Amana NFW7200TW Parts list manual

Front Loading Washer
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
DRAIN SYSTEM OPTIONS
NFW7200T
Electrical: 120-volt, 60 Hz, 15-amp fuse or circuit
breaker. It is recommended that a separate circuit
serving only this appliance be provided. Do not use
an extension cord.
Water: Pressure of 20 to 120 p.s.i. (138 to 827 kPa)
is required.
Hot and cold water faucets must be within 4 ft
(1.2 m) of the back of the washer for inlet hoses.
NOTE: Inlet hoses are available in lengths up to
10 ft (3m) for faucets more than 4 ft (1.2 m) from
the washer.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. W10161756
09-11-08
The standpipe or laundry tub must be at least 18" (45.7 cm)
high and no higher than 96" (2.4 m). The standpipe must be
large enough to accept the outside diameter of the factory-
attached drain hose.
LOCATION CONSIDERATIONS
It is recommended that the washer never be installed in areas
where water may freeze since the washer will always maintain
some water in the water valve, pump and hose areas. This can
cause damage to belts, pump, hoses and other components.
Operating temperature should be above 60° F.
®
A. Overall height: 38" (96.5 cm)
B. Width: 27" (68.6 cm)
C. Depth with door open 90°: 49" (124.5 cm)
D. Depth: 28" (71.1 cm)
NOTE: The height of the washer from the floor is 38" (96.5 cm). This includes the
leveling leg screwed all the way in. The leg can be unscrewed an additional 7/8" (2.2 cm)
for a total overall height of 38-7/8" (98.7 cm).
Alcove or closet installation:
Minimum clearances for closet and alcove installations:
Sides 0" (0 cm) Rear 2-3/8" (6.0 cm)
Top 0" (0 cm) Closet front 2" (5.1 cm)
The closet front must have a total unobstructed air opening of
72"2(465 cm2) minimum, if both washer and dryer are installed
together. A louvered door with equivalent air opening is
acceptable. Washer alone does not require specific air opening.
