CONTROL PANEL PARTS
1
For Models: AMV3204VAB0, AMV3204VAQ0, AMV3204VAS0
(Black) (White) (Stainless)
Microwave Oven/Hood
2.0 Cu. Ft.
Illus. Part
No. No. DESCRIPTION
1 Literature
W10208077 U & C Guide
W10221334 Tech Sheet, Slim
W10217364 Cook Guide Label
W10238252 Install,Instruct.
2 Panel Asy, Control
Includes Lens and
Membrane Switch
W10250308 White
W10250307 Black
W10250309 Stainless
3
W10245199 Bracket, Control
4
W10250306 Microcomputer
12−10 Litho in U.S.A. (MP) (psw) Part No. W10250880 Rev. C

DOOR PARTS
2
For Models: AMV3204VAB0, AMV3204VAQ0, AMV3204VAS0
(Black) (White) (Stainless)
W10250880
Illus. Part
No. No. DESCRIPTION
1 COMPLETE DOOR
W10250311 White
W10250310 Black
W10250312 Stainless
2 Handle
W10212410 White
W10212411 Black
W10212412 Stainless
3
W10138802 Screw

INTERIOR AND VENTILATION PARTS
3
For Models: AMV3204VAB0, AMV3204VAQ0, AMV3204VAS0
(Black) (White) (Stainless)
W10250880

INTERIOR AND VENTILATION PARTS
4
For Models: AMV3204VAB0, AMV3204VAQ0, AMV3204VAS0
(Black) (White) (Stainless)
W10250880
Illus. Part
No. No. DESCRIPTION
1 W10245184 Chassis
2 8206232 Lamp
3
W10210871 Holder, Lamp
4
W10208631 Filter, Grease
5
W10245196 Plate, Bottom
6
W10210875 Glass, Lamp
7
W10210873 Holder, Glass
8
W10211972 Switch, Micro
V15T16−CZ200
9
W10211973 Switch, Micro
V15T16−CC200
10
W10156812 Spring, Interlock
11
W10156811 Plate, Cam
12 Support, Interlock
8206419 Top
W10156813 Bottom
13
W10197758 Piston Assembly
14
W10245191 Capacitor, 125 V
15
W10163422 Thermistor (PCBA)
16
W10245193 Plate, Side
17
W10245189 Chassis Assembly
18
W10245190 Resistor, Cement
19
W10211974 Switch, Micro
V15T16−CP200
20
W10250232 Holder, Fuse
21
W10138793 Fuse
22
W10245195 Thermostat
23
W10245185 Transformer, H.V.
24
W10156817 Bracket, Capacitor
25
W10138798 Capacitor, H.V.
26
W10245187 Diode, H.V.
27
W10245188 HV Diode Support

AIR FLOW PARTS
5
For Models: AMV3204VAB0, AMV3204VAQ0, AMV3204VAS0
(Black) (White) (Stainless)
W10250880
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10245181 Deflector, Air
2 8206382 Cover, Lamp
3
W10245178 Sensor, Humidity
4 4393681 Lamp
5
W10245192 Cover, Side Inlet
6
W10245205 Motor, Fan Assy
7
W10245179 Support, Sensor
8 8206230 Filter, Charcoal
9
W10110862 Mounting, Nut
10
W10245210 Air Guide,Plate
11 8206624 Filter
12
W10210878 Holder, Lamp
13
W10245211 Base Plate,
Air Guide
14
W10245206 Holder
15
W10245186 Brkt−Mntg,Filter
16
W10139750 Socket, Motor Wire
17
W10245214 Cover, Inlet
Air Cavity Guide
18
W10245183 Magnetron
19 8206342 Thermostat
20
W10164716 Plate, Water Proof
21
W10245182 Cover, Right Duct
22
W10245212 Cavity Lamp Foil
23
W10245215 Sealing Plate

TURNTABLE PARTS
6
For Models: AMV3204VAB0, AMV3204VAQ0, AMV3204VAS0
(Black) (White) (Stainless)
W10250880
Illus. Part
No. No. DESCRIPTION
1 W10245224 Cover, Inlet
Includes Nails
and Bushings
2
W10245207 Hook Front
3
W10245208 Hook Left Rear
4
W10245209 Hook Right Rear
5
W10138801 Plastic Rivets
6 4393799 Turntable
7 8206227 Ring, Turntable
8 8206228 Driver, Turntable
9
W10210848 Motor, Turntable
10 8205042 Rack
11
W10107790 Washer
12 8206618 Screw
13 8184109 Seal, Waterproof

CABINET AND INSTALLATION PARTS
7
For Models: AMV3204VAB0, AMV3204VAQ0, AMV3204VAS0
(Black) (White) (Stainless)
W10250880
Illus. Part
No. No. DESCRIPTION
1 W10245177 Plate, Mounting
2 8206385 Support, Wire Clip
3 8206442 Damper Assembly
4 8206388 Cord, Power
5 Case, Outer
W10245176 Black
W10244765 White
6 Grille, Vent
W10212404 Black
W10212405 Stainless
W10212400 White
7
W10210832 Plate, Damper
Miscellaneous
8205948 Installation,
Hardware
W10190018 Template, Upper
8169704 Screw, Top Mountng
W10250237 Main Harness
8205696 Ground Wire Assy
W10107760 Grnd Wire, Filter
W10245226 Hdlmp/TT Wire Assy
