Amana W10656455A User manual

W10656455A
W10656456A - SP
If you have any problems or questions, visit us at www.amana.com
Designed to use only HE
High Efciency detergents.
Conçue pour l’utilisation
d’un détergent haute
efcacité seulement.
Use & Care Guide
Guide d’utilisation et d’entretien
Para obtener acceso al
Manual de uso y
cuidado en español, o para
obtener información adicional
acerca de su producto, visite:
www.amana.com
Front-Loading Automatic Washer
Laveuse automatique à chargement frontal

2
Washer Safety
Table of Contents
WASHER SAFETY...................................................................2
ACCESSORIES .......................................................................3
CONTROL PANEL AND FEATURES ......................................4
USING THE DISPENSER DRAWER .......................................5
CYCLE GUIDE ........................................................................6
USING YOUR WASHER .........................................................7
WASHER MAINTENANCE ...................................................10
TROUBLESHOOTING ..........................................................13
WARRANTY...........................................................................20
ASSISTANCE OR SERVICE .................................Back Cover
Table de matières
SÉCURITÉ DE LA LAVEUSE ................................................21
ACCESSOIRES .....................................................................22
TABLEAU DE COMMANDE ET CARACTÉRISTIQUES ......22
UTILISATION DU TIROIR DU DISTRIBUTEUR ...................24
GUIDE DES PROGRAMMES................................................25
UTILISATION DE LA LAVEUSE ............................................27
ENTRETIEN DE LA LAVEUSE ..............................................31
DÉPANNAGE .........................................................................34
GARANTIE ............................................................................43
ASSISTANCE OU SERVICE ..................... Couverture arrière

3
Accessories
Customize your new washer and dryer with the following
genuine Whirlpool accessories. For more information on
options and ordering, call 1-866-616-2664, or visit us at:
www.amana.com/help. In Canada, call 1-866-587-2002
or visit us at www.amana.com/help.
Stack Kit
If space is at a premium, the stack kit
allows the dryer to be installed on top
of the washer.
15" Pedestal
Color-matched pedestals raise the
washer and dryer to a more comfortable
working height. The large drawer
provides convenient storage.

4
Control Panel and Features
NOTE: The control panel features a sensitive surface that responds to a light touch of your nger. To ensure your selections are
registered, touch the control panel with your nger tip, not your ngernail. When selecting a setting or option, simply touch its name.
Cycle Status Lights
Delay Wash – If a Delay Wash is set, the Delay Wash
indicator will light and the delay time will count down
in the display.
Door Locked – Door Locked will light to indicate that
the door is locked and cannot be opened without rst
pausing or canceling the cycle.
Add Garment – When “Add Garment” is lit, you may
pause the washer, open the door, and add items. Touch
and hold START to start the washer again.
Done – Once the cycle is complete, this light will come
on. Remove the load promptly for best results.
Efciency Monitor – The Efciency Monitor allows you
to see how the settings you select affect your energy
savings. To use the Efciency Monitor, choose the best
cycle, temperature, spin speed, and options for the
fabrics being washed. The Efciency Monitor will rate
the water and energy use of those selections, from Good
to Best. You can then adjust the settings and options to
decrease the amount of energy used within that cycle.
Wash Temp
The recommended wash temperature is preset for each cycle.
You may also select a wash temperature based on the type
of fabric and soils being washed. For best results, follow the
garment label instructions. All wash temperatures feature a
cold rinse.
Spin
This washer automatically selects the spin speed based on
the cycle selected. Some preset speeds can be changed.
nFaster spin speeds mean shorter dry times, but may
increase wrinkling in your load.
nSlower spin speeds reduce wrinkling, but will leave
your load more damp.
3
4
2
1
5
6
POWER
Touch to turn the washer on and off. Touch to stop/cancel
a cycle at any time.
NOTE: Turning the Wash Cycle knob will also turn the
washer on and off.
WASH CYCLE KNOB
Turn the knob to select a cycle for your laundry load. An LED
will light up for the cycle selected.
NOTE: The Clean Washer with affresh®LED will ash when
the washer has run 30 wash cycles as a reminder to run the
Clean Washer with affresh® cycle.
See “Cycle Guide” for detailed descriptions of cycles.
START
Touch and hold until the light above START comes on to start
a cycle, or touch once while a cycle is in process to pause it.
If you want to add a garment, you can touch START when the
“Add Garment” LED is on.
DELAY WASH
Use +and –to delay the start of the wash cycle by up to
8 hours. To turn off Delay Wash, use +and –to set the delay
time to “0,” or touch POWER.
LED DISPLAY AND SETTINGS
When you select a cycle, its default settings will light up and
the Estimated Time Remaining will be displayed (for times
longer than 99 minutes, hours will be displayed, followed
by minutes). Factors such as load size, wash temperature,
and water pressure may affect the time shown in the display
during the cycle. Tightly packing garments, unbalanced loads,
or excessive suds may cause the washer to adjust the cycle
time, as well.
Touch the desired setting along the bottom of the display to
adjust. See “Cycle Guide” for available settings on each cycle.
Not all settings are available with all cycles.
1
2
3
4
5

5
7
High Efciency “HE” detergent compartment
This compartment holds liquid or powdered HE
detergent for your main wash cycle.
Liquid fabric softener compartment
Automatically dilutes and dispenses liquid fabric softener
at the optimum time in the cycle.
nUse only liquid fabric softener in this dispenser.
Liquid chlorine bleach compartment
Automatically dilutes and dispenses liquid chlorine
bleach at the optimum time during the rst rinse after the
wash cycle. This compartment cannot dilute powdered
bleach.
B
C
A
DISPENSER DRAWER
The dispenser drawer gives you the convenience of
automatically adding HE detergent, liquid chlorine bleach,
and liquid fabric softener to the wash load at the proper time.
See “Using the Dispenser Drawer” for information on using
the dispenser drawer.
B
A
HE detergent
Liquid fabric
softener
Chlorine bleach
7C
A
C
B
Adding HE detergent to dispenser
Powdered detergent:
Lift the selector to the high
position.
Liquid detergent:
Push down the selector to
the low position.
Pour a measured amount of HE
detergent into detergent compartment.
For powdered detergent, lift the selector
to the high position. For liquid detergent,
push down the selector to the low
position.
Do not overll; adding too much
detergent may cause detergent to be
dispensed into the washer too early.
Use only High Efciency
(HE) detergent.
IMPORTANT:
nDo not add single-dose laundry packet to dispenser
drawer.
nUse powdered detergent when using the Delay Wash
option. Liquid detergent may seep out before the wash
begins.
HE detergent
compartment
Using the Dispenser Drawer
1. Open the dispenser drawer.
2. Add laundry products as described in steps 4–6 in the “Using
Your Washer” section.
3. Slowly close the dispenser drawer. Make sure it is
completely closed.
NOTE: A small amount of water may remain in the dispensers
from the previous wash cycle. This is normal.
Selector
Selector
in high
position
Selector
in low
position
Use only High Efciency (HE) detergent.
Choosing the Right Detergent
Use only High Efciency detergents. The package will be marked
“HE” or “High Efciency.” Low-water washing creates excessive
sudsing with a non-HE detergent. Using non-HE detergent
will likely result in longer cycle times and reduced rinsing
performance. It may also result in component failure and, over
time, buildup of mold or mildew. HE detergents are low-sudsing
and quick-dispersing to produce the right amount of suds for
the best performance. They hold soil in suspension so it is not
re-deposited onto clean clothes. Follow the manufacturer’s
instructions to determine the amount of detergent to use.
OPTIONS
Touch to activate additional wash
options or additional features on the washer.
Control Lock
Touch and hold for 3 seconds to lock the controls
to avoid unwanted changes or operation. Touch and hold
3 seconds again to unlock. For each second CONTROL
LOCK is held down, the display will count down one
second: you will see “3,” then “2,” then “1.” You may still
touch START to pause the cycle, or touch POWER to turn
off the washer.
6

6
Cycle Guide
Settings and options shown in bold are default settings for that cycle. For best fabric care, choose the cycle, options, and settings
that best t the load being washed. Not all settings are available with each cycle, and some options cannot be used together.
NOTE: All wash temperature selections feature a cold rinse.
Normally soiled Normal Hot Fast Delay Wash This cycle combines medium-speed tumbling
cottons, linens, Warm Medium and a fast-speed spin. This cycle is designed
sheets, and mixed Cool Off to provide the most energy efciency.
garment loads Cold
Sturdy colorfast Heavy Hot Fast Delay Wash Fast-speed tumbling and a fast-speed nal
fabrics and heavily Duty Warm Medium spin help provide optimal cleaning and reduce
soiled garments Cool Slow drying times.
Cold Off
Wet load of clothes Drain N/A Fast Delay Wash Use Drain & Spin to remove excess water from
& Spin Medium the load. Spin speed can be set to a slower
Slow setting.
Off
No clothes in washer Clean Delay Wash Use this cycle every 30 washes to keep
Washer the inside of your washer fresh and clean.
with This cycle uses a higher water level. Use with
affresh®affresh® washer cleaner tablet or liquid chlorine
bleach to thoroughly clean the inside of your
washer. This cycle should not be interrupted.
See “Washer Care.”
IMPORTANT: Do not place garments or other
items in the washer during the Clean Washer
with affresh®cycle. Use this cycle with an empty
wash tub. See “Washer Care” in “Washer
Maintenance.”
Small loads of 2–4 Quick Hot Fast Delay Wash For small loads (2–4 items) needed quickly.
lightly soiled Warm Medium This cycle combines fast-speed tumbling,
garments Cool Slow a shortened wash time, and a fast-speed spin
Cold Off for reduced drying times.
Bright or darkly Cold Cold Fast Delay Wash This cycle uses a concentrated detergent
colored cottons, Medium solution along with cold water throughout
linens, casual and Off the cycle to gently lift out stains and care for
mixed loads fabrics.
Sheer fabrics, Delicates Hot Fast Delay Wash This cycle combines slow-speed tumbling and
lingerie, sweaters, Warm Medium slow-speed spin for gentle fabric care and
and lightly-soiled Cool Slow reduced wrinkling.
shirts, blouses, Cold Off
trousers, pants,
and skirts
Items to wash
using default
cycle settings: Cycle: Wash
Temperature: Spin
Speed: Available
Options: Cycle Details:
Load Size Recommendations
For best results, follow the load size recommendations noted for
each cycle.
Small load: Fill the washer drum with 3–4 items, not more
than 1/4 full.
Medium load: Fill the washer drum up to about 1/2 full.
Large load: Fill the washer drum up to about 3/4 full.
Extra-large load: Fill the washer drum, but make sure
clothes can tumble freely. For best results, avoid packing
tightly.

7
Using Your Washer
Sort items by recommended cycle, water temperature, and
colorfastness. Separate heavily soiled items from lightly soiled.
Separate delicate items from sturdy fabrics. Treat stains
promptly and check for colorfastness by testing stain remover
products on an inside seam.
IMPORTANT:
nEmpty pockets. Loose change, buttons, or any small object
can plug pumps and may require a service call.
nClose zippers, fasten hooks, tie strings and sashes, and
remove non-washable trim and ornaments.
nMend rips and tears to avoid further damage to items
during washing.
nTurn knits inside out to prevent pilling. Separate lint-takers
from lint-givers. Synthetics, knits, and corduroy fabrics will
pick up lint from towels, rugs, and chenille fabrics.
nDo not dry garments if stains remain after washing, because
heat can set stains into fabric.
nAlways read and follow fabric care labels and laundry
product instructions. Improper usage may cause damage
to your garments.
1. Sort and prepare your laundry
Place a load of sorted clothes loosely in the washer. Items
need to move freely for best cleaning and to reduce wrinkling
and tangling. Close the washer door by pushing it rmly until
the latch clicks.
nDepending on load type and cycle, the washer can be fully
loaded, but not tightly packed. Washer door should close
easily. See “Cycle Guide” for loading suggestions.
nMix large and small items and avoid washing single items.
Load evenly.
nWash small items in mesh garment bags. For multiple items,
use more than one bag and ll bags equally.
3. Load laundry into washer
First wash cycle without laundry
Before washing clothes for the rst time, if not completed
during the nal installation step, choose the QUICK cycle and
run it without clothes. Use only HE detergent. Use 1/2 the
manufacturer’s recommended amount for a medium-size load.
This initial cycle serves to ensure the interior is clean before
washing clothes.
2. Add laundry products (if desired)
Single-dose laundry packet, Oxi-type boosters, color-safe
bleach, or fabric softener crystals can be added to the drum
prior to adding laundry.
NOTE: Do not add clothes to washer drum prior to adding
laundry products. Always follow manufacturer’s instructions.

8
Add liquid chlorine bleach to the bleach compartment.
Do not overll, dilute, or use more than 2/3 cup (157 mL).
Do not use color-safe bleach or Oxi in the same cycle with
liquid chlorine bleach.
nAlways measure liquid chlorine bleach. Use a measuring
cup with a pour spout; do not guess.
nDo not ll beyond the “MAX” level. Overlling could cause
garment damage.
6. Add liquid chlorine bleach to dispenser
(if desired)
Pour a measured amount of liquid fabric softener into liquid
fabric softener compartment. Always follow manufacturer’s
directions for correct amount of fabric softener based on your
load size.
IMPORTANT: Do not overll, dilute, or use more than 1/4 cup
(60 mL) of fabric softener. Do not ll past the MAX line.
Overlling dispenser will cause fabric softener to immediately
dispense into washer.
nDo not spill or drip any fabric softener onto the clothes.
nDo not use liquid fabric softener dispenser balls in this
washer. They will not dispense correctly.
5. Add liquid fabric softener to dispenser
(if desired)
Adjust the selector, based on type of HE detergent used
(either liquid or powdered). See “Using the Dispenser
Drawer” instructions on how to use the dispenser.
7. Touch POWER to turn on washer
(optional)
Slowly close the dispenser drawer. Make sure the drawer is
closed completely, then touch POWER to turn on the washer
or go to Step 8.
USING LAUNDRY PRODUCT DISPENSERS
NOTE: Do not add single-dose laundry packets, Oxi-type
boosters, color-safe bleach, or fabric softener crystals to
dispensers. They will not dispense correctly.
4. Add HE detergent
Powdered
HE detergent
Liquid
HE detergent
8. Select CYCLE*
Turn cycle knob to select your wash cycle. See “Cycle Guide”
for details on cycle features.
Using Your Washer
* Not all options and settings are available with all cycles.
See “Cycle Guide” for available options and settings.

9
The display will show the default settings for the selected
cycle. To adjust a setting, touch its name – Wash Temp or Spin.
Adjusting settings will change the Estimated Time Remaining.
Tightly packing the load, unbalanced loads, or excessive suds
may also cause the washer to increase the cycle time.
9. Adjust settings, if desired*
*Not all options and settings are available with all cycles.
See “Cycle Guide” for available options and settings.
10. Setting a delayed wash
If you do not want to begin a cycle immediately, you may
choose the DELAY WASH option. This will delay the start
of the wash cycle by up to 8 hours.
To set a delayed wash:
1. Touch DELAY WASH +and –buttons to set the desired
delay time.
2. Touch and hold START to set the delay. The delay
countdown has started when the START light stops blinking.
11. Touch and hold START to begin
wash cycle
Unlocking the door to add garments:
If you need to open the door to add 1 or 2
missed garments, you may do so while the
“Add Garment” light is lit.
Touch START once; the door will unlock once
the washer movement has stopped. This may
take several minutes. Then close door and touch
and hold START again to restart the cycle.
12. Remove garments promptly
after cycle is nished
Promptly remove garments after cycle has
completed to avoid odor and rusting of
metal objects on garments. When unloading
garments, pull back the door seal and check
for small items between the tub and the washer drum.
NOTES:
n
A small amount of water may remain in the dispensers after
the wash cycle is complete. This is normal.
n This washer has a tight seal to avoid water leaks. To avoid
odors, leave the door open to allow the washer to dry
between uses.
Touch and hold START to start the wash cycle. To pause a
cycle in progress, touch START once, then touch and hold
again to continue the cycle. To cancel a cycle, touch POWER.
Once you touch and hold START, you will hear the door lock,
unlock, and lock again. The washer door will remain locked
during the wash cycle.

10
WASHER CARE
Recommendations to Help Keep Your Washer Clean
and Performing at its Best
1. Always use High Efciency (HE) detergents and follow the
HE detergent manufacturer’s instructions regarding the
amount of HE detergent to use. Never use more than the
recommended amount because that may increase the
rate at which detergent and soil residue accumulate inside
your washer, which in turn may result in undesirable odor.
2. Use warm or hot water washes sometimes (not exclusively
cold water washes), because they do a better job of
controlling the rate at which soils and detergent accumulate.
3. Always leave the washer door slightly ajar between uses
to help dry out the washer and avoid the buildup of odor-
causing residue.
4. Periodically clean residue from the underside of the glass
window.
Cleaning Your Front Loading Washer
Read these instructions completely before beginning the
routine cleaning processes recommended below. This
Washer Maintenance Procedure should be performed,
at a minimum, once per month or every 30 wash cycles,
whichever occurs sooner, to control the rate at which soils
and detergent may otherwise accumulate in your washer.
Cleaning the Door Seal
1. Open the washer door and remove any clothing or items
from the washer.
2. Inspect the colored seal between the door opening and
the drum for stained areas or soil buildup. Pull back the
seal to inspect all areas under the seal and to check for
foreign objects.
3. If stained areas or soil buildup are found, wipe down
these areas of the seal using either of the following
two procedures:
a. affresh®Grit Grabber™ Cloth Procedure:
i. When the cycle is complete, gently pull back the
rubber door seal and clean the entire surface with
the rough side of the Grit Grabber™ cloth.
b. Dilute Liquid Chlorine Bleach Procedure:
i. Mix a dilute bleach solution, using 3/4 cup (177 mL)
of liquid chlorine bleach and 1 gallon (3.8 L) of warm
tap water.
ii. Wipe the seal area with the dilute solution, using
a damp cloth.
iii. Let stand 5 minutes.
iv. Wipe down area thoroughly with a dry cloth and let
washer interior air dry with door open.
IMPORTANT:
nWear rubber gloves when cleaning with bleach.
nRefer to the bleach manufacturer’s instructions
for proper use.
WASHER CARE (cont.)
Cleaning the Inside of the Washer
This washer has a special cycle that uses higher water
volumes in combination with affresh®Washer Cleaner or
liquid chlorine bleach to thoroughly clean the inside of the
washer. Steam washer models also utilize steam to enhance
cleaning in this special cycle.
NOTE: Read these instructions completely before beginning
the cleaning process.
Begin procedure
1. Clean Washer with affresh®Cycle Procedure
(Recommended for Best Performance):
a. Open the washer door and remove any clothing
or items.
b. Add an affresh®Washer Cleaner tablet to the washer
drum.
c. Do not add the affresh®Washer Cleaner tablet
to the dispenser drawer.
d. Do not add any detergent or other chemical to the
washer when following this procedure.
e. Close the washer door.
f. Select the Clean Washer with affresh®cycle.
g. On some models: Select the Fan Fresh™/Tumble
Fresh™option to help dry the washer interior after the
cycle is complete. NOTE: The washer remembers your
last option selection and will use it for future wash
cycles until you deselect that option. While the fan is
on, the washer door will lock. To unlock the door, touch
POWER.
h. Touch and hold START to begin the cycle. The Clean
Washer with affresh®Cycle Operation is described
below.
2. Chlorine Bleach Procedure:
a. Open the washer door and remove any clothing
or items.
b. Open the dispenser drawer and add liquid chlorine
bleach to the MAX level in both the bleach
compartment and the fabric softener compartment.
Either traditional or HE chlorine bleach can be used.
NOTE: Use of more liquid chlorine bleach than is
recommended above could cause washer damage
over time.
c. Close the washer door and the dispenser drawer.
d. Do not add any detergent or other chemicals to the
washer when following this procedure.
e. Close the washer door.
f. Select the Clean Washer with affresh®cycle.
g. On some models: Select the Fan Fresh™/Tumble
Fresh™option to help dry the washer interior after the
cycle is complete. NOTE: The washer remembers your
last option selection and will use it for future wash
cycles until you deselect that option. While the fan is
on, the washer door will lock. To unlock the door, touch
POWER.
h. Touch and hold START to begin the cycle. The Clean
Washer with affresh®Cycle Operation is described
below.
NOTE: For best results, do not interrupt cycle.
Washer Maintenance
Replace inlet hoses after 5 years of use to reduce the risk
of hose failure. Periodically inspect and replace inlet hoses
if bulges, kinks, cuts, wear, or leaks are found.
When replacing your inlet hoses, mark the date of
replacement on the label with a permanent marker.
WATER INLET HOSES

11
WASHER CARE (cont.)
Description of Clean Washer with affresh®Cycle
Operation:
1. The Clean Washer with affresh®cycle will determine
whether clothing or other items are in the washer.
2. If no items are detected in the washer, it will proceed
with the cycle.
a. If any items are detected in the washer, “rL” (remove
load) will be displayed. The door will unlock. Open
washer and remove any garments from the washer
drum.
b. Touch POWER to clear the “rL” code.
c. Touch and hold START to restart the cycle.
3. Steam models only: During the rst 20 minutes of the
cycle, it will activate the steamer but the drum will not spin
or ll with water. You may see condensation on the door
glass during this initial phase. If you are using an affresh®
Washer Cleaner tablet, it will not dissolve completely
during the steam phase. This is normal.
After the cycle is complete, leave the door open slightly to
allow for better ventilation and drying of the washer interior.
Cleaning the Dispensers
After a period of using your washer, you may nd some
residue buildup in the washer’s dispensers. To remove
residue from the dispensers, remove the drawer and wipe
the surfaces with a damp cloth and towel dry either before
or after you run the Clean Washer with affresh®cycle. Use an
all-purpose surface cleaner, if needed.
IMPORTANT: Dispenser is not dishwasher safe.
Cleaning the Outside of the Washer
Use a soft, damp cloth or sponge to wipe up any spills.
Occasionally wipe the outside of your washer to help
keep it looking new. Use mild soap and water.
IMPORTANT: To avoid damaging the washer’s nish, do not
use abrasive products.
REMOVING THE DISPENSER
To remove:
1. Pull dispenser drawer out until it stops.
2. Press down on the release tab and pull straight out to
remove the dispenser.
3. Lift off cover panel by
pulling straight up.
To replace:
1. Slide cover panel back onto
posts on dispenser.
2. Align edges of dispenser
with guides in washer,
then slide dispenser
back into slot.
CLEAN WASHER CYCLE REMINDER
NOTE: Not all models have the Clean Washer with affresh®
cycle reminder light.
The Clean Washer with affresh®LED will
ash at the end of a wash cycle when
the washer has run 30 wash cycles.
This is a reminder to run the Clean
Washer with affresh®cycle.
If the Clean Washer with affresh®cycle is not turned on, the
LED will stop ashing at the end of a wash cycle after running
3 more regular wash cycles. After 30 more wash cycles are
completed, the Clean Washer with affresh®LED will again
ash at the end of a wash cycle as a reminder.

12
Operate your washer only when you are home. If moving,
or not using your washer for a period of time, follow these
steps:
1. Unplug or disconnect power to washer.
2. Turn off water supply to washer to avoid ooding due
to water pressure surges.
3. Clean the dispensers. See “Cleaning the Dispensers.”
WINTER STORAGE CARE
IMPORTANT: To avoid damage, install and store washer
where it will not freeze. Because some water may stay in
hoses, freezing can damage washer. If storing or moving
during freezing weather, winterize your washer.
To winterize washer:
1. Shut off both water faucets, disconnect and drain water
inlet hoses.
2. Put 1 qt. (1 L) of R.V.-type antifreeze in washer drum
and run washer on NORMAL cycle for about two
minutes to mix antifreeze and remaining water.
3. Unplug washer or disconnect power.
NON-USE AND VACATION CARE
TRANSPORTING YOUR WASHER
1. Shut off both water faucets. Disconnect and drain water
inlet hoses.
2. If washer will be moved during freezing weather, follow
WINTER STORAGE CARE directions before moving.
3. Disconnect drain hose from drain system and from back
of washer.
4. Unplug power cord.
5. Place inlet hoses and drain hose inside washer drum.
6. Bundle power cord with a rubber band or cable tie to
keep it from hanging onto the ground.
IMPORTANT: Call for service to install new transport bolts.
Do not reuse transport bolts. Washer must be transported
in the upright position. To avoid structural damage to
your washer, it must be properly set up for relocation
by a certied technician.
REINSTALLING/USING WASHER AGAIN
To reinstall washer after non-use, vacation, winter storage,
or moving:
1.Refer to Installation Instructions to locate, level, and
connect washer.
2.Before using again, run washer through the following
recommended procedure:
To use washer again:
1.Flush water pipes and hoses. Reconnect water inlet
hoses. Turn on both water faucets.
2.Plug in washer or reconnect power.
3.Run washer through HEAVY DUTY cycle to clean washer
and remove antifreeze, if used. Use only HE detergent.
Use half the manufacturer’s recommended amount for a
medium-size load.
Washer Maintenance

13
If you experience Possible Causes Solution
First try the solutions suggested here or visit our website at www.amana.com/help
for assistance and to possibly avoid a service call.
Error Code Appears in Display
“Sd” (Excess suds)
appears in display Excessive suds in washer. Washer is
running a suds reduction routine.
Allow the washer to continue. Use only HE detergent.
Always measure detergent, and base detergent quantity
on load size. Follow detergent manufacturer’s instructions.
Touch POWER once to clear the code. Then touch POWER
again to restart washer. If code appears again, call for service.
F 8 followed by E 1(water
supply error) appears in
display
Check for proper water supply. Both hoses must be attached and have water owing to the
inlet valve.
Both hot and cold water faucets must be on.
Inlet valve screens on washer may be clogged.
Remove any kinks in the inlet hose.
F 9 followed by E 1(drain
pump system error)
appears in display
Check plumbing for correct drain
hose installation. Drain hose extends
into standpipe farther than 41⁄2"
(114 mm).
Check drain hose for proper installation.
Make sure the drain hose is not kinked, pinched, or blocked.
Remove any clogs from drain hose.
Use drain hose form and securely attach to drainpipe or tub.
Lower drain hose if the end is higher than 96" (2.4 m) above
the oor.
F 5 followed by E 2(door
will not lock) appears in
display
Washer door not locking. Touch POWER to cancel the cycle. Make sure the door is
closed completely and latching. Check for items in the washer
drum that may be keeping the door from closing completely.
Washer beeps when
START is touched Door not closed. Close the door completely.
“rL” (remove load)
appears in display
Load detected in drum during Clean
Washer with affresh®cycle. Remove items from washer drum and restart Clean Washer
with affresh®cycle.
Washer making error
beeps Door has not been opened and closed for at least 3 cycles. This code may appear when the washer is rst turned on.
Open and close the door to clear the display.
Once any possible issues are corrected, touch POWER once to clear the code. Reselect and restart the cycle.
F # E #code other than
as described above
appears in display
System error code. Touch POWER once to clear the code. Then touch POWER
again to restart washer. If code appears again, call for service.
Not using HE detergent or using too
much HE detergent.
Use only HE detergent. Always measure detergent and follow
manufacturer’s directions based on load size and soil level.
Troubleshooting
“nt” (interrupted)
appears in display The cycle was paused or cancelled. The washer can take 20 to 30 minutes to stop spinning and
drain and will display this error code during that time. Touch
POWER once to clear the code. Then touch POWER again to
restart washer.
Clean Washer LED
ashing at end of wash
cycle
The washer has run 30 wash cycles
and is indicating a reminder to run the
Clean Washer with affresh®cycle.
Run the Clean Washer with affresh®cycle. If the Clean Washer
with affresh®cycle is not turned on, the LED will stop ashing
at the end of a wash cycle after running 3 more regular wash
cycles. After 30 more wash cycles are completed, the Clean
Washer LED will again ash at the end of a wash cycle as a
reminder.

14
First try the solutions suggested here or visit our website at www.amana.com/help
for assistance and to possibly avoid a service call.
If you experience Possible Causes Solution
Feet may not be in contact with the
oor and locked.
Front and rear feet must be in rm contact with oor, and
washer must be level to operate properly. Jam nuts must be
tight against the bottom of the cabinet.
Check oor for exing or sagging. If ooring is uneven, a 3/4"
(19 mm) piece of plywood under your washer will reduce sound.
See “Level the Washer” in Installation Instructions.
Load could be unbalanced
or too large.
Avoid tightly packing the load. Avoid washing single items.
Balance a single item such as a rug or jeans jacket with a
few extra items.
Item or load not suitable for selected cycle. See “Cycle Guide”
and “Using Your Washer.”
Empty pockets before washing. Loose items such as coins
could fall between washer drum and tub or may block pump.
It may be necessary to call for service to remove items.
Fill hoses not attached tightly. Tighten ll-hose connection.
Properly seat all four ll-hose at washers.
Drain hose connection. Check that the drain hose is properly secured to drainpipe or
laundry tub.
Check household plumbing for leaks
or clogged sink or drain. Water can back up out of a clogged sink or drainpipe. Check
all household plumbing for leaks (laundry tubs, drainpipe, water
pipes, and faucets).
Fill hose washers.
Noises
It is normal to hear metal items on clothing such as metal snaps,
buckles, or zippers touch against the stainless steel drum.
Objects caught in washer drain
system.
Clicking or metallic
noises
Gurgling or humming The pump may make a humming sound with periodic gurgling
or surging as nal amounts of water are removed during the
spin/drain cycles. This is normal at certain stages of the cycle.
Washer may be draining water.
Water Leaks
Check the following for
proper installation
Vibration, rocking, or
“walking”
Load not completely
covered in water Water level not visible on door or
does not cover clothes. This is normal for an HE front load washer. The washer senses
load sizes and adds the correct amount of water for optimal
cleaning.
Washer Not Performing as Expected
Washer may not be level.
The door will lock unlock and lock again. You will hear 3 clicks
after touching and holding START. This is normal.
Door locking or unlocking.
Not using HE detergent or using too
much HE detergent. Only use HE detergent. Suds from regular detergents can
cause leaking from the door or rear of cabinet. Always measure
detergent and follow manufacturer’s directions based on your
load requirements.
Water or suds leaking
from door or rear of
cabinet
Residue on door glass. Periodically clean the underside of the glass window to avoid
potential leaks.
The shipping bolts are still in the
back of the washer.
See “Remove transport bolts from washer” in the
Installation Instructions.
Door opened during “Add Garment.” Water can drip off the inside of the door when the door is
opened after the start of a cycle.
Rolling or sloshing
and occasional clicking
(on slow-speed spin)
This is normal at certain stages of the cycle.Steel balls in the balancing system
are balancing the load.
Vibration or Off-Balance
Troubleshooting

15
Normal washer operation. Door must be completely closed and latched for washer to run.
Washer will pause during certain phases of cycle.
Do not interrupt cycle.
The washer pauses for about 2 minutes during certain cycles.
Allow the cycle to continue. Some cycles feature periods of
tumbling and soak.
Washer may be stopped to reduce suds.
Cold Wash uses less water in the beginning of the cycle to
provide a high concentration of detergent for optimal cleaning
action. Following this concentrated tumbling, more water is
used to complete the wash.
Plug power cord into a grounded 3-prong outlet.
Do not use an extension cord.
Ensure there is power to outlet.
Check electrical source or call an electrician to check if voltage
is low.
Reset a tripped circuit breaker. Replace any blown fuses.
NOTE: If problems continue, contact an electrician.
Washer not loaded as recommended. Remove several items, rearrange load evenly in washer drum.
Close door and touch and hold START.
Do not add more than 1 or 2 additional items after cycle has
started to avoid tightly packing or unbalancing.
Do not add more water to the washer.
If you experience Possible Causes Solution
Washer won’t run or ll,
washer stops working Check for proper water supply. Both hoses must be attached and have water owing to
inlet valve.
Both hot and cold water faucets must be turned on.
Check that inlet valve screens have not become clogged.
Check for any kinks in inlet hoses, which can restrict water ow.
Check proper electrical supply.
First try the solutions suggested here or visit our website at www.amana.com/help
for assistance and to possibly avoid a service call.
Washer Not Performing as Expected (cont.)
The washer door is not rmly shut. The door must be closed during operation.
Troubleshooting

16
Washer Not Performing as Expected (cont.)
If you experience Possible causes Solution
Incorrect or wrong
wash or rinse
temperatures
Check for proper water supply. Make sure hot and cold inlet hoses are not reversed.
Both hoses must be attached to both washer and faucet, and
have both hot and cold water owing to inlet valve.
Check that inlet valve screens are not clogged.
Remove any kinks in hoses.
First try the solutions suggested here or visit our website at www.amana.com/help
for assistance and to possibly avoid a service call.
Select DRAIN & SPIN to remove any water remaining in the
washer. The washer door will unlock at the end of the drain.
Water remaining in washer after cycle.
Door locked at end
of wash cycle
Using cycles with a slower spin
speed.
Cycles with slower spin speeds remove less water than cycles
with fast spin speeds. Use the recommended cycle/speed spin
for your garment.
Washer not loaded as recommended. A tightly packed or unbalanced load may not allow the washer
to spin correctly, leaving the load wetter than normal. See
“Cycle Guide” for load size recommendation for each cycle.
Washer not draining/
spinning, loads are
still wet
Drain hose extends into standpipe
farther than 4.5" (114 mm).
Check drain hose for proper installation. Use drain hose form
and securely attach to drainpipe or tub. Do not tape over drain
opening.
Not using HE detergent or using too
much HE detergent. Use only HE detergent. Suds from regular detergent or using too
much detergent can slow or stop draining or spinning. Always
measure and follow manufacturer’s directions for your load.
The load may be out of balance. Avoid washing single items. Balance a single item such as a rug
or jeans jacket with a few extra items.
The drain hose is clogged, or the
end of the drain hose more than
96" (2.4 m) above the oor.
Lower drain hose if the end is higher than 96" (2.4 m) above
the oor. Remove any clogs from drain hose. See “Installation
Requirements” in Installation Instructions.
The drain hose ts too tightly
in the standpipe, or is it taped
to the standpipe.
The drain hose should be loose yet t securely. Do not seal the
drain hose with tape. The hose needs an air gap. See “Secure
the Drain Hose” in Installation Instructions.
Small items may have been caught
in the pump or stuck between the
washer drum and the outer tub.
Check the drum for any items sticking through the drum holes.
Empty pockets and use garment bags when washing small
items.
If the “Add Garment” light is lit, touch START once. The door
will unlock.
Door locks when cycle has started.
Door will not unlock
Washing many loads. Your hot water tank may not have enough hot water to keep up
with the number of hot or warm washes. This is normal.
Not using HE detergent or using too
much HE detergent.
Only use HE detergent. Suds from regular detergents can
slow or stop the washer. Always measure detergent, following
manufacturer’s directions based on your load requirements.
To remove suds, cancel cycle. Select the QUICK cycle. Touch
and hold START. Do not add more detergent.
After 3 wash cycles in a row are completed, the door must be
opened and then closed before a new cycle can begin.
Door not opened between cycles.
Washer won’t run or ll,
washer stops working
(cont.)
Troubleshooting

17
Load not rinsed Check for proper water supply. Make sure hot and cold inlet hoses are not reversed.
Both hoses must be attached and have water owing to the
inlet valve.
Both hot and cold water faucets must be on.
Inlet valve screens on washer may be clogged.
Remove any kinks in the inlet hose.
Not using HE detergent or using too
much HE detergent.
The suds from regular detergent can cause the washer
to operate incorrectly.
Use only HE detergent. Always measure detergent and follow
manufacturer’s directions based on load size and soil level.
Washer not loaded as recommended. Avoid tightly packing the washer. The washer will not rinse well
if tightly packed. Load with dry items only. See the “Cycle
Guide” for load size recommendations for each cycle.
Use cycle designed for the fabrics being washed.
Add only 1 or 2 garments after washer has started.
If you experience Possible Causes Solution
First try the solutions suggested here or visit our website at www.amana.com/help
for assistance and to possibly avoid a service call.
Washer Not Performing as Expected (cont.)
Washer not loaded as recommended.
Not cleaning or
removing stains
Add load loosely. Items need to move freely for best cleaning.
See the “Cycle Guide” for load size recommendations for each
cycle.
Add only 1 or 2 garments after washer has started.
Not using HE detergent or using too
much HE detergent. Use only HE detergent. Always measure detergent and follow manufacturer’s directions based on load size and soil level.
Hard water or high level of iron (rust)
in water. You may need to install a water softener and/or iron lter.
Fabric softener dispensing ball used. Dispensing balls will not operate correctly with this washer.
Add liquid fabric softener to the fabric softener compartment.
Powdered detergent used for
slow-speed cycle.
Consider using liquid detergent.
Load is wrinkled,
twisted, or tangled Washer not loaded as recommended. Add load loosely. Items need to move freely reduce wrinkling and tangling. See the “Cycle Guide” for load
size recommendations for each cycle.
Reduce tangling by mixing types of load items. Use the
recommended cycle for the type of garments being washed.
Select a slower spin speed. Note that items will be wetter
than when using a faster speed spin.
Spin speed too fast for load.
Unload the washer as soon as it stops.
The washer is not unloaded promptly.
Use the Delicates cycle or another cycle with a slow spin
speed to reduce wrinkling.
Not choosing the right cycle for the
load being washed.
If safe for load, use warm or hot wash water.
The wash water was not warm
enough to relax wrinkles.
The load may be out of balance. When load unbalance occurs, a washing process will start
to redistribute the load. This may lengthen the cycle time.
Avoid washing single items. Balance a single item such as
a rug or jeans jacket with a few extra items.
For best performance, not all settings
are available with each cycle, and
some options cannot be used together.
Desired setting or
option does not light See the “Cycle Guide” for the available settings and options for
each cycle.
Troubleshooting

18
Not using correct cycle for fabric type. Use a higher soil level setting and warmer wash temperature
to improve cleaning.
If using Quick cycle, wash only a few items.
Use Heavy Duty cycle for tough cleaning.
If you experience Possible Causes Solution
First try the solutions suggested here or visit our website at www.amana.com/help
for assistance and to possibly avoid a service call.
Washer Not Performing as Expected (cont.)
Empty pockets, zip zippers, and snap or hook fasteners before
washing to avoid snags and tears.
Sharp items were in pockets during
wash cycle.
Strings and straps could have tangled.
Items may have been damaged before
washing. Mend rips and broken threads in seams before washing.
Fabric damage can occur if washer is
tightly packed.
Liquid chlorine bleach may have been
added incorrectly. Do not pour liquid chlorine bleach directly onto load. Wipe up
bleach spills.
Undiluted bleach will damage fabrics. Do not use more than
recommended by manufacturer.
Avoid tightly packing the washer. Load with dry items only.
Use cycle designed for the fabrics being washed.
Add only 1 or 2 garments after washer is started.
Tie all strings and straps before starting wash load.
Fabric Damage
The transfer of dye can occur when mixing whites and colors in
a load. Sort dark clothes from whites and lights.
Use hot or warm temperatures if safe for the load. Make sure
your hot water system is adequate to provide a hot water wash.
Use more detergent for washing heavy soils in cold or
hard water.
Load not sorted properly.
Gray whites, dingy
colors
Wash temperatures too low.
Not enough detergent used,
or hard water.
Monthly maintenance not done as
recommended. Run the Clean Washer with affresh®cycle monthly or every 30
wash cycles. See “Washer Care” in “Washer Maintenance.”
Unload washer as soon as cycle is complete.
Use only HE detergent. Be sure to measure correctly. Always
follow the manufacturer’s directions.
See “Washer Care” section.
This washer has a tight seal to avoid water leaks. To avoid
odors, leave the door open to allow the washer to dry
between uses.
Odors
Not using HE detergent or using too
much HE detergent.
Door not left open after use.
Not washing like colors together. Wash like colors together and remove promptly after the cycle is
complete to avoid dye transfer.
Use more detergent for washing heavy soils in cold or
hard water.
Not enough detergent used,
or hard water.
Not cleaning or
removing stains (cont.)
Not using dispensers. Use dispensers to avoid chlorine bleach and fabric softener
staining.
Load dispensers before starting a cycle.
Avoid overlling.
Do not add products other than those specied directly to load.
Troubleshooting

19
Clogged dispensers or laundry
products dispensing too soon. Do not overll dispenser. Overlling causes immediate
dispensing.
Load dispensers before starting a cycle.
Homes with low water pressure may result in residual powder
in the dispenser. To avoid, select a warmer wash temperature if
possible, depending on your load.
Use only liquid chlorine bleach in the bleach compartment.
Incorrect dispenser
operation
Liquid chlorine bleach not used in
bleach compartment.
It is normal for small amounts of water to remain in dispenser at
the end of the cycle.
Water in dispenser after cycle has
nished.
If you experience Possible Causes Solution
First try the solutions suggested here or visit our website at www.amana.com/help
for assistance and to possibly avoid a service call.
Washer Not Performing as Expected (cont.)
Not using correct cycle for load type.
When using the Quick or Delicates cycles, you should wash
small loads. This ensures a gentle wash for your garments
without increasing cycle times.
The Quick cycle is designed for smaller load sizes (2–4 items)
of lightly soiled garments. If larger loads are washed in this
cycle, cycle time will be increased.
Normal washer operation. The cycle times vary automatically based on your water
pressure, water temperature, detergent, and clothes load.
The options you select will also affect the cycle times.
Cycle time changes or
cycle time too long
Excessive suds in washer.
Load may be out of balance.
When excessive suds are detected, a special suds routine
automatically starts to remove extra suds and ensure proper
rinsing of your garments. This routine will add time to the
original cycle.
When load unbalance occurs, a washing process will start
to redistribute the load. This extends the cycle time. Avoid
washing single items. Balance a single item such as a rug or
jeans jacket with a few extra items.
Single-dose laundry
packet not dissolving Adding laundry packet incorrectly. Be sure laundry packet is added to washer drum before
adding clothes. Do not add packet to dispenser. Follow the
manufacturer’s instructions to avoid damage to your garments.
Troubleshooting
Control Lock is on. Touch and hold CONTROL LOCK for 3 seconds to turn off
Control Lock. For each second CONTROL LOCK is held down,
the display will count down one second: you will see “3,” then
“2,” then “1.”
The controls are not
responding

20
WHIRLPOOL CORPORATION LAUNDRY WARRANTY
LIMITED WARRANTY
For one year from the date of purchase, when this major appliance is installed, operated, and maintained according to instructions
attached to or furnished with the product, Amana, Admiral, Estate, Inglis, or Roper brands of Whirlpool Corporation or Whirlpool
Canada LP (hereafter “Whirlpool”) will pay for Factory Specied Replacement Parts and repair labor to correct defects in materials or
workmanship that existed when this major appliance was purchased.
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
Service must be provided by a company designated by Whirlpool to service Amana, Admiral, Estate, Inglis, or Roper brand appliances.
This limited warranty is valid only in the United States or Canada and applies only when the major appliance is used in the country in
which it was purchased. This limited warranty is effective from the date of original consumer purchase. Proof of original purchase date
is required to obtain service under this limited warranty.
ITEMS EXCLUDED FROM WARRANTY
This limited warranty does not cover:
1. Replacement parts or repair labor if this major appliance is used for other than normal, single-family household use or when it is
used in a manner that is inconsistent to published user or operator instructions and/or installation instructions.
2. Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or
repair house fuses, or to correct house wiring or plumbing.
3. Service calls to repair or replace appliance light bulbs, air lters, or water lters. Consumable parts are excluded from warranty
coverage.
4. Damage resulting from accident, alteration, misuse, abuse, re, ood, acts of God, improper installation, installation not in
accordance with electrical or plumbing codes, or use of products not approved by Whirlpool.
5. Cosmetic damage, including scratches, dents, chips or other damage to the nish of your major appliance, unless such damage
results from defects in materials or workmanship and is reported to Whirlpool within 30 days from the date of purchase.
6. Pick up and delivery. This major appliance is intended to be repaired in your home.
7. Repairs to parts or systems resulting from unauthorized modications made to the appliance.
8. Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an
authorized company designated by Whirlpool to service Amana, Admiral, Estate, Inglis, or Roper brands is not available.
9. The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance
with Whirlpool’s published installation instructions.
10. Replacement parts or repair labor on major appliances with original model/serial numbers that have been removed, altered, or
cannot be easily determined.
The cost of repair or replacement under these excluded circumstances shall be borne by the customer.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and
provinces do not allow limitations on the duration of implied warranties of merchantability or tness, so this limitation may not apply
to you. This warranty gives you specic legal rights, and you also may have other rights that vary from state to state or province to
province.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
WHIRLPOOL SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow
the exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This
warranty gives you specic legal rights, and you also may have other rights that vary from state to state or province to province.
If outside the 50 United States and Canada, contact your authorized Whirlpool, Amana, Admiral, Estate, Inglis, or Roper dealer to
determine if another warranty applies.
If you think you need repair service, rst see the “Troubleshooting” section of the Use & Care Guide. If you are unable to resolve
the problem after checking “Troubleshooting,” additional help can be found by checking the “Assistance or Service” section or by
calling the following numbers for assistance: In the U.S.A., call 800-843-0304 for Amana brand products; 800-688-9920 for Admiral
brand products; 800-253-1301 for Estate brand products, or 800-447-6737 for Roper brand products. For assistance In Canada,
call: 800-807-6777 for Amana, Admiral, Estate, Inglis, or Roper brand products. 1/12
DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY
Whirlpool makes no representations about the quality, durability, or need for service or repair of this major appliance other than the
representations contained in this Warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes
with this major appliance, you should ask Whirlpool or your retailer about buying an extended warranty.
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your major appliance
to better help you obtain assistance or service if you ever need
it. You will need to know your complete model number and serial
number. You can nd this information on the model and serial
number label located on the product.
Dealer name _____________________________________________
Address _________________________________________________
Phone number ___________________________________________
Model number ___________________________________________
Serial number ____________________________________________
Purchase date ___________________________________________
