Amana NTW5200T User manual

JOB AID 8178662
AL-1
TOP-LOAD WASHER
TECHNICAL EDUCATION
MODELS: NTW5200T, NTW5240T, NTW5400T
NTW5500T, NTW5505T, NTW5640T
NTW5700T, NTW5705T, NTW5800T

- ii -
WHIRLPOOL CORPORATION assumes no responsibility for any repairs made on
our products by anyone other than authorized In-Home Service Professionals.
FORWARD
This Amana Job Aid, “Top-Load Washer” (Part No. 8178662), provides the In-Home Service
Professional with information on the installation, operation, and service of the Top-Load Washer.
For specific information on the model being serviced, refer to the “Use and Care Guide,” or “Tech
Sheet” provided with the washer.
The Wiring Diagram used in this Job Aid is typical and should be used for training purposes only.
Always use the Wiring Diagram supplied with the product when servicing the washer.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide information that will enable the In-Home Service Profes-
sional to properly diagnose malfunctions and repair the Top-Load Washer.
The objectives of this Job Aid are to:
Understand and follow proper safety precautions.
Successfully troubleshoot and diagnose malfunctions.
Successfully perform necessary repairs.
Successfully return the washer to its proper operational status.
•
•
•
•
Copyright © 2007, Whirlpool Corporation, Benton Harbor, MI 49022

- iii -
TABLE OF CONTENTS
Page
GENERAL .............................................................. 1-1
WasherSafety.......................................................... 1-1
Model&SerialNumberDesignations........................................ 1-2
Model & Serial Number Label And Tech Sheet Locations. . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Specifications .......................................................... 1-4
INSTALLATION INFORMATION ............................................. 2-1
InstallationRequirements................................................. 2-1
InstallationInstructions................................................... 2-5
PRODUCT OPERATION.................................................... 3-1
WasherUse............................................................ 3-1
WasherCare........................................................... 3-4
Troubleshooting......................................................... 3-5
COMPONENT ACCESS .................................................. 4-1
ComponentLocations.................................................... 4-1
Removing The Console Components And The Power Supply Cord . . . . . . . . . . . . . . . . . 4-2
RemovingTheLidSwitch................................................. 4-5
Removing The Bleach Dispenser Wax Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Removing The Rear Panel Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
RemovingThePumpAndMotor............................................4-11
Removing The Agitator And Transmission. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Removing The Basket, Outer Tub, And Basket Drive Assembly . . . . . . . . . . . . . . . . . . . 4-17
Removing The Skate Plate And Suspension Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
COMPONENT TESTING ................................................... 5-1
TimerMotor............................................................ 5-1
LidSwitch(N.O.)........................................................ 5-1
WaterLevelPressureSwitch .............................................. 5-2
WaterInlet/ATCSensor................................................... 5-3
MotorStartCapacitor .................................................... 5-4
Motor................................................................. 5-5
MotorThermalProtector.................................................. 5-6
BasketDriveShaftChecks................................................ 5-6
DIAGRAMS AND CHARTS ................................................. 6-1
WiringDiagram......................................................... 6-1
Timer Sequence Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
CycleCharts........................................................... 6-4

- iv -
— NOTES —

1-1
GENERAL
WASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word
“DANGER” or “WARNING.” These words mean:
All safety messages will tell you what the potential hazard is, tell you how to reduce the
chance of injury, and tell you what can happen if the instructions are not followed.
You can be killed or seriously injured if you don’t
immediately follow instructions.
You can be killed or seriously injured if you don’t
follow instructions.
DANGER
WARNING

1-2
MODEL & SERIAL NUMBER DESIGNATIONS
MODEL NUMBER
SERIAL NUMBER
SERIAL NUMBER C T 48 20327
MANUFACTURING SITE
C = Clyde, OH
YEAR OF PRODUCTION
T = 2006
WEEK OF PRODUCTION
48 = 48th Week
PRODUCT SEQUENCE NUMBER
MODEL NUMBER N T W 5 2 00 T W 0
BRAND
N = Amana
ACCESS / FUEL
T = Top Load G = Gas
F = Front Load H = Horizontal
W = Work Space V = Vertical
E = Electric
PRODUCT
W = Washer P = Pedestal
D = Dryer B = Combo
T = Thin Twin C = Compact
SERIES
1 = Innovation 6 = Oasis
2 = Commercial 7 = Merloni
3 = Compact 8 = Horizon
4 = Stack 9 = Duet/Combo
5 = LEAP
PRICE POINT LEVELS (1 - 9)
TRADE PARTNER
00 = Brand 30 = NATM
10 = SBC 40 = Lowe’s
20 = Best Buy
YEAR OF INTRODUCTION
T = 2007
COLOR CODE
W = Silver Metallic - on - White
Q = White-on-White
ENGINEERING CHANGE
0 = Basic Original Release
1 = First Revision

1-3
MODEL & SERIAL NUMBER LABEL
AND TECH SHEET LOCATIONS
The Model & Serial Number Label and Tech Sheet locations are shown below.
Model & Serial Number Label
Tech Sheet (Behind Console)

1-4
SPECIFICATIONS
NTW5200T
Super Capacity
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
J-line Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
5 Cycle
1 Speed Motor
2 Speed Combo
3 Temps - In Timer (LC 1-ATC)
3 Water Levels
No Speed Select
Slate Porcelain Basket
Painted Top
1 PC DD Surgilator (Anti-Microbial)
No Detergent Dispenser
Dump Bleach
No Fabric Softener Dispenser
No Extra Rinse
No EOC
“Anti-Microbial Product Protection” On Console
Anti-Microbial Parts: Tub Ring, Agitator Base
No Quiet
NTW5240T
Super Capacity
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
J-line Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
6 Cycle
1 Speed Motor
2 Speed Combo
3 Temps - In Timer (LC 1-ATC)
2 Water Levels
No Speed Select
Slate Porcelain Basket
Painted Top
1 PC DD Surgilator (Anti-Microbial)
No Detergent Dispenser
Dump Bleach
No Fabric Softener Dispenser
No Extra Rinse
No EOC
“Anti-Microbial Product Protection” On Console
Anti-Microbial Parts: Tub Ring, Agitator Base
No Quiet

1-5
NTW5400T
Super Capacity
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
J-line Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
8 Cycle
1 Speed Motor
2 Speed Combo
3 Temps - (LC 1-ATC)
3 Water Levels
No Speed Select
Slate Porcelain Basket
Painted Top
2 PC Clothesmover (Anti-Microbial)
No Detergent Dispenser
Dump Bleach
Agitator Fabric Softener Dispenser
No Extra Rinse
No EOC
No “Anti-Microbial Product Protection” On
Console
No Anti-Microbial Parts: Tub Ring, Agitator
Base
No Quiet
NTW5500T
Super Capacity Plus
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
J-line Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
9 Cycle
2 Speed Motor
3 Speed Combo
4 Temps - (LC 2-ATC)
4 Water Levels
No Speed Select
Slate Porcelain Basket
Painted Top
Xtra Roll Plus Agitator
No Detergent Dispenser
Dump Bleach
Agitator Fabric Softener Dispenser
No Extra Rinse
No EOC
“Anti-Microbial Product Protection” On Console
Anti-Microbial Parts: Tub Ring, Agitator Base
No Quiet

1-6
NTW5505T
Super Capacity Plus
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
J-line Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
9 Cycle
2 Speed Motor
3 Speed Combo
4 Temps - (LC 2-ATC)
4 Water Levels
No Speed Select
Slate Porcelain Basket
Painted Top
Xtra Roll Plus Agitator
No Detergent Dispenser
Dump Bleach
Agitator Fabric Softener Dispenser
No Extra Rinse
No EOC
No “Anti-Microbial Product Protection” On
Console
No Anti-Microbial Parts: Tub Ring, Agitator
Base
No Quiet
NTW5640T
Super Capacity Plus
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
J-line Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
10 Cycle
2 Speed Motor
3 Speed Combo
4 Temps - (LC 2-ATC)
4 Water Levels
No Speed Select
Slate Porcelain Basket
Painted Top
Xtra Roll Plus Agitator
No Detergent Dispenser
Dump Bleach
Agitator Fabric Softener Dispenser
No Extra Rinse
No EOC
“Anti-Microbial Product Protection” On Console
Anti-Microbial Parts: Tub Ring, Agitator Base
No Quiet

1-7
NTW5700T
Super Capacity Plus
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
Wide Open Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
11 Cycle
2 Speed Motor
4 Speed Combo
4 Temps - ATC 4
Variable Water Level
No Speed Select
Slate Porcelain Basket
Painted Top
Xtra Roll Plus Agitator
No Detergent Dispenser
Dump Bleach
Agitator Fabric Softener Dispenser
Extra Rinse Knob
No EOC
“Anti-Microbial Product Protection” On Console
Anti-Microbial Parts: Tub Ring, Agitator Base
Quiet (FM)
NTW5705T
Super Capacity Plus
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
Wide Open Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
11 Cycle
2 Speed Motor
4 Speed Combo
4 Temps - ATC 4
Variable Water Level
No Speed Select
Slate Porcelain Basket
Painted Top
Xtra Roll Plus Agitator
No Detergent Dispenser
Dump Bleach
Agitator Fabric Softener Dispenser
Extra Rinse Knob
No EOC
No “Anti-Microbial Product Protection” On
Console
No Anti-Microbial Parts: Tub Ring, Agitator
Base
Quiet (FM)

1-8
NTW5800T
Super Capacity Plus
J-line Console Shape
New Amana Bladed Knobs
Amana Formed Badge
Wide Open Top/lid
3.2 Cu.ft. Porcelain Basket
27˝Cabinet
Mult Cycles
2 Speed Motor
5 Speed Combo
ATC 4 - Smart Temps
Variable Water Level
5 Position Speed Select - Smart
Slate Porcelain Basket
Painted Top
Xtra Roll Plus Agitator
No Detergent Dispenser
Dump Bleach
Agitator Fabric Softener Dispenser
Extra Rinse/EOC Options Knob
“Anti-Microbial Product Protection” On Console
Anti-Microbial Parts: Tub Ring, Agitator Base
Quiet II (FM, SM)

2-1
INSTALLATION INFORMATION
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before
starting installation. The parts supplied are in
the washer basket.
Tools needed for connecting the drain hose
and water inlet hoses:
Pliers that open to 1-9/16˝ (3.95 cm)
Flashlight (optional)
Parts Supplied
•
•
Alternate Parts
Your installation may require additional parts.
For information on ordering, please refer to
the toll-free phone numbers on the front page
of the Use and Care Guide.
If You Have: You Will Need to Buy:
Laundry tub or Sump pump system (if not
standpipe taller already available)
than 96 in. (2.4 m)
1 in. (2.5 cm) 1-1/4 in. (3.2 cm) diameter to 1 in.
diameter standpipe (2.5 cm ) diameter standpipe
adapter, Part No. 280130
Overhead sewer Standard 20 gal. (76 L) 39 in.
(99 cm) tall drain tub or utility
sink, sump pump and connectors
(available from local plumbing
suppliers)
Floor drain Siphon break kit, Part Number
280129, additional drain hose,
Part Number 3357090
Water faucets 2 longer water fill hoses:
beyond reach of 6 ft (1.8 m) Part Number 76314,
fill hoses 10 ft (3.0 m) Part Number 350008
Drain hose too Kit Part No. 280131
short
Lint clogged drain Drain protector, Part No. 367031
A. Drain hose form
B. Water inlet hoses (2)
C. Flat water inlet hose washers (4)
A B C
A. Beaded tie strap
B. Front leveling feet with nuts (2)
AB
Tools needed for securing the drain hose
and leveling the washer:
Adjustable or 9/16˝ (14 mm) open end
wrench
Level
Wood block
Ruler or measuring tape
Parts Supplied
•
•
•
•

2-2
LOCATION REQUIREMENTS
Selecting the proper location for your washer
improves performance and minimizes noise
and possible washer “walk.”
Your washer can be installed in a basement,
laundry room, closet, or recessed area (see
“Drain System”).
IMPORTANT: Do not install or store the wash-
er where it will be exposed to the weather.
Proper installation is your responsibility.
You will need:
A water heater set to deliver 120°F (49°C)
water to the washer.
A grounded electrical outlet located within
4ft. (1.2 m) of where the power cord is
attached to the back of the washer (see
“Electrical Requirements”).
Hot and cold water faucets located within
3ft. (90 cm) of the hot and cold water fill
valves, and water pressure of 5-100 psi
(34.5-690 kPa). Washers with triple dis-
pensers require 20-100 psi (138-690 kPa)
for best performance.
A level floor with a maximum slope of 1˝
(2.5 cm) under entire washer. Installing the
washer on carpeting is not recommended.
A sturdy floor to support the washer
weight (washer, water and load) of 315 lbs
(143 kgs).
Do not store or operate your washer in tem-
peratures at or below 32°F (0°C). Some wa-
ter can remain in the washer and can cause
damage in low temperatures (see “Washer
Care”).
•
•
•
•
•
Recessed area or closet installation
The dimensions shown are for the
recommended spacing allowed (A and B), ex-
cept the closet door ventilation openings. The
dimensions shown for the closet door ventila-
tion openings (C) are the minimum required.
Additional spacing should be considered
for ease of installation and servicing.
Additional clearances may be required for
wall, door and floor moldings.
Additional spacing of 1˝ (2.5 cm) on all
sides of the washer is recommended to re-
duce noise transfer.
If a closet door is installed, the minimum
air openings in the top and bottom of the
door are required (C). Louvered doors with
air openings in the top and bottom are ac-
ceptable.
Companion appliance spacing should also
be considered.
•
•
•
•
•
A. Front view
B. Side view
C. Closet door with vents
"
"
"
"
"
"
"
"
"
"
"
"
ABC

2-3
DRAIN SYSTEM
The washer can be installed using the stand-
pipe drain system (floor or wall), the laundry
tub drain system, or the floor drain system.
Select the drain hose installation method you
need (see “Tools and Parts”).
Standpipe drain system -
wall or floor (views A & B)
The standpipe drain requires a minimum diam-
eter standpipe of 2˝ (5 cm). The minimum car-
ry-away capacity can be no less than 17 gal.
(64 L) per minute. A 1-1/4 in. (3.2 cm) diameter
to 1˝ (2.5 cm) diameter standpipe adapter kit
is available (see “Tools and Parts”).
The top of the standpipe must be at least 39˝
(99 cm) high and no higher than 96˝ (244 cm)
from the bottom of the washer.
To avoid siphoning, no more than 8˝ (20.3 cm)
of drain hose should be below the top of the
washtub. Secure drain hose with beaded tie
strap.
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal.
(76 L) capacity. The top of the laundry tub
must be at least 39 in. (99 cm) above the floor
and no higher than 96 in. (244 cm) from the
bottom of the washer.
Floor drain system (view D)
The floor drain system requires a siphon break
that may be purchased separately (see “Tools
and Parts”).
The siphon break must be a minimum of
28 in. (71 cm) from the bottom of the washer.
Additional hoses might be needed.
To avoid siphoning, no more than 8˝ (20.3 cm)
of drain hose should be inside the standpipe.
Secure drain hose with beaded tie strap.
AB
"93
)mc99(
CD
"93
)mc99(
"82
)mc17(

2-4
ELECTRICAL REQUIREMENTS
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, fire, or electrical shock.
A 120-volt, 60-Hz., AC-only, 15 or 20-am-
pere, fused electrical supply is required.
Time-delay fuse or circuit breaker is rec-
ommended. It is recommended that a sep-
arate circuit serving only this appliance be
provided.
This washer is equipped with a power sup-
ply cord having a 3 prong ground plug.
To minimize possible shock hazard, the
cord must be plugged into a mating, 3
prong, grounding-type outlet, grounded
in accordance with local codes and ordi-
nances. If a mating outlet is not available,
it is the personal responsibility and obli-
gation of the customer to have the prop-
erly grounded outlet installed by a qualified
electrician.
If codes permit and a separate ground wire
is used, it is recommended that a qualified
electrician determine that the ground path
is adequate.
Do not ground to a gas pipe.
Check with a qualified electrician if you are
not sure the washer is properly grounded.
Do not have a fuse in the neutral or ground
circuit.
•
•
•
•
•
•
•
GROUNDING INSTRUCTIONS
For a grounded, cord-connected washer:
This washer must be grounded. In the event
of a malfunction or breakdown, grounding
will reduce the risk of electrical shock by
providing a path of least resistance for elec-
tric current. This washer is equipped with a
cord having an equipment-grounding con-
ductor and a grounding plug. The plug must
be plugged into an appropriate outlet that
is properly installed and grounded in accor-
dance with all local codes and ordinances.
WARNING: Improper connection of the
equipment-grounding conductor can re-
sult in a risk of electric shock. Check with
a qualified electrician or serviceman if you
are in doubt as to whether the appliance is
properly grounded.
Do not modify the plug provided with the
appliance – if it will not fit the outlet, have a
proper outlet installed by a qualified electri-
cian.
For a permanently connected washer:
This washer must be connected to a
grounded metal, permanent wiring system,
or an equipment-grounding conductor must
be run with the circuit conductors and con-
nected to the equipment-grounding termi-
nal or lead on the appliance.
WARNING

2-5
INSTALLATION INSTRUCTIONS
Excessive Weight Hazard
Use two or more people to move and
install washer.
Failure to do so can result in back or
other injury.
BEFORE YOU START
WARNING
NOTE: To avoid floor damage, set the washer
onto cardboard before moving across floor.
REMOVE SHIPPING MATERIALS
Removing the shipping material is necessary
for proper operation. If the shipping material
is not removed, the washer will make exces-
sive noise.
1. Move the washer to within approximately
3 ft (90 cm) of its final location.
2. The washer must be in the upright po-
sition and not tilted before removing the
shipping material.
3. Locate the yellow shipping materials
on the rear of the machine, near the
bottom. Follow the steps for your particular
model, either the one with the straight
power cord and cord restraint or the
looped power cord version.
Straight power cord
Straight power cord
1. Remove power plug and yellow strap
from machine base to release the rear
leveling system.
2. Firmly grasp the power cord and pull to
completely remove the power cord, cord
restraint, and pin from the rear panel.
3. Confirm that the power cord restraint (A),
and pin (B) are removed.
A
A. Power cord restraint
B. Pin
B
4. To remove the power cord from the cord
restraint, push the power cord in, press
TAB, and then pull the power cord out.

2-6
Looped power cord
1. Firmly grasp the yellow shipping strap
and pull until both ends are completely
removed from washer.
2. Check that two (2) cotter pins were re-
moved with the shipping strap.
drocrewopdepooL
CONNECT DRAIN HOSE
Proper connection of the drain hose protects
your floors from damage due to water leak-
age. Read and follow these instructions.
The drain hose is connected to your washer
and is stored inside the washer cabinet.
Remove drain hose from washer cabinet
Gently pull the corrugated drain hose out of
the washer from the top of the hose. Continue
to pull the hose until the end emerges. Do not
force excess drain hose back into the rear of
the washer.
Laundry tub drain or standpipe drain
Connecting the drain hose form to the
corrugated drain hose
Drain hose reliefsA.
A
1. Feed end of drain hose into one end of
form. Place end of drain hose form into
the drain hose relief.
2. Bend the hose over the top of the form
and feed into the other end of the form.

2-7
Connect the inlet hoses to the water faucets
Make sure the washer basket is empty.
1. Attach the hose labeled hot to the hot
water faucet. Screw on coupling by hand
until it is seated on the washer.
2. Attach the hose labeled cold to the cold
water faucet. Screw on coupling by hand
until it is seated on the washer.
3. Using pliers, tighten the couplings with
an additional two-thirds turn.
NOTE: Do not overtighten or use tape
or sealants on the valve. Damage to the
valves can result.
CouplingA.
WasherB.
BA
Clear the water lines
Run water through both faucets and inlet
hoses, into a bucket, drainpipe, or laundry
tub, to get rid of particles in the water lines
that might clog the inlet valve screens.
Check the temperature of the water to
make sure that the hot water hose is con-
nected to the hot water faucet and that the
cold water hose is connected to the cold
water faucet.
•
•
To keep drain water from going back into
the washer:
Do not force excess drain hose into stand-
pipe. Hose should be secure but loose
enough to provide a gap for air.
Do not lay excess hose on the bottom of
the laundry tub.
Floor drain
Do not install the drain hose form on to the
corrugated drain hose. You may need addi-
tional parts. See Floor drain under “Tools and
Parts.”
CONNECT THE INLET HOSES
The washer must be connected to the water
faucets using the new inlet hoses. Do not use
old hoses.
Insert new flat washers (supplied) into each
end of the inlet hoses. Firmly seat the wash-
ers in the couplings.
•
•
Connect the inlet hoses to the washer
Cold water inlet valve
Hot water inlet valve
A.
B.
A
B
1. Attach the hot water hose to the bottom
inlet valve.
2. Attaching the hot water coupling first
makes it easier to tighten connection with
pliers.
3. Screw on coupling by hand until it is
seated on the washer.

2-8
5. Attach the cold water hose to the top inlet
valve.
6. Screw on coupling by hand until it is
seated on the washer.
7. Using pliers, tighten the couplings with
an additional two-thirds turn.
NOTE: Do not overtighten or use tape
or sealants on the valve. Damage to the
valves can result.
Check for leaks
Turn on the water faucets and check for leaks.
A small amount of water might enter the wash-
er. You will drain this later.
NOTE: Replace inlet hoses after 5 years of
use to reduce the risk of hose failure. Record
hose installation or replacement dates for fu-
ture reference.
If you connect only one water hose, you
must cap off the remaining water inlet
port.
Periodically inspect and replace hoses
if bulges, kinks, cuts, wear, or leaks are
found.
SECURE THE DRAIN HOSE
1. Remove the shipping material from the
power cord. Drape the power cord over
the console.
2. Remove any cardboard used to move
washer.
•
•
4. Using pliers, tighten the couplings with
an additional two-thirds turn.
NOTE: Do not overtighten or use tape
or sealants on the valve. Damage to the
valves can result.
Beaded tie strap
3. Wrap the drain hose to the laundry tub
leg, drain standpipe or inlet hoses with
the beaded tie strap. Push fastener into
the nearest hole in the beaded tie strap.
See view A or B.
CBA
If the washer faucets and the drain stand-
pipe are recessed, put the formed end of
the drain hose into the standpipe. Tightly
wrap the tie strap around the water inlet
hoses and the drain hose. See view C.
LEVEL THE WASHER
Properly leveling your washer avoids exces-
sive noise and vibration.
Install the front leveling feet
1. Prop up the front of the washer about 4˝
(10.2 cm) with a wood block or similar
object. The block needs to support the
weight of the washer.
A.Threaded holes for feet
A
4"
(10.2 cm)
