⅞
31 ⅞
A
21 ⅛
2 ⅝
14
23
1½
1⅜
¾
28 ¾
2⅜
1⅞
2½
2
2¾
6½
1⅞
26 ½
23 ½
UNFOLDED FLANGES
22
FOLDED FLANGES
D
FOLDED FLANGES
E
UNFOLDED FLANGES
AIR
DISCHARGE
SIDE CUT-OUT SIDE CUT-OUT
AIR
DISCHARG E
LEFT SIDE VIEW FRONT VIEW RIGHT SIDE VIEW
CONDENSATE DRAIN
TRAP EXTERIOR
CONNECTION
(RIGHT OR LEFT SIDE)
¾ PVC
VENT/FLUE PIPE
2" PVC ALTERNATE
VENT/FLUE
LOCATION
RIGHT SIDE
DRAIN TRAP
EXTERIOR HOLES
HIGH VOLTAGE
ELECTRICAL OUTLET
ALTERNATE
GAS SUPPLY
LOW VOLTAGE
ELECTRICAL OUTLET
STANDARD
GAS SUPPLY
LOCATION
CENTER DIMPLE
FOR ALTERNATE
AIR INTAKE PIPE
3" OD HOLE
AIR INTAKE
2" PIPE
LEFT SIDE
DRAIN TRAP
EXTERIOR HOLES
HIGH VOLTAGE
ELECTRICAL OUTLET
LOW VOLTAGE
ELECTRICAL OUTLET
Model A B C D E
*MSS920402BN** 17-1/2" 16" 13-7/8" 12-1/8" 13-5/8"
*MSS920603BN** 17-1/2" 16" 13-7/8" 12-1/8" 13-5/8"
*MSS920803BN** 17-1/2" 16" 13-7/8" 12-1/8" 13-5/8"
*MSS920804CN** 21" 19-1/2" 17-3/8" 16" 17-1/2"
*MSS920805CN** 21" 19-1/2" 17-3/8" 16" 17-1/2"
*MSS921004CN** 21" 19-1/2" 17-3/8" 16" 17-1/2"
*MSS921005CN** 21" 19-1/2" 17-3/8" 16" 17-1/2"
*MSS921205DN** 24-1/2" 23" 20-3/8" 10-3/8" 20-7/8"

5
PRODUCT DIMENSIONS *CSS92
C =If placed on combustible floor, the floor MUST be wood ONLY.
NC = For installation on non-combustible floors only. Acombustible floor sub-base must be used for installations on combustible flooring.
Horizonta l 6" 0" 3" C 0" 6"
Position Sides Rear Front Bottom Flue Top
Downfl ow 0" 0" 3" NC 0" 1"
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIAL
Model A B C D E
*CSS920402BN** 17-1/2" 14-5/8" 14" 14-1/2" 16"
*CSS920603BN** 17-1/2" 14-5/8" 14" 14-1/2" 16"
*CSS920804CN** 21" 18-1/8" 17-1/2" 18" 19-1/2"
*CSS921005CN** 21" 18-1/8" 17-1/2" 18" 19-1/2"
A
34 ½
4⅛
11⅜
14¾
25⅛
28¾
C
6⅞6⅞
11⅜
14⅞
14¾
25⅛
3½
2½
2
1⅞
2⅝
23
14
1⅜
1½
1⅝
E
UNFOLDED
FLANGES
D
FOLDED FLANGES
18 ⅛
FOLDED FLANGES
20 ⅛
UNFOLDED FLANGS
2⅝
1 ⅞
2½
6½
2
AIR
DISCHARGE
SIDE CUT-OU T SIDE CUT-OU T
AIR
DISCHARGE
LEFT SIDE VIEW
FRONT VIEW
RIGHT SIDE VIEW
LOW VOLTAGE
ELECTRICAL OUTLET
ALTERNATE GAS
SUPPLY LOCATION
HIGH VOLTAG E
ELECTRICAL
OUTLET
STANDARD DRAIN TRAP
CONNECTION
¾ PVC
LEFT SIDE EXTERIOR
DRAIN TRAP HOLE S
ALTERNATE
GAS SUPPLY
LOCATIO N
ALTERNATE VENT/
FLUE LOCATION
HIGH VOLTAGE
ELECTRICAL
OUTLET
RIGHT SIDE EXTERIO R
DRAIN TRAP HOLES
LOW VOLTAGE
ELECTRICAL
OUTLET
RIGHT SIDE VIEW
TOP VIEW FRONT VIEW

FURNACE SPECIFICATIONS
6
*MSS92
*MSS92
0402BNA *MSS92 0603BNA *MSS92 0803BNA *MSS92 0804CNA *MSS92 0805CNA *MSS92 1004CNA *MSS92 1005CNA *MSS92 1205DNA
Heating Data
High Fire Input¹ 40,000 60,000 80,000 80,000 80,000 100,000 100,000 120,000
High Fire Output¹ 36,840 55,260 73,680 73,680 73,680 92,100 92,100 110,520
AFUE² 92 92 92 92 92 92 92 92
Temperature Rise Range (°F) 30 - 60 35 - 65 35 - 65 35 - 65 25 - 55 35 - 65 35 - 65 35 - 65
VentDiameter³ 2" -3" 2" -3" 2" - 3" 2" - 3" 2"- 3" 2"- 3" 2" - 3" 3"
No.ofBurners 23444556
Circulator Blower
Available AC @0.5"ESP 1.5 - 3 1.5 - 3 1.5 - 3 3 - 5 3 - 5 3 - 5 3 - 5 3 - 5
Size (D xW) 10"x8" 10"x8" 10"x8" 10"x10" 11"x10" 10"x10" 11"x10" 11"x11"
Horsepower @1075 RPM 1/3 1/3 1/3 1/2 3/4 1/2 3/4 3/4
Speed 44444444
Filter Size (in²)
Permanent 363 491 654 654 818 818 818 981
Disposable 182 245 327 327 409 409 409 491
Electrical Data
Min.CircuitAmpacity 9.6 9.6 9.6 11.7 13.7 11.7 13.7 13.7
Max. Overcurrent Device (amps) 15 15 15 15 15 15 15 15
Shipping Weight (lbs) 109 112 115 137 138 139 140 152
¹ Natural Gas BTU/h
² DOEAFUEbased upon Isolated Combustion System(ICS)
Notes
• All furnaces are manufactured for use on 115 VAC, 60 Hz, single-phase electrical supply.
• Gas Service Connection ½" FPT
• For bottomreturn: Failure to unfold flanges may reduce airflow by up to 18%. This could result in performance and noise issues.
³ Installer must supply one or two PVCpipes: one for combustion air (optional) and one for the flue outlet (required). Vent pipe must be either
2" or 3" in diameter, depending upon furnace input, number of elbows, length of run and installation (1 or 2 pipes). The optional Combustion
Air Pipe is dependent on installation/code requirements and must be 2" or 3" diameter PVC.
?
MinimumCircuit Ampacity = (1.25 x Circulator Blow er Amps) + ID Blower amps. Wire size should be determined in accordance with
National Electrical Codes. Extensive wire runs will require larger w ire sizes.
?
MaximumOvercurrent Protection Device refers to maximumrecommended fuse or circuit breaker size. May use fuses or HACR-type circuit
breakers of the same size as noted.
• For servicing or cleaning, a 24" front clearance is required. Unit connections (electrical, flue and drain) may necessitate greater clearances
than the minimumclearances listed above. In all cases, accessibility clearance must take precedencee over clearances fromthe enclosure
where accessibility clearances are greater.
• Important: Size fuses and w ires properly and make electrical connection in accordance with the National Electrical Code and/or all existing
localcodes.

FURNACE SPECIFICATIONS
7
*CSS92
*CSS92
0402BNA *CSS92 0603BNA *CSS92 0804CNA *CSS92 1005CNA
Heating Data 40,000 60,000 80,000 100,000
High Fire Input¹
High Fire Output¹ 36,840 55,260 73,680 92,100
AFUE² 92 92 92 92
Temperature Rise Range (°F) 30 - 60 35 - 65 35 - 65 35 - 65
VentDiameter³ 2"- 3" 2"- 3" 2" - 3" 2" - 3"
No.ofBurners 2 3 4 5
Circulator Blower 2.5 - 4 2.5 - 4
Available AC @ 0.5" ESP 1.5 - 3 1.5 - 3
Size (D x W) 10" x 8" 10" x 8" 10" x 10" 11" x 10"
Horsepower@1075 RPM 1/3 1/3 1/2 ¾
Speed 4 4 4 4
Filter Size (in²) 363 491 654 818
Permanent
Disposable 182 245 327 409
Electrical Data 9.6 9.6 11.7 13.7
Min. Circuit Ampacity
Max. Overcurrent Device (amps) 15 15 15 15
Shipping Weight (lbs) 109 112 137 140
¹ Natural Gas BTU/h
² DOEAFUEbased upon Isolated Combustion System (ICS)
Notes
• All furnaces are manufactured for use on 115 VAC, 60 Hz, single-phase electrical supply.
• Gas Service Connection ½" FPT
• For bottomreturn: Failure to unfold flanges may reduce airflow by up to 18%. This could result in performance and noise issues.
³ Installer must supply one or tw o PVC pipes: one for combustion air (optional) and one for the flue outlet (required). Vent pipe must be either
2" or 3" in diameter, depending upon furnace input, number of elbows, length of run and installation (1 or 2 pipes). The optional Combustion
Air Pipe is dependent on installation/code requirements and must be 2" or 3" diameter PVC.
?
MinimumCircuit Ampacity = (1.25 x Circulator Blow er Amps) + ID Blower amps. Wire size should be determined in accordance with
National Electrical Codes. Extensive wire runs will require larger wire sizes.
?
MaximumOvercurrent Protection Device refers to maximumrecommended fuse or circuit breaker size. May use fuses or HACR-type circuit
breakers of the same size as noted.
• Important: Size fuses and w ires properly and make electrical connection in accordance with the National Electrical Code and/or all existing
localcodes.
• For servicing or cleaning, a 24" front clearance is required. Unit connections (electrical, flue and drain) may necessitate greater clearances
than the minimumclearances listed above. In all cases, accessibility clearance must take precedencee over clearances fromthe enclosure
where accessibility clearances are greater.

AIRFLOW DATA *MSS92
0.6 0.7 0.8
CFM Rise CFM Rise CFM Rise CFM Rise CFM Rise CFM CFM CFM
High 3 1,498 N/A 1,446 N/A 1,368 N/A 1,302 N/A 1,227 N/A 1,145 1,059 954
Med 2.5 1,223 N/A 1,182 N/A 1,153 30 1,099 31 1,051 32 982 901 813
Med-Lo 2 983 35 971 35 945 36 919 37 878 39 813 746 659
Low 1.5 816 42 794 43 758 45 734 46 678 50 637 597 523
High 3 1,494 N/A 1,428 36 1,362 38 1,294 39 1,231 42 1,162 1,076 972
Med 2.5 1,203 42 1,178 43 1,147 45 1,101 46 1,045 49 986 927 831
Med-Lo 2 977 52 965 53 939 54 904 57 866 59 801 763 639
Low 1.5 801 64 786 65 751 N/A 714 N/A 714 N/A 680 635 596
High 3 1,459 47 1,397 49 1,339 51 1,270 54 1,202 57 1,107 1,049 952
Med 2.5 1,191 57 1,166 58 1,137 60 1,086 63 1,033 N/A 973 889 797
Med-Lo 2 985 N/A 967 N/A 932 N/A 900 N/A 859 N/A 805 731 620
Low 1.5 808 N/A 785 N/A 758 N/A 726 N/A 679 N/A 629 590 513
High 5 2,115 N/A 2,050 N/A 1,973 35 1,915 36 1,810 38 1,695 1,587 1,467
Med 4 1,802 38 1,739 39 1,725 40 1,665 41 1,612 42 1,532 1,443 1,320
Med-Lo 3.5 1,517 45 1,509 45 1,496 46 1,475 46 1,441 47 1,388 1,304 1,205
Low 3 1,213 56 1,225 56 1,216 56 1,194 57 1,179 58 1,135 1,084 1,005
High 5 2,284 30 2,231 31 2,170 31 2,103 32 2,037 33 1,945 1,836 1,750
Med 4 1,865 37 1,869 36 1,775 38 1,732 39 1,684 40 1,619 1,548 1,480
Med-Lo 3.5 1,594 43 1,571 43 1,530 45 1,492 46 1,454 47 1,414 1,355 1,293
Low 3 1,411 48 1,366 50 1,325 51 1,296 53 1,251 54 1,200 1,147 1,096
High 5 2,082 41 1,997 43 1,943 44 1,847 46 1,749 49 1,669 1,560 1,443
Med 4 1,823 47 1,782 48 1,711 50 1,659 51 1,574 54 1,513 1,402 1,305
Med-Lo 3.5 1,565 54 1,545 55 1,529 56 1,487 57 1,441 59 1,365 1,287 1,196
Low 3 1,261 N/A 1237 N/A 1,242 N/A 1,216 N/A 1,179 N/A 1,145 1,098 1,034
High 5 2,137 40 2,073 41 2,031 42 1,949 44 1,879 45 1,811 1,734 1,625
Med 4 1,793 48 1,754 49 1,704 50 1,648 52 1,590 54 1,534 1,451 1,371
Med-Lo 3.5 1,558 55 1,518 56 1,477 58 1,425 60 1,376 62 1,316 1,242 1,170
Low 3 1,370 62 1,325 64 1,288 N/A 1,237 N/A 1,191 N/A 1,134 1,086 1,024
High 5 2,256 45 2,192 47 2,133 48 2,054 50 1,986 51 1,907 1,834 1,718
Med 4 1,805 57 1,762 58 1,722 59 1,677 61 1,618 63 1,563 1,507 1,441
Med-Lo 3.5 1,565 65 1,513 N/A 1,480 N/A 1,415 N/A 1,392 N/A 1,346 1,269 1,198
Low 3 1,368 N/A 1,326 N/A 1,278 N/A 1,238 N/A 1,208 N/A 1,165 1,093 1,052
¹ at 0.5" ESP
Notes
• All furnaces ship as high-speed cooling and medium-speed heating. Installer must adjust blower cooling & heating speed as needed.
• For most jobs, about 400 CFMper ton when cooling is desirable.
• CFMin chart is without filter(s). Filters do not ship w ith this furnace, but must be provided by the installer. If the
*MSS92
0402BNA
*MSS92
0603BNA
*MSS92
0803BNA
*MSS92
0804CNA
*MSS92
0805CNA
*MSS92
1004CNA
*MSS92
1005CNA
*MSS92
1205DNA
0.4 0.5
(CFM & Temperature Rise vs. External Static Pressure)
• The above chart is for U.S. furnaces installed at 0-2000 feet. At higher altitudes, a properly derated unit will have
approximately the same temperature rise at a particular CFM, w hile ESPat the CFMw ill be lower.
• INSTALLATION IS TO BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE.
• This chart is for information only. For satisfactory operation, external static pressure should not exceed value shown on the
rating plate.
Motor
Speed Tons AC¹ 0.1 0.2 0.3Model ExternalStatic Pressure,(Inches Water Column)

AIRFLOW DATA
9
*CSS92
0.6 0.7 0.8
CFM Rise CFM Rise CFM Rise CFM Rise CFM Rise CFM CFM CFM
High 3 1,400 N/A 1,331 N/A 1,263 N/A 1,189 N/A 1,106 31 1,020 941 843
Med 2.5 1,204 N/A 1,176 N/A 1,121 30 1,072 32 1,002 34 927 853 740
Med-Lo 2 1020 33 998 34 968 35 923 37 880 39 820 739 652
Low 1.5 841 41 827 41 797 43 766 44 727 47 680 634 556
High 3 1,668 31 1,335 38 1,288 40 1,207 42 1,133 45 1,061 955 845
Med 2.5 1,224 42 1,182 43 1,139 45 1,088 47 1,015 50 948 859 759
Med-Lo 2 1030 50 1005 51 988 52 942 54 893 57 830 751 666
Low 1.5 859 60 830 62 815 63 789 65 751 N/A 693 629 556
High 4 1,770 39 1,645 41 1,610 42 1,528 45 1,437 47 1,340 1,251 1,141
Med 3.5 1,690 40 1,615 42 1,531 45 1,470 46 1,393 49 1,308 1,196 1,099
Med-Lo 3.0 1,612 42 1,540 44 1,472 46 1,398 49 1,306 52 1,223 1,132 1,010
Low 2.5 1,396 49 1,339 51 1,304 52 1,250 55 1,170 58 1,092 1,010 906
High 4 1,793 48 1,699 50 1,610 53 1,533 56 1,461 58 1,363 1,247 1,146
Med 3.5 1,693 50 1,622 53 1,552 55 1,467 58 1,390 61 1,320 1,205 1,083
Med-Lo 3.0 1,632 52 1,546 55 1,493 57 1,415 60 1,332 64 1,257 1,148 1,054
Low 2.5 1,429 60 1,380 62 1,334 64 1,258 N/A 1,199 N/A 1,136 1,041 942
¹ at 0.5" ESP
Notes
• All furnaces ship as high-speed cooling and medium-speed heating. Installer must adjust blower cooling & heating speed as needed.
• For most jobs, about 400 CFMper ton when cooling is desirable.
*CSS92
1005CNA
• CFMin chart is without filter(s). Filters do not ship w ith this furnace, but must be provided by the installer. If the
furnace requires two return filters,
• INSTALLATION IS TO BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE.
• This chart is for information only. For satisfactory operation, external static pressure should not exceed value shown on the
ti l t
• The above chart is for U.S. furnaces installed at 0-2000 feet. At higher altitudes, a properly derated unit will have
approximately the same temperature rise at a particular CFM, w hile ESPat the CFMwill be low er.
*CSS92
0402BNA
*CSS92
0603BNA
*CSS92
0804CNA
(CFM & Temperature Rise vs. External Static Pressure)
Model Motor
Speed Tons AC¹ External Static Pressure, (Inches Water Column)
0.10.20.30.40.5

HIGH VOLTAGE!
DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS
UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO
DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
10
WIRING DIAGRAMS
Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
*MSS92/*CSS92
